Hyundai Equus (2016 year). Instruction - part 16

Driving your vehicle

START

(Continued)

To start the engine, depress the

•

Before leaving the driver’s

brake pedal and press the Engine

seat, always make sure the

Start/Stop Button with the shift gear

shift gear is engaged in P

in P(Park) or N(Neutral).

(Park), fully set the parking

For your safety, start the engine with

brake and turn the engine

the shift gear in P(Park).

OFF. Unexpected and sudden

vehicle movement may occur

i

Information

if these precautions are not

taken.

• If you press the Engine Start/Stop

•

Never touch the Engine

button without depressing the brake

Start/Stop button, or any other

pedal, the engine does not start.

controls on the steering wheel

When the Engine Start/Stop button

while the vehicle is in motion.

is pressed, it changes as follows:

Reaching out for those con-

OFF → ACC → ON → OFF

trols with your hand or arm

• If you leave the Engine Start/Stop

may cause a loss of vehicle

Button in the ACC or the ON posi-

control, an accident, serious

tion for a long time, the battery will

bodily injury or death.

be discharged.

•

Do not place any loose

objects around the driver’s

seat, as they may toss about

WARNING

while driving, interfering with

• Never press the Engine

the driver's pedal operation

Start/Stop button while the

and leading to an accident.

vehicle is in motion except in

an emergency situation. This

would turn the engine OFF,

resulting in loss of power

assist for the steering wheel

and brake. This may lead to

loss of directional control and

braking function, which could

cause an accident.

(Continued)

5-8

Driving your vehicle

■ Type A

(Continued)

• When the stop light fuse is blown

out, you cannot normally start the

engine. Replace the blown-out fuse

with a new one. If you are not able

to replace the fuse, you can start the

engine by pressing the Smart Key

onto the Engine Start/Stop button

for 10 seconds. The engine can start

without depressing the brake pedal.

However, for your safety, always

OVI055003N

depress the brake pedal before

■ Type B

starting the engine.

NOTICE

Do not press the Engine

Start/Stop Button for more than 5

seconds except when the stop

light fuse is disconnected.

OVI055004N

i

Information

• When the battery is weak, or when

the Smart Key does not properly

operate, you can start the engine by

pressing the Smart Key onto the

Engine Start/Stop button.

The Smart Key edge near the lock

button should be directly contacted

onto the Engine Start/Stop button.

When you press the Smart Key onto

the Engine Start/Stop button, the

Smart Key should be contacted onto

the button at a right angle.

(Continued)

5-10

Driving your vehicle

05

AUTOMATIC TRANSMISSION

Release button

+ (UP)

- (DOWN)

OVI055009N

Depress the brake pedal and press the release button when moving the shift lever.

(If the shift lock system is not equipped, it is not necessary to depress the brake pedal.

However, it is recommended to depress the brake pedal to avoid inadvertent movement

of the vehicle.)

Press the release button when moving the shift lever.

The shift lever can freely operate.

5-11

Driving your vehicle

Automatic transmission opera-

(Continued)

tion

• When a vehicle stops on a

slope, do not stop the vehicle

The automatic transmission has 8

with the engine power.

forward speed levels and 1 reverse

speed level. Vehicle speed is auto-

Set the service brake or the

matically selected, depending on the

parking brake.

shift lever position.

• Do

not

shift

from

N(Neutral)/P(Park)

to

i

Information

D(Drive)/R(Reverse), when the

engine runs faster than the idle

A new vehicle may experience some-

speed.

what abrupt movement during the

first few shifts.

Transmission ranges

Always depress the brake pedal

The shift lever position is displayed

when moving the shift lever from N

on the instrument cluster, when the

(Neutral) to a forward or reverse gear.

Engine Start/Stop button is ON.

WARNING

P (Park)

Always completely stop the vehicle

- Automatic transmission

before moving the shift lever to P

• Always take a look around

(Park). This locks the transmission

your vehicle for any passers-

and prevents the drive wheels from

by, especially children, before

rotating.

moving the shift lever to D

(Drive) or R (Reverse).

