Honda Ridgeline (2019 year). Instruction - part 22





336

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

System

Clock

Clock Display

Selects whether the clock display comes on.

On

*1

/Off

Clock Location

Changes the clock display layout.

Upper Right

*1

/Upper

Left/Lower Right/
Lower Left/Off

Clock Reset

Resets the clock settings to the factory default.

Yes/No

Others

Language

Changes the display language.

English

*1

/French/

Spanish

Touch Panel Sensitivity

Sets the sensitivity of the touch panel screen.

High/Low

*1

Detail Information

Displays the Android setting items.

Factory Data Reset

Resets all the settings to their factory default.

Defaulting All the Settings P. 348

Yes/No

Default

Cancels/Resets all customized items in the System settings group as default.

Yes/No

337

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle

Driver
Assist
System
Setup

*

Forward Collision Warning
Distance

Changes at which distance CMBS

TM

 alerts.

Long/Normal

*1

/Short

ACC Forward Vehicle
Detect Beep

Causes the system to beep when the system
detects a vehicle, or when the vehicle goes out of
the ACC range.

On/Off

*1

Road Departure Mitigation
Setting

Changes the setting for the road departure
mitigation system.

Normal

*1

/Wide/

Warning Only

Lane Keeping Assist
Suspend Beep

Causes the system to beep when the LKAS is
suspended.

On/Off

*1

Blind Spot Info

*

Changes the setting for the blind spot
information.

Audible and Visual
Alert

*1

/Visual Alert/

Off

* Not available on all models

338

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle

Meter
Setup

Language Selection

Changes the displayed language on the multi-
information display.

English

*1

/French/

Spanish

Adjust Outside Temp
Display

Adjusts the temperature reading by a few degrees.

-5°F ~ ±0°F

*1

 ~ +5°F

(U.S.)
-3°C ~ ±0°C

*1

 ~ +3°C

(Canada)

“Trip A” Reset Timing

Changes the setting of how to reset trip meter A and
average fuel economy A.

With Refuel/IGN Off/
Manually Reset

*1

“Trip B” Reset Timing

Changes the setting of how to reset trip meter B and
average fuel economy B.

With Refuel/IGN Off/
Manually Reset

*1

Adjust Alarm Volume

Changes the alarm volume, such as the buzzers,
warnings, turn signal sound, and so on.

High/Mid

*1

/Low

Turn by Turn Display

*

Selects whether the turn-by-turn display comes on
during the route guidance.

On

*1

/Off

Display km/Miles

Selects the trip computer units.

Auto/km/Miles

*1

(U.S.)
Auto/km

*1

/Miles

(Canada)

* Not available on all models

339

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle

Driving
Position
Setup

Easy Entry/Exit

Moves the seat rearward when you get in/get out of
the vehicle. Changes the setting for this feature.

On

*1

/Off

Memory Position Link

*

Turns the driving position memory system on and off.

On

*1

/Off

Keyless
Access
Setup

Door Unlock Mode

Changes which doors unlock when you grab the
driver’s door handle.

Driver Door Only

*1

/

All Doors

Keyless Access Light Flash

Causes some exterior lights to flash when you unlock/
lock the doors.

On

*1

/Off

Keyless Access Beep

Causes the beeper to sound when you unlock/lock the
doors.

On

*1

/Off

Remote Start System On/
Off

Turns the remote engine start feature on and off.

On

*1

/Off

Walk Away Auto Lock

Changes the settings for the automatic locking the
doors when you walk away from the vehicle while
carrying the smart entry remote.

Enable/Disable

*1

* Not available on all models

340

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle

Lighting
Setup

Interior Light Dimming
Time

Changes the length of time the interior lights stay
on after you close the doors.

60 sec/30 sec

*1

/15 sec

Headlight Auto Off Timer

Changes the length of time the exterior lights
stay on after you close the driver’s door.

60 sec/30 sec/
15 sec

*1

/0 sec

Auto Interior Illumination
Sensitivity

*

Changes the sensitivity of the brightness of the
instrument panel when the headlight switch is in
the AUTO position.

Min/Low/Mid

*1

/

High/Max

Auto Headlight On with
Wiper On

*

Changes the settings for the wiper operation
when the headlights automatically come on
while the headlight switch is in the AUTO
position.

Off/On

*1

Auto Light Sensitivity

Changes the timing for the headlights to come
on.

Max/High/Mid

*1

/

Low/Min

* Not available on all models

341

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle

Door
Setup

Auto Door Lock

Changes the setting for the automatic locking
feature.

With Vehicle
Speed

*1

/Shift from P/

Off

Auto Door Unlock

Changes the setting for when the doors unlock
automatically.

