Honda CR-V (2024 year). Manual in english - page 3

NORMAL

Mode

Indicator

•

Comes on when you set the drive mode to

NORMAL

SNOW

Mode

Indicator

•

Comes on when you set the drive mode to

SNOW

Hill Descent Control System

Hill Descent
Control System
Indicator (White/
Green)

•

Lights up in white when the hill descent
control system is on and ready to use.

•

Lights up in green when the hill descent
control system is in operation.

P. 449

System Message
Indicator

•

Comes on along with a beep when a
problem is detected. A system message on
the driver information interface appears at
the same time.

•

While the indicator is on, press the

(home)

button, and select

Warnings

to see the message

again.

Switching the Display

P. 113

•

Refer to the Indicators information in this chapter
when a system message appears on the driver
information interface. Take the appropriate action
for the message.

•

The driver information interface will not return to
the normal screen unless the warning is canceled,
or the

(home) button is pressed.

103

Indicators

Continued

strum

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Auto Idle Stop

OFF

Indicator

●

Comes on when the Auto Idle Stop system
has been turned off by the Auto Idle Stop

OFF

button.

Auto Idle Stop System ON/OFF

P. 441

Auto Idle Stop
System Indicator
(Amber)

●

Blinks if there is a problem with the Auto
Idle Stop system.

●

Blinks

- Have your vehicle checked by a dealer.

Auto Idle Stop
Indicator (Green)

●

Comes on when Auto Idle Stop is in
operation. The engine automatically shuts
off.

P. 440

104

Indicators

strum

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Auto Idle Stop
Suspend Indicator

●

Comes on while Auto Idle Stop is
temporarily suspended in the following
situations.

—

Brake pedal is not fully pressed

●

Depress the brake pedal firmly.

The transmission is in a position other than

(

P. 440

System charging is prioritized

Climate control system is prioritized

Engine coolant temperature is not in
operating range

SNOW

mode is selected.

P. 440

The battery temperature is too low.

Adaptive Cruise Control (ACC) with Low
Speed Follow

P. 440

Auto Idle Stop does not activate for some
reason.

—

●

If you press and hold the Auto Idle Stop

OFF

button, you can select whether to display the status
messages or not.

105

Indicators

Continued

strum

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Adaptive Cruise
Control (ACC)
with Low Speed
Follow Indicator
(Amber)

●

Comes on if there is a problem with ACC
with Low Speed Follow.

●

Comes on while driving

- Have your vehicle

checked by a dealer.

●

Indicator may come on temporarily when the
Maximum Load Limit is exceeded.

●

ACC with Low Speed Follow has been
automatically canceled.

●

Make sure the total load is within the Maximum
Load Limit.

Maximum Load Limit

P. 419

●

Stays on constantly

- Have your vehicle checked

by a dealer.

●

Comes on if the ACC with Low Speed Follow
is deactivated temporarily after the battery
has been disconnected, then re-connected.

●

Drive a short distance at more than 12 mph (20
km/h). The indicator should go off. If it does not,
have your vehicle checked by a dealer.

Adaptive Cruise
Control (ACC)
with Low Speed
Follow Indicator
(White/Green)

●

Lights up in white when you press the

button.

●

Lights up in green when you press the

RES/+/SET/−

switch up or down.

P. 495

Cruise Mode
Indicator (White/
Green)

●

Lights up in white when you change to
cruise mode.

●

Lights up in green when you have set a
speed for cruise control.

To Switch ACC with Low Speed Follow to
Cruise Control

P. 512

106

Indicators

strum

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Lane Keeping
Assist System
(LKAS) Indicator
(Amber)

●

Comes on if there is a problem with the
LKAS.

●

Stays on constantly

- Have your vehicle checked

by a dealer.

●

Indicator may come on temporarily when the
Maximum Load Limit is exceeded.

●

Make sure the total load is within the Maximum
Load Limit.

Maximum Load Limit

P. 419

●

Stays on constantly

- Have your vehicle checked

by a dealer.

Lane Keeping
Assist System
(LKAS) Indicator
(White/Green)

●

Lights up in white when you press the LKAS
button.

