Honda Ridgeline (2019 year). Instruction - part 36





uu

Cleaning

u

Interior Care

560

Main

tenan

ce

The front and rear seat floor mats hook over
the floor anchors, which keep mats them from
sliding forward. To remove a mat for cleaning,
turn the anchor knobs to the unlock position.
When reinstalling the mat after cleaning, turn
the knobs to the lock position.

Do not put additional floor mats on top of
the anchored mats.

Vacuum dirt and dust from the leather frequently. Pay close attention to the pleats
and seams. Clean the leather with a soft cloth dampened with a 90% water and
10% neutral soap solution. Then buff it with a clean, dry cloth. Remove any dust or
dirt on leather surfaces immediately.

Floor Mats

1

Floor Mats

If you use any floor mats that were not originally
provided with your vehicle, make sure they are
designed for your specific vehicle, fit correctly, and
are securely anchored by the floor anchors.
Position the rear seat floor mat properly. If they are
not properly positioned, the floor mats can interfere
with the front seat functions.

Lock

Unlock

Maintaining Genuine Leather

*

* Not available on all models

561

uu

Cleaning

u

Exterior Care

Continued

Main

tenan

ce

Exterior Care

Dust off the vehicle body after you drive.
Regularly inspect your vehicle for scratches on painted surfaces. A scratch on a
painted surface can result in body rust. If you find a scratch, promptly repair it.

Wash the vehicle regularly. Wash more frequently when driving in the following
conditions:
• If driving on roads with road salt.
• If driving in coastal areas.
• If tar, soot, bird droppings, insects, or tree sap are stuck to painted surfaces.

Use a water and mild detergent solution, and
a soft brush or cloth to clean the inside of the
trunk.

To drain water from the trunk, remove the
drain plug by turning it counter-clockwise.

u

When you are finished washing the
trunk, dry it with a soft cloth, and
reinstall the drain plug.

Washing the Vehicle

Washing the Trunk

1

Washing the Vehicle

Do not spray water into the air intake vents or engine
compartment. It can cause a malfunction.

Do not spray water on to the capless unit when the
fuel fill door is open.  It can cause damage to the fuel
system or engine.

Air Intake Vents

Drain plug

uu

Cleaning

u

Exterior Care

562

Main

tenan

ce

• Make sure to follow the instructions indicated on the automated car wash.
• Fold in the door mirrors.
• Automatic intermittent wipers

*

 equipment vehicles, wipers switch to OFF.

• Keep sufficient distance between the cleaning nozzle and the vehicle body.
• Take particular care around the windows. Standing too close may cause water to

enter the vehicle interior.

• Do not spray high pressure water directly into the engine compartment. Instead,

use low pressure water and a mild detergent.

A good coat of automotive body wax helps protect your vehicle’s paint from the
elements. Wax will wear off over time and expose your vehicle’s paint to the
elements, so reapply as necessary.

Using an Automated Car Wash

Using High Pressure Cleaners

Applying Wax

1

Applying Wax

NOTICE

Chemical solvents and strong cleaners can damage
the paint, metal, and plastic on your vehicle. Wipe
away spills immediately.

* Not available on all models

Continued

563

uu

Cleaning

u

Exterior Care

Main

tenan

ce

If you get gasoline, oil, engine coolant, or battery fluid on resin coated parts, they
may be stained or the coating may peel. Promptly wipe it away using a soft cloth and
clean water.

Wipe using a glass cleaner.

Aluminum is susceptible to deterioration caused by salt and other road
contaminants. Use a sponge and mild detergent to wipe away promptly.
Be careful not to use harsh chemicals (including some commercial wheel cleaners) or
a stiff brush. They can damage the clear coat of the aluminum alloy wheels that help
keep the aluminum from corroding and tarnishing.

Maintaining the Bumpers and Other Resin Coated Parts

Cleaning the Window

Maintaining Aluminum Wheels

1

Maintaining the Bumpers and Other Resin Coated Parts

Ask a dealer about the correct coating material when
you want to repair the painted surface of the parts
made of resin.

564

uu

Cleaning

u

Exterior Care

Main

tenan

ce

The inside lenses of exterior lights (headlights, brake lights, etc.) may fog temporarily
if you have driven in the rain, or after the vehicle has been run through a car wash.
Dew condensation also may build up inside the lenses when there is a significant
enough difference between the ambient and inside lens temperatures (similar to
vehicle windows fogging up in rainy conditions). These conditions are natural
processes, not structural design problems in the exterior lights.
Lens design characteristics may result in moisture developing on the light lens frame
surfaces. This also is not a malfunction.
However, if you see large amounts of water accumulation, or large water drops
building up inside the lenses, have your vehicle inspected by a dealer.

