DRIVING YOUR HYUNDAI

WINTER DRIVING

C160A01A-AAT

chains on the tire will provide a greater

C160D01A-AAT

The more severe weather conditions

driving force, but will not prevent side

Check Battery and Cables

of winter result in greater wear and

skids.

Winter puts additional burdens on the

other problems. To minimize the prob-

battery system. Visually inspect the

lems of winter driving, you should fol-

NOTE:

battery and cables as described in

low these suggestions:

Tire chains are not legal in all prov-

Section 6. The level of charge in your

inces. Check province laws before

battery can be checked by your Hyun-

fitting tire chains.

dai dealer or a service station.

C160B01A-GAT

Snowy or Icy Conditions

To drive your vehicle in deep snow, it

C160E01A-AAT

may be necessary to use snow tires or

C160C01A-AAT

Change to "Winter Weight" Oil if

to install tire chains on your tires. If

Use High Quality Ethylene

snow tires are needed, it is necessary

Necessary

Glycol Coolant

to select tires equivalent in size and

In some climates it is recommended

Your Hyundai is delivered with high

type to the original equipment tires.

that a lower viscosity "winter weight"

quality ethylene glycol coolant in the

Failure to do so may adversely affect

oil be used during cold weather. See

cooling system. It is the only type of

the safety and handling of your car.

Section 9 for recommendations. If you

coolant that should be used because it

Speeding, rapid acceleration, sudden

aren't sure what weight oil you should

helps prevent corrosion in the cooling

brake applications, and sharp turns

use, consult your Hyundai dealer.

system, lubricates the water pump and

are potentially very hazardous prac-

prevents freezing. Be sure to replace

tices. During deceleration, use engine

or replenish your coolant in accor-

braking to the fullest extent. Sudden

dance with the maintenance schedule

brake applications on snowy or icy

in Section 5. Before winter, have your

roads may cause skids to occur. You

coolant tested to assure that its freez-

need to keep sufficient distance be-

ing point is sufficient for the tempera-

tween the vehicle in front and your

tures anticipated during the winter.

vehicle. Also, apply the brake gently. It

should be noted that installing tire

2 DRIVING YOUR HYUNDAI

C160G01A-AAT

C160I01HR-GAT

C160J01A-AAT

To Keep Locks from Freezing

Don't Let Your Parking Brake

Don't Let Ice and Snow Accumu-

Freeze

late Underneath

To keep the locks from freezing, squirt

an approved de-icer fluid or glycerine

Under some conditions your parking

Under some conditions, snow and ice

into the key opening. If a lock is cov-

brake can freeze in the engaged posi-

can build up under the fenders and

ered with ice, squirt it with an approved

tion. This is most likely to happen

interfere with the steering. When driv-

de-icing fluid to remove the ice. If the

when there is an accumulation of snow

ing in severe winter conditions where

lock is frozen internally, you may be

or ice around or near the rear brakes or

this may happen, you should periodi-

able to thaw it out by using a heated

if the brakes are wet. If there is a risk

cally check underneath the car to be

key. Handle the heated key with care

the parking brake may freeze, apply it

sure the movement of the front wheels

to avoid injury.

only temporarily while you put the gear

and the steering components is not

selector lever in first or reverse gear

obstructed.

and block the rear wheels so the car

C160H01A-AAT

cannot roll. Then release the parking

C160K01A-AAT

Use Approved Anti-Freeze in

brake.

Carry Emergency Equipment

Window Washer System

Depending on the severity of the

To keep the water in the window washer

weather where you drive your car, you

system from freezing, add an approved

should carry appropriate emergency

anti-freeze solution in accordance with

equipment. Some of the items you

instructions on the container. Window

may want to carry include tire chains,

washer anti-freeze is available from

tow straps or chains, flashlight, emer-

Hyundai dealers and most auto parts

gency flares, sand, a shovel, jumper

outlets. Do not use engine coolant or

cables, a window scraper, gloves,

other types of anti-freeze as these

ground cloth, coveralls, a blanket, etc.

may damage the finish.

