12-216

Electrical System

______________________________________________________

C9-B/ 2 WAY PASSENGER HEATED SEAT CONNECTOR LOCATION: UNDER THE CENTER
CONSOLE

C10-A/ 4 WAY DRIVERS HEATED SEAT CONNECTOR LOCATION: UNDER THE CENTER
CONSOLE

C10-B/ 4 WAY PASSENGER HEATED SEAT CONNECTOR LOCATION: UNDER THE CENTER CON-
SOLE

PIN

CKT

COLOR

DESCRIPTION

A

59

BK

Ground G4

B

241

RD

+12v ignition voltage

PIN

CKT

COLOR

DESCRIPTION

A

254

WH

Low temp request to module

B

255

OR

High temp request to module

C

--

--

--

D

253

PP

Output +12v to switch input

PIN

CKT

COLOR

DESCRIPTION

A

251

WH

Low temp request to module

B

252

OR

High temp request to module

C

--

--

--

D

250

PP

Output +12v to switch input

A

D

_____________________________________________________

 Electrical System  12-217

C11/ 13 WAY ABS MODULATOR  LOCATION: BELOW BRAKE MASTER CYLINDER

C12/10 WAY CTIS  LOCATION INSTRUMENT PANEL, RIGHT

PIN

CKT

COLOR

DESCRIPTION

1

970

TN

Left front outlet valve activation

2

971

PP

Left front inlet valve activation

3

--

--

--

4

977

WH

Right rear inlet valve activation

5

976

RD

Right rear outlet valve activation

6

978

BK

Reference ground

7

--

--

--

8

--

--

--

9

677

GY

Shuttle valve switch signal

10

972

YL

Right front outlet valve activation

11

973

OR

Right front inlet valve activation

12

975

LB

Left rear inlet valve activation

13

974

DB

Left rear outlet valve activation

PIN

CKT

COLOR

DESCRIPTION

A

915

LB

+10 volt supply to the CTIS module

B

17

PP

Gauge illumination voltage

C

59

BK

Ground G4

D

47

LG

Deflate solenoid activation

CAV 1

CAV 6

CAV 10

CAV 5

CAV 9

CAV 13

  MALE

A

S

A

S

    FEMALE

12-218

Electrical System

______________________________________________________

C13/ 8 WAY COMPASS MIRROR  LOCATION: WINDSHIELD CENTER PILLAR TRIM

C14/ 4 WAY SHIFTER CONNECTOR

E

91

TN

Front inflate/deflate solenoid activation

F

92

GY

Rear inflate/deflate solenoid activation

G

46

WH

Compressor Relay activation

H

640

OR

Fused battery voltage

J

428

PK

Low air warning light signal

K

912

DB

“Bulb Check” input from the coolant/fuel module

L

83

TN

+12v ignition to heated windshield switch

M

59

BK

Ground G4

N

580

BR

Fused battery input to the heated mirror.

P

405

OR

Rear blower high

R

346

PK

Rear blower switch input (+12v)

S

404

YL

Rear blower low

PIN

CKT

COLOR

DESCRIPTION

A

59

768

BK
BK

Ground (G4)

B

407

PK

Compass Cutout Circuit

C

841

RD

Not Used

D

767

BR

Temperature signal from sensor

E

768

BK

Ground (G4)

F

400

LG

Ignition feed

G

140

OR

Reverse Inhibit

H

53

DB

Not Used

PIN

CKT

COLOR

DESCRIPTION

A

520

WH

12 Volt Input From Brak Switch

B

32

LB

Ground

C

17

PP

Illumination

D

1072

BK

Ground

PIN

CKT

COLOR

DESCRIPTION

   MALE

    FEMALE

A

D

E

H

A

H

D

E

_____________________________________________________

 Electrical System  12-219

C15/4 WAY LF DOOR LEFT FRONT OUTSIDE KICK PANEL

C16/3 WAY LF DOOR JAM SWITCH CONNECTOR

C17/ 4 WAY RF DOOR  RIGHT FRONT OUTSIDE KICK PANEL

PIN

CKT

COLOR

DESCRIPTION

A

117

PK

Unlock signal to the drivers door lock actuators

B

118

BR

Lock signal to the drivers door lock actuators

C

222

PP

Drivers front door power window signal

D

228

WH

Drivers front door power window signal

PIN

CKT

COLOR

DESCRIPTION

A

53

DB

To Dome Lamp

B

159

WH

To Chime Module

C

54

DG

12 Volt Power

PIN

CKT

COLOR

DESCRIPTION

A

117

PK

Unlock signal to the passenger front door lock actuator

B

118

BR

Lock signal to the passenger front door lock actuator

C

226

YL

Passenger front power window signal

D

227

RD

Passenger front power window signal

   MALE

      FEMALE

A

D

A

D

A

D

A

D

     MALE

     FEMALE
