Honda Accord (2022 year). Manual in english

Gauges and Displays

Driver Information Interface

156

strum

nt Pa

nel

■

The Driver Attention Monitor resets when:

•

The engine is turned off.

•

The driver unfastens the seat belt and opens the door while the vehicle is stopped.

■

For the Driver Attention Monitor to function:

•

The vehicle must be traveling above 25 mph (40 km/h).

•

The electric power steering (EPS) system indicator must be off.

■

Depending on driving conditions or other factors, the Driver Attention
Monitor may not function in the following circumstances:

•

The steering assist function of the Lane Keeping Assist System (LKAS) is active.

Lane Keeping Assist System (LKAS)

P. 486

•

The condition of the road is poor, e.g. the surface is unpaved or bumpy.

•

It is windy.

•

The driver is frequently operating the vehicle in an assertive manner such as
changing lanes or accelerating.

■

Customizing

You can change the Driver Attention Monitor settings. Select

Tactile And Audible

Alert

Tactile Alert

, or

OFF

Customized Features

P. 351

For the Driver Attention Monitor to function:

The bars on the driver information interface remain
grayed out unless the Driver Attention Monitor is
functioning.

Continued

157

Gauges and Displays

Driver Information Interface

strum

nt Pa

nel

Shows the interval between your vehicle and
the vehicle detected ahead.
Informs you whether ACC with Low Speed
Follow and/or LKAS is activated or not. If ACC
with Low Speed Follow is activated, the set
following interval is displayed. If LKAS is
activated, the displayed lane marks change to
indicate that LKAS is activated.

Adaptive Cruise Control (ACC) with Low
Speed Follow

P. 470

Lane Keeping Assist System (LKAS)

P. 486

■

Driving Support Information

Driving Support Information

In case ACC with Low Speed Follow is not activated,
when the distance between your vehicle and the
vehicle ahead becomes too small, the section behind
the vehicle icon turns amber and alerts you.

Amber gradation

Icon of vehicle ahead

Distance of vehicle ahead

When ACC and LKAS is in On

Set Vehicle Interval

ACC on: The section behind the
vehicle icon turns green.
LKAS on: The lane outlines
appear on the display.
LKAS starts: The lane lines
change to solid ones.
LKAS suspend: The lane lines
change to dotted ones.

Gauges and Displays

Driver Information Interface

158

strum

nt Pa

nel

Indicates the status of RDM, CMBS

, Low Speed Braking Control

and the blind

spot information system

, such as On, Off, or Failure, by color and letters.

The following colors indicate the status of any of the above mentioned systems:

•

Green: The system is on.

•

Gray: The system is off.

•

Amber: There is a problem with the system.

■

Safety Support

Safety Support

If a system is indicated by the color amber, have your
vehicle checked by a dealer immediately.

To turn on or off each system, first rotate the left
selector wheel to switch displays. From the next
display you can select which system to turn on or off.

P. 459

Blind spot information System On and Off

P. 452

System On and Off

P. 467

You can also confirm the status of each function by
the color of the safety support indicator.

Safety Support Indicator (Amber)

P. 105

Safety Support Indicator (Green/Gray)

P. 108

Even when the Low Speed Braking Control icon is
green, if the parking sensor is turned off for the rear
only, the brake assist will not operate when reversing.

Turning off All Rear Sensors

P. 524

Models with Low Speed Braking Control

Area Info for CMBS

CMBS

Icon

and Status Info

Area Info for
blind spot
information
system

Blind spot
information
system Icon
and Status
Info

Low Speed
Braking Control
Icon and Status
Info

Area Info for Low Speed Braking Control

RDM Icon and
Status Info

Area Info
for RDM

* Not available on all models

159

Gauges and Displays

Head-Up Display

Continued

strum

nt Pa

nel

Head-Up Display

Shows the current mode for ACC with Low Speed Follow and LKAS, tachometer,
traffic sign recognition system, shift position indicator,

(sequential mode*/7-

speed manual shift mode*) Indicator/Gear Selection Indicator, compass or turn-by-
turn directions along with the vehicle speed. You can choose which item to be
displayed using the

(HUD) button on the steering wheel. They are displayed

when the power mode is in ON.