DRIVING YOUR HYUNDAI

HIGHER SPEED MOTORING

USE OF LIGHTS

TRAILER OR VEHICLE

TOWING

C170A01A-AAT

C180A01A-AAT

C190A01HR-GAT

Pre-Trip Inspections

Check your lights regularly for correct

If you are considering towing with your

1. Tires:

operation and always keep them clean.

car, you should first check with your

When driving during the day in condi-

Province Department of Motor Vehicles

Adjust the tire inflation pressures to

tions of poor visibility, it is helpful to

to determine their legal requirements.

specification. Low tire inflation pres-

drive with headlights on low beam.

Since laws vary from province to prov-

sures will result in overheating and

This enables you to be seen as well as

ince, the requirements for towing trail-

possible failure of the tires.

to see.

ers, cars, other types of vehicles, or

Avoid using worn or damaged tires

apparatus may differ. Ask your Hyundai

which may result in reduced traction or

dealer for further details before towing.

tire failure.

NOTE:

Never exceed the maximum tire in-

CAUTION

flation pressure shown on the tires.

Do not do any towing with your car

during its first 1,000 km (600 miles)

2. Fuel, engine coolant and

in order to allow the engine to prop-

engine oil:

erly break in. Failure to heed this

High speed travel consumes more fuel

caution may result in serious en-

than urban motoring. Do not forget to

gine or transmission damage.

check both engine coolant and engine

oil.

3. Drive belt:

A loose or damaged drive belt may

result in overheating of the engine.

2 DRIVING YOUR HYUNDAI

C190B01S-AAT

C190C03S-GAT

and allow the engine to idle until it

Trailer Hitches

Trailer Brakes

cools down. You may proceed

Select the proper hitch and ball combi-

If your trailer is equipped with a braking

once the engine has cooled suffi-

nation, making sure that it's location is

system, make sure it conforms to fed-

ciently.

compatible with that of the trailer or

eral and/or local regulations and that it

vehicle being towed.

is properly installed and operating cor-

Use a quality non-equalizing hitch which

rectly.

C190D01A-GAT

distributes the tongue load uniformly

Safety Chains

throughout the chassis.

NOTE:

If you tow a trailer or vehicle, your

Should the hitch connection between

The hitch should be bolted securely to

car will require more frequent main-

your car and the trailer or vehicle you

the car and installed by a qualified

tenance due to the additional load.

are towing fail, the trailer or vehicle

technician. DO NOT USE A HITCH

See "Maintenance Under Severe

could wander dangerously across other

DESIGNED FOR TEMPORARY IN-

Usage Conditions" on page 5-8.

lanes of traffic and ultimately collide

STALLATION AND NEVER USE ONE

with another vehicle. To eliminate this

THAT ATTACHES ONLY TO THE

potentially dangerous situation, safety

BUMPER.

CAUTION:

chains, attached between your car and

o Never connect a trailer brake sys-

the trailer or towed vehicle, are re-

tem directly to the vehicle brake

quired in most provinces.

system.

o When towing a trailer on steep

grades (in excess of 6%) pay close

attention to the engine coolant

temperature gauge to ensure the

engine does not overheat. If the

needle of the coolant temperature

gauge moves across the dial to-

wards "H" (HOT), pull over and

stop as soon as it is safe to do so,

DRIVING YOUR HYUNDAI

C190E01HR-GAT

and/or too much luggage in the

Trailer Weight Limit

cargo deck can overload the rear

axle. Redistribute the load and

check the axle weight again.

CAUTION:

Gross Axle Weight

Gross Vehicle

The following specifications are rec-

Weight

ommended when towing a trailer.

Tongue load

C190E02L

The loaded trailer weight cannot

Total trailer weight

safely exceed the values in the chart

2. The total gross vehicle weight with

C190E01L

below.

trailer must not exceed the Gross

Tongue loads can be increased or de-

Vehicle Weight Rating (GVWR)

creased by redistributing the load in the

shown on the vehicle identifica-

kg. (Lbs)

trailer. This can be verified by checking

tion plate (see page 8-2). The total

Maximum Towable Weight

the total weight of the loaded trailer and

gross vehicle weight is the com-

then checking the load on the tongue.

bined weight of the vehicle, driver,

Trailer

Tongue

all passengers and their luggage,

With

1200

cargo, hitch, trailer tongue load

NOTE:

and other optional equipment.