●

Lights up in green when the LKAS is in
operation.

Lane Keeping Assist System (LKAS)

P. 515

107

Indicators

Continued

strum

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Safety Support
Indicator (Amber)

●

Comes on if there is a problem with the
Road Departure Mitigation system, CMBS

Low Speed Braking Control

, or blind spot

information system

●

Stays on constantly

- Have your vehicle checked

by a dealer.

●

Comes on if there is a problem with the
parking sensor.

●

Check if the area around the sensor(s) is covered
with mud, ice, snow, etc. If the indicator stays on
even after you clean the area, have the system
checked by a dealer.

●

Indicator may come on temporarily when the
Maximum Load Limit is exceeded.

●

Make sure the total load is within the Maximum
Load Limit.

Maximum Load Limit

P. 419

●

Stays on constantly

- Have your vehicle checked

by a dealer.

●

Comes on if the Road Departure Mitigation
system, CMBS

and Low Speed Braking

Control

are deactivated temporarily after

the battery has been disconnected and then
re-connected.

●

Drive a short distance at more than 12 mph (20
km/h). The indicator should go off. If it does not,
have your vehicle checked by a dealer.

Models with Parking Sensor System

* Not available on all models

108

Indicators

strum

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Safety Support
Indicator (Amber)

●

Comes on when the Road Departure
Mitigation system and/or CMBS

shuts itself

off.

●

Indicator may come on temporarily if the radar sensor
cannot detect any objects when passing through an
enclosed space such as a tunnel, or driving on an open
road without any structures nearby.

●

The area around the radar sensor is blocked by dirt,
mud, etc. Stop your vehicle in a safe place and wipe
the debris off with a soft cloth. Indicator may take
some time to go off after the radar sensor is cleaned.

●

Have your vehicle checked by a dealer if the
indicator does not go off even after you have
cleaned the radar sensor.

Radar Sensor

P. 544

●

Stays on

- The temperature inside the camera is

too high.
Use the climate control system to cool down the
camera.
The system activates when the temperature inside
the camera cools down.

Front Sensor Camera

P. 542

●

Stays on

- The area around the camera is blocked

by dirt, mud, etc. Stop your vehicle in a safe place
and wipe the debris off with a soft cloth.

●

Have your vehicle checked by a dealer if the
indicator and message are still displayed even after
you have cleaned the area around the camera.

Front Sensor Camera

P. 542

●

It may come on when the ambient conditions are
dark, such as when driving in a tunnel, or at night,
dawn, or dusk.

109

Indicators

strum

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Safety Support
Indicator (Amber)

●

Comes on when mud, snow, or ice
accumulates in the vicinity of the sonar
sensor.

●

Remove the obstacle in the vicinity of the sonar
sensor.

Low Speed Braking Control

P. 481

●

Comes on when mud, snow, or ice
accumulates in the vicinity of the blind spot
information system sensor.

●

Comes on when the temperature of the
blind spot information system sensor is high.

●

Comes on while driving

- Something may be

interfering with the blind spot information system
sensor. Check the vicinity of the blind spot
information system sensor and remove any
obstacles.

●

The system will return to normal when the
temperature cools down.

Blind Spot Information System

P. 462

Safety Support
Indicator (Green/
Gray)

●

Lights up in green when the Road Departure
Mitigation system, CMBS

, Low Speed

Braking Control

, Parking Sensor System

and blind spot information system

are on.

●

Lights up in green and gray when the Road
Departure Mitigation system, CMBS

, Low

Speed Braking Control

, Parking Sensor

System

, or blind spot information system

or any two, three or four of these systems
are off.

●

Lights up in gray when the Road Departure
Mitigation system, CMBS

, Low Speed

Braking Control

, Parking Sensor System

and blind spot information system

are off.

Road Departure Mitigation System

P. 487

Collision Mitigation Braking System

(CMBS

)

P. 469

Blind Spot Information System

P. 462

Low Speed Braking Control

P. 481

Parking Sensor System

P. 558

Models with Low Speed Braking Control

Models with blind spot information system

* Not available on all models

110

strum

nt Pa

nel

Gauges and Driver Information Interface

Gauges

Gauges include the speedometer, fuel gauge, and other related indicators.
They are displayed when the power mode is in ON.

