Convenient features of your vehicle
Air conditioning
NOTICE
• When opening the windows in
humid weather air conditioning
HYUNDAI Air Conditioning Systems
•
The refrigerant system should
may create water droplets inside
are filled with R-134a or R-1234yf
only be serviced by trained and
the vehicle. Since excessive
refrigerant.
certified technicians to insure
water droplets may cause dam-
1. Start the engine. Push the air con-
proper and safe operation.
age to electrical equipment, air
ditioning button.
•
The refrigerant system should
conditioning should only be
2. Set the mode to the
position.
be serviced in a well-ventilated
used with the windows closed.
3. Set the air intake control to the out-
place.
side air or recirculated air position.
•
The air conditioning evaporator
Air conditioning system operation
4. Adjust the fan speed control and
(cooling coil) shall never be
tips
temperature control to maintain
repaired or replaced with one
• If the vehicle has been parked in
maximum comfort.
removed from a used or salvaged
direct sunlight during hot weather,
vehicle and new replacement
open the windows for a short time
MAC evaporators shall be certi-
i
Information
to let the hot air inside the vehicle
fied
(and labelled) as meeting
escape.
Your vehicle is filled with R-134a or
SAE Standard J2842.
• After sufficient cooling has been
R-1234yf according to the regulation
achieved, switch back from the
in your country at the time of produc-
NOTICE
recirculated air to the fresh outside
tion. You can find out which air condi-
air position.
tioning refrigerant is applied to your
• When using the air conditioning
vehicle on the label located inside of
system, monitor the temperature
• To help reduce moisture inside of
the bonnet. Refer to chapter 8 for the
gauge closely whilst driving up
the windows on rainy or humid
location of the air conditioning refrig-
hills or in heavy traffic when out-
days, decrease the humidity inside
erant label.
side temperatures are high. Air
the vehicle by operating the air con-
conditioning system operation
ditioning system with the windows
may cause engine overheating.
and sunroof closed.
Continue to use the fan but turn
• Use the air conditioning system
the air conditioning system off if
every month for a few minutes to
the temperature gauge indicates
ensure maximum system perform-
engine overheating.
ance.
3-178
• If you operate the air conditioner
This filter is installed behind the
Checking the amount of air con-
excessively, the difference between
glove box. It filters the dust or other
ditioner refrigerant and com-
the temperature of the outside air
pollutants that enter the vehicle
pressor lubricant
and that of the windscreen could
through the heating and air condi-
When the amount of refrigerant is
cause the outer surface of the wind-
tioning system.
low, the performance of the air con-
screen to fog up, causing loss of
We recommend that the climate con-
ditioning is reduced. Overfilling also
visibility. In this case, set the mode
trol air filter be replaced by a
reduces the performance of the air
selection button to the
position
HYUNDAI authorised repairer accord-
conditioning system.
3
and set the fan speed control knob
ing to the maintenance schedule. If the
to the lowest speed setting.
Therefore, if abnormal operation is
vehicle is being driven in severe con-
found, we recommend that the sys-
ditions such as dusty or rough roads,
tem be inspected by a HYUNDAI
more frequent climate control filter
System maintenance
authorised repairer.
inspections and changes are required.
Climate control air filter
If the air flow rate suddenly decreas-
WARNING
es, we recommend the system be
checked at a HYUNDAI authorised
repairer.
Vehicles equipped with R-134a
Because the refriger-
ant is at very high
pressure, the air con-
ditioning
system
should only be serviced by
trained and certified technicians.
It is important that the correct
type and amount of oil and refrig-
OIK047401L
erant is used. Otherwise, it may
cause damage to the vehicle and
[A] : Outside air, [B] : Recirculated air
[C] : Climate control air filter, [D] : Blower
personal injury.
[E] : Evaporator core, [F] : Heater core
3-179
Convenient features of your vehicle
Air Conditioning refrigerant
Each symbols and specification on
WARNING
label
air conditioning refrigerant label
means as below:
Vehicles equipped with R-1234yf
■ Example
• Type A
Because the refriger-
1. Classification of refrigerant
ant is mildly inflamma-
2. Amount of refrigerant
ble at very high pres-
sure, the air condition-
3. Classification of Compressor lubri-
ing system should
cant
only be serviced by
trained and certified
You can find out which air conditioning
technicians. It is
refrigerant is applied to your vehicle on
important that the cor-
the label located inside of the bonnet.
rect type and amount of oil and
ODH044365R
Refer to chapter 8 for the location of
refrigerant is used. Otherwise, it
the air conditioning refrigerant label.
may cause damage to the vehi-
• Type B
cle and personal injury.
