Honda HR-V eHEV (2022 year). Manual in english

Quick

Referenc

e Guide

CMBS On and Off

●

When a possible frontal collision is likely
unavoidable, the CMBS can help you to
reduce the vehicle speed and the severity
of the collision.

●

The CMBS is turned on every time you
start the power system.

●

To turn the CMBS on or off, use the safety
support switch.

VSA On and Off

(P390)

●

The Vehicle Stability Assist (VSA) system
helps to stabilise the vehicle during
cornering, and helps to maintain traction
while accelerating on loose or slippery
road surfaces.

●

VSA comes on automatically every time
you start the power system.

●

To partially disable or fully restore VSA
function, press and hold the

button

until you hear a beep.

Deflation Warning
System

(P392)

●

Detects a change in tyre conditions and
overall dimensions due to decrease in tyre
pressures.

●

The Deflation Warning System is turned
on automatically every time you turn on
the power system.

●

A calibration procedure must be
performed when certain conditions arise.

Adjustable Speed Limiter

(P376)

This system enables you to set a maximum
speed that cannot be exceeded even if you
are depressing the accelerator pedal.

●

To use the adjustable speed limiter, press

the

button. Select the adjustable

speed limiter by pressing the

LIM

button,

then press the

SET/−

button when your

vehicle reaches the desired speed.

●

The vehicle speed limit can be set from 30
km/h (18 mph) to 250 km/h (156 mph).

Quick

Referenc

e Guide

Refueling

(P495)

Pull the fuel fill door release handle.

Turn the fuel fill cap slowly to remove the cap.

Place the cap in the holder on the fuel fill door.

After refueling, screw the cap back on until it
clicks at least once.

Fuel recommendation:

EN 228 standards petrol/gasohol fuel
Unleaded premium petrol/gasohol up to E10 (90% petrol and 10% ethanol), research octane
number 95 or higher

Fuel tank capacity:

40 L (8.8 Imp gal)

Quick

Referenc

e Guide

Honda Sensing

(P402)

Honda Sensing is a driver support system
which employs the use of two distinctly
different kinds of sensors, a front wide view
camera mounted to the interior side of the
windscreen, behind the rearview mirror, and
the sonar sensors located in the front and
rear bumpers.

Front Wide
View Camera

Sonar Sensors

Collision Mitigation
Braking System (CMBS)

(P 405)

The system can assist you when it
determines there is a possibility of your
vehicle colliding with a vehicle (including
motorcycles) ahead from behind, an
oncoming vehicle in front, a pedestrian, or
someone riding a bicycle (moving bicycle).
The CMBS is designed to alert you when the
potential for a collision is determined, as
well as assist in reducing speed, avoiding
collisions, and reducing collision severity.

Low Speed Braking
Control

(P 417)

Using sonar sensors located on the front and
rear bumpers, this system detects if there is
danger of a potential collision with a wall or
other obstacle during normal driving or
when the accelerator pedal is depressed
with too much force. The system then assists
in avoiding collisions and reducing damage
from impact through assistive braking and/
or assistive driving power suppression.

Adaptive Cruise Control
(ACC) with Low Speed
Follow

(P 423)

Helps to maintain a constant vehicle speed
and a set following-interval behind a vehicle
detected ahead of yours and, if the detected
vehicle comes to a stop, can decelerate and
stop your vehicle, without you having to
keep your foot on the brake or the
accelerator.

Lane Keeping Assist
System (LKAS)

(P 441)

Provides steering input to help to keep the
vehicle in the middle of a detected lane and
provides tactile, audible and visual alerts if
the vehicle is detected drifting out of its
lane.

Quick

Referenc

e Guide

Road Departure
Mitigation System

(P 453)

Alerts and helps to assist you when the
system detects a possibility of your vehicle
crossing over detected lane markings, or
approaching the outer edge of the
pavement (into grass or gravel border) or an
oncoming vehicle.

Traffic Sign Recognition
System

(P 461)

Reminds you of road sign information, such
as the current speed limit and that
overtaking is prohibited, your vehicle has
just passed through, showing it on the
gauge.

Quick

Referenc

e Guide

Maintenance

(P499)

Under the Bonnet

(P517)

●

Check engine oil, engine coolant, and windscreen washer
fluid. Add when necessary.

●

Check brake fluid.

●

Check the 12-volt battery condition monthly.

Pull the bonnet release handle under the corner of the
dashboard.

Locate the bonnet latch lever, push it to the side, and
then raise the bonnet. Once you have raised the
bonnet slightly, you can release the lever.

When finished, close the bonnet and make sure it is
firmly locked in place.

Lights

(P530)

●

Inspect all lights regularly.

Wiper Blades

(P536)

●

Replace blades if they leave streaks
across the windscreen or become noisy.

Tyres

(P541)

●

Inspect tyres and wheels regularly.

●

Check tyre pressures regularly.

●

Install winter tyres for winter
driving.

Quick

Referenc

e Guide

Handling the Unexpected

(P567)

Flat Tyre

(P569)

●

Park in a safe location and repair the flat
tyre using the tyre repair kit.

