Honda e (2021 year). Manual in english

Quick

Referenc

e Guide

High Voltage Battery

The High Voltage battery gradually discharges when the vehicle is not in use. If allowed to discharge too much, the battery may become
damaged.
If your vehicle is parked for an extended period of time, during storage for example, periodically recharge the battery to maintain sufficient
charge levels. At least once every three months, recharge the High Voltage battery.
Excessive heat can also damage the battery. On hot, sunny days, try to avoid parking your vehicle under direct sunlight.
If the High Voltage battery becomes fully discharged or damaged and you are unable to start the power system as a result, consult a dealer.

Temperature

When storing the vehicle, make sure not to expose it to extremely low temperatures:
If the temperature of the High Voltage battery drops to -30°C or below, the power system will not start. Wait for the High Voltage battery
to warm up or move the vehicle to a warmer location. Note using the battery heating system will not help in this case.

Quick

Referenc

e Guide

Maintenance, Repair, and Disposal

Always consult a dealer regarding maintenance, repair, and disposal.
High Voltage batteries that have been removed from disposed vehicles are collected
through a dealer. Do not dispose of these batteries yourself.

In Case of a Crash

●

Be careful of electric shock hazard.

If a severe crash damaged your vehicle’s High Voltage system, there is a possibility of
electrical shock due to exposed High Voltage components or wires. If this happens, do
not touch any of the High Voltage system components or any of its orange wires.

●

Avoid contact with High Voltage battery fluid.

The High Voltage battery contains a flammable electrolyte that could leak as a result
of a severe crash. Avoid any skin or eye contact with the electrolyte as it is corrosive.
If you accidentally touch it, flush your eyes or skin with a large quantity of water for at
least five minutes, and seek medical attention immediately.

●

Use a fire extinguisher for an electrical fire.

Attempting to extinguish an electrical fire with a small quantity of water, from a
garden hose for instance, can be dangerous.

●

Anytime the vehicle is damaged in an accident, have it repaired by a dealer.

Emergency Shutdown System for the High Voltage
System

The emergency shutdown system may activate when the vehicle is impacted by a crash or a
collision. When this system activates, the High Voltage system automatically shuts down,
and your vehicle no longer moves.
To return the High Voltage system to normal operation, consult a dealer.

WARNING

High voltage parts and/or the cables
(orange) connecting them may be exposed
as a result of a crash. Stay clear of these
parts as you may be electrocuted.

If High Voltage battery fluid leaks, be
careful not to touch the fluid. It can harm
your eyes and skin. If it comes in contact
with your eyes and skin; flush the affected
area with clean water immediately for a
few minutes, and seek immediate medical
attention.

Quick

Referenc

e Guide

Regenerative Energy and Regenerative Braking

When decelerating or while driving downhill, the electric motor acts as a generator that recovers a portion of the electrical energy that was
used to accelerate the vehicle.
In the following situations, the vehicle generates electricity while decelerating.

●

The accelerator pedal is released with the shift position in

(

●

The brake pedal is depressed with the shift position in

(

When the High Voltage battery is fully charged or its temperature is too cold/hot, or another factor or factors are affecting the
condition of the battery, the regenerative braking system may not be activated.

●

The deceleration paddle selector is used with the shift position in

(

You can control the rate of deceleration by using the deceleration paddle selector.

Quick

Referenc

e Guide

Safe Driving

(P39)

Airbags

(P57)

●

Your vehicle is fitted with airbags to help to protect you and
your passengers during a moderate-to-severe collision.

Child Safety

(P75)

●

All children 12 and younger should be seated in the rear seat.

●

Small children should be properly restrained in a front facing child restraint
system.

●

Infants must be properly restrained in a rear-facing child restraint system on a
rear seat.

Before Driving Checklist

(P44)

●

Before driving, check that the front seats, head restraints,
steering wheel, and mirrors have been properly adjusted.

Seat Belts

(P45)

●

Fasten your seat belt and sit upright well
back in the seat.

●

Check that your passengers are wearing
their seat belts correctly.

Fasten your lap belt as
low as possible.

Quick

Referenc

e Guide

Instrument Panel

(P105)

Gauges

(P154)

/Driver Information Interface

(P156)

/System Indicators

(P130)

Deceleration Paddle Selector Indicator

(P114)

Speedometer

(P154)

Driver Information Interface

(P156)

POWER/CHARGE

Gauge

(P154)

High Voltage Battery Charge Level Gauge

(P154)

Shift Position Indicator

(P113)

Traffic Sign Recognition System

(P155)

Quick

Referenc

e Guide

Controls

(P171)

Clock

(P274)

You can adjust the clock and customize the
clock display.

