Evaporative Emission (EVAP) Canister Purge Solenoid Terminal Identification

Evaporative Emission (EVAP) Canister Vent Solenoid Terminal Identification

A

D-BU/WH

1869

CKP Sensor Signal

B

YE/BK

1868

Low Reference

C

L-GN

1867

12 Volt Reference

Connector Part Information

z

12124037

z

2-Way F Metri-Pack 150 Series Sealed (BK)

Pin

Wire Color

Circuit No.

Function

A

PK

439

Ignition 1 Voltage

B

D-GN/

WH

428

EVAP Canister Purge Solenoid Control

Connector Part Information

z

12052643



2004 Hummer H2

2004 ENGINE PERFORMANCE Engine Controls (Introduction) - 4.8L, 5.3L, and 6.0L - Hummer H2



Fuel Injector 1 Terminal Identification

Fuel Injector 2 Terminal Identification

z

2-Way F Metri-Pack 150 Series Sealed (RD)

Pin

Wire Color

Circuit No.

Function

A

WH

1310

EVAP Canister Vent Solenoid Control

B

OG

2640

Ignition 1 Voltage

Connector Part Information

z

15326181

z

2-Way F (GY)

Pin

Wire Color

Circuit No.

Function

A

PK

1039

Ignition 1 Voltage

B

BK

1744

Fuel Injector 1 Control



2004 Hummer H2

2004 ENGINE PERFORMANCE Engine Controls (Introduction) - 4.8L, 5.3L, and 6.0L - Hummer H2



Fuel Injector 3 Terminal Identification

Fuel Injector 4 Terminal Identification

Connector Part Information

z

15326181

z

2-Way F (GY)

Pin

Wire Color

Circuit No.

Function

A

PK

1239

Ignition 1 Voltage

B

L-GN/BK

1745

Fuel Injector 2 Control

Connector Part Information

z

15326181

z

2-Way F (GY)

Pin

Wire Color

Circuit No.

Function

A

PK

1039

Ignition 1 Voltage

B

PK/BK

1746

Fuel Injector 3 Control



2004 Hummer H2

2004 ENGINE PERFORMANCE Engine Controls (Introduction) - 4.8L, 5.3L, and 6.0L - Hummer H2



Fuel Injector 5 Terminal Identification

Connector Part Information

z

15326181

z

2-Way F (GY)

Pin

Wire Color

Circuit No.

Function

A

PK

1239

Ignition 1 Voltage

B

L-BU/BK

844

Fuel Injector 4 Control

Connector Part Information

z

15326181

z

2-Way F (GY)

Pin

Wire Color

Circuit No.

Function

A

PK

1039

Ignition 1 Voltage

B

BK/WH

845

Fuel Injector 5 Control



2004 Hummer H2

2004 ENGINE PERFORMANCE Engine Controls (Introduction) - 4.8L, 5.3L, and 6.0L - Hummer H2