Indicators Come On

(P593)

●

Identify the indicator and consult the
owner’s manual.

Power System Won’t
Start

(P583)

●

If the 12-volt battery is dead, jump start
using a booster battery.

Blown Fuse

(P600)

●

Check for a blown fuse if an electrical
device does not operate.

Overheating

(P591)

●

Park in a safe location. If you do not see
steam under the bonnet, open the
bonnet, and let the power system cool
down.

Emergency Towing

(P606)

●

Call a professional towing service if you
need to tow your vehicle.

Quick

Referenc

e Guide

What to Do If

The power mode does not
change from VEHICLE OFF
(LOCK) to ACCESSORY.
Why?

●

The steering wheel may be locked.

●

Move the steering wheel left and right
after pressing the

POWER

button.

The power mode does not
change from ACCESSORY
to VEHICLE OFF (LOCK).
Why?

The shift lever should be moved to

(

Why does the brake pedal
pulsate slightly when
applying the brakes?

This can occur when the ABS activates and does not indicate a
problem. Apply firm, steady pressure on the brake pedal. Never
pump the brake pedal.

Anti-lock Brake System (ABS)

(P478)

Quick

Referenc

e Guide

The rear door cannot be
opened from inside the
vehicle. Why?

Check if the childproof lock is in the
lock position. If so, open the rear door
with the outside door handle.
To cancel this function, slide the lever
up to the unlock position.

Why do the doors lock
after I unlocked the doors?

If you do not open the doors within 30 seconds, the doors are
relocked automatically for security.

Why does the beeper
sound when I open the
driver’s door?

The beeper sounds when:

●

The power mode is in ACCESSORY.

●

The exterior lights are left on.

Why does the beeper
sound when I start driving?

The beeper sounds when the driver and/or front passenger are
not wearing their seat belts.

Pressing the electric
parking brake switch does
not release the parking
brake. Why?

Press the electric parking brake switch with the brake pedal
depressed.

Quick

Referenc

e Guide

I’m seeing an amber
indicator of a tyre with an
exclamation point. What is
that?

The Deflation Warning System needs attention. If you recently
inflated or changed a tyre, you have to recalibrate the system.

Deflation Warning System

(P392)

Depressing the accelerator
pedal does not release the
parking brake
automatically. Why?

•

Fasten the driver’s seat belt.

•

Check if the transmission is in

(

. If so, select any other

position.

Why do I hear a screeching
sound when I apply the
brake pedal?

The brake pads may need to be replaced. Have your vehicle
inspected by a dealer.

Is it possible to use
unleaded petrol with a
Research Octane Number
(RON) of 91 or higher on
this vehicle?

Your vehicle is designed to operate on premium unleaded
petrol with a research octane of 95 or higher. If this octane
grade is unavailable, regular unleaded petrol with a research
octane of 91 or higher may be used temporarily.
The use of regular unleaded petrol can cause metallic knocking
noises in the engine and will result in decreased engine
performance. The long-term use of regular-grade petrol can
lead to engine damage.

Safe Driving

For Safe Driving

The following pages explain your vehicle’s safety features and how to use them
properly. The safety precautions below are ones that we consider to be among the
most important.

Important Safety Precautions

■

Always wear your seat belt

A seat belt is your best protection in all types of collisions. Airbags are designed to
supplement seat belts, not replace them. So even though your vehicle is equipped
with airbags, make sure you and your passengers always wear your seat belts, and
wear them properly.

■

Restrain all children

Children aged 12 and under should ride properly restrained in a back seat, not the
front seat. Infants and small children should be restrained in a child restraint system.
Larger children should use a booster seat and a lap/shoulder seat belt until they can
use the belt properly without a booster seat.

■

Be aware of airbag hazards

While airbags can save lives, they can cause serious or fatal injuries to occupants
who sit too close to them, or are not properly restrained. Infants, young children,
and short adults are at the greatest risk. Be sure to follow all instructions and
warnings in this manual.

■

Don’t drink and drive

Alcohol and driving don’t mix. Even one drink can reduce your ability to respond to
changing conditions, and your reaction time gets worse with every additional drink.
So don’t drink and drive, and don’t let your friends drink and drive, either.

Important Safety Precautions

Some countries prohibit the use of mobile phones
other than hands-free devices by the driver while
driving.

For Safe Driving

Important Safety Precautions

Safe Driving

■

Pay appropriate attention to the task of driving safely

Engaging in mobile phone conversation or other activities that keep you from paying
close attention to the road, other vehicles, and pedestrians could lead to a crash.
Remember, situations can change quickly, and only you can decide when it is safe to
divert some attention away from driving.

■

Control your speed

Excessive speed is a major factor in crash injuries and deaths. Generally, the higher
the speed, the greater the risk, but serious injuries can also occur at lower speeds.
Never drive faster than is safe for current conditions, regardless of the maximum
speed posted.

■

Keep your vehicle in safe condition

Having a tyre blowout or a mechanical failure can be extremely hazardous.
To reduce the possibility of such problems, check your tyre pressures and condition
frequently, and perform all regularly scheduled maintenance.

