Quick

Referenc

e Guide

Auto Idle Stop Function

To improve fuel economy, the engine stops and then restarts as detailed below. When Auto Idle Stop is on, the Auto Idle Stop indicator
(green) comes on.

(P 492)

Automatic transmission

Engine status

Deceleration

Stop

Start-up

Stop the vehicle and depress the brake pedal.

Keep the brake pedal
depressed.

With the automatic brake hold system activated,
you can release the brake pedal when the

indicator comes on.

U.S.

Canada

Off

Release the brake pedal.

With the automatic brake hold system activated,
depress the accelerator pedal.

Restarting

Quick

Referenc

e Guide

Eco Assist

System

(P 497)

Ambient Meter

The color of the ambient meter changes to
green to indicate that the vehicle is being
driven in a fuel efficient manner.

ECON Button

(P 497)

Helps maximize fuel economy.

ECON Mode Indicator

(P 99)

Comes on when the

ECON

button is pressed.

Quick

Referenc

e Guide

Safe Driving

(P35)

Airbags

(P49)

●

Your vehicle is fitted with airbags to help protect you and
your passengers during a moderate-to-severe collision.

Child Safety

(P67)

●

All children 12 and younger should be seated in the rear seat.

●

Smaller children should be properly restrained in a forward-facing child seat.

●

Infants must be properly restrained in a rear-facing child seat.

Exhaust Gas Hazard

(P85)

●

Your vehicle emits dangerous exhaust gases that contain carbon
monoxide. Do not run the engine in confined spaces where
carbon monoxide gas can accumulate.

Before Driving Checklist

(P39)

●

Before driving, check that the front seats, head
restraints, steering wheel, and mirrors have been
properly adjusted.

Seat Belts

(P40)

●

Fasten your seat belt and sit upright well
back in the seat.

●

Check that your passengers are wearing
their seat belts correctly.

Fasten your lap belt as
low as possible.

Quick

Referenc

e Guide

Instrument Panel

(P87)

System Indicators

Malfunction Indicator
Lamp

Charging System
Indicator

Anti-lock Brake System
(

ABS

) Indicator

Vehicle Stability
Assist

(VSA

) System

Indicator

VSA

OFF

Indicator

Low Tire Pressure/TPMS
Indicator

Immobilizer System Indicator/
Security System Alarm Indicator

Lights Indicators

Lights On Indicator

High Beam Indicator

Fog Light Indicator

Lane Keeping Assist
System (LKAS)
Indicator (Green/
Amber/White)

Seat Belt Reminder
Indicator

System Indicators

Econ Mode Indicator

System Message
Indicator

Parking Brake and
Brake System Indicator
(Red)

Supplemental Restraint
System Indicator

Driver Information Interface

Auto Idle Stop

OFF

Indicator

Tachometer

(Sequential mode) Indicator/

Sequential Mode Gear Selection
Indicator

Speedometer

Fuel Gauge

Gear Position Indicator/
Transmission System
Indicator

Auto Idle Stop System
Indicator (Amber)/
Auto Idle Stop
Indicator (Green)

Indicators

(P88)

/Gauges

(P127)

Driver Information Interface

(P128)

Automatic Brake Hold
Indicator

Adaptive Cruise
Control (ACC) with
Low Speed Follow
Indicator (Green/
Amber/White)

Turn Signal and Hazard
Warning Indicators

Electric Power Steering
(EPS) System Indicator

Cruise Mode Indicator
(White/Green)

Auto Idle Stop
Suspend Indicator

Temperature Gauge

Parking Brake and
Brake System Indicator
(Amber)

U.S.

Canada

U.S.

Canada

System Indicators

U.S.

Canada

Low Fuel Indicator

Automatic Brake Hold
System Indicator

Auto High-Beam
Indicator

Snow

Mode Indicator

Normal

Mode

Indicator

Safety Support
Indicator (Green/
Amber/Gray)

Quick

Referenc

e Guide

Controls

(P143)

Clock

(P144)

To adjust time

To adjust date

Set Date

Blu-Ray

Save

Month

Day

Year

Cancel

Phone

Navigati..

12:34

Select

, then select

Settings

Select

System

, then

Date & Time

Select

Set Date & Time

Select

Automatic Date & Time

, then

select

OFF

Select

Set Date

Set Time

Adjust the dates, hours and minutes by
selecting /

Select

Save

to set the time.

