The odometer will remain displayed for 5 seconds.

Trip Odometers

The trip odometer is capable of displaying values from 0-9999.9 KM or MI.

When the maximum value is reached, the trip odometer will roll over to 0.0.

Holding the control stem for greater than 4 seconds while the trip odometer is displayed will reset
the displayed trip odometer to 0.0 upon release of the stem. The trip odometer will remain
displayed after being reset.

Engine Oil Life

Engine Oil Life percentage values are based on class 2 messages to the instrument panel cluster
(IPC). The IPC requests this value when Engine Oil Life is selected on the DIC.

Engine Oil Life is capable of displaying values from 0 to 100%.

Pressing the control stem for longer than 2 seconds while Engine Oil Life is displayed on the DIC
will reset the value to 100%. An audible warning will sound confirming that the system has been
reset.

Display appears as OIL LIFE: XXX%.

Display Language

The driver information center (DIC) is capable of displaying messages in more than one language.
The DIC language selection procedure is as follows:

1. With the engine OFF, turn the key to ON, but do not start the engine.

2. Close all doors so the DOORS message does not display in the DIC.

3. Momentarily press and release the trip reset stem until the current language is displayed:

English, French or Spanish.

4. To select a different language, press and hold the trip reset stem until the next language

appears.

5. Repeat Step 4 until the desired language is displayed. Once the desired language is shown

on the DIC display, the language is set.

6. To exit language selection, momentarily press and release the trip stem. All DIC messages

will now display in the language selected.

2007 Hummer H3

2007 ACCESSORIES & EQUIPMENT Displays and Gages - H3

Feature Programming

Refer to Personalization Description and Operation .

Driver Warnings

For the list of Driver Warnings, refer to Indicator/Warning Message Description and
Operation.

INDICATOR/WARNING MESSAGE DESCRIPTION AND OPERATION

Indicators

Symbol

Description

ABS: Refer to ABS Description and

Operation

Air Bag: Refer to SIR System Description

and Operation

2007 Hummer H3

2007 ACCESSORIES & EQUIPMENT Displays and Gages - H3

BRAKE (U.S.)

Charge: Refer to Charging System

Description and Operation

CRUISE: Refer to Cruise Control

Description and Operation