WARNING

• Before leaving the driver’s

seat, always make sure the

• Moving the shift lever to P

shift lever is in P (Park). Then,

(Park), while driving, locks the

fully set the parking brake and

drive wheels, possibly result-

turn

the engine OFF.

ing in your loss of vehicle

Unexpected and sudden vehi-

control.

cle movement may occur

• Do not set the shift lever in P

when these precautions are

(Park) instead of setting the

not taken.

parking brake. Always make

sure the shift lever is latched

in P(Park) position, and the

NOTICE

parking brake is fully set.

• To avoid damage to your trans-

• Never leave a child unattend-

mission, do not depress the

ed in a vehicle.

accelerator, when the shift lever

is in R (Reverse) or any forward

gear positions, and when the

brake is set.

(Continued)

5-12

Driving your vehicle

05

R (Reverse)

Set the shift lever in this position to

drive backwards.

+ (UP)

NOTICE

Always completely stop the vehi-

Sports mode

cle before changing the shift lever

to or out of R (Reverse). You may

damage the transmission when

changing the shift lever to R while

- (DOWN)

driving, except as explained in

OVI055010N

"Rocking the Vehicle" in this chap-

Sports Mode

ter.

Whether the vehicle is idle or in

motion, sports mode is selected by

N (Neutral)

moving the shift lever from D(Drive)

The wheels and transmission are not

to the manual gate. To return to

engaged. The vehicle rolls freely

D(Drive), push the shift lever back

even on the slightest slope, unless

into the main gate.

the parking brake or service brake is

applied.

In sports mode, moving the shift

lever backwards and forwards will

D (Drive)

allow rapid gear shifting.

This is for the forward driving posi-

Up (+)

: Push the shift lever for-

tion. The transmission will automati-

wards once to shift up one

cally shift in a 8-gear sequence, pro-

gear.

viding the best fuel economy and

Down (-) : Pull the shift lever back-

power.

wards once to shift down

For extra power to pass ahead

one gear.

another vehicle or to climb a slope,

fully depress the accelerator. Then,

i

Information

the transmission will automatically

• In sports mode, the driver must exe-

downshift to the next lower gear (or

gears, as appropriate).

cute upshifts in accordance with

road conditions, taking care to keep

the engine speed below the red zone.

i

Information

• In sports mode, only the 8 forward

Always come to a complete stop before

gears can be selected. To reverse or

changing the shift lever to D (Drive).

park the vehicle, move the shift

lever to the R (Reverse) or P (Park)

position as required.

(Continued)

5-13

Driving your vehicle

05

Good driving practices

•

Never move the shift lever from

P(Park)/N(Neutral) to any other

position, while depressing the

accelerator.

•

Never move the gearshift to P

(Park), when the vehicle is in

motion.

•

Make sure to completely stop the

vehicle before moving the shift

lever to R(Reverse)/D(Drive).

OVI055011N

•

Never disengage the gear, while

Shift-lock override

driving down on a slope. This may

When the shift lever cannot be

be extremely hazardous. Always

moved from P(Park)/N(Neutral) to R

engage the gear while driving.

(Reverse), while depressing the

•

Do not "ride" the brakes. This may

brake pedal, keep depressing the

cause overheating and malfunc-

brake, and do the followings:

tion. Instead, when you drive down

1.Carefully remove the cover (1) of

a long slope, slow the vehicle

the shift-lock access hole.

down, set in Sports Mode, and shift

2.Insert a screwdriver into the

to a lower gear. Those will help the

access hole and press it.

engine brake slow the vehicle

3.Move the shift lever.

down.

4.Immediately have your vehicle

•

Slow down before shifting to a

inspected by an authorized

lower gear in sports mode.

EQUUS dealer.

Otherwise, the lower gear may not

be engaged.

•

Always set the parking brake. Do

not depend on the shift gear in P

(Park) to prevent the vehicle from

moving.

•

Exercise extreme caution when

driving on a slippery surface. Be

careful especially when braking,

accelerating or shifting gears. On a

slippery surface, an abrupt change

in vehicle speed may cause the

drive wheels to lose traction and

the vehicle to go out of control.

•

Optimum vehicle performance and

fuel economy are obtained by

smoothly depressing and releasing

the accelerator.

5-15

Driving your vehicle

WARNING

WARNING

•

Always buckle up! In a colli-

When your vehicle is stuck in

sion, an unbelted occupant is

snow, mud, sand and others,

more likely to be seriously

you may rock the vehicle by

injured or killed than a proper-

moving it forward and back-

ly belted occupant.

wards. Do not attempt this pro-

cedure when there are people

•

Avoid high speeds when cor-

or objects near the vehicle.

nering or turning.

