Continued

75

uu

Child Safety

u

Safety of Infants and Small Children

Safe

Driving

A tether anchor point is provided behind each
rear seating position.
If you have a child seat that comes with a
tether but can be installed with a seat belt, the
tether may be used for additional security.

1.

Locate the appropriate tether anchor point
and lift the cover.

2.

Route the tether strap over the head
restraint. Make sure the strap is not twisted.

3.

Secure the tether strap hook to the anchor.

4.

Tighten the tether strap as instructed by the
child seat manufacturer.

■

Adding Security with a Tether

1

Adding Security with a Tether

Always use a tether for forward-facing child seats
whether using the seat belt or lower anchors.

Tether Anchor Points

Cover

Anchor

Anchor

Tether Strap

Hook

Other Top Tether Type

in Outer Position

Anchor

Tether Strap

Hook

Straight Top Tether Type

in Outer Position

76

uu

Child Safety

u

Safety of Infants and Small Children

Safe

Driving

Anchor

Tether Strap

Hook

Straight Top Tether Type

in Center Position

Anchor

Tether Strap

Hook

Other Top Tether Type

in Center Position

77

uu

Child Safety

u

Safety of Larger Children

Continued

Safe

Driving

Safety of Larger Children

The following pages give instructions on how to check proper seat belt fit, what kind
of booster seat to use if one is needed, and important precautions for a child who
must sit in front.

When a child is too big for a child seat, secure the child in a rear seat using the lap/
shoulder seat belt. Have the child sit upright and all the way back, then answer the
following questions.

■

Checklist

•

Do the child’s knees bend comfortably over
the edge of the seat?

•

Does the shoulder belt cross between the
child’s neck and arm?

•

Is the lap part of the seat belt as low as
possible, touching the child’s thighs?

•

Will the child be able to stay seated like this
for the whole trip?

If you answer yes to all these questions, the child is ready to wear the lap/shoulder
seat belt correctly. If you answer no to any question, the child needs to ride on a
booster seat until the seat belt fits properly without a booster seat.

■

Protecting Larger Children

■

Checking Seat Belt Fit

1

Safety of Larger Children

3

WARNING

Allowing a child age 12 or under to sit in
front can result in injury or death if the
passenger’s front airbag inflates.

If a larger child must ride in front, move the
vehicle seat as far to the rear as possible,
have the child sit up properly and wear the
seat belt properly, using a booster seat if
needed.

uu

Child Safety

u

Safety of Larger Children

78

Safe

Driving

If a lap/shoulder seat belt cannot be used
properly, position the child in a booster seat in
the rear seat. For the child’s safety, check that
the child meets the booster seat
manufacturer’s recommendations.

Your vehicle has a rear seat where children can be properly restrained. If you ever
have to carry a group of children, and a child must ride in front:

•

Make sure you read and fully understand the instructions and safety information
in this manual.

•

Move the front passenger seat as far back as possible.

•

Have the child sit upright and well back in the seat.

•

Check that the seat belt is properly positioned so that the child is secure in the
seat.

■

Monitoring child passengers

We strongly recommend that you keep an eye on child passengers. Even older, more
mature children sometimes need to be reminded to fasten their seat belts and sit up
properly.

■

Booster Seats

1

Booster Seats

When installing a booster seat, make sure to read the
instructions that came with it, and install the seat
accordingly.
There are high- and low-type booster seats. Choose a
booster seat that allows the child to wear the seat
belt correctly.

Some U.S. states require children to use a booster
seat until they reach a given age or weight (e.g. 6
years or 60 lbs). Be sure to check current laws in the
state where you intend to drive.

■

Protecting Larger Children-Final Checks

79

Safe

Driving

Exhaust Gas Hazard

Carbon Monoxide Gas

The engine exhaust from this vehicle contains carbon monoxide, a colorless,
odorless, and highly toxic gas. As long as you properly maintain your vehicle, carbon
monoxide gas will not get into the interior.

■

Have the exhaust system inspected for leaks whenever

•

The exhaust system is making an unusual noise.

•

The exhaust system may have been damaged.

•

The vehicle is raised for an oil change.

When you operate a vehicle with the trunk open, airflow can pull exhaust gas into
the interior and create a hazardous condition. If you must drive with the trunk open,
open all the windows and set the climate control system as shown below.

1.

Select the fresh air mode.

2.

Select the

 mode.

3.

Set the fan speed to high.

4.

Set the temperature control to a comfortable setting.

Adjust the climate control system in the same manner if you sit in your parked
vehicle with the engine running.

1

Carbon Monoxide Gas

An enclosed area such as a garage can quickly fill up
with carbon monoxide gas.
Do not run the engine with the garage door closed.
Even when the garage door is open, drive out of the
garage immediately after starting the engine.

3

WARNING

Carbon monoxide gas is toxic.

Breathing it can cause unconsciousness and
even kill you.

Avoid any enclosed areas or activities that
expose you to carbon monoxide.