To turn the head-up display on and off

: Press the

HUD

button on the driver side

control panel.
The display can be moved up and down to become level with your eyes.

To raise or lower the head-up display

: Press the

button until the

desired position is reached.

Head-Up Display

When you unlock and open the driver’s door with a
remote transmitter or keyless access system, the
head-up display adjusts automatically to one of the
two preset positions.

Button

3 4

HUD

Button

Head-Up Display

Press the

button to raise

the display.

Press the

button to lower

the display.

* Not available on all models

160

Gauges and Displays

Head-Up Display

strum

nt Pa

nel

The display also shows the following
warnings.

•

Lane Departure Warning:

When your

vehicle is too close to the traffic lane lines,
the lane departure warning appears.

Lane Keeping Assist System (LKAS)

P. 486

•

Head-up Warning Lights:

Flash when the

BRAKE

message appears

on the driver information interface.

Collision Mitigation Braking System

(CMBS

)

P. 456

Adaptive Cruise Control (ACC) with
Low Speed Follow

P. 470

Low Speed Braking Control

P. 465

Lane Departure Warning

* Not available on all models

161

Gauges and Displays

Head-Up Display

Continued

strum

nt Pa

nel

Each time you press the

(HUD) button on the steering wheel, the head-up

display content will change.

■

To Change Head-Up Display Content

Head-Up Display

Current Mode for ACC with
Low Speed Follow and the
LKAS, Vehicle Speed, Traffic
Sign Recognition System

Vehicle Speed, Traffic
Sign Recognition
System

Tachometer, Shift Position Indicator,

(sequential mode

/7-speed manual

shift mode

) Indicator/Gear Selection

Indicator, Vehicle Speed, Traffic Sign
Recognition System

Traffic Sign
Recognition System,
Vehicle Speed

Turn-by-Turn
Directions, Vehicle
Speed, Traffic Sign
Recognition System

Compass, Vehicle
Speed, Traffic Sign
Recognition System

(HUD)

Button

* Not available on all models

Gauges and Displays

Head-Up Display

162

strum

nt Pa

nel

Shows your driving speed in mph or km/h.

Shows the number of engine revolutions as a bar graph.

Shows the current shift position.

Shift Position Indicator

P. 88

Shows the current mode for the sequential mode

/7-speed manual shift mode

Shows the current mode for ACC with Low Speed Follow and LKAS.

Adaptive Cruise Control (ACC) with Low Speed Follow

P. 470

Lane Keeping Assist System (LKAS)

P. 486

■

Vehicle Speed

■

Tachometer

■

Shift Position Indicator

■

M (sequential mode

/7-speed manual shift mode

)

Indicator/Gear Selection Indicator

■

Current Mode for ACC with Low Speed Follow and LKAS

Vehicle Speed

Switch between mph and km/h by using the driver
information interface or customized features on the
audio/information screen.

Speed/Distance Units

P. 151

Customized Features

P. 351

* Not available on all models

163

Gauges and Displays

Head-Up Display

strum

nt Pa

nel

■

Compass

Shows the compass screen.

■

Turn-by-Turn Directions

When driving guidance is provided by the navigation system, Android Auto or Apple
CarPlay, turn-by-turn directions to your destination appear.

Refer to the Navigation System Manual

Android Auto

P. 320

Apple CarPlay

P. 313

Shows the traffic sign recognition system.

Traffic Sign Recognition System

P. 498

■

Navigation

■

Traffic Sign Recognition System

Navigation

You can select whether the turn-by-turn display
comes on during the route guidance.

Customized Features

P. 351

Turn-by-turn directions may not be available for all
apps.

166

Co
ntrols

Clock

Adjusting the Clock

You can adjust the time manually in the audio/information screen, with the power
mode in ON.

Press the

, then select

Settings

Select

System

Select

Day & Time

Select

Set Date & Time

Select

Automatic Date & Time

, then

select

OFF

To adjust time:
6.

Select

Set Time

Selecting /

Select

Save

to set the time.

