3. Exhaust emission control
Engine exhaust gas precautions
•
Do not operate the engine in confined
system
(carbon monoxide)
or closed areas (such as garages) any
•
Carbon monoxide can be present with
more than what is necessary to move
The Exhaust Emission Control System is
other exhaust fumes. Therefore, if you
the vehicle in or out of the area.
a highly effective system which controls
smell exhaust fumes of any kind inside
•
When the vehicle is stopped in an
exhaust emissions whilst maintaining
good vehicle performance.
your vehicle, have it inspected and
open area for more than a short time
repaired immediately. If you ever sus-
with the engine running, adjust the
pect exhaust fumes are coming into
ventilation system (as needed) to draw
Vehicle modifications
your vehicle, drive it only with all the
outside air into the vehicle.
• This vehicle should not be modified.
windows fully open. Have your vehicle
•
Never sit in a parked or stopped vehi-
Modification of your vehicle could
checked and repaired immediately.
cle for any extended time with the
affect its performance, safety or dura-
engine running.
bility and may even violate governmen-
•
When the engine stalls or fails to start,
tal safety and emissions regulations.
WARNING - Exhaust
excessive attempts to restart the
In addition, damage or performance
Engine exhaust gases contain car-
engine may cause damage to the
problems resulting from any modifica-
bon monoxide
(CO). Though
emission control system.
tion may not be covered under warran-
colourless and odourless, it is dan-
ty.
gerous and could be lethal if
• If you use unauthorised electronic
inhaled. Follow the instructions
devices, it may cause the vehicle to
following to avoid CO poisoning.
operate abnormally, wire damage, bat-
tery discharge and fire. For your safety,
do not use unauthorised electronic
devices.
7 77
Maintenance
Operating precautions for catalytic
Your vehicle is equipped with a catalytic
Diesel Particulate Filter (if equipped)
converters (if equipped)
converter emission control device.
The Diesel Particulate Filter (DPF) sys-
Therefore, the following precautions
tem removes the soot emitted from the
must be observed:
vehicle.
WARNING - Fire
•
Use only UNLEADED FUEL for petrol
Unlike a disposable air filter, the DPF
•
A hot exhaust system can ignite
engine.
system automatically burns
(oxidizes)
flammable items under your vehi-
•
Do not operate the vehicle when there
and removes the accumulated soot
cle. Do not park, idle, or drive the
are signs of engine malfunction, such
according to the driving condition. In
vehicle over or near flammable
as misfire or a noticeable loss of per-
other words, the active burning by engine
objects, such as dry grass, paper,
leaves, etc.
formance.
control system and high exhaust gas
temperature caused by normal/high driv-
•
The exhaust system and catalytic
•
Do not misuse or abuse the engine.
ing condition burns and removes the
system are very hot whilst the
Examples of misuse are coasting with
the ignition off and descending steep
accumulated soot.
engine is running or immediately
grades in gear with the ignition off.
However, if the vehicle continues to be
after the engine is turned off. Keep
driven at low speed for long time, the
away from the exhaust system
•
Do not operate the engine at high idle
accumulated soot may not be automati-
and catalytic, you may get burned.
speed for extended periods (5 minutes
cally removed because of low exhaust
Also, do not remove the heat sink
or more).
gas temperature. In this particular case,
around the exhaust system, do
•
Do not modify or tamper with any part
the amount of soot is out of detection
not seal the bottom of the vehicle
of the engine or emission control sys-
limit, the soot oxidation process by
or do not coat the vehicle for cor-
tem. We recommend that the system
engine control system may not happen
rosion control. It may present a
be inspected by a HYUNDAI autho-
and the malfunction indicator light may
fire risk under certain conditions.
rised repairer.
blink.
•
Avoid driving with a extremely low fuel
When the malfunction indicator light
level. Running out of fuel cause the
blinks, it may stop blinking by driving the
engine to misfire, damaging the cat-
vehicle at more than 37 mph (60km/h) or
alytic converter.
at more than second gear with 1500 ~
Failure to observe these precautions
2000 engine rpm for a certain time (for
could result in damage to the catalytic
about 25 minutes).
converter and to your vehicle.