80

Safe

Driving

Safety Labels

Label Locations

These labels are in the locations shown. They warn you of potential hazards that can cause serious injury or death. Read these labels
carefully.

If a label comes off or becomes hard to read (except for the dashboard label which may be removed by the owner), contact a dealer for a
replacement.

Sun Visor

Radiator Cap

Dashboard

Air Conditioner System

Radiator Cap

82

In

strum

ent Pa

nel

Indicators

Deceleration Paddle

Selector Indicator



 P. 89

Parking Brake and

Brake System

Indicator (Red)

Parking Brake and

Brake System

Indicator (Amber)

Automatic Brake

Hold System Indicator

Automatic Brake Hold

Indicator

*1 : When you set the power mode to ON, these indicators come on to indicate that system checks are being performed. They go off a few seconds later or after the power

system has started. If an indicator does not come on or turn off, there may be a malfunction in the corresponding system. To resolve the issue, follow the instructions in
the owner’s manual.



 P. 83

Malfunction Indicator

Lamp

12-Volt Battery

Charging System

Indicator

Anti-lock Brake System

(

ABS

) Indicator

Seat Belt Reminder

Indicator

Low Fuel Indicator

Vehicle Stability Assist

TM



(VSA

®

) System Indicator

Vehicle Stability Assist

TM



(VSA

®

)

OFF

 Indicator

Supplemental Restraint

System Indicator

Auto High-Beam

Indicator

Low Tire Pressure/TPMS

Indicator

Electric Power Steering

(EPS) System Indicator

Turn Signal and Hazard

Warning Indicators

Lights On Indicator

High Beam Indicator

Fog Light Indicator

*

ECON Mode Indicator

System Message Indicator

SPORT

 Mode Indicator

Adaptive Cruise Control

(

ACC

) with Low Speed

Follow Indicator (Amber)

Lane Keeping Assist

System (

LKAS

) Indicator

(Amber)

Safety Support Indicator

(Amber)

Safety Support Indicator

(Green/Gray)



 P. 84



 P. 85



 P. 85



 P. 88



 P. 89

*1

*1

*1



 P. 94

*1

*1

Shift Position Indicator



 P. 89

Transmission System

Indicator



 P. 90



 P. 91



 P. 91



 P. 92



 P. 92



 P. 95



 P. 93

*1

*1

*1



 P. 93

*1



 P. 92



 P. 95



 P. 98

*1



 P. 95



 P. 95



 P. 97



 P. 95



 P. 97



 P. 97



 P. 99



 P. 100



 P. 103

*1

Adaptive Cruise Control

(

ACC

) with Low Speed

Follow Indicator (Green)



 P. 99

*1

Lane Keeping Assist

System (

LKAS

) Indicator

(Green)



 P. 99

*1

POWER SYSTEM



Indicator



 P. 86

*1

READY

 Indicator



 P. 87

EV

 Indicator



 P. 87

*1

EV

 Mode Indicator



 P. 87

*1

*1

Immobilizer System

Indicator



 P. 96

Security System Alarm

Indicator



 P. 96

*1

*1

* Not available on all models

83

uu

Indicators

u

Continued

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Parking Brake
and Brake
System
Indicator (Red)

•

Comes on when the parking brake
is applied, and goes off when it is
released.

•

Comes on when the brake fluid
level is low.

•

Comes on if there is a problem with
the brake system.

•

The beeper sounds and the
indicator comes on if you drive with
the parking brake applied.

•

Comes on for about 30 seconds
when you pull or push the electric
parking brake switch when the
power mode is in ACCESSORY or
VEHICLE OFF.

•

Stays on for about 30 seconds
when you set the power mode to
VEHICLE OFF while the electric
parking brake is set.

•

Comes on while driving

- Make sure

the parking brake is released. Check the
brake fluid level.

2

What to do when the indicator
comes on while driving

 P. 572

•

Comes on along with the brake system
indicator (amber)

 - Immediately stop in a

safe place. Contact a dealer for repair. The
brake pedal becomes harder to operate.
Depress the pedal further than you
normally do.

•

Comes on along with the ABS
indicator

- Have your vehicle checked by

a dealer.

2

If the Brake System Indicator (Red)
Comes On or Blinks

 P. 572

•

Blinks and the brake system indicator
(amber) comes on at the same time

-

There is a problem with the electric
parking brake system. The parking brake
may not be set.
Avoid using the parking brake and have
your vehicle checked by a dealer
immediately.

2

If the Brake System Indicator (Red)
Comes On or Blinks at the Same Time
When the Brake System Indicator
(Amber) Comes On

 P. 573

84

uu

Indicators

u

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Parking Brake
and Brake
System
Indicator
(Amber)

•

Comes on if there is a problem with
a system related to braking other
than the conventional brake
system.

•

Comes on if there is a problem with
the cooperative control with
regenerative braking, the electric
servo brake system, or the hill start
assist system.

•

Comes on if there is a problem with
the electric parking brake system.

•

Stays on constantly

- Avoid high speeds

and sudden braking. Take the vehicle to a
dealer immediately.