(P274)

POWER Button

(P197)

Press the button to change the vehicle’s
power mode.

Turn Signals

(P202)

Lights

(P201)

Turn Signal Control Lever

Right

Left

Light Control Switches

Low Beam

High Beam

Flashing the high beams

Wipers and Washers

(P210)

AUTO

should always be turned

OFF

before

the following situations in order to prevent
severe damage to the wiper system:

•

Cleaning the windscreen

•

Driving through a car wash

•

No rain present

Wiper/Washer Control Lever

MIST
OFF
AUTO

: Wiper speed varies

automatically

: Low speed wipe

: High speed wipe

Pull toward
you to spray
washer fluid.

Adjustment Ring

(

: Low Sensitivity

(

: High Sensitivity

Quick

Referenc

e Guide

Steering Wheel

(P214)

●

To adjust, push the adjustment lever
down, adjust to the desired position, then
lock the lever back in place.

To adjust

To lock

Lever

Unlocking the Front
Doors from the Inside

(P182)

●

Pull either front door inner handle to
unlock and open it at the same time.

●

When you open any door from inside the
vehicle by using the inner handle, front
door outer handles pop out.

Tailgate

(P186)

●

Press the outer handle to unlock and
open the tailgate when you carry the
keyless remote on you.

Quick

Referenc

e Guide

Side Camera Mirror
System

(P221)

●

With the power mode in ON, move the

L/R

selector switch to

●

Push the appropriate edge of the
adjustment switch to adjust the field of
view.

L/R

Selector Switch

Adjustment Switch

Power Windows

(P194)

●

With the power mode in ON, open and
close the power windows.

●

If the power window lock button is in the
off position, each passenger’s window
can be opened and closed with its own
switch.

●

If the power window lock button is in the
on position (indicator on), each
passenger’s window switch is disabled.

Power Window Lock Button

Window Switch

Indicator

Quick

Referenc

e Guide

Climate Control System

(P247)

●

Press the

AUTO

button to activate the climate control system.

●

Press the

button to turn the system on or off.

●

Press the

button to defrost the windscreen.

Air flows from
dashboard
vents.

Air flows from
floor and
dashboard
vents.

Air flows from
floor vents.

Air flows from
floor and
windscreen
demister vents.

AUTO

Button

Temperature Control Dial

Fan Control Dial

MODE

Control Button

(Windscreen Demister) Button

(On/Off) Button

A/C

(Air Conditioning) Button

(Recirculation) Button

Quick

Referenc

e Guide

Features

(P253)

Audio System

(P 256)

(Home) Button

Shortcut Icon

(Brightness) Button

Assistant Screen

Centre Screen

VOL

Knob

Shortcut Icon

AUDIO

(Power/Audio) Button

Quick

Referenc

e Guide

Audio Remote Controls

(P 261)

●

VOL

(

VOL

(

(Volume) Buttons

Press to adjust the volume up/down.

●

Left Selector Wheel
When selecting the audio mode
Press the

(home) button, then roll up

or down to select

(audio) on the

driver information interface, and then
press the left selector wheel.

(Seek/Skip) Buttons

Left
Selector
Wheel

VOL

(

VOL

(

(Volume) Buttons

(Home)

Button

(Back) Button

Roll up or down:

To cycle through the audio

modes, roll up or down and then press the
left selector wheel:
FM/DAB/iPod/USB/Apple CarPlay/
Android Auto/

Bluetooth

Audio/HDMI

Depending on a connected device, the
displayed modes may be changed.

●

(Seek/Skip) Buttons

Depending on a connected device, the
displayed modes may be changed.

Radio:Press

to change the

preset radio station.

iPod, USB drive,

Bluetooth

Audio or

Smartphone Connection:

Press

to skip to the

beginning of the next song or
return to the beginning of the
current song.

Radio:Press and hold

change the strong station.

USB drive:

Press and hold

change a folder.

iPod: Press and hold

change a song.

Quick

Referenc

e Guide

Driving

(P 375)

Reverse

Press back the

(

button.

Used when reversing.

Neutral

Press the

(

button.

Transmission is not locked.

Drive

Press the

(

button.

Used for normal driving.

The deceleration paddle selector can be used temporarily.

The deceleration paddle selector can be used.

When not use the single pedal control

When use the single pedal control

Shift Position Indicator

The shift position indicator
and the shift button
indicator indicate the
current gear selection.

Shift Position Indicator

Shift Button
Indicator

Shift Operation

Electronic Gear Selector

(P386 )

●

Select

(

and depress the brake pedal when turning on the power.

