Honda Pilot (2022 year). Manual in english - page 1

Quick

Referenc

e Guide

Auto Idle Stop Function

To improve fuel economy, the engine stops and then restarts as detailed below. When Auto Idle Stop is on, the Auto Idle Stop indicator
(green) comes on.

(P470)

Automatic transmission

Engine status

Deceleration

Stop the vehicle and depress the brake
pedal.

Stop

Keep the brake pedal depressed.

Start-up

Release the brake pedal.

Off

Restarting

Quick

Referenc

e Guide

Eco Assist

System

Ambient Meter

●

The color of the ambient meter changes
to green to indicate that the vehicle is
being driven in a fuel efficient manner.

ECON Button

(P475 )

Helps maximize fuel economy.

ECON Mode Indicator

(P88 )

Comes on when the

ECON

button is pressed.

The message is displayed for a few seconds when the

ECON

button is pressed.

Quick

Referenc

e Guide

Safe Driving

(P31)

Airbags

(P45)

●

Your vehicle is fitted with airbags to help protect you and
your passengers during a moderate-to-severe collision.

Child Safety

(P60)

●

All children 12 and younger should be seated in the rear seat.

●

Smaller children should be properly restrained in a forward-facing child seat.

●

Infants must be properly restrained in a rear-facing child seat.

Exhaust Gas Hazard

(P76)

●

Your vehicle emits dangerous exhaust gases that contain carbon
monoxide. Do not run the engine in confined spaces where carbon
monoxide gas can accumulate.

Before Driving Checklist

(P436)

●

Before driving, check that the front seats, head restraints,
steering wheel, and mirrors have been properly adjusted.

Seat Belts

(P37)

●

Fasten your seat belt and sit upright well
back in the seat.

●

Check that your passengers are wearing
their seat belts correctly.

Fasten your lap belt as
low as possible.

Quick

Referenc

e Guide

Instrument Panel

(P79)

System Indicators

Malfunction Indicator

Lamp

Charging System

Indicator

Anti-lock Brake System

(

ABS

) Indicator

Vehicle Stability

Assist

(VSA

) System

Indicator

Low Tire Pressure/

TPMS Indicator

Immobilizer System

Indicator/Security

System Alarm Indicator

Lights Indicators

Lights On Indicator

High Beam Indicator

Fog Light Indicator

Lane Keeping Assist
System (

LKAS

)

Indicator (Green/
Amber)

Seat Belt Reminder

Indicator

System Indicators

Econ Mode Indicator

System Message

Indicator

Parking Brake and
Brake System Indicator
(Red)

Supplemental

Restraint System

Indicator

Driver Information Interface

Tachometer

(Sequential mode) Indicator/

Sequential Mode Gear Selection Indicator

Speedometer

Fuel Gauge

Gear Position Indicator/

Transmission System

Indicator

Auto Idle Stop System

Indicator (Amber)/

Auto Idle Stop

Indicator (Green)

Gauges

(P108)

/Driver Information Interface

(P109)

/System

Indicators

(P80)

Adaptive Cruise

Control (

ACC

) Indicator

(Green/Amber)

Turn Signal and

Hazard Warning

Indicators

Electric Power Steering

(EPS) System Indicator

Blind spot information

System Indicator

Temperature Gauge

Parking Brake and
Brake System Indicator
(Amber)

U.S.

Canada

System Indicators

U.S.

Canada

Low Fuel Indicator

Auto High-Beam

Indicator

Road Departure

Mitigation (RDM)

Indicator

Collision Mitigation
Braking System

(CMBS

) Indicator

All-wheel drive

(

AWD

) Indicator

Intelligent Traction
Management
Indicator

Vehicle Stability

Assist

(VSA

) OFF

Indicator

Quick

Referenc

e Guide

Controls

(P123)

Clock

(P124)

To adjust time

To adjust date

Select

, then select

Settings

Select

System

, then

Date & Time

Select

Set Date & Time

Select

Automatic Date & Time

, then

select

OFF

Select

Set Date

Set Time

Adjust the dates, hours and minutes by
selecting /

3 4

Select

Save

to set the time.

The navigation system receives signals from
GPS satellites, updating the clock
automatically.

ENGINE START/STOP
Button

(P158)

Press the button to change the vehicle’s
power mode.

