WEATHERSTRIP REPLACEMENT - FRONT DOOR WINDOW

Removal Procedure

1. Open the door.

2. Lower window to the full down position.

3. Remove the door trim panel. Refer to Trim Panel Replacement - Side Front Door .



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Doors - Hummer H2



Fig. 123: Front Door Window Weatherstrip
Courtesy of GENERAL MOTORS CORP.

4. Starting at one side, remove the weatherstrip by pulling the weatherstrip off the flange in the door

window frame (1).

Installation Procedure



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Doors - Hummer H2



Fig. 124: Front Door Window Weatherstrip
Courtesy of GENERAL MOTORS CORP.

1. Install weatherstrip down onto the flange in the door frame (1), ensuring that it is fully seated.

2. Install the door trim panel. Refer to Trim Panel Replacement - Side Front Door .

3. Raise the window and inspect for proper fit.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Doors - Hummer H2



WEATHERSTRIP REPLACEMENT - REAR DOOR WINDOW

Removal Procedure

1. Position the window in the full down position.

Fig. 125: Rear Door Window Weatherstrip
Courtesy of GENERAL MOTORS CORP.
