Hyundai Sonata Hybrid (2017 year). Instruction

Convenient features of your vehicle

Turn signals and lane change

Onetouch turn signal function

WARNING

signals

To activate an One Touch Turn Signal

function, move the turn signal lever

•

Do not place any accessories,

slightly and then release it. The lane

stickers or tint the windshield.

change signals will blink 3, 5 or 7

•

Have the windshield glass

times.

replaced from an authorized

You can activate or deactivate the

dealer.

One Touch Turn Signal function or

•

Do not remove or impact relat-

choose the number of blinking (3, 5,

ed parts of the Smart High

or 7) from the User Settings Mode

Beam system.

(Light) on the LCD display.

•

Be careful that water doesn’t

get into the Smart High Beam

For more information, refer to the

unit.

"LCD Display" section in this

OLF044091N

•

Do not place objects on the

chapter.

To signal a turn, push down on the

dashboard that reflects light

lever for a left turn or up for a right

such as mirrors, white paper,

turn in position (A). To signal a lane

etc. The system may malfunc-

change, move the turn signal lever

tion if sunlight is reflected.

slightly and hold it in position (B). The

•

At times, the Smart High

lever will return to the OFF position

Beam system may not work

when released or when the turn is

properly, always check the

completed.

road conditions for your safe-

If an indicator stays on and does not

ty. When the system does not

flash or if it flashes abnormally, one

operate normally, manually

of the turn signal bulbs may be

change between the high

burned out and will require replace-

beam and low beam.

ment.

3-114

Battery saver function

Headlamp delay function

NOTICE

The purpose of this feature is to pre-

(if equipped)

If the driver gets out of the vehicle

vent the battery from being dis-

If the key is removed from the ignition

through other doors (except dri-

charged. The system automatically

switch or placed in the ACC position or

ver's door), the battery saver func-

turns off the parking lamp when the

the LOCK/OFF position with the head-

tion does not operate and the

key is removed (remote key) or when

lamps ON, the headlamps (and/or

headlamp delay function does not

the driver turns the engine off (smart

parking lamps) remain on for about 5

turn off automatically. Therefore, It

key) and opens the driver-side door.

minutes. However, if the driver’s door

causes the battery to be dis-

With this feature, the parking lamps

is opened and closed, the headlights

charged. In this case, make sure

will turn off automatically if the driver

are turned off after

15 seconds.

to turn off the lamp before getting

parks on the side of road at night.

However, with the engine off if the dri-

out of the vehicle.

ver's door is opened and closed, the

If necessary, to keep the lamps on

headlamps (and/or parking lamps) are

when the engine is turned off, perform

turned off after 15 seconds.

the following:

The headlamps (and/or parking lamps)

1) Open the driver-side door.

can be turned off by pressing the lock

2) Turn the parking lamps OFF and

button on the remote key or smart key

ON again using the light switch on

twice or turning the light switch to the

the steering column.

OFF or AUTO position. However, if you

turn the light switch to the AUTO posi-

tion when it is dark outside, the head-

lamps will not be turned off.

You can activate or deactivate the

Headlamp Delay function from the

User Settings Mode (Light) on the

LCD display.

For more information, refer to the

"LCD Display" section in this

chapter.

3-115

Convenient features of your vehicle

AFLS (Adaptive Front Lighting

If the AFLS malfunction indicator

for U.S.A

System) a.k.a. DBL (Dynamic

comes on, the AFLS is not working

The DRL will turn off when:

Bending Light) (if equipped)

properly. Drive to the nearest safe

location and restart the engine. If the

• Type A

indicator continuously remains on,

1. The light switch is not in the AUTO

we recommend that the system be

position.

checked by an authorized HYUNDAI

dealer.

2. The parking brake is applied.

3. The engine is turned off.

Daytime running light (DRL)

• Type B

(if equipped)

1. The light switch is not in DRL posi-

The Daytime Running Lights (DRL)

tion.

can make it easier for others to see

the front of your vehicle during the

2. The parking brake is applied.

OAD045436N

day, especially after dawn and before

3. The engine is turned off.

sunset.

Adaptive front lighting system uses

the steering angle and vehicle speed

for Canada

to help maximize your field of vision

The DRL will turn off when:

by swiveling and leveling the head-

1. The light switch is in the headlamp

lamp.

position, including the operation

Change the switch to the AUTO posi-

that the headlamp is turned on

tion when the engine is running. The

automatically in the AUTO light

adaptive front lighting system will

position.

operate when the headlamps are

2. The parking brake is applied.

ON. To turn off the AFLS, change the

3. The engine is turned off.

switch to other positions. After turn-

ing the AFLS off, headlamp swiveling

no longer occurs, but the leveling will

operate continuously.