Additionally, such actions could void your
warranties.
7 78
Maintenance
If the malfunction indicator light contin-
ues to blink in spite of the procedure, we
recommend that the system be checked
by a HYUNDAI authorised repairer.
If you continue to drive with the malfunc-
tion indicator light blinking for a long
time, the DPF system can be damaged
and fuel consumption can be worsen.
CAUTION - Diesel Fuel
(if equipped with DPF)
It is recommended to use the regu-
lated automotive diesel fuel for
diesel vehicle equipped with the
DPF system.
If you use diesel fuel including high
sulfur
(more than 50 ppm sulfur)
and unspecified additives, it can
cause the DPF system to be dam-
aged and white smoke can be emit-
ted.
7 79
Specifications & Consumer information
Dimensions
8-2
Engine
8-2
Air conditioning system
8-2
Bulb wattage
8-3
Tyres and wheels
8-4
Load and speed capacity tyres
8-4
Gross vehicle weight
8-5
Luggage volume
8-5
Recommended lubricants and capacities
. . . . . . 8-6
• Recommended engine oil
8-7
• Recommended SAE viscosity number
8-8
Vehicle identification number (VIN)
8-9
Vehicle certification label
8-9
Tyre specification and pressure label
8-10
Engine number
8-10
Air conditioner compressor label
8-11
Declaration of conformity
8-11
8
Specifications & Consumer information
DIMENSIONS
Item
in (mm)
Overall length
173.6 (4410)
Overall width
71.7 (1820)
Overall height
65.2 (1655)/65.6 (1665)*1
Front tread
62.6 (1591)*2/62.4 (1585)*3
*1 with roof rack
Rear tread
62.7 (1592)*2/62.4 (1586)*3
*2 with 215/70R16
*3 with 225/60R17 or 225/55R18
Wheelbase
103.9 (2640)
ENGINE
Item
Petrol 1.6
Petrol 2.0
Diesel 1.7
Diesel R2.0
Displacement
97.09 (1,591)
121.99 (1,999)
102.8 (1,685)
121.74 (1,995)
cu. in (cc)
Bore x Stroke
3.03X3.36
3.19X3.81
3.04X3.81
3.30X3.54
in. (mm)
(77X85.4)
(81X97)
(77.2X90)
(84X90)
Firing order
1-3-4-2
1-3-4-2
1-3-4-2
1-3-4-2
No. of cylinders
4. In-line
4. In-line
4. In-line
4. In-line
AIR CONDITIONING SYSTEM
Item
Weight of volume
Classification
Refrigerant
550±25g
R134a
Compressor lubricant
120±10cc
PAG oil
8 2
Specifications & Consumer information
BULB WATTAGE
Light Bulb
Wattage
Headlights (Low/High)
55 or 35 (HID)
Front turn signal lights
21
Position lights
LED
Side repeater lights (Outside mirror)*
LED
Side repeater lights*
5
Front fog lights*
27
Rear fog light*
21
Stop and tail lights (Outside)
21/5/LED
Stop and tail lights (Inside)
LED
Rear turn signal lights (Outside)
21
Tail light* (Inside)
5
Back-up lights (Inside)
16
High mounted stop light
LED
License plate lights
5
Map lamps
10
Room lamps
10
Luggage lamp*
5
Glove box lamp*
5
Vanity mirror lamps*
5
* If equipped
8 3
Specifications & Consumer information
TYRES AND WHEELS
Inflation pressure bar (psi, kPa)
Normal load
Maximum load
Wheel lug nut torque
Item
Tyre size
Wheel size
(
)
(
)
kg•m (lb•ft, N•m)
Front
Rear
Front
Rear
215/70R16
6.5Jx16
2.6 *1
2.7 *1
2.3
2.3
(38,260)
(39,270)
9~11
Full size tyre
225/60R17
6.5Jx17
(33, 230)
(33, 230)
2.3 *2
2.3 *2
(65~79, 88~107)
225/55R18
6.5J×18
(33,230)
(33,230)
*1 : For Europe
*2 : Except Europe
CAUTION
When replacing tyres, use the same size originally supplied with the vehicle.