Models with navigation system

Turn Signals

(P161)

Lights

(P162)

Turn Signal Control Lever

Right

Left

Light Control Switches

Low Beam

High Beam

Flashing

Not available on all models

Quick

Referenc

e Guide

Wipers and Washers

(P170)

*1:Models with automatic intermittent

wipers

*2:Models without automatic intermittent

wipers

Wiper/Washer Control Lever

MIST
OFF
AUTO

: Wiper speed varies

automatically

INT

: Low speed with

intermittent

: Low speed wipe

: High speed wipe

Pull toward
you to spray
washer fluid.

Adjustment Ring
Low Sensitivity

Lower speed, fewer sweeps

High Sensitivity

Higher speed, more sweeps

(

AUTO

should always be turned

OFF

before

the following situations in order to prevent
severe damage to the wiper system:

●

Cleaning the windshield

●

Driving through a car wash

●

No rain present

Steering Wheel

(P178)

●

To adjust, push the adjustment lever
down, adjust to the desired position, then
pull up the lever back in place.

Models with automatic intermittent wipers

Unlocking the Front
Doors from the Inside

(P137)

●

Pull either front door inner handle to
unlock and open it at the same time.

Quick

Referenc

e Guide

Tailgate

(P140)

Use a forward and back kicking motion
under the center of the rear bumper to
open or close the power tailgate while
carrying the keyless remote.

Models with Hands Free Access

1 sec.

●

Press the tailgate outer handle to unlock
and open the tailgate when you carry the
keyless remote.

●

Press the power tailgate button on the
driver’s door or the remote transmitter to
open and close the power tailgate.

Outer Handle

Models without power tailgate

Models with power tailgate

Power Door Mirrors

(P180)

●

With the power mode in ON, move the
selector switch to

●

Push the appropriate edge of the
adjustment switch to adjust the mirror.

●

Press the folding button

to fold in and

out the door mirrors.

Selector Switch

Adjustment Switch

Folding Button

Not available on all models

Quick

Referenc

e Guide

Power Windows

(P153)

●

With the power mode in ON, open and
close the power windows.

●

If the power window lock button is in the
off position, each passenger’s window
can be opened and closed with its own
switch.

●

If the power window lock button is in the
on position (indicator is on), each
passenger’s window switch is disabled.

Power Window Lock Button

Indicator

Window Switch

Quick

Referenc

e Guide

Climate Control System

(P218)

●

Press the

AUTO

button to activate the climate control system.

●

Press the

button to turn the system on or off.

●

Press the

button to defrost the windshield.

Fan Control
Button

(Windshield

Defroster) Button

A/C

(Air

Conditioning)
Button

Air flows from floor and
windshield defroster vents.

Air flows from floor vents.

Air flows from floor and
dashboard vents.

Air flows from dashboard
vents.

(Recirculation)

Button

Passenger’s Side
Temperature
Control Switch

AUTO

Button

Driver’s Side
Temperature
Control Switch

Mode Control Button

SYNC

(Synchronization) Button

(On/Off) Button

Rear Climate Control

(P223)

●

Press the

AUTO

button to activate the

rear climate control system.

●

Press the

button to turn the system

on or off.

Rear Temperature
Control Buttons

(Rear Fan
Control) Buttons

Rear

AUTO

Button

(Rear On/

Off) Button

Mode Control Button

Air flows from the rear floor vents.

Air flow from the rear console
vents and floor vents.

Air flows from the rear console vents.

Quick

Referenc

e Guide

Features

(P225)

Audio system

(P226)

VOL

AUDIO

(Volume/Power) Knob

(Home) Icon

(Back) Icon

(Day/Night) Icon

Audio/Information Screen

For navigation system operation

()

See the Navigation System Manual

(Eject) Button

Disc Slot

Models with Blu-ray

player

Quick

Referenc

e Guide

Audio Remote Controls

(P230)

●

(

Bar

Press to adjust the volume up/down.

●

ENTER

Buttons

Press

to select

Now Playing

the home screen of the driver
information interface, and then press the

ENTER

button.

Press

to cycle through the audio

mode as follows:
Android Auto/Apple CarPlay/SiriusXM

Rear Entertainment

/AUX Input/AM/

Bluetooth

Audio/Social Playlist/FM/My

Honda Music/USB/iPod/CD

ENTER

Button

Buttons

(

Bar

Radio: Press

to change the

preset station.

