1 FEATURES OF YOUR HYUNDAI

10

B030C01Y-AAT

NOTE:

NOTE:

ILLUMINATED

IGNITION

You can get the limp home pass-

If the engine dies while driving after

SWITCH

word when the vehicle is first deliv-

limp home procedure, you can start

ered to you. If you do not have the

your engine within 8 seconds with-

password, consult your authorized

out limp home procedure again.

Hyundai dealer.

5. If the immobilizer indicator blinks for

1. To set the password you may turn

five seconds, you have to try the

the ignition key "ON" and then turn

limp home procedure again from

it "OFF" according to the digit num-

the beginning.

bers, then the immobilizer indicator

will blink along with the operation of

After doing the limp home procedure,

the ignition key. For example, turn

you have to consult with your autho-

the ignition key once for digit num-

rized Hyundai dealer as soon as pos-

B030C01E

ber "1", and twice for "2", and so on.

sible.

Whenever a front door is opened, the

However, for the digit number "0",

ignition switch will be illuminated for

you must turn the ignition key for 10

!

your convenience, provided the igni-

times.

CAUTION:

tion switch is not in the "ON" position.

2. Wait for 3~10 seconds.

o If you fail to try the limp home

The light will go off approximately 10

3. You may set the remaining number

procedure with the sequence of

seconds after closing the door or when

of digits by following the same pro-

three times, you have to wait for

the ignition switch is turned on.

cedures 1 and 2.

about one hour to do the limp

4. If all of four digits have been tried

home procedure again.

successfully, turn the ignition key

o If you cannot start your engine in

"ON" and check that the immobi-

spite of limp home procedure,

lizer indicator illuminates. From this

have your vehicle towed by an

time, you have to start your engine

authorized Hyundai dealer.

within 30 seconds. If you start your

engine after 30 seconds, your en-

gine will not start.

FEATURES OF YOUR HYUNDAI

1

DOOR LOCKS

11

B040A02Y-AAT

B040B01A-AAT

B040C02Y-DAT

Locking and Unlocking Front

Locking from the Outside

Doors with a Key

!

WARNING:

o Unlocked doors can be danger-

UNLOCK

ous. Before you drive away (es-

pecially if there are children in

the car), be sure that all the doors

LOCK

are securely closed and locked

so that the doors cannot be inad-

vertently opened from the inside.

This helps ensure that the doors

will not be opened accidentally.

B040C01HP

Also, when combined with the

HHP2003

The doors can be locked without a key.

proper use of seat belts, locking

To lock the doors, first push the inside

the doors helps keep occupants

o

The door can be locked or unlocked

lock switch to the "LOCK" position so

from being ejected from the car

with a key.

that the red mark on the switch is not

o

Lock the door by turning the key

in case of an accident.

visible, then close the door.

o Before opening the door, always

toward the front of the vehicle and

The door will not lock if the key is left in

look for and avoid oncoming traf-

unlock it by turning the key toward

the ignition switch when the front doors

fic.

the rear.

are closed. This is normal.

o In case of accident, the door is

NOTE:

unlocked automatically (If In-

o When locking the door this way,

stalled).

be careful not to lock the door

with the ignition key left in the

vehicle.

o To reduce the chance of theft,

always remove the ignition key,

close all windows and lock all

doors when leaving your vehicle

unattended.

1 FEATURES OF YOUR HYUNDAI

12

B040D01S-AAT

B040E04A-AAT

If you wish to be able to open the door

Locking from the Inside

Child-Protector Rear Door Lock

from the outside, the outside door

handle will function normally.

LOCK

UNLOCK

B040G02HP-AAT

Central Door Locks

LOCK

UNLOCK

HHP2004

HHP2008

To lock the doors from the inside,

Your Hyundai is equipped with a "child-

simply close the door and push the

protector" rear door lock assembly.

lock switch to the "LOCK" position.

