Hummer H1 (2002+). Manual - part 4







_______________



 General Information, Lubrication and Maintenance  1-13



¨



05745159



BOLT IDENTIFICATION AND TORQUE LIMITS (DRY*)



* A phosphate and oil bolt is
   considered dry



Bolt Head ID Marks and SAE GRADE


BOLT
SIZE

SAE GRADE
 NO. 1 OR 2

SAE GRADE
 NO. 5

SAE GRADE
 NO. 6 OR 7

SAE GRADE
 NO. 8

DIA.
INCHES

MILLI-
METERS

THREADS
 PER INCH

 POUND FEET
(NEWTON-
METERS)

 POUND FEET
(NEWTON-
METERS)

 POUND FEET
(NEWTON-
METERS)

 POUND FEET
(NEWTON-
METERS)

1/4

6

20

5(7)

8(11)

10(14)

12(16)

1/4

6

28

6(8)

10(14)

ÑÑ

14(19)

5/16

8

18

11(15)

17(23)

19(26)

24(33)

5/16

8

24

13(18)

19(26)

ÑÑ

27(37)

3/8

10

16

18(24)

31(42)

34(46)

44(60)

3/8

10

24

20(27)

35(47)

ÑÑ

49(66)

7/16

11

14

28(38)

49(66)

55(75)

70(95)

7/16

11

20

30(41)

55(75)

ÑÑ

78(106)

1/2

13

13

39(53)

75(102)

85(115)

105(142)

1/2

13

20

41(56)

85(115)

ÑÑ

120(163)

9/16

14

12

51(69)

110(149)

120(163)

155(210)

9/16

14

18

55(75)

120(163)

ÑÑ

170(231)

5/8

16

11

63(85)

150(203)

167(226)

210(285)

5/8

16

18

95(129)

170(231)

ÑÑ

240(325)

3/4

19

10

105(142)

270(366)

280(380)

375(509)

3/4

19

16

115(156)

295(400)

ÑÑ

420(570)

7/8

22

9

160(217)

395(536)

440(597)

605(820)

7/8

22

14

175(237)

435(590)

ÑÑ

675(915)

1

25

8

235(319)

590(800)

660(895)

910(1234)

1

25

14

250(339)

660(895)

ÑÑ

990(1342)

1-1/8

29

Ñ

ÑÑ

800 - 880
(1085 - 1193)

ÑÑ

1280 - 1440
(1736 - 1953)

1-1/4

32

Ñ

ÑÑ

Ñ

ÑÑ

1820 - 2000
(2468 - 2712)

1-3/8

35

Ñ

ÑÑ

1460 - 1680
(1980 - 2278)

ÑÑ

2380 - 2720
(3227 - 3688)

1-1/2

38

Ñ

ÑÑ

1940 - 2200
(2631 - 2983)

ÑÑ

3160 - 3560
(4285 - 4827)

1-14

General Information, Lubrication and Maintenance

________________

¨

BOLT IDENTIFICATION AND TORQUE LIMITS (WET*)

*A cadmium plated bolt is  considered wet.

Bolt Head ID Marks and SAE Grade

BOLT
SIZE

SAE GRADE
NO. 1 OR 2

SAE GRADE
NO. 5

SAE GRADE
NO. 6 OR 7

SAE GRADE
NO. 8

DIA.
INCHES

 MILLI-
METERS

THREADS
 PER INCH

POUND FEET
(NEWTON-
METERS)

POUND FEET
(NEWTON-
METERS)

POUND FEET
(NEWTON-
METERS)

POUND FEET
(NEWTON-
METERS)

1/4

6

20

4(5)

7(10)

9(12)

11(15)

1/4

6

28

5(7) 9(12)

ÑÑ 13(17)

5/16

8

18

10(14)

15(20)

17(23)

22(30)

5/16

8

24

12(16)

17(23)

ÑÑ 24(33)

3/8

10

16

16(22)

28(38)

31(42)

40(54)

3/8

10

24

18(24)

32(43)

ÑÑ 44(60)

7/16

11

14

25(34)

44(60)

50(68)

63(85)

7/16

11

20

27(37)

50(68)

ÑÑ 70(95)

1/2

13

13

35(48)

68(92)

77(104)

95(129)

1/2

13

20

37(50)

77(104)

ÑÑ 108(146)

9/16

14

12

46(62)

99(134)

108(146)

