Honda Ridgeline (2022 year). Manual in english - page 1





11

Quick

 Referenc

e Guide

Auto Idle Stop Function

To improve fuel economy, the engine stops and then restarts as detailed below. When Auto Idle Stop is on, the Auto Idle Stop indicator
(green) comes on.

(P406)

At

Automatic transmission

Engine status

Deceleration

Stop the vehicle and depress the brake
pedal.

Stop

Keep the brake pedal depressed.

Start-up

Release the brake pedal.

On

Off

Restarting

*

 Not available on all models

12

Quick

 Referenc

e Guide

Eco Assist

®

 System

Ambient Meter

The color of the ambient meter changes to green
to indicate that the vehicle is being driven in a fuel
efficient manner.

ECON Mode Indicator

(P92)

Comes on when the

ECON

 button is

pressed.

ECON Button

(P403)

Helps maximize fuel economy.

13

Quick

 Referenc

e Guide

Safe Driving

(P31)

Airbags

(P44)

Your vehicle is fitted with airbags to help protect you and
your passengers during a moderate-to-severe collision.

Child Safety

(P59)

All children 12 and younger should be seated in the rear seat.

Smaller children should be properly restrained in a forward-facing child seat.

Infants must be properly restrained in a rear-facing child seat.

Exhaust Gas Hazard

(P74)

Your vehicle emits dangerous exhaust gases that contain carbon
monoxide. Do not run the engine in confined spaces where carbon
monoxide gas can accumulate.

Before Driving Checklist

(P36)

Before driving, check that the front seats, head restraints,
steering wheel, and mirrors have been properly adjusted.

Seat Belts

(P37)

Fasten your seat belt and sit upright well
back in the seat.

Check that your passengers are wearing
their seat belts correctly.

Fasten your lap belt as
low as possible.

14

Quick

 Referenc

e Guide

Instrument Panel

(P77)

System Indicators

Malfunction Indicator
Lamp
Low Oil Pressure
Indicator

Charging System
Indicator

Anti-lock Brake System
(

ABS

) Indicator

Vehicle Stability Assist

TM



(VSA

®

) System Indicator

VSA

®



OFF

 Indicator

Electric Power Steering
(EPS) System Indicator

Lights Indicators

Lights On Indicator

High Beam Indicator

Immobilizer System
Indicator

Seat Belt Reminder
Indicator

System Indicators

System Message
Indicator

Parking Brake and
Brake System
Indicator (Red)

Supplemental
Restraint System
Indicator

Low Fuel Indicator

Gauges

(P110)

/Multi-Information Display

(P111)

/System Indicators

(P78)

Low Tire Pressure/
TPMS Indicator

Turn Signal and
Hazard Warning
Indicators

Keyless Access System
Indicator

Ambient Meter

Shift Position Indicator/
Transmission System
Indicator

Fuel Gauge

Tachometer

Temperature
Gauge

Speedometer

Multi-Information
Display

Brake System
Indicator (Amber)

All-wheel drive (

AWD

Indicator

*

Blind spot information
System Indicator

*

System Indicators

Collision Mitigation Braking
System

TM

 (CMBS

TM

) Indicator

Road Departure Mitigation
Indicator

Security System Alarm
Indicator

U.S.

Canada

U.S.

Canada

Fog Light Indicator

ECON Mode Indicator

Auto High-Beam
Indicator

Lane Keeping Assist
System (

LKAS

) Indicator

(Green/Amber)

Adaptive Cruise
Control (

ACC

Indicator (Green/
Amber)

Intelligent Traction
Management Indicator

Bed Lights On Indicator

Auto Idle Stop System
Indicator (Amber)/
Auto Idle Stop
Indicator (Green)

M

 (Sequential mode)

Indicator/Sequential Mode
Gear Selection Indicator

15

Quick

 Referenc

e Guide

Controls

(P115)

Clock

(P116)

a

Select

, then select

Settings

.

b

Select

Clock/Info

, then

Clock

Adjustment

.

c

Adjust the hours and minutes by
selecting /

.

d

Select

OK

 to set the time.

3 4

ENGINE START/STOP
Button

(P145)

Press the button to change the vehicle’s
power mode.

Turn Signals

(P148)

Lights

(P149)

Turn Signal Control Lever

Right

Left

Light Control Switches

Low Beam

High Beam

Flashing

*

 Not available on all models

16

Quick

 Referenc

e Guide

Wipers and Washers

(P157)

*1:Models with automatic intermittent

wipers

*2:Models with manual intermittent wipers

Wiper/Washer Control Lever

MIST
OFF
AUTO

*1

: Wiper speed varies

automatically

INT

*2

: Low speed with intermittent

LO

: Low speed wipe

HI

: High speed wipe

Pull toward
you to spray
washer fluid.