We recommend the air conditioning
system be serviced by a HYUNDAI
authorised repairer.
ODH043366
The actual Air Conditioning refriger-
ant label in the vehicle may differ
from the illustration.
3-180
WINDSCREEN DEFROSTING AND DEFOGGING
•
For maximum windscreen defrost-
Manual climate control system
WARNING
ing, set the temperature control
To defog inside windscreen
knob to the highest temperature
Windscreen heating
setting and the fan control knob to
Do not use the
or
posi-
the highest fan speed. Select the
front defrost button on the climate
tion during cooling operation in
extremely humid weather. The
control display. After the engine
warm-up period, warm air will be
difference between the temper-
3
ature of the outside air and that
directed to the front windscreen.
of the windscreen could cause
•
If warm air to the floor is desired
the outer surface of the wind-
whilst defrosting or defogging, set
screen to fog up, causing loss
the mode to the floor-defrost posi-
of visibility. In this case, set the
tion.
mode selection knob or button
•
Before driving, clear all snow and
to the
position and fan
OTM048324
ice from the windscreen, rear win-
speed control knob or button to
[A] : Type A, [B] : Type B
dow, outside rear view mirrors, and
lower speed.
all side windows.
1. Select any fan speed except “0”
•
Clear all snow and ice from the bon-
position.
net and air inlet in the cowl grill to
2. Select the desired temperature.
improve heater and defroster effi-
3. Press the defroster button (
).
ciency and to reduce the probability
of fogging up inside of the wind-
4. The outside (fresh) air will be select-
screen.
ed automatically. Additionally, the air
conditioning (if equipped) will auto-
matically operate if the mode is
i
Information
selected to the
position.
If the engine temperature is still cold
If the air conditioning and outside
after starting, then a brief engine warm
(fresh) air position are not selected
up period may be required for the
automatically, press the correspon-
vented air flow to become warm or hot.
ding button manually.
3-181
Convenient features of your vehicle
To defrost outside windscreen
Automatic climate control
If the air-conditioning, outside (fresh)
system
air position and higher fan speed are
not selected automatically, adjust the
To defog inside windscreen
corresponding button or knob manu-
ally.
If the
position is selected, lower
fan speed is controlled to higher fan
speed.
OTM048326
[A] : Type A, [B] : Type B
OTM048327
1. Set the fan speed to the highest
(extreme right) position.
[A] : Type A, [B] : Type B
2. Set the temperature to the
1. Select the desired fan speed.
extreme hot position.
2. Select the desired temperature.
3. Press the defroster button (
).
3. Press the defroster button (
).
4. The outside (fresh) air and air con-
4. The air-conditioning will turn on
ditioning
(if equipped) will be
according to the detected ambient
selected automatically.
temperature, outside
(fresh) air
position and higher fan speed will
be selected automatically.
3-182
To defrost outside windscreen
Auto defogging system
i
Information
(only for automatic climate
For efficiency, do not select recirculat-
control system, if equipped)
ed air position whilst the Auto defog-
Auto defogging reduces the possibili-
ging system is operating.
ty of fogging up the inside of the wind-
screen by automatically sensing the
moisture on inside the windscreen.
NOTICE
3
The auto defogging system operates
Do not remove the sensor cover
when the heater or air conditioning is
located on the top of the wind-
on.
screen glass.
Damage to system parts could
i
Information
occur and may not be covered by
OTM048328
your vehicle warranty.
The auto defogging system may not
[A] : Type A, [B] : Type B
operate normally, when the outside
1. Set fan speed to the highest posi-
temperature is below -10 °C.
tion.
2. Set temperature to the extreme
To cancel or set the Auto Defogging
hot (HI) position.
System, keep the front defroster but-
3. Press the defroster button (
).
ton pressed for 3 seconds. The “ADS
OFF” symbol will be shown in the cli-
4. The air-conditioning will turn on
mate display to inform you that the
according to the detected ambient
system is deactivated. To re-activate
temperature and outside
(fresh)
the auto defogging system, follow the
air position will be selected auto-
procedure mentioned above and the
matically.
