Hummer H1 (2006+). Manual - part 400

12-276

Electrical System

______________________________________________________

C112/ 10 WAY DRIVERS HEATED SEAT SWITCH CONNECTOR LOCATION: DRIVERS CONSOLE

C113/ 10 WAY PASSENGER HEATED SEAT SWITCH CONNECTOR LOCATION: PASSENGER CONSOLE

PIN

CKT

COLOR

DESCRIPTION

1

251

WH

High Out Put Signal

2B

250

PP

12 Volt Feed

3

252

OR

Low Out Put Signal

4

--

--

--

5B

--

--

--

6

--

--

--

7

17

PP

Illumination

8

17

PP

Illumination

8

17

PP

Illumination

9

598

BK

Ground For The Illumination Circuit (G4)

10

598

BK

Ground For The Illumination Circuit (G4)

10

598

BK

Ground For The Illumination Circuit (G4)

PIN

CKT

COLOR

DESCRIPTION

1

251

WH

High Out Put Signal

2B

250

PP

12 Volt Feed

3

252

OR

Low Out Put Signal

4

--

--

--

5B

--

--

--

6

--

--

--

7

17

PP

Illumination

8

17

PP

Illumination

8

17

PP

Illumination

9

598

BK

Ground For The Illumination Circuit (G4)

10

598

BK

Ground For The Illumination Circuit (G4)

10

598

BK

Ground For The Illumination Circuit (G4)

_____________________________________________________

 Electrical System  12-277

C114/ 10 WAY WINDOW LOCK OUT SWITCH CONNECTOR LOCATION: DRIVERS CONSOLE

C115/ 10 WAY FRONT E LOCKER SWITCH CONNECTOR LOCATION: DRIVERS CONSOLE

PIN

CKT

COLOR

DESCRIPTION

1

--

--

--

2B

171

RD

12 Volt Ignition Feed

3

170

PP

12 Volt Feed Out

4

--

--

--

5B

--

--

--

6

--

--

--

7

59

BK

Ground

7

59

BK

Ground

8

59

BK

Ground

8

59

BK

Ground

9

17

PP

Illumination

9

17

PP

Illumination

10

17

PP

Illumination

10

17

PP

Illumination

PIN

CKT

COLOR

DESCRIPTION

1

59

BK

Ground

1

59

BK

Ground

2B

875

PK

Out Put Signal

3

860

RD

12 Volt Ignition Feed

3

860

RD

12 Volt Ignition Feed

4

--

--

--

5B

--

--

--

12-278

Electrical System

______________________________________________________

C116/ 10 WAY REAR E LOCKER SWITCH CONNECTOR LOCATION: DRIVERS CONSOLE

6

--

--

--

7

877

GY/BK

Lock Indicator

8

59

BK

Ground

8

59

BK

Ground

9

860

RD

12 Volt Ignition Feed

10

17

PP

Illumination

10

17

PP

Illumination

8

59

BK

Ground

PIN

CKT

COLOR

DESCRIPTION

1

59

BK

Ground

1

59

BK

Ground

2B

866

OR

Out Put Signal

3

860

RD

12 Volt Ignition Feed

3

860

RD

12 Volt Ignition Feed

4

--

--

--

5B

--

--

--

6

--

--

--

7

868

GY

Lock Indicator

8

59

BK

Ground

8

59

BK

Ground

9

860

RD

12 Volt Ignition Feed

10

17

PP

Illumination

10

17

PP

Illumination

PIN

CKT

COLOR

DESCRIPTION

_____________________________________________________

 Electrical System  12-279

C117/ 10 WAY LEFT FRONT WINDOW SWITCH CONNECTOR LOCATION: DRIVERS CONSOLE

PIN

CKT

COLOR

DESCRIPTION

1

56

BK

Ground

2B

222

PP

Power Up

3

171

RD

12 Volt Ignition

3

171

RD

12 Volt Ignition

4

171

RD

12 Volt Ignition

4

171

RD

12 Volt Ignition

5B

226

YL

Power Down

6

56

BK

Ground

6

56

BK

Ground

7

59

BK

Ground

7

59

BK

Ground

8

59

BK

Ground

8

59

BK

Ground

9

17

PP

Illumination

9

17

PP

Illumination

10

17

PP

Illumination

10

17

PP

Illumination