Parking

Press the

(

button.

Used when parking or before turning the power on or off.
Transmission is locked.

Quick

Referenc

e Guide

When you release the accelerator pedal, you can control the rate of deceleration
without releasing your hands from the steering wheel. Using the deceleration
paddle selector situated on the steering wheel, you can sequentially shift through
four

or three

stages of deceleration.

●

*1: When the Single Pedal Control is OFF
If you pull back the paddle selector, the rate of deceleration will change
temporarily, and the stage will appear in the instrument panel.

●

*2: When the Single Pedal Control is ON
If you pull back the paddle selector, the rate of deceleration will change and the
stage along with

will appear in the instrument panel.

Deceleration Paddle Selector

(P395)

Single Pedal Control

(P398)

(

Paddle

Selector

Deceleration Paddle
Selector Indicator

(

Paddle

Selector

When the Single
Pedal Control is OFF,
the deceleration
stage appears.

When the Single Pedal
Control is ON, the
deceleration stage
and

appear.

Deceleration Paddle
Selector Indicator

VSA On and Off

(P 419)

●

The Vehicle Stability Assist (VSA) system
helps stabilise the vehicle during
cornering and helps maintain traction
while accelerating on loose or slippery
road surfaces.

●

VSA comes on automatically every time
you turn on the power system.

●

To partially disable VSA functionality/

features, press the

(VSA

OFF

) icon

(green) is in the safety config of the
audio/information screen.

CMBS On and Off

(P 326, 434)

●

When a possible collision is likely
unavoidable, the CMBS can help you to
reduce the vehicle speed and the severity
of the collision.

●

The CMBS is turned on every time you
start the power system.

●

To turn the CMBS on or off, use the
audio/information screen or the safety
support of the driver information
interface.

Quick

Referenc

e Guide

Deflation Warning
System

(P 420)

●

Detects a change in tyre conditions and
overall dimensions due to decrease in tyre
pressures.

●

The Deflation Warning System is turned
on automatically every time you turn on
the power system.

●

A calibration procedure must be
performed when certain conditions arise.

Adjustable Speed Limiter

(P 405)

●

This system enables you to set a maximum
speed that cannot be exceeded even if
you are depressing the accelerator pedal.

●

To use the adjustable speed limiter, press

the

button. Select the adjustable

speed limiter by pressing the

LIM

button,

then press the

SET/−

button when your

vehicle reaches the desired speed.

●

The vehicle speed limit can be set from 30
km/h (18 mph) to 250 km/h (156 mph).

Quick

Referenc

e Guide

Honda Sensing

(P427 )

Honda Sensing is a driver support system
which employs the use of two distinctly
different kinds of sensors, a radar sensor
located behind the emblem and a front
sensor camera mounted to the interior side
of the windshield, behind the rearview
mirror.

The camera is
located behind the
rearview mirror.

Front Sensor
Camera

Radar
Sensor

The radar sensor
is in the front
grille.

Collision Mitigation
Braking System (CMBS)

(P 430)

Can assist you when there is a possibility of
your vehicle colliding with a vehicle,
pedestrian on foot or riding a bicycle
(moving bicycle) detected in front of yours.
The CMBS is designed to alert you when a
potential collision is determined, as well as
assist in reducing speed, avoiding collisions,
and reducing collision severity.

Low Speed Braking
Control

(P 441)

The Low Speed Braking Control system has
three functions: Low Speed Brake function,
Collision Mitigation Throttle Control, and
Rear Collision Mitigation Throttle Control.
Using sonar sensors located on the front and
rear bumpers, the vehicle detects if there
danger of collision with a wall or other
obstacle when the accelerator is depressed
with too much force, and the system assists
in avoiding collisions and reducing damage
from impact by limiting power system
output.

Adaptive Cruise Control
(ACC) with Low Speed
Follow

(P 447)

Helps to maintain a constant vehicle speed
and a set following-interval behind a vehicle
detected ahead of yours and, if the detected
vehicle comes to a stop, can decelerate and
stop your vehicle, without you having to
keep your foot on the brake or the
accelerator.

Lane Keeping Assist
System (LKAS)

(P 467)

Provides steering input to help keep the
vehicle in the middle of a detected lane and
provides tactile and visual alerts if the
vehicle is detected drifting out of its lane.

Road Departure
Mitigation System

(P 478)

Alerts and helps to assist you when the
system detects a possibility of your vehicle
unintentionally crossing over detected lane
markings and/or leaving the roadway
altogether.

Honda e (2021 year). Manual in english - page 2