Fogged Exterior Light Lenses

565

Main

tenan

ce

Accessories and Modifications

Accessories

When installing accessories, check the following:
• Do not install accessories on the windshield. They can obstruct your view and

delay your reaction to driving conditions.

• Do not install any accessories over areas marked SRS Airbag, on the sides or backs

of the front seats, on front or side pillars, or near the side windows. Accessories
installed in these areas may interfere with proper operation of the vehicle’s
airbags or may be propelled into you or another occupant if the airbags deploy.

• Be sure electronic accessories do not overload electrical circuits or interfere with

proper operation of your vehicle.

Fuses P. 591

• Before installing any electronic accessory, have the installer contact a dealer for

assistance. If possible, have a dealer inspect the final installation.

• Your vehicle should not be used to carry a slide-in camper. If you install a truck

cap, be sure it is properly installed and does not exceed your vehicle’s load limits.

Maximum Load Limit P. 415

1

Accessories and Modifications

Honda Genuine accessories are recommended to
ensure proper operation on your vehicle.

3

WARNING

Improper accessories or modifications can
affect your vehicle’s handling, stability, and
performance, and cause a crash in which
you can be seriously hurt or killed.

Follow all instructions in this owner’s
manual regarding accessories and
modifications.

566

uu

Accessories and Modifications

u

Modifications

Main

tenan

ce

Modifications

Do not modify your vehicle in a manner that may affect its handling, stability, or
reliability, or install non-genuine Honda parts or accessories that may have a similar
effect.
Even minor modifications to vehicle systems can affect overall vehicle performance.
Always make sure all equipment is properly installed and maintained, and do not
make any modification to your vehicle or its systems that might cause your vehicle
to no longer meet federal, state, province, territory, and local regulations.

The on-board diagnostic port (OBD-II/SAE J1962 connector) installed on this vehicle
is intended to be used with automobile system diagnostic devices or with other
devices that Honda has approved. Use of any other type of device may adversely
affect the vehicle’s electronic systems or allow them to be compromised, possibly
resulting in a system malfunction, drained battery, or other unexpected problems.

Do not modify or attempt to repair any of the electrical components.

568

Han

d

lin
g the U

n

expected

Tools

Types of Tools

1

Types of Tools

The tools are stored in the trunk.

Wheel Nut Wrench/
Jack Handle

Jack

Jack Handle Bar

Funnel

Trunk

569

Continued

Han

d

lin
g the U

n

expected

If a Tire Goes Flat

Changing a Flat Tire

If a tire goes flat while driving, grasp the steering wheel firmly, and brake gradually
to reduce speed. Then, stop in a safe place. Replace the flat tire with a compact
spare tire. Go to a dealer as soon as possible to have the full-size tire repaired or
replaced.

1. Park the vehicle on firm, level, non-slippery surface and apply the parking brake.
2. Move the shift lever to

(

P.

3. Turn on the hazard warning lights and set the power mode to VEHICLE OFF

(LOCK).

1

Changing a Flat Tire

Follow compact spare precautions:
Periodically check the tire pressure of the compact
spare. It should be set to the specified pressure.
Specified Pressure: 60 psi (420 kPa, 4.2 kgf/cm

2

)

When driving with the compact spare tire, keep the
vehicle speed under 50 mph (80 km/h). Replace with
a full-size tire as soon as possible.

The compact spare tire and wheel in your vehicle are
specifically for this model. Do not use them with
another vehicle. Do not use another type of compact
spare tire or wheel with your vehicle.

Do not mount tire chains on a compact spare tire.
If a chain-mounted front tire goes flat, remove one of
the full-size rear tires and replace it with the compact
spare tire. Remove the flat front tire and replace it
with the full-size tire that was removed from the rear.
Mount the tire chains on the front tire.

Do not use a puncture-repairing agent on a flat tire,
as it can damage the tire pressure sensor.

uu

If a Tire Goes Flat

u

Changing a Flat Tire

570

Han

d

lin
g the U

n

expected

1. Open the trunk.
2. Remove the two tire tray holding bolts.

3. Pull out the tire tray with the handles, and

hook the rear of the tire tray to the guides
on the back edge of the trunk.

4. Loosen the strap, then take the jack out.

Getting Ready to Replace the Flat Tire

1

Changing a Flat Tire

NOTICE

Do not use the jack if it doesn’t work properly. Call
your dealer or a professional towing service.

Tire Tray

Tire Tray Holding Bolts

Handles

Strap

Jack

571

uu

If a Tire Goes Flat

u

Changing a Flat Tire

Continued

Han

d

lin
g the U

n

expected

5. Unscrew the wing bolt, and remove the

tool box and the spacer cone. Then, remove
the compact spare tire.

