Driving your vehicle
Recognizing pedestrians
-
The pedestrian is not completely
within the range of the camera sen-
sor or the pedestrian is not in a typ-
ical upright walking posture.
-
The pedestrian moves very fast.
-
The pedestrian suddenly crosses
in front.
-
The pedestrian wears clothes that
are difficult to distinguish from the
OUM054046L
ODM055053
background.
-
It is too bright or too dark outside.
When a vehicle in front moves out of
- Recognizing the vehicle
the lane to avoid a stopped vehicle
-
The vehicle drives at night or in the
When the vehicle in front has cargo
further ahead, the AEB may not
darkness.
extending beyond the back of the
detect the stopped vehicle ahead.
vehicle or has a high ground clear-
-
There are items that resemble a
Always exercise caution.
ance, the AEB may not detect the
person's silhouette.
nearest hazard.
-
The pedestrian is small.
-
The pedestrian is using a mobility
assistance device.
-
It is difficult to distinguish the
pedestrian from the surroundings.
-
The sensor recognition is limited.
-
There is a group of pedestrians.
5 65
Driving your vehicle
✽ NOTICE
This device complies with Part
WARNING
15 of the FCC rules.
In some instances, the AEB system
•
Cancel the AEB in the User
may be cancelled when subjected to
Operation is subject to the following
Settings on the LCD before
electromagnetic interference.
two conditions:
towing another vehicle. While
1. This device may not cause harm-
towing, the brake application
ful interference, and
may adversely affect your
vehicle safety.
2. This device must accept any inter-
ference received, including inter-
•
Exercise caution when there
ference that may cause undesired
is a vehicle in front that has
operation.
cargo extending beyond the
back of the vehicle or has a
high ground clearance.
•
The sensor only detects
standing or walking pedestri-
ans, not carts, bicycles,
motorcycles, luggage bags, or
strollers.
•
The AEB is not guaranteed to
work in every possible situa-
tion. Never test the AEB
against a person or an object.
It may cause severe injuries
or death.
5 66
Driving your vehicle
CRUISE CONTROL SYSTEM (IF EQUIPPED)
(Continued)
WARNING
•
Do not use the Cruise Control
•
If the cruise control is left on,
when it may be unsafe to keep
(CRUISE indicator light in the
the vehicle at a constant
instrument cluster is illumi-
speed:
nated), the cruise control can
be switched on accidentally.
- When driving in heavy traffic
Keep the cruise control sys-
or when traffic conditions
tem off
(CRUISE indicator
make it difficult to drive at a
light OFF) when the cruise
constant speed
control is not in use, to avoid
- When driving on rainy, icy, or
ODM052024
inadvertently setting a speed.
snow-covered roads
1.Cruise indicator
•
Use the cruise control system
- When driving on hilly or
only when driving on open
windy roads
2.Cruise set indicator
highways in good weather.
- When driving in windy areas
•
Pay particular attention to the
The cruise control system allows you
•
Do not use the Cruise Control
driving conditions whenever
to program the vehicle to maintain a
when towing a trailer.
using the cruise control sys-
constant speed without depressing
tem.
the accelerator pedal.
•
Be careful when driving
This system is designed to function
downhill using the cruise con-
above approximately
25 mph (40
trol system, which may
km/h).
increase the vehicle speed.
(Continued)
5 67
Driving your vehicle
✽ NOTICE
Cruise control switch
To set cruise control speed:
•
During normal cruise control
operation, when the SET switch is
activated or reactivated after
applying the brakes, the cruise
control will energize after approx-
imately 3 seconds. This delay is
normal.
•
To activate cruise control, depress
the brake pedal at least once after
turning the ignition switch to the
ON position or starting the engine.