Brake Type

(2646)

(106)

1. Never load the trailer with more

weight in the back than in the

3. The front or rear axle weight must

Without

750

not exceed the Gross Axle Weight

front. About 60% of the trailer

Brake Type

(1653)

(106)

Rating (GAWR) shown on the

load should be in the front half

vehicle identification plate (see

on the trailer and the remaining

page 8-2). It is possible that your

40% in the rear.

towing package does not exceed

the GVWR but exceeds the

GAWR. Improper trailer loading

2 DRIVING YOUR HYUNDAI

C190F01HR-GAT

8. When parking your car and trailer,

Trailer or Vehicle Towing Tips

especially on a hill, be sure to fol-

WARNING:

low all the normal precautions. Turn

Before towing, check hitch and

Improperly loading your car and

your front wheel into the curb, set

safety chain connections as well

trailer can seriously affect its steer-

the parking brake firmly, and put

as proper operation of the trailer

ing and braking performance caus-

the transmission in 1st or Reverse.

running lights, brake lights, and

ing a crash which could cause seri-

In addition, place wheel chocks at

turn signals.

ous injury or death.

each of the trailer's tires.

Always drive your vehicle at a mod-

9. If the trailer has electric brakes,

erate speed (Less than 100 km/h).

start your vehicle and trailer mov-

Trailer towing requires more fuel

ing, and then apply the trailer brake

than normal conditions.

controller by hand to be sure the

To maintain engine braking effi-

brakes are working. This lets you

ciency, do not tow a trailer with

check your electrical connection at

transmission in fifth gear.

the same time.

Always secure items in the trailer

10. During your trip, check occasion-

to prevent load shift while driving.

ally to be sure that the load is

Check the condition and air pres-

secure, and that the lights and

sure of all tires on the trailer and

any trailer brakes are still working.

your car. Low tire pressure can

11. Avoid jerky starts, sudden accel-

seriously affect the handling. Also

eration or sudden stops.

check the spare tire.

12. Avoid sharp turns and rapid lane

The vehicle/trailer combination is

changes.

more affected by crosswind and

13. Avoid holding the brake pedal down

buffeting.

too long or too frequently. This

When being passed by a large

could cause the brakes to over-

vehicle, keep a constant speed

heat, resulting in reduced braking

and steer straight ahead. If there is

efficiency.

too much wind buffeting, slow down

to get out of the other vehicle's air

turbulence.

DRIVING YOUR HYUNDAI

14. When going down a hill, shift into a

lower gear and use the engine brak-

CAUTION:

ing effect.

When ascending a long grade,

If overheating should occur when

downshift the transmission to a

towing, (temperature gauge reads

lower gear and reduce speed to

near red zone), taking the following

reduce chances of engine over-

action may reduce or eliminate the

loading and/or overheating.

problem.

15. If you have to stop while going

1. Turn off the air conditioner.

uphill, do not hold the vehicle in

2. Reduce highway speed.

place by pressing on the accelera-

3. Select a lower gear when going

tor. Use the parking brake or

uphill.

footbrake.

4. While in stop and go traffic, place

the gear selector in park or neu-

NOTE:

tral and idle the engine at a higher

When towing check transmission

speed.

fluid more frequently.

3 WHAT TO DO IN AN EMERGENCY

IF THE ENGINE WILL NOT

START

D010A01A-AAT

2. Turn on the interior light. If the light

3. Check fuel line in the engine room.

dims or goes out when you operate

4. If engine still refuses to start, call a

the starter, the battery is discharged.

Hyundai dealer or seek other quali-

CAUTION:

3. Check the starter connections to be

fied assistance.

If the engine will not start, do not

sure they are securely tightened.

push or pull the car to start it. This

4. Do not push or pull the vehicle to

D010D01HR-AAT

could result in a collision or cause

start it. See instructions for "Jump

If the Engine Stalls While Driv-

other damage. In addition, push or

Starting".

ing

pull starting may cause the cata-

lytic converter to be overloaded and

1. Reduce your speed gradually, keep-

D010C01HR-GAT

create a fire hazard.

ing a straight line. Move cautiously

If Engine Turns Over Normally

off the road to a safe place.

but Does Not Start

2. Turn on your emergency flashers.

D010B01HR-GAT

3. Try to start the engine again. If your

If Engine Doesn't Turn Over or

vehicle will not start, contact a

Turns Over Slowly

Hyundai dealer or seek other quali-

fied assistance.