/USB device/My Honda Music/

Bluetooth

Audio:

Press

to skip to the

beginning of the next song or
return to the beginning of the
current song.

Not available on all models

Quick

Referenc

e Guide

Driving

(P435)

Automatic Transmission

(P462)

●

Select

(

and depress the brake pedal when starting the engine.

Park

Press the

(

button.

Used when parking or before
turning off or starting the engine.
Transmission is locked.

Reverse

Pull back the

(

button.

Used when reversing.

Neutral

Press the

(

button.

Transmission is not locked.

Gear Position Indicator

The gear position indicator and the
shift button indicator indicate the
current gear selection.

Gear Position Indicator

Shift Button
Indicator

●

Gear selection

Intelligent Traction
Management Button

Drive/S Position

Each time you press the

button, the mode

switches between Drive and S position mode.
Used for:

●

Normal driving (gears change between 1st
and 9th automatically)

●

Temporarily driving in the sequential mode

●

Automatically changing gears between 1st
and 8th (8th gear is used only at high speed)

●

Driving in the sequential mode

D/S

Drive

S Position

Quick

Referenc

e Guide

Paddle Shifters

(P469)

●

Paddle shifters allow you to shift gears much like a manual
transmission (1st through 9th). This is useful for engine braking.

●

The transmission will shift back
to automatic mode once the
system detects that the vehicle
is cruising.

Gear Position Indicator

Shift Down

(

Paddle Shifter

Shift Up

(

Paddle Shifter

Sequential Mode Gear
Selection Indicator

(sequential

mode)
Indicator

When the transmission is in

(

●

Holds the selected gear, and
the

(sequential mode)

indicator comes on.

●

The sequential mode gear
selection is shown in the
instrument panel.

When the transmission is in

(

Quick

Referenc

e Guide

VSA

On and Off

(P479)

●

The Vehicle Stability Assist

(VSA

)

system helps stabilize the vehicle during
cornering, and helps maintain traction
while accelerating on loose or slippery
road surfaces.

●

VSA

comes on automatically every time

you start the engine.

●

To partially disable or fully restore VSA

function, press and hold the button until
you hear a beep.

CMBS

On and Off

(P497)

●

When a possible frontal collision is likely
unavoidable, the CMBS

can help you to

reduce the vehicle speed and the severity
of the collision.

●

The CMBS

is turned on every time you

start the engine.

●

To turn the CMBS

on or off, press and

hold the button until you hear a beep.

Tire Pressure Monitoring System (TPMS) with Tire
Fill Assist

(P487, 632)

●

The TPMS monitors tire pressure.

●

TPMS is turned on automatically every time you start the engine.

●

TPMS fill assist provides audible and visual guidance during tire pressure adjustment.

Refueling

(P553)

Press the fuel fill door
release button.

After refueling, wait for
about five seconds
before removing the
filler nozzle.

Fuel recommendation: Unleaded gasoline, pump octane number 87 or

higher

Fuel tank capacity: 19.5 US gal (73.8 L)

Quick

Referenc

e Guide

Honda Sensing

(P491)

Honda Sensing

is a driver support system

which employs the use of two distinctly
different kinds of sensors, a radar sensor
located behind the emblem and a front
sensor camera mounted to the interior side
of the windshield, behind the rearview
mirror.

The camera is located
behind the rearview
mirror.

Front Sensor
Camera

Radar Sensor

The radar sensor is
behind the emblem.

Collision Mitigation
Braking System

(CMBS

)

(P494)

The system can assist you when it
determines there is a possibility of your
vehicle colliding with a vehicle or a
pedestrian detected in front of your vehicle.
The CMBS

is designed to alert you when

the potential for a collision is determined, as
well as to reduce your vehicle speed to help
minimize collision severity when a collision is
deemed unavoidable.

Adaptive Cruise Control
(ACC)

(P506)

Helps maintain a constant vehicle speed and
a set following-interval behind a vehicle
detected ahead of yours, without you
having to keep your foot on the brake or
the accelerator.

Lane Keeping Assist
System (LKAS)

(P519)

Provides steering input to help keep the
vehicle in the middle of a detected lane and
provides tactile and visual alerts if the
vehicle is detected drifting out of its lane.

Road Departure
Mitigation (RDM) System

(P528)

Alerts and helps to assist you when the
system detects a possibility of your vehicle
unintentionally crossing over detected lane
markings and/or leaving the roadway
altogether.