During the rocking operation,

•

Do not make quick wheel

the vehicle may suddenly move

steering, such as sharp lane

forwards or backwards as it

changes or fast, sharp turns.

becomes unstuck, causing

•

The risk of rollover is greatly

injury or damage to nearby peo-

increased when you lose con-

ple or objects.

trol of your vehicle at a high

speed.

•

Loss of control often occurs,

Moving up a steep grade from a

when two or more wheels are

standing start

swerved out of the roadway

To drive up on a steep slope,

and are overly steered to

depress the brake pedal, move the

reenter the roadway.

shift gear to D (Drive), and release

•

In the event your vehicle is

the parking brake. Gradually depress

swerved out of the roadway,

the accelerator while releasing the

do not make a sharp steering.

service brakes.

Instead, slow down the vehi-

When accelerating on a steep

cle before reentering into the

slope, the vehicle may have a ten-

lanes.

dency to slide backwards. Shifting

•

Never exceed posted speed

to the 2nd gear (Second Gear) will

limits.

help prevent the vehicle from slid-

ing backwards.

5-16

Driving your vehicle

05

BRAKE SYSTEM

Power brakes

(Continued)

Your vehicle is equipped with the

•

Wet brakes may impair the

power-assisted brakes that automat-

vehicle’s ability to safely slow

ically adjust themselves in a normal

down. The vehicle may also be

driving condition.

swerved to one side when the

In the event that the power-assisted

wet brakes are depressed.

brakes lose power because of a

Lightly depress the brakes to

stalled engine or some other rea-

verify whether the brakes are

sons, you can still stop your vehicle

wet and show the above

by depressing the brake pedal hard-

symptom. Always test your

er than you do in normal driving. A

brakes in this fashion after

braking distance, however, will be

driving through deep water.

longer.

To dry the wet brakes, lightly

When the engine is OFF, the reserve

depress the brakes, while

brake power becomes partially

maintaining a safe driving

depleted each time the brake pedal

speed until the brake perform-

is depressed. Do not repeatedly

ance returns to normal.

depress the brake pedal when the

•

Always confirm the positions

power brake is automatically set.

of the brake and accelerator,

Pump the brake pedal only when

before driving. If you do not

necessary to maintain the steering

so, you may be confused and

control on slippery surfaces.

depress the accelerator

instead of the brake pedal. It

may cause a serious accident.

WARNING

- Brakes

• Do not put your foot on the

brake pedal while driving. This

may abnormally increase the

brake temperatures, wear

down the brake lining/pad,

and increase the braking dis-

tances.

• When driving down on a long

or steep slope, shift to a lower

gear and avoid depressing the

brakes in a continuous man-

ner. Depressing brakes in a

continuous manner may over-

heat the brakes, resulting in a

temporary loss of braking per-

formance.

(Continued)

5-17

Driving your vehicle

In the event of brake failure

Disc brakes wear indicator

When service brakes fail to operate

Your vehicle is equipped with disc

while driving, you can make an

brakes. When your brake pads are

emergency stop by setting the park-

worn down and new pads are

ing brake. The braking distance,

required, you will hear a high-pitched

however, will become longer than

warning sound from the front or rear

normal.

brakes. You may hear this beeping

sound or it may sound when the

brake pedal is depressed.

WARNING

Please remember that some driving

- Parking brake

conditions or climates may cause a

brake squeal when you first apply (or

Setting the parking brake while

lightly apply) the brakes. This is nor-

driving at a normal speed may

mal and does not indicate a problem

cause a sudden loss of vehicle

with your brakes.

control. If you must set the

parking brake to stop, set it with

great caution.

NOTICE

• To prevent costly brake repairs,

do not drive continuously with

the worn-down brake pads.

• Always replace brake pads in a

set of a complete front and rear

axle.

WARNING

- Brake wear

This brake wear warning sound

indicates that your vehicle

should be repaired. If you

ignore this audible warning

sound, you will eventually lose

braking performance, which

may lead to a serious accident.