“ADS OFF” symbol will disappear.
If the
position is selected, lower
If the battery has been disconnected
fan speed is controlled to higher fan
or discharged, it resets to the auto
speed.
defogging status.
3-183
Convenient features of your vehicle
CLIMATE CONTROL ADDITIONAL FEATURES
Automatic ventilation
Sunroof inside air recirculation
(if equipped)
(if equipped)
To increase cabin air quality and
When the heater or air conditioning
reduce windscreen misting, air recir-
system is on with the sunroof opened,
culation mode switches off automati-
the outside (fresh) air position will be
cally after about
5 to 30 minutes,
automatically selected. At this time, if
depending on outside temperature,
you press the recirculated air position
and the air intake will change to out-
button, the recirculated air position
side (fresh) mode.
will be selected but will change back
To cancel or set the automatic venti-
to the outside (fresh) air position after
3 minutes.
lation feature, select Face level mode
and whilst pressing toe air con-
When the sunroof is closed, the air
ditioning button (A/C), press the air
intake position will return to the orig-
recirculation mode button at least 5
inal position that was selected.
times within 3 seconds.
When the automatic ventilation is
set, the air recirculation indicator will
blink
6 times. When cancelled, the
indicator will blink 3 times.
3-184
STORAGE COMPARTMENT
Centre console storage
Glove box
WARNING
Never store cigarette lighters,
propane cylinders, or other
flammable/explosive materials
in the vehicle. These items may
catch fire and/or explode if the
3
vehicle is exposed to hot tem-
peratures for extended periods.
WARNING
OTM048081R
OTM048082R
ALWAYS keep the storage com-
partment covers closed secure-
To open :
The glove box can be locked and
ly whilst driving. Items inside
unlocked with the mechanical key (1).
Pull the lever.
your vehicle are moving as fast
To open:
as the vehicle. If you have to
Pull the lever (2).
stop or turn quickly, or if there
is a crash, the items may fly out
WARNING
of the compartment and may
cause an injury if they strike the
ALWAYS close the glove box
driver or a passenger.
door after use.
An open glove box door can
NOTICE
cause serious injury to the pas-
senger in an accident, even if the
To avoid possible theft, do not
passenger is wearing a seat belt.
leave valuables in the storage
compartments.
3-185
Convenient features of your vehicle
Cool box (if equipped)
Sunglass holder (if equipped)
To close:
Push back into position.
Make sure the sunglasses holder is
closed whilst driving.
WARNING
•
Do not keep objects except
sunglasses inside the sun-
glasses holder. Such objects
can be thrown from the holder
in the event of a sudden stop or
OTM048435R
OTM048083
an accident, possibly injuring
You can keep beverage cans or other
To open:
the passengers in the vehicle.
items cool in the glove box.
Press the cover and the holder will
•
Do not open the sunglass
1. Turn on the air conditioning.
slowly open. Place your sunglasses
holder whilst the vehicle is
in the compartment door with the
moving. The rear view mirror
2. Slide the open/close lever (1) of
lenses facing out.
of the vehicle can be blocked
the vent installed in the glove box
by an open sunglass holder.
to the open position.
•
Do not attempt to force sun-
3. When the cool box is not used,
glasses into the sunglass
slide the lever
(1) to the closed
holder. If the sunglasses
position.
become jammed and you try
to open it forcibly, personal
NOTICE
injury may occur.
If some items in the cool box block
the vent, the cooling effectiveness
of the cool box is reduced.
3-186
Tray
Luggage tray (if equipped)
Grasp the handle on the top of the
cover and lift it.
■ Type A
3
OTM048422R
OTM048085
■ Type B
WARNING
Do not place the heavy, sharp or
breakable objects in the tray.
Such objects can be thrown
from the tray in the event of a
sudden stop or an accident,
possibly injuring the passen-
gers in the vehicle.
OTM048410
You can place a first aid kit, a reflec-
tor triangle (front tray), tools, etc. in
the box for easy access.
3-187
Convenient features of your vehicle
INTERIOR FEATURES
Ashtray (if equipped)
Cup holder
■ 3rd low seat (if equipped)
Front
■ Type A
OTM048087
Cups or small beverages cups may
OPDE046419
be placed in the cup holders.
