AT -28
AUTOMATIC TRANSAXLE (F4A51)
SIGNALS OF SPORTS MODE SWITCH
Items
Mode S/W
UP S/W
DOWN S/W
D range selection
OFF
OFF
OFF
Sports mode selection
ON
OFF
OFF
Sports mode up-shift selection
ON
ON
OFF
Sports mode downshift selection
ON
OFF
ON
CONTROLLER AREA NETWORK (CAN)
Previously, for different computers in the vehicle to share
the same information, each signal required a different pin
and wiring. However, with the introduction of a CAN sys-
tem, only two lines are required to achieve the same func-
tion. The information is in digital format. This method does
not use an integrated ECM.
ECM
TCM
(PCM)
Others
ABS
H
L
Frequency: 500Kbit/sec
EKRF005D
Input signals to TCM(PCM) through ‘ CAN communi-
cation’
- Engine rpm, TPS signal
- A/CON signal, Engine coolant temperature
- Quantity of intake airflow, Vehicle speed
- Shift holding signal (FTCS ON)
Output signals from TCM(PCM) through ‘ CAN com-
munication’
- Request signal for torque reduction
- ATF temperature, TCM(PCM) type, TCM(PCM) error or
not
- Damper clutch ON, OFF / Gear position
