Continued

543

uu

Honda Sensing

®

u

Lane Keeping Assist System (LKAS)

Driving

■

The system operation is suspended if
you:

•

Set the wipers to high speed.

u

Turning the wipers off, setting it to

LO

,

or the wipers are operating intermittently
resumes the LKAS.

•

Decrease the vehicle speed to about 40
mph (64 km/h) or less.

u

Increasing the vehicle speed to about 45
mph (72 km/h) or more resumes the
LKAS.

•

Depress the brake pedal.

u

The LKAS resumes and starts detecting
the lane lines again once you release the
brake pedal.

•

Your vehicle is driving to the right or the left
of the lane.

1

The system operation is suspended if you:

You can change the setting for the LKAS.
LKAS suspended beep

ON

 and

OFF

 can be selected.

2

Customized Features

 P. 413

When the LKAS is suspended,
the lane lines on the driver
information interface change
to lane outlines, and the beeper
sounds (if activated).

 (white) is on.

544

uu

Honda Sensing

®

u

Lane Keeping Assist System (LKAS)

Driving

■

The LKAS may automatically be suspended when:

•

The system fails to detect lane lines.

•

The steering wheel is quickly turned.

•

You fail to steer the vehicle.

•

Driving through a sharp curve.

•

Driving at a speed in excess of approximately 90 mph (145 km/h).

Once these conditions no longer exist, the LKAS automatically resumes.

■

The LKAS may automatically be canceled when:

•

The camera temperature gets extremely high.

•

The camera behind the rearview mirror, or the area around the camera, including
the windshield, gets dirty.

•

The ABS or VSA

®

 system engages.

The beeper sounds if the LKAS is automatically canceled.

545

uu

Honda Sensing

®

u

Lane Keeping Assist System (LKAS)

Continued

Driving

The system may not detect lane markings and therefore may not keep the vehicle in
the middle of a lane under certain conditions, including the following:

■

Environmental conditions

•

Driving in bad weather (rain, fog, snow, etc.).

•

Sudden changes between light and dark, such as an entrance or exit of a tunnel.

•

There is little contrast between lane lines and the roadway surface.

•

Driving into low sunlight (e.g., at dawn or dusk).

•

Strong light is reflected onto the roadway.

•

Driving in the shadows of trees, buildings, etc.

•

Shadows of adjacent objects are parallel to lane markings.

•

Roadway objects or structures are misinterpreted as lane markers.

•

Reflections on the interior of the windshield.

•

Driving at night or in a dark condition such as a tunnel.

■

LKAS Conditions and Limitations

546

uu

Honda Sensing

®

u

Lane Keeping Assist System (LKAS)

Driving

■

Roadway conditions

•

Driving on a snowy or wet roadway (obscured lane marking, vehicle tracks,
reflected lights, road spray, high contrast).

•

Driving on a road with temporary lane markings.

•

Faint, multiple, or varied lane markings are visible on the roadway due to road
repairs or old lane markings.

•

The roadway has merging, split, or crossing lines (e.g., such as at an intersection
or crosswalk).

•

The lane markings are extremely narrow, wide, or changing.

•

The vehicle in front of you is driving near the lane lines.

•

The road is hilly or the vehicle is approaching the crest of a hill.

•

Driving on rough or unpaved roads, or over bumpy surfaces.

Faded lines

Duplicate lines

Tire tracks

Very wide or narrow traffic lane

547

uu

Honda Sensing

®

u

Lane Keeping Assist System (LKAS)

Driving

•

When objects on the road (curb, guard rail, pylons, etc.) are recognized as white
lines (or yellow lines).

•

Driving on roads with double lines.

■

Vehicle conditions

•

Headlight lenses are dirty or the headlights are not properly adjusted.

•

The outside of the windshield is streaked or blocked by dirt, mud, leaves, wet
snow, etc.

•

The inside of the windshield is fogged.

•

The camera temperature gets too high.

•

An abnormal tire or wheel condition (wrong size, varied size or construction,
improperly inflated, compact spare tire, etc.).

•

The vehicle is tilted due to a heavy load or suspension modifications.

•

The vehicle is towing a trailer.