This is to check if the brake switch
ODMEDR2016
ODM052025
which is important part to cancel
cruise control is in normal condi-
CRUISE : Turns cruise control sys-
1. Press the CRUISE button on the
tion.
tem on or off.
steering wheel to turn the system
on. The CRUISE indicator light in
CANCEL: Cancels cruise control
the instrument cluster will illumi-
operation.
nate.
RES+: Resumes or increases cruise
2. Accelerate to the desired speed,
control speed.
which must be more than 25 mph
SET-: Sets or decreases cruise con-
(40 km/h).
trol speed.
5 68
Driving your vehicle
To increase cruise control set
To decrease the cruising
speed:
speed:
ODM052027
3. Move the toggle switch down (to
SET-), and release it at the desired
ODM052026
ODM052027
speed. The SET indicator light in
the instrument cluster will illumi-
Follow either of these procedures:
Follow either of these procedures:
nate. Release the accelerator
• Move the toggle switch up
(to
• Move the toggle switch down (to
pedal at the same time. The
RES+) and hold it. Your vehicle will
SET-) and hold it. Your vehicle will
desired speed will automatically
accelerate. Release the toggle
gradually slow down. Release the
be maintained.
switch at the speed you want.
toggle switch at the speed you
On a steep grade, the vehicle may
want to maintain.
• Move the toggle switch up
(to
slow down or speed up slightly while
RES+) and release it immediately.
• Move the toggle switch down (to
going uphill or downhill.
SET-) and release it immediately.
The cruising speed will increase by
1 mph (1 km/h) each time you
The cruising speed will decrease
move the toggle switch up
(to
by 1 mph (1 km/h) each time you
RES+) in this manner.
move the toggle switch down (to
SET-) in this manner.
5 69
Driving your vehicle
To temporarily accelerate with
To cancel cruise control, do
Each of these actions will cancel
the cruise control on:
one of the following:
cruise control operation
(the SET
indicator light in the instrument clus-
If you want to speed up temporarily
ter will go off), but it will not turn the
when the cruise control is on,
system off. If you wish to resume
depress the accelerator pedal.
cruise control operation, move up the
Increased speed will not interfere
toggle switch (to RES+) located on
with cruise control operation or
your steering wheel. You will return to
change the set speed.
your previously preset speed.
To return to the set speed, take your
foot off the accelerator pedal.
ODM052028
• Depress the brake pedal.
• Shift into N (Neutral) with an auto-
matic transaxle.
• Press the CANCEL switch located
on the steering wheel.
• Decrease the vehicle speed lower
than the memory speed by 9 mph
(15 km/h).
• Decrease the vehicle speed to less
than approximately
25 mph (40
km/h).
5 70
Driving your vehicle
To resume cruising speed at
✽ NOTICE
To turn cruise control off, do
more than approximately 25
one of the following:
Always check the road conditions
mph (40 km/h):
when you move the toggle switch up
(to RES+) to resume the speed.
ODM052025
ODM052026
• Press the CRUISE button
(the
If any method other than the
CRUISE indicator light in the
CRUISE button was used to cancel
instrument cluster will go off).
cruising speed and the system is still
• Turn the ignition off.
activated, the most recent set speed
Both of these actions cancel cruise
will automatically resume when you
control operation. If you want to
move the toggle switch up (to RES+).
resume cruise control operation,
It will not resume, however, if the
repeat the steps provided in “To set
vehicle speed has dropped below
cruise control speed” on the previous
approximately 25 mph (40 km/h).
page.
5 71
Driving your vehicle
ADVANCED SMART CRUISE CONTROL SYSTEM (IF EQUIPPED)
WARNING
WARNING
For your safety, please read the
Take the following precautions:
owner's manual before using
•
If the Smart Cruise Control is
the Smart Cruise Control sys-
left on,
(CRUISE indicator
tem.
light in the instrument cluster
is illuminated) the Smart
Cruise Control can be activat-
WARNING
ed unintentionally. Keep the
Smart Cruise Control System
The Smart Cruise Control
off
(CRUISE indicator light
System is not a substitute for
ONC047126N
OFF) when the Smart Cruise
safe driving practices, but a
➀ Cruise Indicator
Control is not in use, to avoid
convenience function only. It is
inadvertently setting a speed.