6. Place a wheel block or rock in front and rear

of the wheel diagonal to the flat tire.

7. Place the compact spare tire, wheel side up

under the vehicle body, near the tire that
needs to be replaced.

Wing Bolt

Spacer Cone

Tool Box

Wheel Blocks

The tire to be replaced.

572

uu

If a Tire Goes Flat

u

Changing a Flat Tire

Han

d

lin
g the U

n

expected

8. Loosen each wheel nut about one turn

using the wheel nut wrench.

Continued

573

uu

If a Tire Goes Flat

u

Changing a Flat Tire

Han

d

lin
g the U

n

expected

1. Place the jack under the jacking point

closest to the tire to be changed.

2. Turn the end bracket clockwise as shown in

the image until the top of the jack contacts
the jacking point.

u

Make sure that the jacking point tab is
resting in the jack notch.

3. Raise the vehicle, using the jack handle bar

and the jack handle, until the tire is off the
ground.

How to Set Up the Jack

1

How to Set Up the Jack

Do not use the jack with people or luggage in the
vehicle.

Use the jack provided in your vehicle.
Other jacks may not support the weight (“load”) or
their shape may not match.

The following instructions must be followed to use
the jack safely:

Do not use while the engine is running.

Use only where the ground is firm and level.

Use only at the jacking points.

Do not get in the vehicle while using the jack.

Do not put anything on top of or underneath the
jack.

3

WARNING

The vehicle can easily roll off the jack,
seriously injuring anyone underneath.

Follow the directions for changing a tire
exactly, and never get under the vehicle
when it is supported only by the jack.

Jacking Points

Jack Handle Bar

Wheel Nut Wrench as Jack Handle

uu

If a Tire Goes Flat

u

Changing a Flat Tire

574

Han

d

lin
g the U

n

expected

1. Remove the wheel nuts and flat tire.

2. Wipe the mounting surfaces of the wheel

with a clean cloth.

3. Mount the compact spare tire.
4. Screw the wheel nuts until they touch the

lips around the mounting holes, then stop
rotating.

5. Lower the vehicle and remove the jack.

Tighten the wheel nuts in the order
indicated in the image. Go around,
tightening the nuts, two to three times in
this order.
Wheel nut torque:
94 lbf∙ft (127 N∙m, 13 kgf∙m)

Replacing the Flat Tire

1

Replacing the Flat Tire

Do not over tighten the wheel nuts by applying extra
torque using your foot or a pipe.

Continued

575

uu

If a Tire Goes Flat

u

Changing a Flat Tire

Han

d

lin
g the U

n

expected

1. Wrap a cloth around the tip of a small flat-

tip screwdriver. Put it into the cap as shown
in the image, and remove the cap.

2. Remove the center cap and place the tire on

the pickup bed.

3. Place the spacer cone onto the wheel hub,

then secure the flat tire to the pickup bed
with the wing bolt as shown.

4. Securely store the jack on the tire tray using

the strap.

5. Release the tire tray and slide it back in

place.

6. Tighten the tire tray holding bolts securely.
7. Store the center cap and the tool box in the

trunk.

u

Make sure it does not get scratched or
damaged.

If you remove the tire from the pickup bed,
reinstall the cap to its original location.

Securing the Flat Tire on the Pickup Bed

1

Securing the Flat Tire on the Pickup Bed

3

WARNING

Loose items can be thrown out of the
vehicle in a crash and could seriously injure
the occupants.

Store the wheel, jack, and tools securely
before driving.

Cap

Wing Bolt

Spacer Cone

uu

If a Tire Goes Flat

u

Changing a Flat Tire

576

Han

d

lin
g the U

n

expected

As a temporary mounting location, you may secure the compact spare tire on the
pickup bed, if needed.

1. Wrap a cloth around the tip of a small flat-

tip screwdriver. Put it into the cap as shown
in the image, and remove the cap.

2. Remove the compact spare tire from the

tire tray.

Getting Ready to Replace the Flat Tire

P. 570

3. Place the compact spare tire on the pickup

bed as shown.

4. Place the spacer cone on the wheel hub and

the spacer washer within the spacer cone.
Then secure the compact spare tire to the
pickup bed with the wing bolt as shown.

5. Store or secure the tool box.

If you remove the compact spare tire from the
pickup bed, reinstall the cap to its original
location.

Securing a Compact Spare Tire on the Pickup Bed

1

Securing a Compact Spare Tire on the Pickup Bed

The spacer washer is stored in the tool box.

Cap

Spacer Cone

Wing Bolt

Spacer Washer















Content   ..  34  35  36  37   ..