140(190)

9/16

14

18

50(67)

108(146)

ÑÑ 153(207)

5/8

16

11

57(77)

135(183)

150(203)

189(256)

5/8

16

18

85(115)

153(207)

ÑÑ 216(293)

3/4

19

10

95(129)

243(330)

252(342)

338(458)

3/4

19

16

104(141)

266(361)

ÑÑ 378(513)

7/8

22

9

144(195)

356(483)

396(537)

545(739)

7/8

22

14

158(214)

392(532)

ÑÑ

608(824)

1

25

8

212(287)

531(720)

594(805)

819(1111)

1

25

14

225(305) 594(805)

ÑÑ

891(1208)

1-1/8

29

Ñ

ÑÑ

720 - 792
(976 - 1074)

ÑÑ

1152 - 1296
(1562 - 1757)

1-1/4

32

Ñ

ÑÑ

ÑÑ

ÑÑ

1638 - 1800
(2221 - 2441)

1-3/8

35

Ñ

ÑÑ

1314 - 1512
(1782 - 2050)

ÑÑ ÑÑ

1-1/2

39

Ñ

ÑÑ

1746 - 1980
(2368 - 2685)

ÑÑ

2844 - 3204
(3857 - 4345)

_______________

 General Information, Lubrication and Maintenance  1-15

¨

05745159

U.S./METRIC CONVERSIONS AND EQUIVALENTS

Metric Conversions

MULTIPLY

BY

 TO GET

INCHES

2.54

CENTIMETERS

FEET

0.305

METERS

MILES

1.609

KILOMETERS

SQUARE INCHES

6.451

SQUARE CENTIMETERS

CUBIC INCHES

16.39

CUBIC CENTIMETERS

FLUID OUNCES

29.573

MILLILITERS

PINTS

0.473

LITERS

QUARTS

0.946

LITERS

GALLON

3.785

LITERS

POUNDS

0.454

KILOGRAMS

SHORT TONS

0.907

METRIC TONS

POUND-INCHES

0.113

NEWTON-METERS

POUND-FEET

1.356

NEWTON-METERS

POUNDS PER SQUARE INCH

6.895

KILOPASCALS

MILES PER GALLON

0.425

KILOMETERS PER LITER

MILES PER HOUR

1.609

KILOMETERS PER HOUR

U.S. Standard Conversions

MULTIPLY

BY

TO GET

CENTIMETERS/MILLIMETERS

0.3937

INCHES

METERS

3.280

FEET

KILOMETERS

0.621

MILES

SQUARE CENTIMETERS

0.155

SQUARE INCHES

CUBIC CENTIMETERS

0.061

CUBIC INCHES

MILLILITERS

0.034

FLUID OUNCES

LITERS

2.113

PINTS

LITERS

1.057

QUARTS

LITERS

0.264

GALLONS

KILOGRAMS

2.205

POUNDS

METRIC TONS

1.102

SHORT TONS

NEWTON-METERS

0.738

POUND-FEET

NEWTON-METERS

8.851

POUND-INCHES

KILOPASCALS

0.145

POUNDS PER SQUARE INCH

KILOMETERS PER LITER

2.354MILES PER GALLON

KILOMETERS PER HOUR

0.621MILES PER HOUR

Temperature

32¡ FAHRENHEIT = 0¡ CELSIUS

212¡ FAHRENHEIT = 100¡ CELSIUS

CELSIUS = 0.556 X (F¡ -32)

FAHRENHEIT = (1.8 X C¡) +32

1-16

General Information, Lubrication and Maintenance

________________

¨

PAINT AND TRIM COLORS

Interior trim colors are tan and gray. Seating materials are
available in cloth and vinyl.

Soft top colors and codes are: Tan (T) and Black (B).

Exterior paint colors and codes are outlined in the following
chart.

REPLACEMENT KEYS

Replacement keys can be cut using Briggs and Stratton or Cur-
tis key cutting tools. Key codes are provided on an identific-
aion tag included with each key set (Figure 1-10).

Figure 1-10:   Key Code Location

Top Coat Description

AM General Code

Candy Apple Red

R19

White Gloss

W8

Black Gloss

B9

Competition Yellow

Y20

Burgundy Metallic

P17

Bright White

W14

Silver Metallic

S15

Mesa Dusk Carmel

C22

Metallic Pewter

P33

Woodland Green

G23
