Fig. 6: Inserting Screwdriver Behind Inner Race Of Seal 5. Remove the front output shaft seal by inserting a flat-tipped screwdriver behind the inner race of the seal. 6. Pry the inner seal race forward. NOTE: Refer to Transfer Case Seal Removal Notice in Cautions and Notices. IMPORTANT: The front output shaft seal is a two piece internal seal. The inner seal race is a force fit on the front output shaft.
2004 Hummer H2 2004 DRIVELINE/AXLE Transfer Case - Overhaul - BW 4482-NR4
|