➁ Set Speed
the responsibility of the driver
to always check the speed and
•
Use the Smart Cruise Control
➂ Vehicle-to-Vehicle Distance
distance to the vehicle ahead.
System only when traveling
on open highways in good
The Smart Cruise Control System
weather.
allows you to program the vehicle to
•
Do not use the Smart Cruise
maintain a set speed so long as it is
Control when it may not be
not limited by traffic. When traffic is
safe to keep the vehicle at a
encountered the vehicle will slow
constant speed:
down to maintain a set distance
behind traffic without depressing the
- When driving in heavy traffic
accelerator or brake pedal.
or when traffic conditions
make it difficult to drive at a
constant speed
(Continued)
5 72
Driving your vehicle
To Adjust the Sensitivity of
•
Normal:
(Continued)
Smart Cruise Control
Vehicle speed following the front
- When driving on rainy, icy, or
vehicle to maintain the set distance
snow-covered roads
is normal
- When driving on hilly or
•
Fast:
windy roads
Vehicle speed following the front
- When driving in windy areas
vehicle to maintain the set distance
- When driving in parking lots
is faster than normal speed.
- When driving near crash
barriers
- When driving on a sharp
curve
- When driving with limited
OAN057006N
view (possibly due to bad
weather, such as fog, snow,
The sensitivity of vehicle speed
rain or sandstorm)
when following the front vehicle to
•
Do not use the Smart Cruise
maintain the set distance can be
Control when towing a trailer.
adjusted. Go to the User Settings
Mode (Driving Assist) and select
SCC (Smart Cruise Control). You
may select one of the three stages
you prefer.
• Slow:
Vehicle speed following the front
vehicle to maintain the set distance
is slower than normal speed.
5 73
Driving your vehicle
To convert to Cruise Control
When the system is canceled using
Smart Cruise Control speed
mode
the CRUISE button or the CRUISE
To set Smart Cruise Control
button is used after the engine is
speed
turned on, the SCC mode will turn
on.
WARNING
When using the Cruise Control
mode, you must manually
adjust the distance to other
vehicles by depressing the
accelerator or brake pedal. The
system does not automatically
ODM056066L/ODM056097L
adjust the distance to vehicles
in front of you.
ODM052025
The driver may choose to only use
the Cruise Control mode (speed con-
1. Push the CRUISE button on the
trol function) by doing as follows:
steering wheel to turn the system
on. The CRUISE indicator will illu-
1.Turn the Smart Cruise Control
minate.
System on (the cruise indicator
light will be on but the system will
2. Accelerate to the desired speed.
not be activated).
The Smart Cruise Control speed
2.Push and hold the Vehicle-to-
can be set as follows:
Vehicle Distance button for more
• About
20 mph (30 km/h)~110
than 2 seconds.
mph (180 km/h): when there is
3.Choose between "Smart Cruise
no vehicle in front
Control (SCC) mode" and "Cruise
• 0 mph (0 km/h)~110 mph (180
Control (CC) mode".
km/h): when there is a vehicle in
front
5
74
Driving your vehicle
To increase Smart Cruise Control
To decrease the Smart Cruise
set speed
Control set speed
ODM052027
3. Push the toggle switch down
(SET-), and release it at the
ODM052026
ODM052027
desired speed.
The Set Speed and Vehicle-to-
Follow either of these procedures:
Follow either of these procedures:
Vehicle Distance on the LCD dis-
• Push the toggle switch up (RES+),
• Push the toggle switch down (SET-),
play will illuminate.
and hold it. Your vehicle set speed
and hold it. Your vehicle set speed
4. Release the accelerator pedal.
will increase by 5 mph (10 km/h).
will decrease by 5 mph (10 km/h).