To adjust date:
6.

Select

Set Date

Selecting /

Select

Save

to set the date.

■

Adjusting the Time

Clock

The clock is automatically updated through the
navigation system, so the time does not need to be
adjusted.

You can also adjust the clock by touching the clock
displayed on the upper right corner of the display or
the

Clock

icon on the home screen.

1. Touch the clock on the display.

The clock screen of the select face-type appears.

2. Select

Settings

3. Select

Day & Time

4. Select

Set Date & Time

5. Select

Automatic Date & Time

, then select

OFF

6. Select

Set Date

Set Time

7. Adjusting the dates, hours, and minutes by

selecting /

8. Select

Save

to set the time.

You can customize the clock display to show the 12
hour clock or 24 hour clock.

Customized Features

P. 351

You can customize the date display to MM/DD/YYYY,
DD/MM/YYYY or YYYY/MM/DD.

Customized Features

P. 351

Models with navigation system

3 4

167

Continued

Co
ntrols

Locking and Unlocking the Doors

Key

This vehicle comes with the following keys:

Use the key to start and stop the engine, lock and unlock all the doors and the fuel
fill door, and open the trunk.

Key

All the keys have an immobilizer system. The
immobilizer system helps to protect against vehicle
theft.

Immobilizer System

P. 184

Follow the advice below to prevent damage to the
keys:

•

Do not leave the keys in direct sunlight, or in
locations with high temperature or high humidity.

•

Do not drop the keys or set heavy objects on them.

•

Keep the keys away from liquids, dust and sand.

•

Do not take the keys apart except for replacing the
battery.

If the circuits in the keys are damaged, the engine
may not start, and the remote transmitter may not
work.
If the keys do not work properly, have them
inspected by a dealer.

You can remotely start the engine using the keyless
remote.

Remote Engine Start

P. 414

Models with remote engine starter

Models without keyless access system

Models with keyless access system

* Not available on all models

Locking and Unlocking the Doors

Key

168

Co
ntrols

The built-in key can be used to lock/unlock the
doors or open the trunk when the keyless
remote battery becomes weak and the power
door lock/unlock operation is disabled.

To remove the built-in key, slide the release
knob and then pull out the key. To reinstall
the built-in key, push the built-in key into the
keyless remote until it clicks.

Contains a number that you will need if you
purchase a replacement key.

■

Built-in Key

Built-in Key

Release Knob

■

Key Number Tag

Key Number Tag

Keep the key number tag separate from the key in a
safe place outside of your vehicle.
If you wish to purchase an additional key, contact a
dealer.

If you lose your key and you cannot start the engine,
contact a dealer.

169

Locking and Unlocking the Doors

Low Keyless Remote Signal Strength

Co
ntrols

Low Keyless Remote Signal Strength

The vehicle transmits radio waves to locate the keyless remote to start the engine,
lock and unlock

all the doors and the fuel fill door, and open

the trunk.

In the following cases, starting the engine, locking/unlocking

the doors/fuel fill

door, or opening

the trunk may be inhibited or operation may be unstable:

•

Strong radio waves are being transmitted by nearby equipment.

•

You are carrying the keyless remote together with telecommunications
equipment, laptop computers, cell phones, or wireless devices.

•

A metallic object is touching or covering the keyless remote.

Low Keyless Remote Signal Strength

Communication between the keyless remote and the
vehicle consumes the keyless remote’s battery.
Battery life is about two years, but this varies
depending on regularity of use.
The battery is consumed whenever the keyless
remote is receiving strong radio waves. Avoid placing
it near electrical appliances such as televisions and
personal computers.

* Not available on all models

170

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

Locking/Unlocking the Doors from the Outside

When you carry the keyless remote, you can
lock/unlock the doors and fuel fill door, and
open the trunk.
You can lock/unlock the doors, fuel fill door
within a radius of about 32 inches (80 cm) of
the outside door handle. You can open the
trunk within about 32 inches (80 cm) radius
from the trunk release button.

■

Locking the doors

Touch the door lock sensor on the front door.

