7 connector and the AT inline 20-way Refer to Testing for Continuity and extxref - Go to Step 12 Go to Step 11 8 Replace the automatic transmission wiring - Go to Step 12 - 9 Replace the TFT sensor. - Go to Step 12 - 10 1. Replace the automatic transmission wiring harness. 2. Replace the TFT sensor. Refer to Valve Body and Pressure Switch - Go to Step 12 - 11 Replace the PCM. - Go to Step 12 - 12 Perform the following procedure in order to 1. Select DTC. 2. Select Clear Info. 3. Operate the vehicle under the following conditions: z Turn ON the ignition, with the z The Trans. Fluid Temp. must be 4. Select Specific DTC. 5. Enter DTC P0713.
-
2004 Hummer H2 2004 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E Diagnosis (DTC P0218 To DTC P2771) - Hummer H2
|