3-116

Welcome System (if equipped)

Headlamp and Parking lamp

Interior lamp

Welcome light

When the headlamp (lamp switch in

When the interior lamp switch is in

the headlamp or AUTO position) is

the DOOR position and all doors

on and all doors

(and trunk) are

(and trunk) are closed and locked,

locked and closed, the parking lamp

the room lamp will come on for 30

and headlamp will come on for 15

seconds if any of the below is per-

seconds if/or any of the below is per-

formed.

• When the door unlock button is

pressed on the remote key or

smart key.

• When the button of the outside

At this time, if you press the door lock

door handle is pressed.

or unlock button on the remote key or

At this time, if you press the door lock

OLF044083N

smart key the parking lamp and

or unlock button on the remote key or

headlamp will turn off immediately.

smart key the room lamp will turn off

Door handle lamp (if equipped)

You can activate or deactivate the

immediately.

When all the doors (and trunk) are

Welcome Light from the User

closed and locked, the door handle

Settings Mode (Light) on the LCD

lamp will come on for about 15 sec-

display.

onds if any of the below is performed.

• When the door unlock button is

For more information, refer to the

pressed on the remote key or

"LCD Display" section in this

smart key.

chapter.

• When the button of the outside

door handle is pressed.

• When the vehicle is approached

with the smart key in possession.

3-117

Convenient features of your vehicle

Interior Lights

Interior lamp AUTO cut

Front lamps

The interior lamps will automatically

■ Type A

WARNING

go off approximately 20 minutes after

the engine is turned off and the

Do not use the interior lights

doors closed. If a door is opened, the

when driving in the dark. The

lamp will go off 40 minutes after the

interior lights may obscure your

engine is turned off. If the doors are

view and cause an accident.

locked by the remote key or smart

key and the vehicle enters the armed

stage of the theft alarm system, the

NOTICE

lamps will go off five seconds later.

OLF044096N

■ Type B

Do not use the interior lights for

extended periods when the engine

is turned off or the battery will dis-

charge.

OLF044097N

■ Type C

OLF046557N

3-118

(1) Front Map Lamp

Front Room Lamp:

Front Door Lamp

(2) Front Door Lamp

The front or rear room lamps come

• Type A

(3) Front Room Lamp

on when the front or rear doors are

: Press this switch to turn the

opened if the engine is running or

front and rear room lamps on.

not. When doors are unlocked by the

: Press this switch to turn the

Front Map Lamp:

remote key or smart key, the front

front and rear room lamps off.

Press either of these lens (1) to turn

and rear lamps come on for approxi-

the map lamp on or off. This light pro-

mately 15 seconds as long as any

duces a spot beam for convenient

door is not opened. The front and

• Type B

use as a map lamp at night or as a

rear room lamps go out gradually

: Press this switch to turn the

personal lamp for the driver and the

after approximately 15 seconds if the

front and rear room lamps on

front passenger.

door is closed. However, if the igni-

and off.

tion switch is in the ON position or all

doors are locked, the front and rear

lamps will turn off immediately.

If a door is opened with the ignition

switch in the ACC position or the

LOCK/OFF position, the front and

rear lamps stay on for about 20 min-

utes. However, if a door is opened

with the ignition switch in the ON

position, the lamps stays on continu-

ously.

3-119

Convenient features of your vehicle

Rear lamps

Trunk room lamp

Door courtesy lamp

■ Type A

OLF044098

■ Type B

OLF044255

OLF044256

The trunk room lamp comes on

The door courtesy lamp comes ON

when the trunk is opened.

when the door is opened to assist

entering or exiting the vehicle. It also

NOTICE

serves as a warning to passing vehi-

cles that the vehicle door is open.

The trunk lamp comes on as long

When the ignition switch is in the

as the trunk lid is open. To prevent

LOCK/OFF or ACC position, the

unnecessary charging system

door courtesy lamp turns off after 20

drain, close the trunk lid securely

OLF044099

minutes.

after using the trunk.

Rear Room Lamp

Press this switch to turn the room

lamp on and off.

3-120

Glove box lamp

Vanity mirror lamp

OLF044257

OLF044258

The glove box lamp comes on when

Opening the lid of the vanity mirror will

the glove box is opened.

automatically turn on the mirror light.

If the glove box is not closed, the

lamp will turn off after 20 minutes.

NOTICE

To prevent unnecessary charging

NOTICE

system drain, close the vanity mir-

ror cover after using the mirror.