If the Engine Stalls at a Cross-

road or Crossing

o If the engine stalls at a crossroad or

crossing, set the shift lever in the N

(Neutral) position and then push the

D010C01HR

vehicle to a safe place.

o If your vehicle has a manual trans-

1. Check fuel level.

mission not equipped with a ignition

D010B01HR

2. With the key in the "OFF" position,

lock switch, the vehicle can move

check all connectors at glow plug

1. Check the battery connections to be

forward by shifting to the 2 (second)

and glow plug relay. Reconnect any

sure they are clean and tight.

or 3 (third) gear and then turning the

that may be disconnected or loose.

starter without depressing the clutch

pedal.

WHAT TO DO IN AN EMERGENCY

JUMP STARTING

D020A01HR-GAT

If you should accidentally get acid on

3. Attach the clamps of the jumper

your skin or in your eyes, immedi-

cable in the exact order shown in the

ately remove any contaminated cloth-

illustration. That is, first, attach one

ing and flush the area with clear

clamp of the jumper cable to the

water for at least 15 minutes. Then

positive

(+) post or cable of the

promptly obtain medical attention. If

discharged battery. Then attach the

you must be transported to an emer-

other end of the same cable to the

gency facility, continue to apply wa-

positive

(+) post or cable of the

ter to the affected area with a sponge

booster battery. Next, using the other

Discharged

or cloth.

cable, attach one clamp to the nega-

battery

The gas produced by the battery

tive (-) post or cable of the booster

during the jump-start operation is

battery. Then attach the other end of

Booster battery HHR4001

highly explosive. Do not smoke or

that cable to a solid metal part of the

allow a spark or open flame in the

vehicle away from the battery. Do

vicinity.

not connect the cable to any moving

WARNING:

The battery being used to provide

part.

The gas produced by the battery

the jump start must be 12-volts. If

4. Start the engine in the car with the

during the jump-start operation is

you cannot determine that it is a 12-

booster battery and let it run for a

highly explosive. If these instruc-

volt battery, do not attempt to use it

few minutes. This will help to assure

tions are not followed exactly, seri-

for the jump start.

that the booster battery is fully

ous personal injury and damage to

To jump start a car with a discharged

charged. During the jumping opera-

the vehicle may occur! If you are

battery, follow this procedure ex-

tion, run the engine in this vehicle at

not sure how to follow this proce-

actly:

about 2,000 rpm.

dure, seek qualified assistance.

5. Start the engine in the car with the

Automobile batteries contain sul-

1. If the booster battery is installed in

discharged battery using the nor-

furic acid. This is poisonous and

another vehicle, be sure the two

mal starting procedure. After the

highly corrosive. When jump start-

vehicles are not touching.

engine starts, leave the jumper

ing, wear protective glasses and be

2. Turn off all unnecessary lights and

cables connected and let the engine

careful not to get acid on yourself,

accessories in both vehicles.

run at fast idle or about 2,000 rpm

your clothing or on the car.

for several minutes.

3 WHAT TO DO IN AN EMERGENCY

IF THE ENGINE OVERHEATS

6. Carefully remove the jumper cables

D030A01HR-GAT

4. Check to see if the water pump drive

in the reverse order of attachment.

If your temperature gauge indicates

belt is missing. If it is not missing,

overheating, you experience a loss of

check to see that it is tight. If the

If you do not know why your battery

power, or hear loud pinging or knock-

drive belt seems to be satisfactory,

became discharged (because the lights

ing, the engine is probably too hot. If

check for coolant leaking from the

were left on, etc.), have the charging

this happens to you, you should:

radiator, hoses or under the car. (If

system checked by your Hyundai

the air conditioning had been in use,

dealer.

1. Pull off the road and stop as soon as

it is normal for cold water to be

it is safe to do so.

draining from it when you stop).