3 4

The navigation system receives signals from
GPS satellites, updating the clock
automatically.

ENGINE START/STOP
Button

(P188)

Press the button to change the vehicle’s
power mode.

Models with navigation system

Quick

Referenc

e Guide

Turn Signals

(P191)

Lights

(P192)

Turn Signal Control Lever

Light Control Switches

Low Beam

High Beam

Flashing

Wipers and Washers

(P200)

*1:Models with automatic intermittent

wipers

*2:Models without automatic intermittent

wipers

AUTO

should always be turned

OFF

before

the following situation in order to prevent
severe damage to the wiper system:

●

Cleaning the windshield

●

Driving through a car wash

●

No rain present

Wiper/Washer Control Lever

Adjustment Ring

(

: Low sensitivity

(

: Lower speed, fewer sweeps

(

: High sensitivity

(

: Higher speed, more sweeps

MIST
OFF
AUTO

: Wiper speed varies automatically

INT

: Low speed with intermittent

: Low speed wipe

: High speed wipe

Pull toward
you to spray
washer fluid.

Models with automatic intermittent wipers

Steering Wheel

(P208)

To adjust, push the adjustment lever down,
adjust to the desired position, then pull up
the lever back in place.

Lever

To lock

To adjust

Quick

Referenc

e Guide

Unlocking the Front
Doors from the Inside

(P157)

Pull either front door inner handle to unlock
and open it at the same time.

Power Sliding Door

(P174)

When the main switch is

, the power

sliding door opens and closes automatically
when you press

OPEN

CLOSE

side of the

switch.

Tailgate

(P161)

With the keyless remote on you, raise and
lower your foot (in a kicking motion) under
the center of the rear bumper to open or
close the tailgate.

Models with Hands Free Access

●

Press the tailgate outer handle to unlock
and open the tailgate when you carry the
keyless remote.

●

Press the power tailgate button on the
instrument panel or the keyless remote to
open and close the power tailgate.

●

Press the tailgate inner button to close
the power tailgate.

Models with the power tailgate

Tailgate Outer Handle

Quick

Referenc

e Guide

Power Door Mirrors

(P210)

●

With the power mode in ON, move the
selector switch to

●

Push the appropriate edge of the
adjustment switch to adjust the mirror.

●

Press the folding button

to fold the door

mirrors in and out.

●

Place the selector switch in the

position to use the reverse tilt door mirror
feature.

Selector Switch

Adjustment Switch

Folding
Button

Models with driving position memory system

Power Windows

(P184)

●

With the power mode in ON, open and
close the power windows.

●

If the power window lock button is in the
off position, each passenger’s window
can be opened and closed with its own
switch.

●

If the power window lock button is in the
on position (indicator is on), each
passenger’s window switch is disabled.

Power Window
Lock Button

Window Switch

Indicator

Not available on all models

Quick

Referenc

e Guide

Climate Control System

(P250)

●

Press the

AUTO

button to activate the climate control system.

●

Press the

button to turn the system on or off.

●

Press the

button to defrost the windshield.

Quick

Referenc

e Guide

Fan Control Button

(Windshield Defroster)

Button

A/C

(Air

Conditioning)
Icon

(Recirculation) Button

Passenger’s
Side
Temperature
Control
Switch

AUTO

Button

Driver’s Side
Temperature
Control
Switch

Mode Control Icon
(Air flows from
dashboard vents)

SYNC

(Synchronized) Button

(On/Off) Button

FRONT
CLIMATE

Button

REAR
CLIMATE

Button

Fan Control
Icon

Mode Control
Icon (Air flows
from floor
vents)

Mode Control
Icon (Air flows
from floor and
windshield
defroster vents)

Mode Control Icon (Air
flows from floor and
dashboard vents)

Rear Climate Control Panel

●

Press the

AUTO

button to activate the

rear climate control system.

●

Press the

button to turn the system

on or off.

Rear Passenger
Compartment
Temperature
Control Buttons

(Fan Control)

Button

Air flows
from the
rear floor
vents.

Airflow is
divided
between the
rear floor
vents and
rear ceiling
vents.

Air flows
from the
rear ceiling
vents.