Displays your driving speed in mph or km/h.

Shows the number of engine revolutions per minute.

Displays the amount of fuel left in the fuel tank.

■

Speedometer

■

Tachometer

■

Fuel Gauge

Speedometer

You can change the Speed/Distance units.

No Content

P. 126

P. 129

P. 359

Tachometer

You can turn the tachometer display on or off.

P. 129

Traffic Sign Recognition System

P. 359

Fuel Gauge

NOTICE

You should refuel when the reading approaches

Running out of fuel can cause the engine to misfire,
damaging the catalytic converter.

The actual amount of remaining fuel may differ from
the fuel gauge reading.

* Not available on all models

Continued

111

Gauges and Driver Information Interface

Gauges

strum

nt Pa

nel

Shows the total number of miles or kilometers that your vehicle has accumulated.

Shows the outside temperature in Fahrenheit (U.S.) or Celsius (Canada).

■

Adjusting the outside temperature display

Adjust the temperature reading by up to ±5°F or ±3°C if the temperature reading
seems incorrect.

Shows certain detected traffic signs while driving.
The indicator blinks when the maximum speed of the traffic sign detected by the
Traffic Sign Recognition System is exceeded.

P. 536

■

Odometer

■

Outside Temperature

■

Traffic Sign Recognition System

Outside Temperature

The temperature sensor is in the front bumper.
Road heat and exhaust from another vehicle can
affect the temperature reading when your vehicle
speed is less than 19 mph (30 km/h).

It may take several minutes for the display to be
updated after the temperature reading has stabilized.

You can adjust the temperature reading.

P. 129

Adaptive Cruise Control (ACC) with Low Speed Follow

P. 359

* Not available on all models

Gauges and Driver Information Interface

Gauges

112

strum

nt Pa

nel

Shows the current mode for ACC with Low Speed Follow, LKAS, and Traffic Jam
Assist.

P. 495

Lane Keeping Assist System (LKAS)

P. 515

Traffic Jam Assist

P. 527

Shows the clock.

■

Current Mode for ACC with Low Speed Follow, the LKAS, and
Traffic Jam Assist

■

Clock

Clock

You can adjust the time manually and change the
clock display to show the 12 hour clock or 24 hour
clock.

Clock

P. 140

113

Gauges and Driver Information Interface

Driver Information Interface

Continued

strum

nt Pa

nel

Driver Information Interface

The driver information interface shows information such as the estimated travelable
distance and fuel economy of the vehicle. It also displays messages such as warnings
and other helpful information.
When a warning message displays, please check the message and contact a dealer
and have the vehicle inspected if necessary. Please refer to the pages below if the

Engine oil pressure low

Engine temperature too hot

message is displayed.

If the Engine oil pressure low Warning Appears

P. 647

Overheating

P. 645

Press the

(home) button, then roll the left selector wheel to scroll to the content

you want to see. Press the left selector wheel to see detailed information.

■

Switching the Display

Switching the Display

You can add or delete the meter contents.

Gauge Display Settings

P. 128

114

Gauges and Driver Information Interface

Driver Information Interface

strum

nt Pa

nel

Gauge display
settings

P. 128

Left Selector
Wheel

(Home) Button

Roll the left
selector wheel.

No content

P. 126

Speed & time

P. 117

Warnings

P. 128

Range & fuel

P. 115

Settings

P. 129

Driver
attention

P. 120

Seat belts

P. 124

Safety
support

P. 124

Maintenance

P. 124

Phone

P. 118

Audio

P. 118

Navigation

P. 119

AWD torque
distribution

P. 123

Brightness

P. 127

* Not available on all models

Gauges and Driver Information Interface

Driver Information Interface

116

strum

nt Pa

nel

■

Trip meter

Shows the total number of miles or kilometers driven since the last reset. Meters A
and B can be used to measure two separate trips.