Adjustment Ring

(

-

: Low Sensitivity

*1

(

-

  : Lower speed, fewer sweeps

*2

(

+

: High Sensitivity

*1

(

+

  : Higher speed, more sweeps

*2

AUTO

 should always be turned

OFF

 before

the following situations in order to prevent
severe damage to the wiper system:

Cleaning the windshield

Driving through a car wash

No rain present

Steering Wheel

(P163)

To adjust, push the adjustment lever
down, adjust to the desired position, then
lock the lever back in place.

Models with automatic intermittent wipers

Unlocking the Front
Doors from the Inside

(P128)

Pull either front door inner handle to
unlock and open it at the same time.

Trunk

(P 133)

Press the trunk release button on the
trunk lid to unlock and open the trunk.

Trunk Release Button

17

Quick

 Referenc

e Guide

Power Door Mirrors

(P165)

With the power mode in ON, move the
selector switch to

L

 or

R

.

Push the appropriate edge of the
adjustment switch to adjust the mirror.

Press the folding button

*

 to fold in and

out the door mirrors.

Selector Switch

Adjustment Switch

Folding Button

*

Power Windows

(P139)

With the power mode in ON, open and
close the power windows.

If the power window lock button is in the
off position, each passenger’s window
can be opened and closed with its own
switch.

If the power window lock button is in the
on position (indicator is on), each
passenger’s window switch is disabled.

Power Window Lock Button

Window Switch

Indicator

*

 Not available on all models

18

Quick

 Referenc

e Guide

Climate Control System

(P195)

Press the

AUTO

 button to activate the climate control system.

Press the

 button to turn the system on or off.

Press the

 button to defrost the windshield.

The climate control system is voice operable.

(P232)

Models with navigation system

Fan Control
Button

 (Windshield

Defroster) Button

A/C

 (Air

Conditioning)
Button

Air flows from dashboard and
back of the center console
vents.

Air flows from dashboard, floor
and back of the center console
vents.

Air flows from floor vents.

Air flows from floor and
windshield defroster vents.

 (Recirculation)

Button

Passenger’s Side
Temperature
Control Switch

AUTO

 Button

Driver’s Side
Temperature
Control Switch

MODE

 Button

SYNC



(Synchronized) Button

 (

ON/OFF

) Button

Rear Climate Control

*



(P200)

Press the

AUTO

 button to activate the

rear climate control system.

Press the

 button to turn the system

on or off.

Rear Temperature
Control Buttons

 /



(Rear Fan
Control) Buttons

Rear

AUTO



Button

 (Rear

ON/

OFF

) Button

MODE

 Button

Air flows from the rear floor vents.

Air flow from the center console
vents and floor vents.

Air flows from the center console
vents.

19

Quick

 Referenc

e Guide

Features

(P203)

Audio system

(P204)

VOL/

 AUDIO

(Volume/Power Audio)
Knob

 (Home) Icon

 (Menu) Icon

 (Back) Icon

 (Day/Night) Icon

Audio/Information Screen

For navigation system operation

()

 See the Navigation System Manual

*

 Not available on all models

20

Quick

 Referenc

e Guide

Audio Remote Controls

(P209)

(

+

 /

(

-

 Button

Press to adjust the volume up/down.

SOURCE

 Button

Press to change the audio mode:
FM/AM/SiriusXM

®

*

/USB/iPod/Pandora

®

*

/

Apps/Apple CarPlay/Android Auto/

Bluetooth

®

 Audio/AUX

(

+

 /

(

-

 Button

SOURCE



Button

 /

 Button

 /

 Button

Radio: Press to change the preset station.

Press and hold to select the next or
previous strong station.

iPod, USB flash drive, or

Bluetooth

®



Audio:

Press to skip to the beginning of
the next song or return to the
beginning of the current song.

USB flash drive, or

Bluetooth

®

 Audio:

Press and hold to change a folder.

Pandora

®

*

:

Press

 to skip to the next song.

Press and hold to select the next or
previous station.

21

Quick

 Referenc

e Guide

Driving

(P363)

Automatic Transmission

(P394)

Select

(

P

 and depress the brake pedal when starting the engine.

Park

Press the

(

P

 button.

Used when parking or before
turn off or start the engine.
Transmission is locked.

Reverse

Pull back the

(

R

 button.

Used when reversing.

Neutral

Press the

(

N

 button.

Transmission is not locked.

Shift Position Indicator

The Shift Position Indicator
indicates the current shift position.

Shift Position Indicator

Shift Button
Indicator

Shifting

Drive/S Position

Each time you press the

 button, the mode

switches between Drive and S position mode.
Used for:

Normal driving (gears change between 1st
and 9th automatically)

Temporarily driving in the sequential mode

Automatically changing gears between 1st
and 8th (8th gear is used only at high speed)

Driving in the sequential mode

D/S

Drive

S Position

*

 Not available on all models

22

Quick

 Referenc

e Guide

Sequential Mode

(P402)

Paddle shifters allow you to shift gears much like a manual
transmission (1st through 9th). This is useful for engine braking.