(On/Off)

Button

AUTO

Button

Quick

Referenc

e Guide

Features

(P257)

Audio System

(P258)

VOL

AUDIO

(Volume/Power) Knob

(Home) Icon

(Back) Icon

(Day/Night) Icon

Audio/Information Screen

For navigation system operation

()

See the Navigation System Manual

(Eject) Button

Disc Slot

Models with Blu-ray

player

Quick

Referenc

e Guide

Audio Remote Controls

(P262)

●

(

Bar

Press to adjust the volume up/down.

●

ENTER

Buttons

Press

to select

Now Playing

the home screen of the driver
information interface, and then press the

ENTER

button.

ENTER

Button

Buttons

(

Bar

Press

to cycle through the audio

mode as follows:
Android Auto/Apple CarPlay/SiriusXM

Rear Entertainment

/AUX Input/AM/

Bluetooth

Audio/Social Playlist/FM/My

Honda Music/USB/iPod

Radio: Press

to change the

preset station.

USB device/My Honda Music/

Bluetooth

Audio:

Press

to skip to the

beginning of the next song or
return to the beginning of the
current song.

Not available on all models

Quick

Referenc

e Guide

Driving

(P 463)

Gear Position Indicator

Shift
Button
Indicator

Automatic Transmission

(P 484)

●

Always depress the brake pedal before selecting

(

or changing the gear position from

(

●

Select

(

and depress the brake pedal when starting the engine.

●

Gear selection

Gear Position Indicator

The gear position indicator and
the shift button indicator
indicate the current gear
selection.

Quick

Referenc

e Guide

Park

Press the

(

button.

Used when parking or before turn off or start the engine.
Transmission is locked.

Reverse

Pull back the

(

button.

Used when reversing.

Neutral

Press the

(

button.

Transmission is not locked.

Drive/S Position

Each time you press the

button, the mode switches

between Drive and S Position mode.

●

Normal driving (gears change between 1st and 10th
automatically)

●

Temporarily driving in the sequential mode

●

Automatically changing gears between 1st and 8th
(8th gear is used only at high speed)

●

Driving in the sequential mode

D/S

Drive

S Position

Quick

Referenc

e Guide

(sequential

mode)
Indicator

Gear Position Indicator

Shift Down

(

Paddle Shifter

Shift Up

(

Paddle Shifter

Paddle Shifters

(P 491)

●

Paddle shifters allow you to shift gears much like a manual
transmission (1st through 10th). This is useful for engine braking.

●

D-paddle shift mode: The
transmission will shift back to
automatic mode once the
system detects that the vehicle
is cruising.

●

Sequential mode gear
selection: Holds the selected
gear, and the

(sequential

mode) indicator comes on.

●

The sequential mode gear
selection is shown in the
instrument panel.

Sequential Mode Gear
Selection Indicator

Quick

Referenc

e Guide

VSA

On and Off

(P500)

●

The Vehicle Stability Assist

(VSA

)

system helps stabilize the vehicle during
cornering and helps maintain traction
while accelerating on loose or slippery
road surfaces.

●

VSA

comes on automatically every time

you start the engine.

●

To partially disable or fully restore VSA

function, press and hold the button until
you hear a beep.

CMBS

On and Off

(P 516)

●

When a possible frontal collision is likely
unavoidable, the CMBS

can help you to

reduce the vehicle speed and the severity
of the collision.

●

The CMBS

is turned on every time you

start the engine.

●

To turn the CMBS

on or off, use the

safety support switch.

Tire Pressure Monitoring System (TPMS) with Tire
Fill Assist

(P 502, 667)

●

The TPMS monitors tire pressure.

●

TPMS is turned on automatically every time you start the engine.

●

TPMS fill assist provides audible and visual guidance during tire pressure adjustment.

Refueling

(P 582)

Fuel recommendation: Unleaded gasoline, pump octane number 87 or higher

Fuel tank capacity: 19.5 US gal (73.8 L)

Unlock the driver’s
door.

Locking/Unlocking
the Doors from the
Inside

(P 156)

Press firmly and then
release the area
indicated by the
arrow to release the
fuel filler door.

After refueling, wait
for about five
seconds before
removing the filler
nozzle.

Wait for five seconds

Content .. 1 2 ..

///////////////////////////////////////