OTM048086R
To use the ashtray, open the cover.
■ Type B
To clean the ashtray:
The plastic receptacle should be
removed by lifting the plastic ashtray
receptacle upward after turning the
cover counterclockwise and pulling it
out.
WARNING
Putting lit cigarettes or matches
OTM048436R
in an ashtray with other com-
bustible materials may cause a
fire.
3-188
Rear (if equipped)
WARNING
WARNING
•
Avoid abrupt starting and
Keep cans or bottles out of
braking when the cup holder
direct sun light and do not put
is in use to prevent spilling
them in a hot vehicle. It may
your drink. If hot liquid spills,
explode.
you could be burned. Such a
3
burn to the driver could cause
NOTICE
loss of vehicle control result-
ing in an accident.
• Keep your drinks sealed whilst
•
Do not place uncovered or
driving to prevent spilling your
unsecured cups, bottles,
drink. If liquid spills, it may get
OTM048088
cans, etc., in the cup holder
into the vehicle's electrical/elec-
containing hot liquid whilst
tronic system and damage elec-
Pull the armrest down to use the cup
the vehicle is in motion.
trical/electronic parts.
holders.
Injuries may result in the
• When cleaning spilled liquids, do
event of a sudden stop or col-
not dry the cup holder at high
lision.
temperature. This may damage
•
Only use soft cups in the cup
the cup holder.
holders. Hard objects can
injure you in an accident.
3-189
Convenient features of your vehicle
Sunvisor
Power outlet (if equipped)
WARNING
■ Front
For your safety, do not block your
view when using the sunvisor.
NOTICE
Do not put several tickets in the
ticket holder at one time. This
could cause damage to the ticket
holder.
OTM048089R
OTM048090R
■ Rear
To use a sunvisor, pull it downward.
To use a sunvisor for a side window,
pull it downward, unsnap it from the
bracket (1) and swing it to the side (2).
To use the vanity mirror, pull down the
sunvisor and slide the mirror cover (3).
Adjust the sunvisor forward or rear-
ward (4) as needed.
Use the ticket holder (5) to hold tick-
ets.
OTM048091
i
Information
The power outlet is designed to pro-
vide power for mobile telephones or
Close the vanity mirror cover securely
other devices designed to operate
and return the sunvisor to its original
with vehicle electrical systems.
position after use.
The devices should draw less than
3-190
180 W(Watt) with the engine running.
•
Close the cover when not in use.
USB charger (if equipped)
WARNING
•
Some electronic devices can
■ Front
cause electronic interference
Avoid electrical shocks. Do not
when plugged into a vehicle’s
place your fingers or foreign
power outlet. These devices may
objects (pin, etc.) into a power
cause excessive audio static
outlet or touch the power outlet
and malfunctions in other elec-
with a wet hand.
tronic systems or devices used
3
in your vehicle.
NOTICE
•
Push the plug in as far as it will
go. If good contact is not made,
To prevent damage to the Power
the plug may overheat and the
Outlets :
fuse may open.
OTM048092R
•
Use the power outlet only when
•
Plug in battery equipped electri-
■ Rear
the engine is running and
cal/ electronic devices with
remove the accessory plug after
reverse current protection. The
use. Using the accessory plug
current from the battery may
for prolonged periods of time
flow into the vehicle's electri-
with the engine off could cause
cal/electronic system and cause
the battery to discharge.
system malfunction.
•
Only use
12V electric acces-
sories which are less than 180
W(Watt) in electric capacity.
•
Adjust the air-conditioner or
heater to the lowest operating
OTM048093
level when using the power out-
let.
The USB charger is designed to
recharge batteries of small size elec-
trical devices using a USB cable.
3-191
Convenient features of your vehicle
The electrical devices can be
AC inverter (if equipped)
recharged when the ignition switch
or the Engine Start/Stop button is in
the ACC, ON or START position.
The battery charging state may be
monitored on the electrical device.
Disconnect the USB cable from the
USB port after use.
•
A smart phone or a tablet PC may
get warmer during the re-charging
OTM048437L
process. It does not indicate any
malfunction with the charging sys-
OTM048094
i
Information
tem.