To prevent unnecessary charging

system drain, close the glove box

securely after using the glove box.

3-121

Convenient features of your vehicle

WIPERS AND WASHERS

Windshield Wipers

Information

Operates as follows when the igni-

If there is heavy accumulation of snow

tion switch is in the ON position.

or ice on the windshield, defrost the

MIST : For a single wiping cycle,

windshield for about 10 minutes, or

push the lever upward and

until the snow and/or ice is removed

release. The wipers will oper-

before using the windshield wipers to

ate continuously if the lever is

ensure proper operation.

held in this position.

If you do not remove the snow and/or

OFF : Wiper is not in operation.

ice before using the wiper and washer,

INT : Wiper operates intermittently at

it may damage the wiper and washer

OLF044278

the same wiping intervals. To

system.

vary the speed setting, move

A : Wiper speed control

the speed control lever.

· MIST - Single wipe

LO : The wiper runs at a lower speed.

· OFF - Off

HI : The wiper runs at a higher speed.

· INT - Intermittent wipe

· LO - Low wiper speed

· HI - High wiper speed

B : Intermittent control wipe time

adjustment

C : Wash with brief wipes

3-122

Windshield Washers

If equipped with the Headlamp

NOTICE

Washer, washer fluid will be sprayed

on the headlamp at the same time you

•

To prevent possible damage to

operate the windshield washer when:

the washer pump, do not oper-

ate the washer when the fluid

1. The ignition switch is in the ON

reservoir is empty.

position.

•

To prevent possible damage to

2. The light switch is in the headlamp

the wipers or windshield, do not

position.

operate the wipers when the

windshield is dry.

WARNING

•

To prevent damage to the wiper

arms and other components, do

When the outside temperature is

not attempt to move the wipers

OLF044095N

below freezing, ALWAYS warm

manually.

the windshield using the

In the OFF position, pull the lever

defroster to prevent the washer

•

To prevent possible damage to

gently toward you to spray washer

the wipers and washer system,

fluid from freezing on the wind-

fluid on the windshield and to run the

shield and obscuring your vision

use anti-freezing washer fluids

wipers

1-3 cycles. The spray and

in the winter season or cold

which could result in an acci-

wiper operation will continue until

dent and serious injury or death.

weather.

you release the lever. If the washer

does not work, you may need to add

washer fluid to the washer fluid

reservoir.

3-123

Convenient features of your vehicle

DRIVER ASSIST SYSTEM

Rear View Camera

This is a supplemental system that

WARNING

shows behind the vehicle through the

navigation display while backing-up.

•

Never rely solely on the Rear

View Camera when backing-

WARNING

up.

•

ALWAYS look around your

The Rear View Camera is not a

vehicle to make sure there are

safety device. It only serves to

no objects or obstacles before

assist the driver in identifying

moving the vehicle in any

objects directly behind the mid-

direction to prevent a collision.

dle of the vehicle. The camera

OLF044282N

does NOT cover the complete

•

Always pay close attention

area behind the vehicle.

when the vehicle is driven

close to objects, particularly

pedestrians, and especially

children.

NOTICE

Always keep the camera lens

clean. The camera may not work

normally if the lens is covered

OLF044281

with foreign matter.

The Rear View Camera will activate

when the engine is running and the

shift lever is in the R (Reverse) posi-

tion.

3-124

Rear Parking Assist System

Operation of the Rear Parking

WARNING

(if equipped)

Assist System

Operating condition

•

ALWAYS look around your vehi-

cle to make sure there are not

•

This system will activate when

any objects or obstacles before

backing up with the ignition switch

moving the vehicle in any direc-

in the ON position. However, if vehi-

tion to prevent a collision.

cle speed exceeds 3 mph (5km/h),

the system may not detect objects.

•

Always pay close attention

when the vehicle is driven close

•

If vehicle speed exceeds 6 mph (10

to objects, particularly pedestri-

km/h), the system will not warn you

ans, and especially children.

even though objects are detected.

Sensor

•

Be aware that some objects

•

When more than two objects are

may not be visible on the

sensed at the same time, the clos-

OLF044062

est one will be recognized first.

screen or be detected by the

The Rear Parking Assist System

sensors, due to the objects

assists the driver during reverse

distance, size or material, all of

movement of the vehicle by chiming

which can limit the effective-

if any object is sensed within the dis-

ness of the sensor.

tance of 50 inches (120 cm ) behind

the vehicle.

This system is a supplemental sys-

tem that senses objects within the

range and location of the sensors, it

cannot detect objects in other areas

where sensors are not installed.

