Remove glove box. Disconnect harness connector from passenger-side air bag connector. Connect Red short
connector to passenger-side air bag connector. See Fig. 2 . Passenger-side air bag is now disabled.

Fig. 2: Disabling Passenger-Side Air Bag (1997 Integra)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

Activating System (1997 Integra)

Ensure ignition switch is in OFF position and both battery cables are disconnected. Remove Red short
connector(s) installed during DISABLING SYSTEM. Install Red short connector(s) in holder(s). Reconnect
connectors as necessary. Install access panel to steering wheel (install glove box as necessary). Reconnect
battery cables. Ensure system is functioning properly. See SYSTEM OPERATION CHECK .

Disabling System (1997 2.2CL, 3.0CL, 3.5RL, 2.5TL & 3.2TL)

1. Obtain radio anti-theft code and write down preset radio frequencies. Ensure ignition is OFF. Disconnect

both battery cables and wait at least 3 MINUTES.

2. From bottom rear of steering wheel, remove access panel. Disconnect 2-pin driver-side air bag connector.

See Fig. 3 . Air bag connector is automatically shorted.



1997 Lexus SC 300

GENERAL INFORMATION Air Bag Deactivation Procedures



Fig. 3: Disabling Driver-Side Air Bag (1997 2.2CL, 3.0CL, 3.5RL, 2.5TL & 3.2TL)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Remove glove box. Disconnect 2-pin passenger-side air bag connector. See Fig. 4 and Fig. 5 . On 3.5RL,

remove left and right "B" pillar trim panels. Disconnect 2-pin seat belt pretensioner connectors. See Fig.
6 .



1997 Lexus SC 300

GENERAL INFORMATION Air Bag Deactivation Procedures



Fig. 4: Disabling Passenger-Side Air Bag (1997 2.2CL, 3.0CL & 3.5RL)
Courtesy of AMERICAN HONDA MOTOR CO., INC.



1997 Lexus SC 300

GENERAL INFORMATION Air Bag Deactivation Procedures



Fig. 5: Disabling Passenger-Side Air Bag (1997 2.5TL & 3.2TL)
Courtesy of AMERICAN HONDA MOTOR CO., INC.
