Hummer H2. Manual - part 2748

Fig. 38: Front Output Shaft Assembly
Courtesy of GENERAL MOTORS CORP.

46. Remove the front output shaft assembly.

2004 Hummer H2

2004 DRIVELINE/AXLE Transfer Case - Overhaul - BW 4482-NR4

Fig. 39: Removing Cup Plug
Courtesy of GENERAL MOTORS CORP.

47. If the cup plug in the front output shaft is leaking, remove the plug using a brass drift.

2004 Hummer H2

2004 DRIVELINE/AXLE Transfer Case - Overhaul - BW 4482-NR4

Fig. 40: Identifying Input Seal
Courtesy of GENERAL MOTORS CORP.

48. Using a hammer and a suitable punch, remove the input seal.

2004 Hummer H2

2004 DRIVELINE/AXLE Transfer Case - Overhaul - BW 4482-NR4

Fig. 41: Tapping Out Input Shaft Bearing With Brass Drift
Courtesy of GENERAL MOTORS CORP.

49. Using a hammer and a brass drift, remove the input shaft bearing from the front case half.

2004 Hummer H2

2004 DRIVELINE/AXLE Transfer Case - Overhaul - BW 4482-NR4