Lane void of lines at exit or
interchange

548

uu

Honda Sensing

®

u

Road Departure Mitigation (RDM) System

Driving

Road Departure Mitigation (RDM) System

Alerts and helps to assist you when the system detects a possibility of your vehicle
unintentionally crossing over detected lane markings and/or leaving the roadway
altogether.

The front camera behind the rearview mirror
monitors left and right lane markings (in white
or yellow). If your vehicle is getting too close
to detected lane markings without a turn
signal activated, the system, in addition to a
visual alert, applies steering torque and alerts
you with rapid vibrations on the steering
wheel, to help you remain within the detected
lane.

2

Customized Features

 P. 413

As a visual alert, the

Lane Departure



message appears on the driver information
interface.

If the system determines that its steering input
is insufficient to keep your vehicle on the
roadway, it may apply braking.

u

Braking is applied only when the lane
markings are solid continuous lines.

The system cancels assisting operations when you turn the steering wheel to avoid
crossing over detected lane markings.

If the system operates several times without detecting driver response, the system
beeps to alert you.

■

How the System Works

1

Road Departure Mitigation (RDM) System

Important Safety Reminder

Like all assistance systems, the RDM system has
limitations.
Overreliance on the RDM system may result in a
collision. It is always your responsibility to keep the
vehicle within your driving lane.

The RDM system only alerts you when lane drift is
detected without a turn signal in use. The RDM
system may not detect all lane markings or lane or
roadway departures; accuracy will vary based on
weather, speed and lane marker condition. It is
always your responsibility to safely operate the
vehicle and avoid collisions.

You can read about handling information for the
camera equipped with this system.

2

Front Sensor Camera

 P. 558

The RDM system may not work properly or may work
improperly under the certain conditions:

2

RDM Conditions and Limitations

 P. 551

There are times when you may not notice RDM
functions due to your operation of the vehicle, or
road surface conditions.

Continued

549

uu

Honda Sensing

®

u

Road Departure Mitigation (RDM) System

Driving

The system activates when all of the following conditions are met:

•

The vehicle is traveling between about 45 and 90 mph (72 and 145 km/h).

•

The vehicle is on a straight or slightly curved road.

•

The turn signals are off.

•

The brake pedal is not depressed.

•

The wipers are not in high speed operation.

•

The system makes a determination that the driver is not actively accelerating,
braking, or steering.

■

How the System Activates

1

Road Departure Mitigation (RDM) System

If LKAS is off and you have selected

Narrow

 from the

customised options using the audio/information
screen, the message below will appear in case the
system determines a possibility of your vehicle
crossing over detected lane markings.

2

Driver Information Interface Warning and
Information Messages

 P. 108

2

Customized Features

 P. 413

1

How the System Activates

The RDM system may automatically shut off and the
safety support indicator (amber) comes and stays on.

2

Indicators

 P. 88

RDM system function can be impacted when the
vehicle is:

•

Not driven within a traffic lane.

•

Driven on the inside edge of a curve, or outside of
a lane.

•

Driven in a narrow lane.

uu

Honda Sensing

®

u

Road Departure Mitigation (RDM) System

550

Driving

When you turn the RDM on and off, do the
following.

1.

Press the safety support switch.

2.

Press the

/

 button to select

 symbol,

then press

ENTER

.

u

A tick appears in the box and the color of
the

 symbol changes green when the

system is on. The tick disappears and the
color of the

 symbol changes gray

when the system is off.

The RDM is in the previously selected on or off
setting each time you start the power system.

■

RDM On and Off

1

RDM On and Off

When you have selected

Warning Only

 from the

customized options using the audio/information
screen, the system does not operate the steering
wheel and braking.

2

Customized Features

 P. 413

Safety Support Switch

/

 Button

3 4

3 4

551

uu

Honda Sensing

®

u

Road Departure Mitigation (RDM) System

Continued

Driving

The system may not properly detect lane markings and the position of your vehicle
under certain conditions. Some examples of these conditions are listed below.

■

Environmental conditions

•

Driving in bad weather (rain, fog, snow, etc.).

•

Sudden changes between light and dark, such as an entrance or exit of a tunnel.

•

There is little contrast between lane lines and the roadway surface.

•

Driving into low sunlight (e.g., at dawn or dusk).

•

Strong light is reflected onto the roadway.

•

Driving in the shadows of trees, buildings, etc.