Resetting a trip meter

To reset the trip meter, display it, press the left selector wheel and then select

Reset

The trip meter is reset to 0.0.

■

Average Fuel Economy

Shows the estimated average fuel economy of each trip meter in mpg or l/100 km.
The display is updated at set intervals. When a trip meter is reset, the average fuel
economy is also reset.

■

Instant Fuel Economy

Shows the instant fuel economy as a bar graph in mpg or l/100 km.

■

Range

Shows the estimated distance you can travel on the remaining fuel. This estimated
distance is based on the vehicle’s current fuel economy.

Average Fuel Economy

You can change when to reset the average fuel
economy.

P. 129

Audio System Basic Operation

P. 359

Range

The driving range displayed is only an estimate and
may differ to the actual distance the vehicle can
travel.

* Not available on all models

Gauges and Driver Information Interface

Driver Information Interface

118

strum

nt Pa

nel

■

Trip meter

P. 116

■

Elapsed time

Shows the time elapsed since Trip A or Trip B was reset.

■

Average speed

Shows the average speed in mph or km/h since Trip A or Trip B was reset.

Shows the current audio information.

P. 237

Shows the current phone information.

Bluetooth

HandsFreeLink

P. 376

■

Audio

■

Phone

Elapsed time

You can change when to reset the elapsed time.

P. 129

P. 359

Average speed

You can change when to reset the average speed.

P. 129

P. 359

* Not available on all models

Continued

119

Gauges and Driver Information Interface

Driver Information Interface

strum

nt Pa

nel

■

Compass

Shows the compass screen.

■

Turn-by-Turn Directions

When driving guidance is provided by the Android Auto or Apple CarPlay, turn-by-
turn directions to your destination appear.

Android Auto

P. 258

Apple CarPlay

P. 254

■

Navigation

Navigation

You can select whether to have the turn-by-turn
display come on or not during the route guidance.

Switching the Display

P. 359

Turn-by-turn directions may not be available for all
apps.

* Not available on all models

Gauges and Driver Information Interface

Driver Information Interface

120

strum

nt Pa

nel

The Driver Attention Monitor analyzes steering inputs to determine if the vehicle is
being driven in a manner consistent with drowsy or inattentive driving. If it
determines that the vehicle is being driven in such a manner, it will display the
degree of the driver’s attention on the driver information interface.

When you select

Driver attention

on the

driver information interface, bars on it light up
in white to indicate the degree of the driver’s
attention.

P. 113

■

Driver Attention Monitor

Driver Attention Monitor

The Driver Attention Monitor cannot always detect if
the driver is tired or inattentive.
Regardless of the system’s feedback, if you are
feeling tired, stop in a safe location and rest for as
long as needed.

Driver Information
Interface

Left Selector
Wheel

(Home) Button

Level

121

Gauges and Driver Information Interface

Driver Information Interface

Continued

strum

nt Pa

nel

If two bars light up, the

Driver attention

level low

message will appear.

If one bar lights up, the

Driver attention

level low. Time for a break.

message will

appear, a beep will sound, and the steering
wheel will vibrate.
If this message appears, stop in a safe location
and rest for as long as needed.
The message will disappear when the left
selector wheel is pressed or when the system
has determined that the driver is driving
normally.
If the driver does not take a break and the
monitor continues to detect that the driver is
very tired, the message will appear again after
approximately 15 minutes, accompanied by a
beep and steering wheel vibrations.
The message does not appear when the
traveling time is 30 minutes or less.

Gauges and Driver Information Interface

Driver Information Interface

122

strum

nt Pa

nel

■

The Driver Attention Monitor resets when:

•

The engine is turned off.

•

The driver unfastens the seat belt and opens the door while the vehicle is stopped.

■

For the Driver Attention Monitor to function:

•

The vehicle must be traveling above 25 mph (40 km/h).

•

The electric power steering (EPS) system indicator must be off.

■

Depending on driving conditions or other factors, the Driver Attention
Monitor may not function in the following circumstances:

•

The steering assist function of the Lane Keeping Assist System (LKAS) is active.

