Fig. 52: Upper Steering Column
Courtesy of GENERAL MOTORS CORP.

Pull the tilt steering column lever (1) out from the steering column (2).

Installation Procedure



2004 Hummer H2

2004 STEERING Steering Wheel and Column - Hummer H2



Fig. 53: Upper Steering Column
Courtesy of GENERAL MOTORS CORP.

Align the tilt steering column lever (1) and push the lever into the steering column (2).

HORN SWITCH REPLACEMENT

Removal Procedure



2004 Hummer H2

2004 STEERING Steering Wheel and Column - Hummer H2



Fig. 54: View Of Horn Plunger At Steering Column
Courtesy of GENERAL MOTORS CORP.

1. Disable the SIR system. Refer to SIR Disabling and Enabling Zone 3 in SIR.

2. Remove the Inflatable Restraint Steering Wheel module. Refer to Inflatable Restraint Steering Wheel

Module Replacement in SIR.

3. Remove the horn plunger from the steering column by pressing inward to the stop and rotating horn

plunger 90 degrees.

CAUTION: Refer to Servicing the SIR System Caution in Cautions and Notices.



2004 Hummer H2

2004 STEERING Steering Wheel and Column - Hummer H2



Fig. 55: Horn Contact Plate & Steering Wheel
Courtesy of GENERAL MOTORS CORP.

4. Disconnect the horn contact plate (2) captured screws (1,4) from the steering wheel (3).

5. Remove the horn switch (2) from the steering wheel (3).

Installation Procedure



2004 Hummer H2

2004 STEERING Steering Wheel and Column - Hummer H2