3-125

Convenient features of your vehicle

Types of warning sound and indicator

NOTICE

To turn off the Rear Parking

Assist System

Types of warning sound

Indicator

•

The indicator may differ from the

illustration as objects or sensors

When an object is 47 in. to 24

status. If the indicator blinks,

in. (120 cm to 60 cm) from the

have your vehicle checked by an

rear bumper : Buzzer beeps

authorized HYUNDAI dealer.

intermittently.

•

If the audible warning does not

sound or if the buzzer sounds

When an object is 24 in. to 12

intermittently when shifting into R

in. (60 cm to 30 cm) from the

(Reverse) position, this may indi-

rear bumper : Buzzer beeps

cate a malfunction with the

more frequently.

Parking Assist System. If this

occurs, have your vehicle checked

When an object is within 12

by an authorized HYUNDAI dealer

OLF044479N

in. (30 cm) of the rear bumper

as soon as possible.

Push the button to turn off the Rear

: Buzzer beeps continuously.

Parking Assist System. The indicator

light on the button will turn on.

3-126

Non-operational conditions of

Detecting range may decrease when:

NOTICE

Parking Assist System

• Outside air temperature is

Sensor may not recognize objects

The Rear Parking Assist System

extremely hot or cold.

less than 12 inches (30 cm) from

may not operate normally when:

• Undetectable objects smaller than

the sensor, or it may sense an

• Moisture is frozen to the sensor.

40 inches (1 m) and narrower than

incorrect distance.

6 inches (14 cm) in diameter.

• Sensor is covered with foreign mat-

ter, such as snow or water, or the

NOTICE

sensor cover is blocked.

The following objects may not be

Do not push, scratch or strike the

recognized by the sensor:

sensor with any hard objects that

There is a possibility of the Rear

•

Sharp or slim objects such as

could damage the surface of the

Parking Assist System malfunction

ropes, chains or small poles.

sensor. Sensor damage could

when:

•

Objects, which tend to absorb sen-

occur.

•

Driving on uneven road surfaces

sor frequency such as clothes,

such as unpaved roads, gravel,

spongy material or snow.

WARNING

bumps, or gradient.

•

Objects generating excessive noise

Your new vehicle warranty does

such as vehicle horns, loud motor-

not cover any accidents or dam-

cycle engines, or truck air brakes

age to the vehicle or injuries to

can interfere with the sensor.

its occupants related to a Rear

Parking Assist System. Always

•

Heavy rain or water spray is present.

drive safely and cautiously.

•

Wireless transmitters or mobile

phones are present near the sensor.

•

The sensor is covered with snow.

•

Any non-factory equipment or

accessories have been installed, or

if the vehicle bumper height or sen-

sor installation has been modified.

3-127

Convenient features of your vehicle

DEFROSTER

NOTICE

Rear Window Defroster

• To activate the rear window

defroster, press the rear window

■ Manual climate control system

To prevent damage to the conduc-

defroster button located in the center

• Type A

tors bonded to the inside surface

facia switch panel. The indicator on

of the rear window, never use

the rear window defroster button illu-

sharp instruments or window

minates when the defroster is ON.

cleaners containing abrasives to

• To turn off the defroster, press the

clean the window.

• Type B

rear window defroster button again.

If you want to defrost and defog

the front windshield, refer to the

Information

"Windshield Defrosting and

• If there is heavy accumulation of

OLF044204

Defogging" section in this chapter.

snow on the rear window, brush it off

■ Automatic climate control system

• Type A

before operating the rear defroster.

• The rear window defroster automat-

ically turns off after approximately

20 minutes or when the ignition

switch is in the LOCK/OFF position.

• Type B

Side view mirror defroster

If your vehicle is equipped with the

OLF044205

side view mirror defrosters, they will

operate at the same time you turn on

The defroster heats the window to

the rear window defroster.

remove frost, fog and thin ice from

the interior and exterior of the rear

window, while engine is running.

3-128

Convenient features of your vehicle

Heating and Air Conditioning

1. Start the engine.

2. Set the mode to the desired posi-

tion.

To improve the effectiveness of

heating and cooling :

- Heating:

- Cooling:

3. Set the temperature control to the

desired position.

4. Set the air intake control to the

outside (fresh) air or recirculated

air position.

5. Set the fan speed control to the

desired speed.

6. If air conditioning is desired, turn

the air conditioning system on.

OLF044207N

* : if equipped

3-130

Hyundai Sonata Hybrid (2017 year). Instruction - part 12