Using tyres of a different size can damage the related parts or make it work irregularly.
LOAD AND SPEED CAPACITY TYRES
Load Capacity
Speed Capacity
Item
Tyre size
Wheel size
LI *1
kg
SS *2
km/h
215/70R16
6.5Jx16
100
800
H
210
Full size tyre
225/60R17
6.5Jx17
99
775
H
210
225/55R18
6.5J×18
98
750
H
210
*1 LI
: LOAD INDEX
*2 SS : SPEED SYMBOL
8 4
Specifications & Consumer information
GROSS VEHICLE WEIGHT
lbs (Kg)
1.6 GDI
NU 2.0 MPI
R2.0
U2 1.7
Item
2WD
4WD
2WD
4WD
2WD
4WD
2WD
4WD
5 seater
4034 (1,930)
-
4365 (1,980)
4475 (2,030)
4607 (2,090)
4717 (2,140)
4276 (1,940)
-
LUGGAGE VOLUME
ltem
5 Seater
MIN.
14.7 cu.ft (415 l)
VDA
MAX.
49.5 cu.ft (1,402 l)
Min : Behind rear seat to upper edge of the seat back.
Max : Behind front seat to roof.
8 5
Specifications & Consumer information
RECOMMENDED LUBRICANTS AND CAPACITIES
To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality. The correct
lubricants also help promote engine efficiency that results in improved fuel economy.
These lubricants and fluids are recommended for use in your vehicle.
Lubricant
Volume
Classification
1.6L
3.6 l (3.16 Imp. qts.)
ACEA A5 (or above)
Engine oil *1 *2
API SM & ILSAC GF-4 (or above),
(drain and refill)
Petrol Engine
MPI
2.0L
4.0 l (3.51 Imp. qts.)
ACEA A5 (or above)
GDI
ACEA A5 (or above)
Recommends
with DPF *3
5.3 l (4.66 Imp. qts.)
ACEA C2 or C3
1.7L
without DPF *3
5.3 l (4.66 Imp. qts.)
ACEA B4
Diesel Engine
with DPF *3
ACEA C2 or C3
2.0L
7,6 l (6.68 Imp. qts.)
without DPF *3
ACEA B4
1.8 ~ 1.9 l
1.6L
(1.58 ~ 1.67 Imp. qts.)
Petrol Engine
MPI
2.1 ~ 2.2 l
2.0L
GDI
(1.84 ~ 1.93 Imp. qts.)
Manual transaxle fluid
API GL-4, SAE 75W/85
1.9 ~ 2.0 l
1.7L
(1.67 ~ 1.75 Imp. qts.)
Diesel Engine
1.8 ~ 1.9 l
2.0L
(1.58 ~ 1.67 Imp. qts.)
1.6L
7.3 l (6.42 Imp. qts.)
Petrol Engine
MICHANG ATF SP-IV, SK ATF SP-IV
Automatic transaxle fluid
2.0L
7.1 l (6.24 Imp. qts.)
NOCA ATF SP-IV, HYUNDAI genuine ATF SP-IV
Diesel Engine
7.8 l (6.86 Imp. qts.)
8 6
Specifications & Consumer information
Lubricant
Volume
Classification
Petrol Engine
6.7 l (5.89 Imp. qts.)
Mixture of antifreeze and distilled water
Coolant
Diesel Engine
8.5 l (7.47 Imp. qts.)
(Ethylene glycol base coolant for aluminium radiator)
0.7 ~ 0.8 l
Brake/clutch fluid
FMVSS116 DOT-3 or DOT-4
(0.62 ~ 0.70 Imp. qts.)
HYPOID GEAR OIL API GL-5, SAE 75W/90
Rear differential oil (4WD)
0.65 l ( 0.57 Imp. qts.)
(SHELL SPIRAX X or equivalent)
HYPOID GEAR OIL API GL-5, SAE 75W/90
Transfer case oil (4WD)
0.6 l (0.52 Imp. qts.)
(SHELL SPIRAX X or equivalent)
Petrol Engine
Fuel
58 l (12.7 Imp. gal.)
Refer to “Fuel requirements” in section 1
Diesel Engine
*1 Refer to the recommended SAE viscosity numbers on 8-8 page.