■

Do not leave children unattended in the vehicle

Children, pets, and people needing assistance left unattended in the vehicle may be
injured if they activate one or more of the vehicle controls. They may also cause the
vehicle to move, resulting in a crash in which they and/or another person(s) can be
injured or killed. Also, depending on the ambient temperature, the temperature of
the interior may reach extreme levels, which can result in harm or death. Even if the
climate control system is on, never leave them in the vehicle unattended as the
climate control system can shut off at any time.

For Safe Driving

Important Handling Information

Safe Driving

Important Handling Information

Your vehicle has higher ground clearance than a passenger vehicle designed for use
only on pavement. Higher ground clearance has many advantages for off-road
driving. It allows you to travel over bumps, obstacles, and rough terrain. It also
provides good visibility so you can anticipate problems earlier.

These advantages come at some cost. Because your vehicle is taller and rides higher
off the ground, it has a higher centre gravity making it more susceptible to tipping
or rollover if you make abrupt turns. Utility vehicles have a significantly higher
rollover rate than other types of vehicles. In a rollover crash, an unbelted person is
significantly more likely to die than a person wearing a seat belt. As a reminder,
make sure you and your passengers always wear seat belts.

Important Handling Information

For information on how to reduce the risk of rollover,
read:

Driving Guidelines for Your Utility Vehicle

P. 362

Off-road Guidelines

P. 357

Failure to operate your vehicle correctly might result
in a crash or a rollover.

In many countries, the law prohibits off-road driving,
e. g. driving in forests, trailblazing, etc. Please check
your local laws and regulations before commencing
any off-road driving activity.

For Safe Driving

Your Vehicle’s Safety Features

Safe Driving

Your Vehicle’s Safety Features

The following checklist will help you take an active role in protecting yourself and
your passengers.

Your Vehicle’s Safety Features

Your vehicle is equipped with many features that
work together to help to protect you and your
passengers during a crash.

Some features do not require any action on your part.
These include a strong steel framework that forms a
safety cage around the passenger compartment,
front and rear crush zones, a collapsible steering
column, and tensioners that tighten the front and
rear outer seat belts in a sufficient crash.

However, you and your passengers cannot take full
advantage of these features unless you remain seated
in the correct position and always wear your seat
belts. In fact, some safety features can contribute to
injuries if they are not used properly.

Crush Zones

Safety Cage

Front Airbags

Side Curtain Airbags

Seat Belts

Side Airbags

Seats and Seat-Backs

Head Restraints

Automatic Seat Belt Tensioners

Collapsible Steering Column

For Safe Driving

Safety Checklist

Safe Driving

Safety Checklist

For the safety of you and your passengers, make a habit of checking these items
each time before you drive.

•

Adjust your seat to a position suitable for driving. Be sure the front seats are
adjusted as far to the rear as possible while allowing the driver to control the
vehicle. Sitting too close to a front airbag can result in serious or fatal injury in a
crash.

Seats

P. 207

•

Adjust head restraints to the proper position. Head restraints are most effective
when the centre of the head restraint aligns with the centre of your head. Taller
persons should adjust their head restraint to the highest position.

Adjusting the Front Head Restraints

P. 215

•

Always wear your seat belt, and make sure you wear it properly. Confirm that any
passengers are properly belted as well.

Fastening a Seat Belt

P. 50

•

Protect children by using seat belts or child restraint systems according to a child’s
age, height, and weight.

Child Safety

P. 73

Safety Checklist

If the door and/or tailgate open message appears on
the driver information interface, a door and/or the
tailgate is not completely closed. Close all doors and
the tailgate tightly until the message disappears.

Driver Information Interface Warning and
Information Messages

P. 120

Continued

Safe Driving

Seat Belts

About Your Seat Belts

Seat belts are the single most effective safety device because they keep you
connected to the vehicle so that you can take advantage of many built-in safety
features. They also help to keep you from being thrown against the inside of the
vehicle, against any passengers, or out of the vehicle. When worn properly, seat
belts also keep your body properly positioned in a crash so that you can take full
advantage of the additional protection provided by the airbags.

In addition, seat belts help to protect you in almost every type of crash, including:

frontal impacts

side impacts

rear impacts

rollovers

About Your Seat Belts

WARNING:

Seat belts are designed to bear upon the

bony structure of the body, and should be worn low
across the front of the pelvis or the pelvis, chest and
shoulders, as applicable; wearing the lap section of
the belt across the abdominal area must be avoided.

WARNING:

Seat belts should be adjusted as firmly as

possible, consistent with comfort, to provide the
protection for which they have been designed. A
slack belt will greatly reduce the protection afforded
to the wearer.

WARNING:

Belts should not be worn with straps

twisted.

WARNING:

Each belt assembly must only be used by

one occupant; it is dangerous to put a belt around a
child being carried on the occupant’s lap.

WARNING

Not wearing a seat belt properly increases
the chance of serious injury or death in a
crash, even though your vehicle has
airbags.

Be sure you and your passengers always
wear seat belts and wear them properly.

Honda HR-V eHEV (2022 year). Manual in english - page 2
