Charging Procedure When charging side-terminal batteries with the battery cables connected, connect the charger to the positive Tighten: Tighten the battery side terminal adapters to 15 N.m (11 lb ft). Use the following procedure to charge the battery: 1. Turn OFF the charger. 2. Ensure that all of the battery terminal connections are clean and tight. 3. Connect the charger positive lead to the battery positive terminal on the battery or the remote jumper stud underhood. 4. Connect the negative charger lead to a solid engine ground or to a ground stud in the engine compartment that is connected directly to the battery negative terminal, but away from the battery. If the negative 5. Turn ON the charger and set to the highest setting for normal charging. 6. Inspect the battery every half hour after starting the battery charger. z Charge the battery until the taper-rate charger indicates that the battery is fully charged. z Estimate the battery temperature by feeling the side of the battery. If it feels hot to the touch or its 7. After charging, test the battery. Refer to Battery Inspection/Test (Non-HP2) . BATTERY ELECTRICAL DRAIN/PARASITIC LOAD TEST (W/BCM) Tools Required z J 38758 Parasitic Draw Test Switch. See Special Tools and Equipment . z J 39200 Digital Multimeter Battery Electrical Drain NOTE: Turn OFF the ignition when connecting or disconnecting the battery cables, the NOTE: Refer to Fastener Notice in Cautions and Notices. NOTE: Do not connect the negative charger lead to the housings of other vehicle
2004 Hummer H2 2004 ELECTRICAL Engine Electrical - Hummer H2
|