When the lock mechanism is engaged,

When this is done, neither the outside

the rear door cannot be opened from

nor the inside door handles can be

the inside. Its use is recommended

used.

whenever there are small children in

B040G01HP

the rear seat.

The central door locking switch is lo-

NOTE:

cated on the driver's armrest. It is

When the door is locked, the red

To engage the child-protector feature

operated by depressing the door lock

mark on the switch is not visible.

so that the door cannot be opened

switch.

from the inside, move the child-protec-

tor lever to the " " position and close

the door. Move the lever to the "

"

position when normal door operation is

desired.

FEATURES OF YOUR HYUNDAI

1

THEFT-ALARM SYSTEM

13

B070A01A-AAT

B070B01O-AAT

NOTE:

(If Installed)

Armed Stage

o When pushing the front portion

of the driver's door lock switch,

This system is designed to provide

Type A

all vehicle doors will lock. If any

protection from unauthorized entry into

door is open when the switch is

the car. This system is operated in

depressed, the door will remain

three stages: the first is the "Armed"

locked when closed.

stage, the second is the "Alarm" stage,

o When pushing the rear portion of

and the third is the "Disarmed" stage.

the switch, all vehicle doors will

If triggered, the system provides an

unlock.

audible alarm with blinking of the turn

o The central door locking is oper-

signal lights.

UNLOCK

ated by turning the key toward

the front or rear of the vehicle.

LOCK

HHP2002

o If the door is locked/unlocked mul-

tiple times in rapid succession

Type B

with either the vehicle key or door

lock switch, the system may stop

operating temporarily in order to

protect the circuit and prevent

damage to system components.

LOCK

UNLOCK

B070B02HP

Park the car and stop the engine. Arm

the system as described below.

1 FEATURES OF YOUR HYUNDAI

14

1) Remove the ignition key from the

B070C01HP-GAT

ignition switch.

Alarm Stage

!

CAUTION:

2) Make sure that the engine hood and

Avoid trying to start the engine while

tail gate are closed and latched.

the system is armed.

3) Lock the doors using the transmitter

of the keyless entry system.

After completion of the steps above,

B070D01HP-AAT

the turn signal lights will blink once to

Disarmed Stage

indicate that the system is armed.

Type A

Type B

NOTE:

1) If any door, tail gate or engine

B070C01HP

hood remains open, the system

The alarm will be activated if any of the

will not be armed.

following occurs while the car is parked

2) If this happens, rearm the system

and the system is armed.

as previously described.

1) A front or rear door is opened with-

out using the transmitter.

2) The tail gate is opened without us-

!

CAUTION:

ing the transmitter.

B070D01HP

Do not arm the system until all

3) The engine hood is opened.

The system will be disarmed when the

passengers have left the car. If the

driver's or passenger's door is un-

system is armed while a

The siren will sound and the turn signal

locked by depressing the "UNLOCK"

passenger(s) remains in the car,

lights will blink continuouly for 27 sec-

button on the transmitter.

the alarm may be activated when

onds (Type B/ Type A : This will repeat

the remaining passenger(s) leaves

3 times). To turn off the system, unlock

the car.

the door or tail gate with the transmit-

ter.

1 FEATURES OF YOUR HYUNDAI

16

B070E02HP-GAT

Type B:

Replacing the battery

Case

When the transmitter's battery begins

to get weak, it may take several pushes

on the button to lock or unlock the

doors, and the LED will not light. Re-

place the battery as soon as possible.

Battery type : CR2032(Type A)

Transmitter

or CR1616 (Type B)

Case

Battery

MSO-0048-2

Replacement instructions:

Type A:

2. Remove the old battery from the

HMXOM033-2

case and note the polarity. Make

1. Carefully separate the case with a

sure the polarity of the new battery

phillips screwdriver.

is the same(+side facing down), then

insert it in the transmitter.

3. Installation is the reverse order of

disassembly.