2. Place the gear selector lever in neu-

tral and set the parking brake. If the

air conditioning is on, turn it off.

WARNING:

3. If engine coolant is running out un-

While the engine is running, keep

der the car or steam is coming out

hair, hands, and clothing away from

from the hood, allow the engine to

moving parts such as the fan and

idle. Do not open the hood until the

drive belts to prevent injury.

engine coolant has stopped running

or the steaming has stopped. If there

is no visible loss of engine coolant

and no steam, leave the engine

HHR4002

running, lift up the passenger's seat

NOTE:

(Refer to "To Inspect the Engine

If your vehicle is equipped with

Compartment Under the Passenger's

double cab, frist pull the cushion of

Seat" on page 1-13.) and check to be

the reat seat forward (Refer to "Rear

sure the engine cooling fan is oper-

Seat Cushion Under Box" on page

ating. If the fan is not running, turn

1-11.) And remove the battery cover

the engine off.

by turning the knob counterclock-

wise. And then you can jump start

the car.

WHAT TO DO IN AN EMERGENCY

SPARE TIRE

D040A01HR-GAT

The following instructions for the FULL

WARNING:

SIZE spare tire should be observed:

Never work on injection system with

Do not remove the radiator cap when

engine running or within 30 sec-

the engine is hot. This can allow

Check inflation pressure as soon as

onds after shutting off engine. High

coolant to be blown out of the open-

practical after installing the spare tire,

pressure pump, rail, injectors and

ing and cause serious burns.

and adjust to the specified pressure.

high pressure pipes are subject to

The tire pressure should be periodi-

high pressure even after the engine

6. If you cannot find the cause of the

cally checked and maintained at the

stopped. The fuel jet produced by

overheating, wait until the engine

specified pressure while the tire is

fuel leaks may cause serious in-

temperature has returned to nor-

stored.

jury, if it touch the body. People

mal. Then, if the engine coolant has

using pacemakers should not move

been lost, carefully add coolant to

Spare Tire Pressure

than 30cm closer to the ECU or

the reservoir (Page 6-10) to bring

TIRE INFLATION

wiring harness within the engine

the fluid level in the reservoir up to

TIRE SIZE

PRESSURE

room while engine is running, since

the halfway mark.

FRONT

REAR

the high currents in the Common

7. Proceed with caution, keeping alert

195/70R15C-6PR

290kPa (42PSI)

Low Deck

340kPa

Rail system produce considerable

for further signs of overheating. If

(STD)

(50PSI)

magnetic fields.

overheating happens again, call a

155R12C-8PR

Low Deck

440kPa

Hyundai dealer for assistance.

(DBL)

(64PSI)

440kPa

5. If the water pump drive belt is broken

195/70R15C-8PR

High Deck

(64PSI)

or coolant is leaking out, stop the

engine immediately and call the near-

CAUTION:

est Hyundai dealer for assistance.

Serious loss of engine coolant indi-

cates there is a leak in the cooling

system and this should be checked

as soon as possible by a Hyundai

dealer.

3 WHAT TO DO IN AN EMERGENCY

D040B02HR-GAT

High

Handling the Spare Tire

Steel wire

(4)

Deck

(5)

Rear wheel tire

Tire support

OHR058110

D040B03HR

3. Disconnect the steel wire (4) from

OHR058109

the tire support hook (5) after the

spare tire comes down completely.

1. Assemble the tools(1)(2)(3) into the

4. To install the spare tire, build the

spare tire carrier wrench orderly like

spare tire as following and pull the

the picture.

tire support.

2. Insert the spare tire carrier wrench

into the hole of the spare tire carrier,

Low

Steel wire

(4)

turn it counterclockwise, then the

Deck

spare tire comes down.

(5)

Rear wheel tire

Wheel carrier guide

OHR058111

Rubber cushion

5. Connect the steel wire (4) with the

support hook (5).

