Fig. 35: Electrical Connector & Inside Air Temperature Sensor
Courtesy of GENERAL MOTORS CORP.

5. Disconnect the electrical connector from the inside air temperature sensor.



2004 Hummer H2

2004 HVAC HVAC Systems - Automatic - Hummer H2



Fig. 36: Inside Air Temperature Sensor & Headliner
Courtesy of GENERAL MOTORS CORP.

6. Remove the inside air temperature sensor from the headliner.

Installation Procedure



2004 Hummer H2

2004 HVAC HVAC Systems - Automatic - Hummer H2



Fig. 37: Inside Air Temperature Sensor & Headliner
Courtesy of GENERAL MOTORS CORP.

1. Install the inside air temperature sensor to the headliner.



2004 Hummer H2

2004 HVAC HVAC Systems - Automatic - Hummer H2



Fig. 38: Electrical Connector & Inside Air Temperature Sensor
Courtesy of GENERAL MOTORS CORP.

2. Connect the electrical connector to the inside air temperature sensor.

3. Install the left sunshade. Refer to Sunshade Replacement in Interior Trim.

4. Install the left windshield garnish molding. Refer to Garnish Molding Replacement - Windshield

Pillar in Interior Trim.

SUN LOAD SENSOR REPLACEMENT

Removal Procedure