*2 Engine oils labeled Energy Conserving Oil are now available. Along with other additional benefits, they contribute to fuel economy by reducing
the amount of fuel necessary to overcome engine friction. Often, these improvements are difficult to measure in everyday driving, but in a year’s
time, they can offer significant cost and energy savings.
*3 Diesel Particulate Filter
Recommended Engine oil (For Europe)
Product
Supplier
Petrol Engine
Diesel Engine
HELIX ULTRA AH-E 5W-30
Shell
HELIX ULTRA AP 5W-30
HELIX ULTRA 5W-40
8 7
Specifications & Consumer information
Recommended SAE viscosity
Temperature Range for SAE Viscosity Numbers
number
°C
-30
-20
-10
0
10
20
30
40
50
Temperature
CAUTION
(°F)
-10
0
20
40
60
80
100
120
Always be sure to clean the area
20W-50
around any filler plug, drain plug, or
Petrol Engine Oil
15W-40
dipstick before checking or drain-
(1.6L GDI/2.0L GDI)
10W-30
ing any lubricant. This is especially
important in dusty or sandy areas
5W-30, 5W-40
and when the vehicle is used on
20W-50
unpaved roads. Cleaning the plug
and dipstick areas will prevent dirt
15W-40
Petrol Engine Oil
and grit from entering the engine
(2.0L MPI)
10W-30
and other mechanisms that could
5W-20, 5W-30
be damaged.
15W-40
Engine oil viscosity (thickness) has an
10W-30
Diesel
effect on fuel economy and cold weather
Engine Oil (1.7L)
5W-30
operating
(engine start and engine oil
0W-30
flowability). Lower viscosity engine oils
can provide better fuel economy and cold
15W-40
weather performance, however, higher
Diesel
10W-30/40
viscosity engine oils are required for sat-
Engine Oil (2.0L)
5W-30/40
isfactory lubrication in hot weather.
Using oils of any viscosity other than
0W-30/40
those recommended could result in
engine damage.
When choosing an oil, consider the range
of temperature your vehicle will be oper-
ated in before the next oil change.
Proceed to select the recommended oil
viscosity from the chart.
8
8
Specifications & Consumer information
VEHICLE IDENTIFICATION NUMBER (VIN)
VEHICLE CERTIFICATION
LABEL
Frame number
VIN label
Type A (if equipped)
OLM089006N
VIN label
OLM089001
OEL089002R
Type B (if equipped)
The vehicle identification number (VIN) is
The vehicle certification label attached
the number used in registering your vehi-
on the driver’s (or front passenger’s) side
cle and in all legal matters pertaining to
centre pillar gives the vehicle identifica-
its ownership, etc.
tion number (VIN).
The number is punched on the floor
under the driver seat. To check the num-
ber, open the cover.
OLM089006N/H
The VIN is also on a plate attached to the
top of the dashboard. The number on the
plate can easily be seen through the
windscreen from outside.
8 9
Specifications & Consumer information
TYRE SPECIFICATION AND
ENGINE NUMBER
PRESSURE LABEL
■ Petrol engine (1.6L)
■ Diesel engine (1.7L)
■ Petrol engine (2.0L)
■ Diesel engine (2.0L)
OEL083008R
The tyres supplied on your new vehicle
are chosen to provide the best perform-
ance for normal driving.
The tyre label located on the driver's side
centre pillar gives the tyre pressures rec-
ommended for your vehicle.
OEL080003/OEL083010/OEL080004/OLM089004
The engine number is stamped on the engine block as shown in the drawing.
8 10
Specifications & Consumer information
AIR CONDITIONER
DECLARATION OF
COMPRESSOR LABEL
CONFORMITY
■ Example
OHC081001
CE0678
A compressor label informs you the type
The radio frequency components of the
of compressor your vehicle is equipped
vehicle comply with requirements and
with such as model, supplier part num-
other relevant provisions of Directive
ber, production number, refrigerant
(1)
1995/5/EC.
and refrigerant oil (2).
Further information including the manu-
facturer's declaration of conformity is
available on HYUNDAI web site as fol-
lows;
8 11