Release the toggle switch at the
Release the toggle switch at the
The desired speed will automati-
speed you want.
speed you want.
cally be maintained.
• Push the toggle switch up (RES+),
• Push the toggle switch down (SET-),
If there is a vehicle in front of you, the
and release it immediately. The
and release it immediately. The
speed may decrease to maintain the
cruising speed will increase by 1
cruising speed will decrease by 1
distance to the vehicle ahead.
mph (1 km/h) each time you move
mph (1 km/h) each time you move
On a steep grade, the vehicle may
the toggle switch up in this manner.
the toggle switch down in this man-
slow down or speed up slightly while
ner.
• You can set the speed up to 110
going uphill or downhill.
mph (180 km/h).
• You can set the speed to 20 mph
(30 km/h).
5 75
Driving your vehicle
To temporarily accelerate with the
Smart Cruise Control will be tem-
The smart cruise control system will
Smart Cruise Control on
porarily canceled when:
be canceled automatically when :
If you want to speed up temporarily
•
The driver's door is opened.
when the Smart Cruise Control is on,
•
The shift lever is shifted to N
depress the accelerator pedal.
(Neutral), R (Reverse) or P (Park).
Increased speed will not interfere
•
The EPB
(Electronic Parking
with Smart Cruise Control operation
Brake) is applied.
or change the set speed.
•
The vehicle speed is over 120 mph
To return to the set speed, take your
(190 km/h).
foot off the accelerator.
•
The vehicle stops on a steep
If you push the toggle switch down
incline.
(SET-) at increased speed, the cruis-
ing speed will be set again.
•
The ESC, TCS or ABS is operat-
ing.
ODM052028
•
The ESC or TCS is turned off.
✽ NOTICE
•
The brake pedal is depressed.
•
The AEB is activated.
Be careful when accelerating tem-
•
CANCEL button located on the
•
The sensor or the cover is dirty or
porarily, because the speed is not
steering wheel is depressed.
blocked with foreign matter.
controlled automatically at this
•
The CANCEL button is depressed
time even if there is a vehicle in front
•
When the vehicle is stopped for
when the vehicle is at a standstill.
of you.
more than 5 minutes.
•
The vehicle stops and goes repeat-
The Advanced Smart Cruise Control
edly for a long period of time.
turns off temporarily when the indica-
•
The driver starts driving by pushing
tor on the LCD display turns off.
the toggle switch up (RES +) or
The CRUISE indicator is illuminated
down (SET -), approximately
3
continuously.
seconds after the vehicle is
stopped by the Smart Cruise
Control System with no other vehi-
cle ahead.
5
76
Driving your vehicle
• The driver starts driving by pushing
To resume Smart Cruise Control
a toggle switch up (RES +) or down
set speed
(SET -), after stopping the vehicle
with a vehicle stopped far away in
front.
• The accelerator pedal is continu-
ously depressed for more than one
minute.
Each of these actions will cancel the
Smart Cruise Control operation an
the Set Speed and Vehicle-to-Vehicle
ODM056058L
Distance on the LCD display will go
If the system is cancelled, the warn-
off.
ing chime will sound and a message
ODM052026
In a condition where the Smart
will appear for a few seconds.
Cruise Control is cancelled automat-
You must adjust the vehicle speed by
If any method other than the
ically, the Smart Cruise Control will
depressing the accelerator or brake
CRUISE toggle switch was used to
not resume even when the RES+ or
pedal according to the road condition
cancel cruising speed and the sys-
SET- toggle switch is pushed. Also,
ahead and driving condition.
tem is still activated, the cruising
the EPB will be applied when the
speed will automatically resume
vehicle is stopped.
Always check the road conditions.
when you push the toggle switch up
Do not rely on the warning chime.
(RES+) or down (SET-).