Front wheel tire

Tire support

D040B01HR

WHAT TO DO IN AN EMERGENCY

IF YOU HAVE A FLAT TIRE

E050D02HR-GAT

D050A01HR-GAT

Spare tire anti-theft device

If a tire goes flat while you are driving:

(If Installed)

1. Take your foot off the accelerator

pedal and let the car slow down

while driving straight ahead. Do not

apply the brakes immediately or at-

tempt to pull off the road as this may

cause a loss of control. When the

car has slowed to such a speed that

it is safe to do so, brake carefully

OHR058112

and pull off the road. Drive off the

6. Insert the spare tire carrier wrench

road as far as possible and park on

into the hole in the spare tire carrier

firm, level ground. If you are on a

OHR058113

and turn it clockwise.

divided highway, do not park in the

7. After the spare tire fully raised, tighten

This device is designed to protect the

median area between the two traffic

by hand to about 30 kg.f (295 N).

spare tire theft.

lanes.

Then, remove the spare tire carrier

To unlock the spare tire-anti theft de-

2. When the car is stopped, turn on

wrench with care not to turn it in the

vice insert the key into the lock, push it

your emergency hazard flashers,

reverse direction. Now, ensure that

once, then pull out it with the key.

set the parking brake and put the

the tire is secured in position.

To lock the spare tire anti-theft device

transmission in reverse.

fit the lock connected to the key in the

3. Have all passengers get out of the

hole of the spare tire carrier, push it

car. Be sure they all get out on the

once until in "clicks", then pull out the

side of the car that is away from

CAUTION:

key.

traffic.

If you cannot secure the spare tire in

4. Change the tire according to the

position, load it on the cargo deck

instructions provided as following.

and ask your nearest service shop

for inspection.

3 WHAT TO DO IN AN EMERGENCY

CHANGING A FLAT TIRE

D060A01HR-GAT

D060K02HR-GAT

Wheel Cover (If Installed)

(1)

OHR058114

OHR058104

To reinstall the wheel cover fit the

OHR058105

The procedure described on the follow-

grooves of the wheel cover in the wheel

ing pages can be used to rotate tires as

Front

lug nuts of wheel and hit the center of

well as to change a flat tire. When

To remove the wheel cover insert the

the wheel cover with your hand.

preparing to change a flat tire, check to

rod (1) into the crack between the wheel

be sure the gear selector lever is in

and wheel cover, and pry up the wheel

reverse gear and that the parking brake

cover gently with the rod.

is set, then:

WHAT TO DO IN AN EMERGENCY

D060B01HR-GAT

1. Obtain Spare Tire and Tool

OHR058107

OHR058106

Rear

To reinstall the wheel cover fit the point

D060F01HR

To remove the wheel cover insert the

(1) of the wheel cover in the valve (2) of

fingers into the holes in the wheel cover

Remove the spare tire and take out the

the wheel, and hit the center of the

and pull the wheel cover powerfully

jack and tool bag.

wheel cover with your hand.

from the wheel.

To remove the spare tire, refer to

"Handling the Spare Tire" on page 3-6.

To take out the jack, loosen the secur-

CAUTION:

ing unt.

Make sure there's nothing behind

you before removing the wheel cover.

NOTE:

The spare tire is located underneath

the car.

3 WHAT TO DO IN AN EMERGENCY

D060C01A-AAT

D060D01A-AAT

D060E01P-AAT

2. Block the Wheel

3. Loosen Wheel Nuts

4. Put the Jack in Place

Flat tire

Front

OHR058115

OHR058108

OHR058116

Block the wheel that is diagonally oppo-

Assemble the tools(1)(2)(3) into the

Rear

site from the flat tire to keep the vehicle

wheel lug nut wrench orderly like the

from rolling when the car is raised on the

picture.

jack.

The wheel nuts should be loosened

slightly before raising the car. To loosen

the nuts, turn the wrench handle coun-

terclockwise. When doing this, be sure

that the socket is seated completely

over the nut so it cannot slip off. For

maximum leverage, position the

wrench so the handle is to the right as

shown in the illustration. Then, while

OHR058117

holding the wrench near the end of the

The method for jacking up the vehicle

handle, pull up on it with steady pres-

should be remembered in order to

sure. Do not remove the nuts at this

change a tire in the event of a puncture

time. Just loosen them about one-half

and in order to install tire chains.

turn.

Hyundai H-100 Truck (2012 year). Instruction - part 7