Screwdriver

MSO-0048-1

1. Carefully separate the case with a

blade screwdriver as shown in the

illustration.

FEATURES OF YOUR HYUNDAI

1

POWER WINDOWS

17

B060A03L-AAT

Hole

Close

Open

(1)

(2)

Battery

Battery Cover

HMXOM033-3

B060A02HP

B060A01HP

2. Take off the battery cover after sepa-

In order to prevent operation of the

The power windows operate when the

rating the transmitter.

passanger front and rear windows, a

ignition key is in the "ON" position. The

3. Remove the old battery from the

window lock switch(2) is provided on

main switches are located on the

transmitter with a blade screwdriver

the armrest of the driver's door. To

driver's armrest and control the front

inserted in the hole and note the

disable the power windows, press the

and rear windows on both sides of the

polarity. Make sure the polarity of

window lock switch. To revert to nor-

vehicle. The windows may be opened

the new battery is the same(+side

mal operation, press the window lock

by depressing the appropriate window

facing up), then insert it in the trans-

switch a second time.

switch and closed by pulling up the

mitter.

switch. To open the window on the

4. Installation is the reverse order of

driver's side, press the switch(1) half-

disassembly.

way down. The window moves as long

as the switch is operated. To fully open

the driver's window automatically, press

the switch fully down. In automatic

operation, the window will fully open

even if you let go of the switch. To stop

at the desired opening, pull up and

release the switch.

1 FEATURES OF YOUR HYUNDAI

18

SEATS

B080A01A-AAT

NOTE:

ADJUSTABLE FRONT SEATS

The power windows can be oper-

!

ated for 30 seconds after the igni-

WARNING:

tion key is turned to the "ACC" or

1) Be careful that someone's head,

!

WARNING:

"LOCK" positions, or removed from

hands and body are not trapped

Never attempt to adjust the seat

the ignition switch.

by a closing window.

while the vehicle is moving. This

If the front doors are opened during

2) Never try to operate the main

could result in loss of control or an

this 30 second period, the power

switch on the driver's door and

accident which may cause death,

windows can no longer be oper-

the individual door window

serious injury, or property damage.

ated without the ignition key turned

switch in opposing directions at

to the "ON" position.

the same time. If this is done, the

window will stop and cannot be

B080B02A-AAT

opened or closed.

Adjusting Seat Forward and

3) Do not leave children alone in the

Rearward

car. Always remove the ignition

Close

key for their safety.

Open

HHP2013

HHP2026

To move the seat toward the front or

rear, pull the lock release lever up-

ward.

FEATURES OF YOUR HYUNDAI

1

19

This will release the seat on its track

To recline the seatback, lean forward to

B080D02JM-GAT

so you can move it forward or rearward

take your weight off it, then pull up on

Adjustable Headrests

to the desired position. When you find

the recliner control lever at the outside

the position you want, release the

edge of the seat. Now lean back until

lever and slide the seat forward or

the desired seatback angle is achieved.

rearward on its track until it locks into

To lock the seatback into position,

the desired position and cannot be

release the recliner control lever.

moved further.

!

!

WARNING:

WARNING:

To ensure the seat is locked se-

To minimize risk of severe injury in

Lock knob

curely, attempt to move the seat

the event of a collision or a sudden

B080D01HP

forward or rearward without using

stop, both the driver and passen-

Headrests are designed to help reduce

the lock release lever.

ger seatbacks should always be in

the risk of neck injuries.

an upright position while the ve-

To raise the headrest, pull it up. To

hicle is in motion. The protection

lower it, push it down while pressing

B080C01A-AAT

provided by the seat belts and

the lock knob. To remove the head-

Adjusting Seatback Angle

airbags in a frontal collision may be

rest, raise it as far as it can go then

reduced significantly when the

press the lock knob while pulling up-

seatbacks are reclined. There is

ward.

greater risk that the driver and pas-

senger will slide under the seat belt

which may result in serious injury if

a crash occurs when the seatbacks

are reclined.