All Doors with
Driver’s Door
Opens

*1

/All Doors

with Shift to P/All
Doors with IGN Off
/
Off

Key and Remote Unlock
Mode

Sets up either the driver’s door or all doors to
unlock on the first push of the remote or built-in
key.

Driver Door

*1

/All

Doors

Keyless Lock Answer Back

LOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds.

On

*1

/Off

Security Relock Timer

Changes the time it takes for the doors to relock
and the security system to set after you unlock
the vehicle without opening any door.

90 sec/60 sec/30 sec

*1

Mainte
nance
Info.

Maintenance Reset

Resets the engine oil life display when you have
performed the maintenance service.

Default

Cancels/Resets all customized items in the
Vehicle group as default.

Yes/No

342

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Audio

Common

Sound

Adjusts the settings of the audio speakers’
sound.

Adjusting the Sound P. 243

-6 ~ 0

*1

 ~ +6 (BASS and TREBLE),

RR9~0

*1

 ~FR9 (FADER),

L90

*1

~R9 (BALANCE),

-6 ~ 0

*1

  ~ +6 (Center and

Subwoofer),
Off/Low/Mid

*1

/

High (Speed Volume
Compensation
)

Audio Source Pop-
Up

Selects whether the list of selectable audio
source comes on when Audio is selected
on the home screen.

On/Off

*1

[Your selected media]
Cover Art

Turns the cover art display on and off.

On

*1

/Off

Bluetooth Device
List

Pairs a new phone to HFL, edits or deletes
a paired phone.

Phone Setup P. 385

FM/AM

HD Radio Mode

*

Selects whether the audio system
automatically switches to the digital radio
waves or receives the analog waves only.

Auto

*1

/Analog

RDS INFO

Turns on and off the RDS information.

On

*1

/Off

iPod or USB mode

FM/AM mode

* Not available on all models

343

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Audio

SXM

*

Tune Start

Turns on and off, starts the song from the
beginning as you change preset stations.

On

*1

/Off

SportsFlash Setup
(Interrupt)

Turns on and off the sports alert function.

Off

*1

/On (one time)/

On (continue)

SportsFlash Setup
(Interrupt Beep)

Causes the system to beep when there is a sports
alert notification.

On/Off

*1

SportsFlash Setup
(Favorite Team)

Selects your favorite sports teams.

Live Sports Alert P. 259

Traffic & Weather
Setup

Selects the region you want to receive the
information.

Default

Cancels/Resets all customized items in the Audio
settings group as default.

Yes/No

SiriusXM® mode

* Not available on all models

344

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Clock/
Info

Clock

Clock/Wallpaper
Type

Clock

See

System

 on P. 335, 336

Wallpaper

Clock
Adjustment

Clock Format

Date Format

Auto Time Zone

*

Manual Time
Zone

*

Auto Daylight

Clock Display

Clock Location

Clock Reset

HondaLink

Diagnostic & Location Data

Turns HondaLink® on and off.

On/Off

*1

Other

Info Screen Preference

Changes the information screen type.

Info Top/Info Menu

*1

/Off

Default

Cancels/Resets all customized items in the
Clock/Info settings group as default.

Yes/No

* Not available on all models

345

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Phone

Phone

Bluetooth Device
List

Pairs a new phone to HFL, connects or disconnects a
paired phone.

Phone Setup P. 385

Edit Speed Dial

Edits, adds or deletes a speed dial entry.

Speed Dial P. 391

Ring Tone

Selects the ring tone.

Fixed/Mobile Phone

*1

Automatic Phone
Sync

Sets phonebook and call history data to be
automatically imported when a phone is paired to
HFL.

On

*1

/Off

HondaLink Assist

Turns HondaLink® Assist on and off.

On

*1

/Off

Text/Email

Enable Text/Email

Turns the text/e-mail message function on and off.

On/Off

*1

Select Account

Selects a text or e-mail message account.

New Message
Notification

Selects whether a pop-up alert comes on the screen
when HFL receives a new text/e-mail messages.

On/Off

Default

Cancels/Resets all customized items in the Phone
settings group as default.

Yes/No

346

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Camera

Rear Camera

Fixed Guideline

Selects whether the fixed guidelines come on the
rear camera monitor.

Multi-View Rear Camera P. 512

On

*1

/Off

Dynamic Guideline

Selects whether the dynamic guidelines come on the
rear camera monitor.

Multi-View Rear Camera P. 512

On

*1

/Off

Default

Cancels/Resets all customized items in the Rear
Camera
 setting group as default.

Yes/No

LaneWatch

*

Show with Turn
Signal

Selects whether the LaneWatch display comes on
when you move the turn signal lever to indicate a
right turn.

On

*1

/Off

Display Time after
Turn Signal Off

Changes the length of time the LaneWatch display
stays on after the turn signal lever returns to the
center.

