6. Remove the negative battery cable. Installation Procedure Fig. 11: Forward Lamp Wiring Harness Ground/Negative Cable Bolt 1. Install the negative battery cable. 2. Position the negative cable and forward lamp wiring harness ring terminals to the frame. Insert the anti-rotation tab on the forward lamp wiring harness into the hole in the frame. NOTE: Refer to Fastener Notice in Cautions and Notices.
2004 Hummer H2 2004 ELECTRICAL Engine Electrical - Hummer H2
|
