Hyundai H1: Body Repair Manual - part 35

139

UNDER BOD

UNDER BOD

UNDER BOD

UNDER BOD

UNDER BODY ANTI-CORR

Y ANTI-CORR

Y ANTI-CORR

Y ANTI-CORR

Y ANTI-CORROSION A

OSION A

OSION A

OSION A

OSION AG E N T

G E N T

G E N T

G E N T

G E N T

The undersides of the floor and wheel house are undercoated to provide greater corrosion resistance. Therefore, when
such panel is replaced or repaired, apply under body anti-corrosion agent to that part.

NOTE
Do not apply the under body anti-corrosion agent to come in contact with tires, muffler and exhaust pipe.

CORROSION PROTECTION - Under body anti-corrosion agent

Under body anti-corrosion agent (Thickness 400

µ

 - 500

µ

)

AAAC0040
