Hummer H2. Manual - part 1429

Ignition Coil #6 Terminal Identification

Ignition Coil #7 Terminal Identification

C

D-GN

2125

IC 5 Control

D

PK

1039

Ignition 1 Voltage

Connector Part Information

z

12162724

z

4-Way F Metri-Pack 150 Sealed (BK)

Pin

Wire Color

Circuit No.

Function

A

BK

550

Ground

B

BN

2130

Low Reference

C

L-BU

2126

IC 6 Control

D

PK

1239

Ignition 1 Voltage

Connector Part Information

z

12162724



2004 Hummer H2

2004 ENGINE PERFORMANCE Engine Controls (Introduction) - 4.8L, 5.3L, and 6.0L - Hummer H2



Ignition Coil #8 Terminal Identification

Intake Air Temperature (IAT)/Mass Air Flow (MAF) Sensor Terminal Identification

z

4-Way F Metri-Pack 150 Sealed (BK)

Pin

Wire Color

Circuit No.

Function

A

BK

550

Ground

B

BN

2129

Low Reference

C

RD

2127

IC 7 Control

D

PK

1039

Ignition 1 Voltage

Connector Part Information

z

12162724

z

4-Way F Metri-Pack 150 Sealed (BK)

Pin

Wire Color

Circuit No.

Function

A

BK

550

Ground

B

BN

2130

Low Reference

C

PU

2128

IC 8 Control

D

PK

1239

Ignition 1 Voltage



2004 Hummer H2

2004 ENGINE PERFORMANCE Engine Controls (Introduction) - 4.8L, 5.3L, and 6.0L - Hummer H2



Knock Sensor Terminal Identification - Front

Connector Part Information

z

15305555

z

5-Way F Metri-Pack 150 Series (BK)

Pin

Wire Color

Circuit No.

Function

A

BK

552

Low Reference

B

TN

472

IAT Sensor Signal

C

BK/WH

451

Ground

D

PK

439

Ignition 1 Voltage

E

YE

492

MAF Sensor Signal



2004 Hummer H2

2004 ENGINE PERFORMANCE Engine Controls (Introduction) - 4.8L, 5.3L, and 6.0L - Hummer H2



Knock Sensor Terminal Identification - Rear

Connector Part Information

z

12103023

z

1-Way TRW (M-GY)

Pin

Wire Color

Circuit No.

Function

A

D-BU

496

Knock Sensor 1 Signal



2004 Hummer H2

2004 ENGINE PERFORMANCE Engine Controls (Introduction) - 4.8L, 5.3L, and 6.0L - Hummer H2