✽ NOTICE
If you push the toggle switch up
If the Smart Cruise Control is can-
(RES+), the speed will resume to the
celled by other than the reasons
recently set speed. However, if vehi-
mentioned, have the system checked
cle speed has dropped below
by an authorized HYUNDAI dealer.
approximately 20 mph (30 km/h), it
will resume when there is a vehicle in
front of your vehicle.
5 77
Driving your vehicle
✽ NOTICE
To turn Cruise Control off
Smart Cruise Control Vehicle-
to-Vehicle Distance
Always check the road conditions
when you push the toggle switch up
To set Vehicle-to-Vehicle Distance
(RES+) to resume speed.
ODM052025
Push the CRUISE button
(the
CRUISE indicator light will go off).
ODM056118L
When the Smart Cruise Control
System is ON, you can set and main-
tain the distance from the vehicle
ahead of you without pressing the
accelerator or brake pedal.
5 78
Driving your vehicle
Each time the button is pressed, the
When the lane ahead is clear:
When there is a vehicle ahead of
vehicle to vehicle distance changes
you in your lane:
as follows:
Distance 4
Distance 3
Distance 2
Distance 1
For example, if you drive at 56 mph
(90 km/h), the distance maintain as
follows:
Distance 4
Distance 3
Distance 4 - approximately 172 feet
ONC047127N
(52.5 m)
The vehicle speed will maintain the
Distance 3 - approximately 130 feet
set speed.
(40 m)
Distance 2 - approximately 106 feet
(32.5 m)
Distance 1 - approximately 82 feet
(25 m)
Distance 2
Distance 1
ONC047126N/ONC047130N/
✽ NOTICE
ONC047129N/ONC047128N
Distance 4 is always set when the
•
Your vehicle speed will slow down
system is used for the first time after
starting the engine.
or speed up to maintain the select-
ed distance (A vehicle will appear
in front of your vehicle in the LCD
display only when there is an actu-
al vehicle in front of you.).
5 79
Driving your vehicle
• If the vehicle ahead speeds up,
your vehicle will travel at a steady
WARNING
cruising speed after accelerating to
the set speed.
ODM056111
ODM056064L
When using the Smart Cruise
Control System:
CAUTION
•
The warning chime sounds
If the vehicle ahead
(vehicle
and the Vehicle-to Vehicle
speed less than
20 mph
Distance indicator blinks if
(30km/h)) moves to the next
the vehicle is unable to main-
lane, the warning chime will
tain the selected distance
sound and a message will
from the vehicle ahead.
appear. Adjust your vehicle
•
If the warning chime sounds,
speed for vehicles or objects
depress the accelerator or
that can suddenly appear in
brake pedal to actively adjust
front of you by depressing the
the vehicle speed, and the dis-
brake pedal.
tance to the vehicle ahead.
Always pay attention to the road
•
Even if the warning chime is
not activated, always pay
condition ahead.
attention to the driving condi-
tions to prevent dangerous
situations from occurring.
5 80
Driving your vehicle
In traffic situation
• If you push the advanced smart
Sensor to detect distance to
cruise control toggle switch (RES+
the vehicle ahead
■ Type A
■ Type B
or SET-) while Auto Hold and
advanced smart cruise control is
operating (The green AUTO HOLD
indicator), Auto Hold will be
released regardless of accelerator
pedal operation and the vehicle will
start to move.
ODM056065L/OAN056065N
• In traffic, your vehicle will stop if the
OAN057116N
vehicle ahead of you stops. Also, if
The Smart Cruise Control uses a
the vehicle ahead of you starts
sensor to detect distance to the vehi-
moving, your vehicle will start as
cle ahead.
well. However, if the vehicle stops
If the sensor is covered with dirt or
for more than 3 seconds, you must
other foreign matter, the vehicle to
depress the accelerator pedal or
vehicle distance control may not
push up the toggle switch (RES+)
operate correctly.
to start driving.
Always keep the area in front of the
sensor clean.
5 81