•

Shadows of adjacent objects are parallel to lane markings.

•

Roadway objects or structures are misinterpreted as lane markers.

•

Reflections on the interior of the windshield.

•

Driving at night or in a dark condition such as a tunnel.

■

RDM Conditions and Limitations

552

uu

Honda Sensing

®

u

Road Departure Mitigation (RDM) System

Driving

■

Roadway conditions

•

Driving on a snowy or wet roadway (obscured lane marking, vehicle tracks,
reflected lights, road spray, high contrast).

•

Driving on a road with temporary lane markings.

•

Faint, multiple, or varied lane markings are visible on the roadway due to road
repairs or old lane markings.

•

The roadway has merging, split, or crossing lines (e.g., such as at an intersection
or crosswalk).

•

The lane markings are extremely narrow, wide, or changing.

•

The vehicle in front of you is driving near the lane lines.

•

The road is hilly or the vehicle is approaching the crest of a hill.

•

Driving on rough or unpaved roads, or over bumpy surfaces.

•

When objects on the road (curb, guard rail, pylons, etc.) are recognized as white
lines (or yellow lines).

•

Driving on roads with double lines.

■

Vehicle conditions

•

Headlight lenses are dirty or the headlights are not properly adjusted.

•

The outside of the windshield is streaked or blocked by dirt, mud, leaves, wet
snow, etc.

•

The inside of the windshield is fogged.

•

The camera temperature gets too high.

•

An abnormal tire or wheel condition (wrong size, varied size or construction,
improperly inflated, compact spare tire, etc.).

•

The vehicle is tilted due to a heavy load or suspension modifications.

•

When tire chains are installed.

•

The vehicle is towing a trailer.

553

uu

Honda Sensing

®

u

Traffic Sign Recognition System

Continued

Driving

Traffic Sign Recognition System

Reminds you of road sign information, such as the current speed limit your vehicle
has just passed through, showing it on the driver information interface.

When the camera located behind the rearview mirror captures traffic signs while
driving, the system displays the ones that are recognized as designated for your
vehicle. The sign icon will be displayed until the vehicle reaches a predetermined
time and distance.
If the system does not detect any traffic signs while you are driving, the sign icon will
not be displayed

The sign icon also may switch to another one, or disappear when:

•

The other designated limit is detected.

•

You make a turn with a turn signal at an intersection.

■

How the System Works

1

Traffic Sign Recognition System

Not all signs may be displayed, but any signs posted
on roadsides should not be ignored. The system does
not work on the designated traffic signs of all the
countries you travel, nor in all situations.
Do not rely too much on the system. Always drive at
speeds appropriate for the road conditions.

Never apply a film or attach any objects to the
windshield that could obstruct the camera’s field of
vision and cause the system to operate abnormally.
Scratches, nicks, and other damage to the windshield
within the camera’s field of vision can cause the
system to operate abnormally. If this occurs, we
recommend that you replace the windshield with a
genuine Honda replacement windshield. Making even
minor repairs within the camera’s field of vision or
installing an aftermarket replacement windshield may
also cause the system to operate abnormally. After
replacing the windshield, have a dealer recalibrate the
camera. Proper calibration of the camera is necessary
for the system to operate properly.

To help reduce the likelihood that high interior
temperatures will cause the camera’s sensing system to
shut off, when parking, find a shady area or face the front
of the vehicle away from the sun. If you use a reflective sun
shade, do not allow it to cover the camera housing.
Covering the camera can concentrate heat on it.

You can read about handling information for the
camera equipped with this system.

2

Front Sensor Camera

 P. 558

uu

Honda Sensing

®

u

Traffic Sign Recognition System

554

Driving

The traffic sign recognition system may not be able to recognize a traffic sign in the
following cases.

■

Vehicle conditions

•

Headlight lenses are dirty or the headlights are not properly adjusted.

•

The outside of the windshield is blocked by dirt, mud, leaves, wet snow, etc.

•

The inside of the windshield is fogged.

•

There are portions remaining to be wiped.

•

An abnormal tire or wheel condition (wrong size, varied size or construction,
improperly inflated, compact spare tire, etc.).

•

The vehicle is tilted due to a heavy load or suspension modifications.