5-18

Driving your vehicle

05

Electric parking brake (EPB)

Releasing the parking brake

Applying the parking brake

OVI055110N

OVI055109N

To release the EPB, press the EPB

switch as follows:

To set the parking brake, depress the

brake pedal first and then pull the

• Turn the Engine Start/Stop Button

EPB switch. Make sure that the

ON.

brake warning light illuminates.

• Depress the brake pedal.

Make sure the brake warning light

goes OFF.

WARNING

Do not set the parking brake

To automatically release EPB:

while the vehicle is moving

• Shift lever in P (Park)

except in an emergency situa-

tion. It may damage the brake

With the engine running, depress

the brake pedal and move the shift

system and lead to an accident.

lever from P (Park) to R (Rear)/

N (Neutral)/D (Drive).

• Shift lever in N (Neutral)

With the engine running, depress

the brake pedal and move the shift

lever from N(Neutral) to R (Rear)/

D (Drive).

• Depress the accelerator pedal, sat-

isfying the following conditions.

1. Run the engine

2. Fasten the driver's seat belt

3. Close the driver's door, engine

hood and trunk

4. Shift the gear to R

(Rear)/

D (Drive)

Make sure the brake warning light

goes OFF.

5-19

Driving your vehicle

i

Information

• You can set the EPB, even though

the Engine Start/Stop button is OFF.

However, for your safety, you can-

not release it.

• For your safety, depress the brake

pedal and manually release the

parking brake by pressing the EPB

switch, when driving down on a

slope and driving back up.

OVINDR5912

NOTICE

• If the accelerator is depressed, but

• When the parking brake warning

still the EPB is not automatically

released, a warning message will

light is still ON, even when the

EPB is released, have the sys-

be displayed with a warning sound.

tem be checked by an author-

• When the driver's seat belt is

ized EQUUS dealer.

unfastened, the engine hood is

open with the shift lever in

• Do not drive your vehicle with

D(Drive), or the trunk is open with

the EPB set. It may excessively

the shift lever in R(Reverse), a

wear down the brake pad and

warning message will be displayed

brake rotor.

with a warning sound.

• When there is a problem with the

EPB may automatically applies,

vehicle, a warning message will be

when:

displayed with a warning sound.

• It is requested by other systems.

If any of the above situations occurs,

• The engine is turned OFF and the

depress the brake pedal and release

EPB is set ON.

EPB by pressing the EPB switch.

5-20

Driving your vehicle

05

EPB malfunction indicator

WARNING

• To prevent unintentional vehi-

cle movement when parking

or after leaving the vehicle, do

not substitute setting of the

parking brake with setting of

the shift lever. Set the parking

brake and secure to position

the shift lever in P(Park).

• Never allow anyone, who is

unfamiliar with the vehicle, to

touch the EPB switch. If the

OVI055111N

EPB is unintentionally

This warning light illuminates when

released, serious injury may

the Engine Start/Stop button is

occur.

turned ON and OFF in approximate-

• All vehicles must always set

ly 3 seconds, even though the sys-

the parking brake, while park-

tem normally operates.

ing, in order to avoid inadver-

If the EPB malfunction indicator

tent vehicle movement, which

remains ON, flash, or does not illumi-

may injure occupants or

nate, when turning ON the Engine

passers-by.

Start/Stop button, this indicates the

malfunction of the EPB.

NOTICE

If this occurs, immediately have your

vehicle checked by an authorized

• A clicking sound may be heard

EQUUS dealer.

while setting or releasing the

EPB. This is a normal condition,

The EPB malfunction indicator may

and indicates that the EPB prop-

illuminate, when the ESC malfunc-

erly functions.

tion indicator illuminates. In this

case, it does not indicate the EPB

• When leaving your key with a

malfunction.

parking lot attendant or valet

assistant, inform him/her of the

EPB operation.

• The EPB may malfunction if you

drive with the EPB set.

• Gradually depress the accelera-

tor, when you want to automati-

cally release EPB by depressing

it.

5-21

Driving your vehicle

NOTICE

WARNING

• The EPB warning light may illu-

minate, when the EPB switch is

Do not operate the parking

abnormally operated. Turn the

brake while the vehicle is mov-

engine OFF and, after a few min-

ing except in an emergency situ-

utes, turn it ON again. The EPB

ation. It may damage the brake

warning light will go OFF and

system and lead to an accident.

the EPB switch will be normally

operable. However, when the

EPB warning light still remains

i

Information

ON, have the system be checked

In emergency braking with the EPB

by an authorized EQUUS dealer.

switch, the parking brake warning

• The EPB is not set ON, when the

light will illuminate to indicate the

parking brake warning light

system operation.

does not illuminate or flash,

even though the EPB switch was

NOTICE

pulled up.