The AC inverter supplies 220V/200W
• Rated voltage : AC 220V
•
A smart phone or a tablet PC,
electric power to operate electric
• Maximum electric power : 200W
which adopts a different re-charg-
accessories or equipments.
• In order to avoid an electrical sys-
ing method, may not be properly
tem failure, electric shock, etc., be
re-charged. In this case, use an
sure to read owner's manual before
exclusive charger of your device.
use.
•
The charging terminal is only to
• Be sure to close the cover except the
recharge a device. Do not use the
time of use.
charging terminal either to turn ON
an audio or to play media on the
AVN.
3-192
•
Do not use an electric accessory
Wireless mobile phone charg-
WARNING
or equipment the power con-
ing system (if equipped)
sumption of which is greater
To reduce a risk of serious or
than 200W(220V).
fatal injuries:
•
Some electric accessories or
• Do not use a heated electric
equipments can cause electron-
device such as a coffeepot,
ic interference. It may cause
toaster, heater, iron, etc.
excessive audio noise and mal-
3
• Do not insert foreign objects
functions in other electric sys-
into the outlet and do not
tems or devices in the vehicle.
touch the outlet as you may
•
Do not use broken electric
get shocked.
accessories or equipments,
• Do not let children touch the
which may damage the AC
AC inverter.
inverter and electrical systems
OTM048084R
of the vehicle.
[A] : Indicator, [B] : Charging pad
•
Do not use two or more electric
NOTICE
accessories or equipments at
There is a wireless mobile phone
• To prevent the battery from being
the same time. It may cause
charger inside the front console.
discharged, do not use the AC
damage to the electrical sys-
The system is available when all
inverter whilst the engine is not
tems of the vehicle.
doors are closed, and when the igni-
running.
•
When the input voltage is lower,
tion switch is in the ACC/ON position.
• When not using the AC inverter,
outlet LED will blink and the AC
make sure to close the AC invert-
inverter will turn off automatical-
er cover.
ly. If the input voltage goes up to
normal, the AC inverter will turn
• After using an electric accessory
on again.
or equipment, pull the plug out.
Leaving the accessory or equip-
ment plugged in for a long time
may cause battery discharge.
3-193
Convenient features of your vehicle
To charge a mobile phone
If your mobile phone is not charging:
NOTICE
The wireless mobile phone charging
- Slightly change the position of the
•
The wireless mobile phone
system charges only the Qi-enabled
mobile phone on the charging pad.
charging system may not sup-
mobile phones (
). Read the label
- Make sure the indicator light is
port certain mobile phones,
on the mobile phone accessory
orange.
which are not verified for the Qi
cover or visit your mobile phone
specification (
).
manufacturer’s website to check
The indicator light will blink orange
•
Locate your mobile phone in the
whether your mobile phone supports
for 10 seconds if there is a malfunc-
middle of the wireless mobile
the Qi technology.
tion in the wireless charging system.
phone charging system. Even
The wireless charging process starts
In this case, temporarily stop the
when your mobile phone locates
when you put a Qi-enabled mobile
charging process, and re-attempt to
slightly to one side, the charging
phone on the wireless charging unit.
wirelessly charge your mobile phone
speed may decrease and the
1. Remove other items, including the
again.
phone may heat when charging.
smart key, from the wireless charg-
The system warns you with a mes-
•
The wireless charging process
ing unit. If not, the wireless charg-
sage on the LCD display if the mobile
may temporarily stop, when a smart
ing process may be interrupted.
phone is still on the wireless charging
key function operates (i.e. starting
Place the mobile phone on the
unit after the engine is turned OFF
the engine, opening the doors, clos-
centre of charging pad.
and the front door is opened.
ing the doors).
2. The indicator light is orange when
For certain mobile phone, the mes-
•
For certain mobile phone, the indi-
the mobile phone is charging. The
sage may not be displayed.
cator colour may not change to
indicator light turns green when
green, even when the wireless
(This is due to the characteristic of
phone charging is complete.
charging process is properly com-
the certain mobile phone and the
3. You can turn ON or OFF the wire-
pleted.
wireless mobile phone charging sys-
less charging function in the User
tem is normal.)
Settings mode on the instrument
cluster. For further information, refer
to the “LCD Display Modes” in this
chapter.
3-194