Lane Keeping Assist System (LKAS)

P. 515

•

The condition of the road is poor, e.g., the surface is unpaved or bumpy.

•

It is windy.

•

The driver is frequently operating the vehicle in an assertive manner such as
changing lanes or accelerating.

■

Customizing

You can change the Driver Attention Monitor settings. Select

Tactile and audible

alert

Tactile And Audible Alert

Tactile alert

Tactile Alert

, or

OFF

P. 129

For the Driver Attention Monitor to function:

P. 359

*1 : Models with 7-in. Color Touchscreen
*2 : Models with 9-in. Color Touchscreen

The bars on the driver information interface remain
grayed out unless the Driver Attention Monitor is
functioning.

* Not available on all models

123

Gauges and Driver Information Interface

Driver Information Interface

Continued

strum

nt Pa

nel

The indicators on the display show the
amount of torque being transferred to the
right front, left front, right rear, and left rear
wheels.

Real Time AWD with Intelligent Control
System

P. 454

■

AWD Torque Distribution Monitor

* Not available on all models

Gauges and Driver Information Interface

Driver Information Interface

124

strum

nt Pa

nel

Occurs, under specified conditions, when seat belts are latched or unlatched.

Seat Belt Reminder

P. 45

Shows the remaining oil life and Maintenance Minder

Maintenance Minder

P. 579

Indicates the status of the Road Departure Mitigation system, CMBS

, Low Speed

Braking Control

, blind spot information system

, and Parking Sensor System

, such

as On, Off, or Failure, by color and letters.

The following colors indicate the status of any of the above mentioned systems:

•

Green: The system is on.

•

Gray: The system is off.

•

Amber: There is a problem with the system.

■

Seat Belts

■

Maintenance

■

Safety Support

Safety Support

If a system is indicated by the color amber, have your
vehicle checked by a dealer immediately.

To turn on or off each system, first rotate the left
selector wheel to switch displays. From the next
display you can select which system to turn on or off.

Road Departure Mitigation System

P. 487

Collision Mitigation Braking System

(CMBS

)

P. 469

Blind Spot Information System

P. 462

Low Speed Braking Control

P. 481

Parking Sensor System

P. 558

You can also confirm the status of each function by
the color of the safety support indicator.

Safety Support Indicator (Amber)

P. 107

Safety Support Indicator (Green/Gray)

P. 109

* Not available on all models

Continued

125

Gauges and Driver Information Interface

Driver Information Interface

strum

nt Pa

nel

Area Info
for CMBS

Area Info
for Road
Departure
Mitigation
System

Area Info
for Blind
Spot
Information
System

Area Info
for Parking
Sensor
System

Road
Departure
Mitigation
System Icon
and Status
Info

Area Info for Low
Speed Braking
Control

Blind Spot
Information
System Icon
and Status
Info

Parking
Sensor
System
Icon and
Status Info

CMBS

Icon and
Status
Info

Low
Speed
Braking
Control
Icon and
Status
Info

Models with Blind Spot
Information System

Models with Low Speed
Braking Control

Models with Parking
Sensor System

Safety Support

Even when the Low Speed Braking Control icon is
green, if the

Rear Sensor Setting

is turned off, the

brake assist will not operate when reversing.

P. 359

Even when the Parking Sensor System icon is green,
if the

Rear Sensor Setting

is turned off, the rear

parking sensor will not operate when reversing.

P. 359

Models with Low Speed Braking Control

Models with Parking Sensor System

Gauges and Driver Information Interface

Driver Information Interface

126

strum

nt Pa

nel

Tachometer

P. 110

■

Speed/Distance Units

Enables you to show another unit on the driver information interface and audio/
information screen and set the displayed measurements to read in either miles and
mph or km and km/h.

Press and hold the left selector wheel when you select

No content

on the driver

information interface. Each time you do this, the unit will change from miles and
mph to km and km/h or vice versa. After this, a confirmation screen will appear for
a few seconds.

■

No Content

No Content

The tachometer can be turned on and off using the
driver information interface or audio/information
screen.

P. 129
