Installation Procedure

Fig. 23: Inside Front Handle Bezel
Courtesy of GENERAL MOTORS CORP.

1. Install the bezel to the vehicle.

2. Install the bezel around the door handle.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Doors - Hummer H2



3. Install the screw that retains the handle bezel to the door panel.

HANDLE BEZEL REPLACEMENT - INSIDE - REAR

Removal Procedure

Fig. 24: Inside Rear Handle Bezel
Courtesy of GENERAL MOTORS CORP.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Doors - Hummer H2



1. Remove the screw that retains the rear inside handle bezel to the door panel.

2. Remove the bezel from around the door handle.

3. Remove the bezel from the vehicle.

Installation Procedure

Fig. 25: Inside Rear Handle Bezel



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Doors - Hummer H2



Courtesy of GENERAL MOTORS CORP.

1. Install the bezel to the vehicle.

2. Install the bezel around the door handle.

3. Install the screw that retains the handle bezel to the door panel.

TRIM PANEL REPLACEMENT - UPPER EXTENSION

Removal Procedure