The seat belt cannot provide full

protection to an occupant if the

seat back is reclined.

HHP2027

1 FEATURES OF YOUR HYUNDAI

20

B080E02A-AAT

while the vehicle is in motion.

Lumbar Support Control

!

WARNING:

(Driver's seat only) (If Installed)

B081D01LZ-AAT

Tilting Headrest Forward and

Rearward (If Installed)

1

2

B080D01JM

HHP2032

o For maximum effectiveness in case

To adjust the lumbar support, turn the

of an accident the headrest should

handle on the inboard side of the seat.

be adjusted so the middle of the

To increase the amount of lumbar sup-

headrest is at the same height as

port, pull the lever forward. To de-

the top of the occupant's eyes. For

HHP2034

crease it, push the lever toward the

this reason, the use of a cushion

rear.

that holds the body away from the

The headrest may be tilted forward to

seatback should not be recom-

three different positions by pulling the

mended.

headrest forward. To adjust the head-

1. Minimum support

o Do not operate vehicle with the

2. Maximum support

rest rearward, pull it fully forward to the

headrests removed as injury to

farthest position and release it. Adjust

the occupants may occur in the

the headrest so that it properly sup-

event of an accident. Headrests

ports the head and neck.

may provide protection against

neck injuries when properly ad-

justed.

o Do not adjust the headrest hejght

FEATURES OF YOUR HYUNDAI

1

21

B080F01S-AAT

B090A02Y-AAT

B090B01L-AAT

Seat Cushion Height Adjustment

POWER DRIVER'S SEAT

Adjusting Seat Forward and

(Driver's Seat Only) (If Installed)

(If Installed)

Rearward

The driver's seat can be adjusted ap-

propriately by using the control knob

on the left side of the seat. Before

1

driving, adjust the seat to the proper

position so as to easily control the

2

steering wheel, pedals and switches

on the instrument panel.

!

CAUTION:

HHP2028

HHP2029

Do not operate two knobs at the

To raise or lower the front part of the

Pull the control knob forward or back-

same time.

seat cushion, turn the front knob for-

ward to move the seat forward or back-

ward or rearward. To raise or lower the

ward to the desired position. Release

rear part of the seat cushion, turn the

the knob and the seat will lock at that

!

rear knob forward or rearward.

position.

WARNING:

o Never attempt to adjust the seat

1. Reclining Control Knob

while the vehicle is moving. This

2. Sliding and Height Adjusting Con-

could result in loss of control or

trol Knob

an accident causing death, seri-

ous injury, or property damage.

o Do not sit or lean unnecessarily

close to the airbag.

1 FEATURES OF YOUR HYUNDAI

22

B090C01Y-AAT

B090D01Y-AAT

Seat Cushion Height Adjustment

Adjusting Seatback Angle

!

WARNING:

To minimize the risk of personal

injury in the event of a collision or

a sudden stop, both the driver's

and passenger's seatbacks should

remain in an upright position while

the car is in motion. The protection

provided by the seat belts and

airbags may be reduced signifi-

cantly when the seatbacks are re-

clined. There is a greater risk that

HHP2031

HHP2030

the seat occupants will slide under

Rotate the upper portion of the control

Move the front portion of the control

the belt resulting in serious injury

knob forward or backward to recline

knob up or down to raise or lower the

if a crash occurs when the seatbacks

the seatback to the desired position.

front part of the seat cushion. Move the

are reclined. The seat belt cannot

Release the control knob and then the

rear portion of the control knob up or

provide full protection to an occu-

seatback will lock in that position.

down to raise or lower the rear part of

pant if the seatback is reclined.

the seat cushion.

FEATURES OF YOUR HYUNDAI

1

23

B080G01O-AAT

B100A02HP-GAT

UNDER TRAY

SEAT WARMER (If Installed)

!