•

Comes on while driving

- Avoid using

the parking brake and have your vehicle
checked by a dealer immediately.

●

Comes on if there is a problem with
the radar sensor.

●

Indicator may come on temporarily
when the Maximum Load Limit is
exceeded.

●

Make sure the total load is within the
Maximum Load Limit.

2

Maximum Load Limit

 P. 379

●

Stays on constantly

- Have your vehicle

checked by a dealer.

•

Comes on if there is a problem with
the automatic brake hold system.

2

Automatic Brake Hold

 P. 473

85

uu

Indicators

u

Continued

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Automatic
Brake Hold
System
Indicator

●

Comes on when the automatic
brake hold system is on.

2

Automatic Brake Hold

 P. 473

Automatic
Brake Hold
Indicator

●

Comes on when the automatic
brake hold is activated.

2

Automatic Brake Hold

 P. 473

—

86

uu

Indicators

u

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

POWER
SYSTEM



Indicator

●

Comes on if there is a problem with
the electric vehicle system.

●

Comes on when the High Voltage
battery temperature becomes high.

●

Have your vehicle checked by a dealer.

87

uu

Indicators

u

Continued

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

READY



Indicator

●

Comes on when the vehicle is ready
to drive.

2

Turning on the Power

 P. 382

EV

 Indicator

●

Comes on when the vehicle is
moved by the motor, and the
engine is not operating.

—

—

EV

 Mode

Indicator

●

Comes on when the vehicle is in EV
mode.

2

SPORT HYBRID i-MMD (intelligent
Multi-Mode Drive)

 P. 11

88

uu

Indicators

u

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Malfunction
Indicator Lamp

•

After you have set the power mode
to ON, the vehicle performs system
checks. However, if the readiness
codes have not been set by that
time, this indicator will blink five
times and then go off.

•

Comes on if there is a problem with
the emissions control system.

•

Blinks when a misfire in the
engine’s cylinders is detected.

•

Comes on if the fuel fill cap is loose
or missing.

•

Readiness codes are part of the on board
diagnostics for the emissions control
systems.

2

Testing of Readiness Codes

 P. 593

•

Comes on while driving

- Have your

vehicle checked by a dealer.

•

Blinks while driving

- Stop in a safe

place where there are no flammable
objects. Stop the power system for 10
minutes or more, and wait for it to cool
down. Then, take your vehicle to a dealer.

2

If the Malfunction Indicator Lamp
Comes On or Blinks

 P. 571

•

Comes on

- Check the fuel cap before

taking your vehicle to a dealer.

89

uu

Indicators

u

Continued

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

12-Volt Battery
Charging
System
Indicator

•

Comes on when there is a problem
with the charging system.

•

Stop in a safe place and have your vehicle
checked by a dealer immediately.

2

If the 12-Volt Battery Charging
System Indicator Comes On

 P. 570

Shift Position
Indicator

•

Indicates the current shift position.

2

Shifting

 P. 391

—

Deceleration
Paddle Selector
Indicator

•

Comes on when the paddle selector
is pulled.

•

Blinks when deceleration does not
occur while pulling the paddle
selector.

•

Comes on with

M

 when

SPORT



mode is selected and pulling the
paddle selector.

2

Deceleration Paddle Selector

 P. 398

—

90

uu

Indicators

u

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Transmission
System
Indicator

•

The current shift position blinks if
the transmission system has a
problem.

•

Blinks while driving

- Avoid sudden

starts and acceleration and have your
vehicle checked by a dealer immediately.

•

The current shift position or all the
shift positions blink if there is a
problem with the transmission and
the vehicle is no longer able to run.

•

Immediately park your car in a safe place.

2

Emergency Towing

 P. 583

•

Have your vehicle checked by a dealer.

•

The current shift position or all the
shift positions blink if there is a
problem with the transmission and
it is not possible to select

(

P

.

•

While the vehicle is stopped, apply the
parking brake.

•

Have your vehicle checked by a dealer
immediately.

91

uu

Indicators

u

Continued

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Seat Belt
Reminder
Indicator

•

Blinks and the beeper sounds for a
few seconds if you are not wearing
a seat belt when you set the power
mode to ON, then the indicator
comes on.

•

If the front passenger is not
wearing a seat belt, the indicator
comes on a few seconds later.

•

Blinks while driving if either you
and/or the front passenger has not
fastened a seat belt. The beeper
sounds and the indicator blinks at
regular intervals.

•

The beeper stops and the indicator goes
off when you and the front passenger
fasten their seat belts.

•

Stays on after you and/or the front
passenger has fastened the seat
belt(s)

- A detection error may have

occurred in the sensor. Have your vehicle
checked by a dealer.

2

Seat Belt Reminder

 P. 45

Low Fuel
Indicator

•

Comes on when the fuel reserve is
running low (approximately 1.59
U.S. gal.).

•

Blinks if there is a problem with the
fuel gauge.

•

Comes on

- Refuel your vehicle as soon

as possible.

•

Blinks

- Have your vehicle checked by a

dealer.