If there is noise or burning smell

• When the parking brake warning

after emergency braking, immedi-

light flashes with the EPB warn-

ately have your vehicle checked

ing light ON, press the EPB

by an authorized EQUUS dealer.

switch, and then pull it up.

Repeat this one more time.

When the EPB warning does not

When the EPB (electric parking

go OFF, have the system

brake) is not released

checked by an authorized

When the EPB is normally released,

EQUUS dealer.

we recommend that you contact an

authorized EQUUS dealer, tow your

Emergency braking

vehicle, and have the system

checked.

When there is a problem with the

brake while driving, emergency brak-

NOTICE

ing is possible by pulling and holding

the EPB switch.

If you continuously notice a noise

However, braking distance will be

or burning smell after using the

longer than it is in normal driving.

EPB for emergency braking, we

recommend that you have the sys-

tem checked by an authorized

EQUUS dealer.

5-22

Driving your vehicle

05

AUTO HOLD

3.The vehicle will remain to be stand-

still even when you release the

brake pedal.

4.When setting the EPB, the Auto

Hold will be released.

Leaving

When you depress the accelerator

pedal with the shift lever in

R(Reverse)/D(Drive) or in sports

mode, the AUTO HOLD will be auto-

matically released automatically.

OVI055123N

Then, the vehicle will start to move.

The indicator color changes from

The AUTO HOLD makes the brakes

green to white.

keep being applied after the com-

plete stop of the vehicle with the shift

lever in D, R, or N. The brakes are

WARNING

released when the throttle is applied.

When driving off from the AUTO

HOLD by depressing the accel-

Set up

erator, always take a look

around your vehicle. Slowly

press the accelerator for a

smooth starting.

Cancel

If you want to manually release or

cancel the AUTO HOLD, release the

Auto Hold switch while depressing

the brake pedal. The Auto Hold indi-

cator will go OFF. For your safety,

OVI055113N

manually release the Auto Hold,

when the distance from the vehicle

1.Press the AUTO HOLD switch. The

ahead is too close or during downhill

AUTO HOLD indicator will illumi-

driving.

nate in white and the system will

be in the standby status.

2.When you completely stop the

vehicle by depressing the brake

pedal, the AUTO HOLD maintains

the brake pressure in order to firm-

ly stop the vehicle. The indicator

color changes from white to green.

5-23

Driving your vehicle

(Continued)

i

Information

Before driving off again, depress

•

The Auto Hold does not operate,

brake pedal, take a look around

when:

your vehicle, and manually release

- The driver's seat belt is unfastened

the parking brake and the EPB

and driver's door is opened

switch.

- The engine hood is opened

• When the AUTO HOLD indicator

- The trunk is opened

illuminates in yellow, the Auto Hold

does not properly work. Take your

- The shift lever is in P (Park)

vehicle to an authorized EQUUS

- The EPB is set

dealer and have the system checked.

•

For your safety, the Auto Hold auto-

matically switches to EPB, when:

WARNING

- The driver's seat belt is unfastened

and driver's door is opened

• Depress the accelerator slow-

- The engine hood is opened with the

ly when you start the vehicle.

shift lever in D (Drive)

• For your safety, cancel the

- The trunk is opened with the shift

AUTO HOLD operation, when:

lever in R (Reverse)

- Drive a downhill

- The vehicle stops for more than 10

- Slowly drive, park or drive

minutes

backwards

- The vehicle stands on a steep slope

- Wash the vehicle in an auto-

- The vehicle moves several times

matic car wash

In these cases, the brake warning

light illuminates, the AUTO HOLD

NOTICE

indicator color changes from green

When there is a malfunction with

to white, and a message will be dis-

the driver’s door, hood or trunk

played with warming sound to

open detection system, the AUTO

inform you that EPB is automatical-

HOLD may not properly operate.

ly set.

Take your vehicle to an authorized

(Continued)

EQUUS dealer and have the sys-

tem checked.

5-24

Content   ..  14  15  16  17   ..
