Fig. 5: Leak Inspection Points Callouts For Fig. 51 Callout Component Name 1 Wiring Harness Pass-Through Connector O-ring Seal 2 Transmission Vent Assembly 3 Converter Housing to Case Joint (Pump to Case Oil Seal) 4 Line Pressure Plug 5 Case Extension to Case Seal 6 Manual Shaft Seal 7 Case Extension Oil Seal Assembly 8 Torque Converter Assembly 9 Pump to Case Oil Seal 10 Pump Oil Seal Assembly 11 Internal Transmission Speed Sensor to Case O-ring Seal - Some Models
2004 Hummer H2 2004 TRANSMISSION Automatic Transaxle - 4L60-E/4L65-E (Troubleshooting)
|