CAUTION:

o The seat warmer will not operate

if ambient temperature is higher

than 31.5°C (88.7°F).

o If the seat warmer doesn't work

when ambient temperature is

lower than 24.5°C (76.1°F), it must

be checked by authorized dealer.

HHP2037

B100A01HP

The tray is located under the front

The seat warmer is provided to warm

passenger seat. It is opend by pulling

the front seats during cold weather.

forward.

With the ignition key in the "ON" posi-

tion, push either of the switches to

warm the driver's seat or the

!

WARNING:

passenger's seat.

During mild weather or under condi-

To avoid the possibility of injury in

tions where the operation of the seat

case of an accident or a sudden

warmer is not needed, keep the

stop, the tray should be kept closed

switches in the "OFF" position.

when the car is in motion.

1 FEATURES OF YOUR HYUNDAI

24

B090A03HP-GAT

B090C02HP-GAT

SECOND SEAT

Adjusting Seatback Angle

!

Adjustable Headrests

WARNING:

(If Installed)

o For maximum effectiveness in

case of an accident the headrest

should be adjusted so the middle

of the headrest is at the same

height as the top of the

occupant's eyes. For this rea-

son, the use of a cushion that

holds the body away from the

seatback should not be recom-

Seatback

mended.

folding lever

o Do not operate vehicle with the

HHP2039

headrests removed as injury to

the occupants may occur in the

To recline the seatback, push the

Lock Knob

B090A01HP

event of an accident. Headrests

seatback folding lever toward the head-

may provide protection against

rest, and release it after the desired

Headrests are designed to help re-

neck injuries when properly ad-

seatback angle is achieved.

duce the risk of neck injuries.

justed.

When you recline the seatback to de-

To raise the headrest, pull it up. To

o Do not adjust the headrest hejght

sired position, always be sure it has

lower it, push it down while pressing

while the vehicle is in motion.

locked into position.

the lock knob.

To remove the headrest, raise it as far

as it can go then press the lock knob

while pulling upward.

FEATURES OF YOUR HYUNDAI

1

25

B090B02HP-DAT

NOTE:

Folding Rear Seatback and Seat

Before folding the seat, fit the seat

!

WARNING:

Cushion

belt webbing in the clip and put the

To minimize the risk of personal

seat belt buckle between the

For greater convenience, the entire

injury in the event of a collision or

seatback and the seat cushion.

seatback and seat cushion may be

a sudden stop, both the driver's

folded down and up.

and passenger's seatbacks should

1. Lower the headrest completely while

remain in an upright position while

pressing the lock knob. (If Installed)

the car is in motion. The protection

provided by the seat belts and

airbags may be reduced signifi-

cantly when the seatbacks are re-

clined. There is a greater risk that

the seat occupants will slide under

the belt resulting in serious injury

if a crash occurs when the seatbacks

are reclined. The seat belt cannot

provide full protection to an occu-

HHP2057

(1)

pant if the seatback is reclined.

HHP2040

2. To fold down the seatback , first

push and hold the seatback folding

lever(1) inward, and then push down

the seatback.

HHP2041

1 FEATURES OF YOUR HYUNDAI

26

!

WARNING:

When folding down or returning

the seatback, always hold the

seatback. Otherwise, the seatback

(3)

could move suddenly and result in

unexpected injury.

HHP2043

HHP2043-1

4. To secure the seat, hook the secur-

NOTE:

ing strap(3) under the seat cushion

o Before lowering the seat cush-

to the headrest stay of front driver

ion when you return the seat, roll

and passenger seat.

the securing strap and put it in

5. To return the seatback and seat

the pocket.

cushion to its normal position, re-

o When you return the seatback to

verse the above procedure.

its upright position, always be

(2)

sure it is locked into position by

HHP2042

pulling and pushing on the top

of seatback.

3. Pull the seat cushion release le-

ver(2) upward, and then fold up the

seat cushion.

Content   ..   1  2  3   ..