Some exterior lights flash; the beeper
sounds; all the doors and fuel fill door
lock; and the security system sets.

■

Using the Keyless Access System

Locking/Unlocking the Doors from the Outside

If the interior light switch is in the door activated
position, the interior light comes on when you unlock
the doors.
No doors opened: The light fades out after 30
seconds.
Doors relocked: The light goes off immediately.

Interior Lights

P. 223

Door Lock Sensor

Using the Keyless Access System

If you do not open a door within 30 seconds of
unlocking the vehicle with the keyless access system,
the doors and trunk will automatically relock.

You can lock or unlock doors using the keyless access
system only when the power mode is in VEHICLE OFF.

•

Do not leave the keyless remote in the vehicle
when you get out. Carry it with you.

•

Even if you are not carrying the keyless remote, you
can lock/unlock the doors while someone else with
the keyless remote is within range.

•

The door may be unlocked if the door handle is
covered with water in heavy rain or in a car wash if
the keyless remote is within range.

•

If you grip a front door handle or touch a door lock
sensor wearing gloves, the door sensor may be
slow to respond or may not respond by unlocking
or locking the doors.

* Not available on all models

Continued

171

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

■

Unlocking the doors and trunk

Grab the driver’s door handle:

The driver’s door and fuel fill door
unlocks.

Some exterior lights flash twice and the
beeper sounds twice.

Grab the front passenger’s door handle:

All the doors and fuel fill door unlock.

Some exterior lights flash twice and the
beeper sounds twice.

Press the trunk release button:

The trunk unlocks and opens.

A beeper will sound.

Using the Trunk Release Button

P. 182

Trunk Release Button

Using the Keyless Access System

•

After locking the door, you have up to 2 seconds
during which you can pull the door handle to
confirm whether the door is locked. If you need to
unlock the door immediately after locking it, wait
at least 2 seconds before gripping the handle,
otherwise the door will not unlock.

•

The door might not open if you pull it immediately
after gripping the door handle. Grip the handle
again and confirm that the door is unlocked before
pulling the handle.

•

Even within the 32 inches (80 cm) radius, you may
not be able to lock/unlock the doors with the
keyless remote if it is above or below the outside
handle.

•

The keyless remote may not operate if it is too close
to the door and door glass.

The light flash, beep and door unlock mode settings
can be customized using the audio/information
screen.

Customized Features

P. 351

* Not available on all models

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

172

Co
ntrols

■

Locking the doors (Walk away auto
lock

)

When you walk away from the vehicle with all
doors closed while carrying the keyless
remote, the doors will automatically lock.
The auto lock function activates when all
doors are closed, and the keyless remote is
within about 5 feet (1.5 m) radius of the
outside door handle.
Exit vehicle while carrying keyless remote and
close door(s).

While within about 5 feet (1.5 m) radius of
the vehicle.

The beeper sounds; the auto lock
function will be activated.

Carry the keyless remote beyond about 5
feet (1.5 m) from the vehicle and remain
outside this range for 2 or more seconds.

Some exterior lights flash; the beeper
sounds; all doors will then lock.

Locking the doors (Walk away auto lock

)

The auto lock function is set to OFF as the factory
default setting. The auto lock function can be set to
ON using the audio/information screen.
If you set the auto lock function to ON using the
audio/information screen, only the keyless remote
that was used to unlock the driver’s door prior to the
setting change can activate auto lock.

Customized Features

P. 351

After the auto lock function has been activated,
when you stay within the locking/unlocking
operation range, the indicator on the keyless remote
will continue to flash until the doors are locked.

When you stay beside the vehicle within the
operation range, the doors will automatically lock
approximately 30 seconds after the auto lock
function activating beeper sounds.

When you open a door after the auto lock function
activating beeper sounds, the auto lock function will
be canceled.

Under the following circumstances, the auto lock
function will not activate:

•

The keyless remote is inside the vehicle.

The beeper will not sound.

•

The keyless remote is taken out of its operational
range before all the doors are closed.

The beeper will sound.

The activation range of
the auto lock function is
about 5 feet (1.5 m)

Honda Accord (2022 year). Manual in english - page 10