The transmission will shift back
to automatic mode once the
system detects that the vehicle
is cruising.

Shift Position Indicator

Shift Down

(

-



Paddle Shifter

Shift Up

(

+



Paddle Shifter

Sequential Mode Gear
Selection Indicator

M

 (sequential mode)

Indicator

When the transmission is in

(

D

Holds the selected gear, and
the

M

 (sequential mode)

indicator comes on.

The sequential mode gear
selection is shown in the
instrument panel.

When the transmission is in

(

S

23

Quick

 Referenc

e Guide

CMBS

TM

 On and Off

(P429)

When a possible frontal collision is likely
unavoidable, the CMBS

TM

 can help you to

reduce the vehicle speed and the severity
of the collision.

The CMBS

TM

 is turned on every time you

start the engine.

To turn the CMBS

TM

 on or off, press and

hold the button until you hear a beep.

VSA

®

 On and Off

(P413)

The Vehicle Stability Assist

TM

 (VSA

®

system helps stabilize the vehicle during
cornering, and helps maintain traction
while accelerating on loose or slippery
road surfaces.

VSA

®

 comes on automatically every time

you start the engine.

To partially disable or fully restore VSA

®



function, press and hold the button until
you hear a beep.

Tire Pressure Monitoring System (TPMS) with Tire
Fill Assist

(P416, 560)

The TPMS monitors tire pressure.

The TPMS is turned on automatically every time you start the engine.

The TPMS fill assist provides audible and visual guidance during tire pressure adjustment.

Refueling

(P483)

a

Press the fuel fill
door release button.

b

After refueling,
wait for about five
seconds before
removing the filler
nozzle.

Fuel recommendation: Unleaded gasoline, pump octane number 87 or

higher

Fuel tank capacity: 19.5 US gal (73.8 L)

24

Quick

 Referenc

e Guide

Honda Sensing

®

(P423)

Honda Sensing

®

 is a driver support system

which employs the use of two distinctly
different kinds of sensors, a radar sensor
located behind the emblem and a front
sensor camera mounted to the interior side
of the windshield, behind the rearview
mirror.

The camera is located
behind the rearview mirror.

Front
Sensor
Camera

Radar Sensor

The radar sensor is
behind the emblem.

Collision Mitigation
Braking System

TM



(CMBS

TM

(P426)

The system can assist you when it
determines there is a possibility of your
vehicle colliding with a vehicle or a
pedestrian detected in front of your vehicle.
The CMBS

TM

 is designed to alert you when

the potential for a collision is determined, as
well as to reduce your vehicle speed to help
minimize collision severity when a collision is
deemed unavoidable.

Adaptive Cruise Control
(ACC)

(P438)

Helps maintain a constant vehicle speed and
a set following-interval behind a vehicle
detected ahead of yours, without you
having to keep your foot on the brake or
the accelerator.

Lane Keeping Assist
System (LKAS)

(P451)

Provides steering input to help keep the
vehicle in the middle of a detected lane and
provides tactile and visual alerts if the
vehicle is detected drifting out of its lane.

Road Departure
Mitigation System

(P460)

Alerts and helps to assist you when the
system detects a possibility of your vehicle
unintentionally crossing over detected lane
markings and/or leaving the roadway
altogether.

25

Quick

 Referenc

e Guide

Maintenance

(P487)

Under the Hood

(P496)

Check engine oil, engine coolant, and windshield washer
fluid. Add when necessary.

Check brake fluid.

Check the battery condition monthly.

a

Pull the hood release handle under the corner of the
dashboard.

b

Locate the hood latch lever, push it to the side, and then
raise the hood. Once you have raised the hood slightly, you
can release the lever.

c

When finished, close the hood and make sure it is firmly
locked in place.

Lights

(P508)

Inspect all lights regularly.

Wiper Blades

(P514)

Replace blades if they leave streaks across
the windshield or become noisy.

Tires

(P516)

Inspect tires and wheels regularly.

Check tire pressures regularly.

Install snow tires for winter
driving.

26

Quick

 Referenc

e Guide

Handling the Unexpected

(P537)

Flat Tire

(P539)

Park in a safe location and replace the
flat tire with the compact spare tire
located in the trunk.

Indicators Come On

(P557)

Identify the indicator and consult the
owner’s manual.

Engine Won’t Start

(P549)

If the battery is dead, jump start using a
booster battery.

Blown Fuse

(P562)

Check for a blown fuse if an electrical
device does not operate.

Overheating

(P555)

Park in a safe location. If you do not see
steam under the hood, open the hood,
and let the engine cool down.

Emergency Towing

(P568)

Call a professional towing service if you
need to tow your vehicle.

















Content      ..      1       2         ..





///////////////////////////////////////