■

Environmental conditions

•

Driving into low sunlight (e.g., at dawn or dusk).

•

Strong light is reflected onto the roadway.

•

Sudden changes between light and dark, such as an entrance or exit of a tunnel.

•

When you drive in the shadows of trees, buildings, etc.

•

Driving at night, in dark areas such as long tunnels.

•

Driving in bad weather (rain, fog, snow, etc.).

•

A vehicle in front of you is kicking up spray or snow.

■

Traffic Sign Recognition System Conditions and Limitations

1

Traffic Sign Recognition System Conditions and Limitations

When the traffic sign recognition system
malfunctions,

 appears on the driver information

interface. If this message does not disappear, have
your vehicle checked by a dealer.

555

uu

Honda Sensing

®

u

Traffic Sign Recognition System

Continued

Driving

■

The position or the condition of the traffic sign

•

A sign is hard to be found since it is in a complicated area.

•

A sign is located far away from your vehicle.

•

A sign is located where the beam of the headlight is hard to reach.

•

A sign is on a corner or bend in the road.

•

Faded or bent signs.

•

Rotated or damaged signs.

•

A sign is covered with mud, snow, or frost.

•

A part of the sign is hidden by the trees, or the sign itself is hidden by a vehicle
and others.

•

Light (a streetlight) or a shadow is reflected on the surface of the sign.

•

A sign is too bright or too dark (an electric sign).

•

A sign of a small size.

■

Other conditions

•

When you are driving at a high speed.

556

uu

Honda Sensing

®

u

Traffic Sign Recognition System

Driving

The traffic sign recognition system may not operate correctly, such as displaying a
sign that does not follow the actual regulation for the roadway or does not exist at
all in the following cases.

u

A speed limit sign may display at a higher or lower speed than the actual speed
limit.

•

There is a supplementary sign with further information such as weather, time,
vehicle type, school zone, etc.

•

Figures on the sign are hard to read (electric signs, numbers on the sign are
blurred, etc.).

•

A sign is in the vicinity of the lane you are driving in, even though it is not for the
lane (speed limit sign situated at the junction between the side road and the main
road, etc.).

•

There are things that look similar to the color or shape of the recognition object
(similar sign, electric sign, signboard, structure, etc.).

•

A truck or another large vehicle with a sticker of the speed limit sign on the back
is traveling in front of you.

557

uu

Honda Sensing

®

u

Traffic Sign Recognition System

Driving

The speed limit sign icon is displayed on the upper right half of the screen.

■

Speed limit sign on and off

You can switch on and off the speed limit sign on the audio/information screen.

2

Customized Features

 P. 413

■

Signs Displayed on the Driver information interface

Speed Limit Sign

558

uu

Honda Sensing

®

u

Front Sensor Camera

Driving

Front Sensor Camera

The camera, used in systems such as Lane Keeping Assist System (LKAS), Road
Departure Mitigation (RDM), Adaptive Cruise Control (ACC) with Low Speed Follow,
Traffic Sign Recognition System, and Collision Mitigation Braking System

TM



(CMBS

TM

), is designed to detect an object that triggers any of the systems to operate

its functions.

This camera is located behind the rearview
mirror.

To help reduce the likelihood that high interior
temperatures will cause the camera’s sensing
system to shut off, when parking, find a shady
area or face the front of the vehicle away from
the sun. If you use a reflective sun shade, do
not allow it to cover the camera housing.
Covering the camera can concentrate heat on
it.

■

Camera Location and Handling Tips

1

Front Sensor Camera

Never apply a film or attach any objects to the
windshield, the hood, or the front grille that could
obstruct the camera’s field of vision and cause the
system to operate abnormally.
Scratches, nicks, and other damage to the windshield
within the camera’s field of vision can cause the
system to operate abnormally. If this occurs, we
recommend that you replace the windshield with a
genuine Honda replacement windshield. Making
even minor repairs within the camera’s field of vision
or installing an aftermarket replacement windshield
may also cause the system to operate abnormally.
After replacing the windshield, have a dealer
recalibrate the camera. Proper calibration of the
camera is necessary for the system to operate
properly.

Do not place an object on the top of the instrument
panel. It may reflect onto the windshield and prevent
the system from detecting lane lines properly.

Front Sensor
Camera