0 second

*1

/2 seconds

Reference Line

Selects whether the reference lines come on the
LaneWatch monitor.

On

*1

/Off

Default

Cancels/Resets all customized items in the
LaneWatch group as default.

Yes/No

Cross Traffic Monitor

*

Turns on and off the cross traffic monitor.

On

*1

/Off

* Not available on all models

347

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Bluetooth/
Wi-Fi

Bluetooth

Bluetooth On/Off
Status

Selects to display the Bluetooth® status.

On

*1

/Off

Bluetooth Device
List

Pairs a new phone to HFL, edits or deletes a paired
phone, or creates a security PIN.

Phone Setup P. 385

Edit Pairing Code

Edits a pairing code.

To change the pairing code setting P. 386

Random/Fixed

*1

Wi-Fi

Wi-Fi On/Off Status

Changes the Wi-Fi mode.

On/Off

*1

Wi-Fi Network List

Connects, disconnects, or deletes the Wi-Fi network.

Wi-Fi Information

Shows the Wi-Fi information of the head unit.

Default

Cancels/Resets all customized items in the
Bluetooth/Wi-Fi group as default.

Yes/No

Smart
phone

Apple
CarPlay

Sets up the Apple CarPlay connection.

Android
Auto

Sets up the Android Auto connection.

348

uu

Customized Features

u

Defaulting All the Settings

Features

Defaulting All the Settings

Reset all the menu and customized settings as the factory defaults.

1. Select .
2. Select Settings.
3. Select System.
4. Select the Others tab.
5. Select Factory Data Reset.

u

A confirmation message appears on the
screen.

6. Select Yes to reset the settings.
7. Select Yes again to reset the settings.

u

A confirmation message appears on the
screen. Select OK.

u

After selecting OK, the system will
reboot.

Models with Display Audio

1

Defaulting All the Settings

When you transfer the vehicle to a third party, reset
all settings to default and delete all personal data.

If you perform Factory Data Reset, it will reset the
preinstalled apps to their factory default.

If you perform Factory Data Reset, you cannot use
the HondaLink® because it becomes off line.

HondaLink® P. 279

349

Features

HomeLink® Universal Transceiver

*

The HomeLink® Universal Transceiver can be programmed to operate up to three
remote controlled devices around your home, such as garage doors, lighting, or
home security systems.

Refer to the safety information that came with your garage door opener to test that
the safety features are functioning properly. If you do not have the safety
information, contact the manufacturer.

Before programming HomeLink, make sure that people and objects are out of the
way of the garage or gate to prevent potential injury or damage.

When programming a garage door opener, park just outside the garage door’s path.

Important Safety Precautions

1

HomeLink® Universal Transceiver

*

Before programming HomeLink to operate a garage
door opener, confirm that the opener has an external
entrapment protection system, such as an “electronic
eye,” or other safety and reverse stop features. If it
does not, HomeLink may not be able to operate it.

* Not available on all models

350

uu

HomeLink® Universal Transceiver

*

u

Training HomeLink

Features

Training HomeLink

If it is necessary to erase a previously entered
learned code:
• Press and hold the two outside buttons for

about 20 seconds, until the red indicator
blinks. Release the buttons, and proceed to
step 1.

• If you are training the second or third

button, go directly to step 1.

The instructions on the next page should work for most gate or garage openers, but
may not work for all. For detailed instructions about your specific remote opener,
visit http://www.homelink.com or call (800) 355-3515.

Red Indicator

Models without moonroof

Red Indicator

Models with moonroof

351

uu

HomeLink® Universal Transceiver

*

u

Training HomeLink

Features

Training a Button

1

Training HomeLink

Retraining a Button
If you want to retrain a programmed button for a
new device, you do not have to erase all button
memory. You can replace the existing memory code
using this procedure:

1. Press and hold the desired HomeLink button

until the HomeLink indicator begins to blink.

2. Quickly release the HomeLink button and follow

steps 1 - 3 under “Training a Button.” You do not
need to press and release the HomeLink button
again in step 2.

Indicator remains on
for about 25 secs.

Standard transmitter

Indicator remains on for
about 25 secs.

Rolling code transmitter

Erasing Codes
To erase all the codes, press and hold the two outside
buttons until the HomeLink indicator begins to blink
(about 10 to 20 secs). You should erase all codes
before selling the vehicle.

If you have any problems, see the device’s
instructions, visiwww.homelink.com, or call
HomeLink at (800) 355-3515.

HomeLink® is a registered trademark of Gentex
Corporation.

4.

3.

2.

5.

A.

B.

1. Position the remote transmitter you wish to link 1 to 3 inches (3 - 8 cm) from the

HomeLink button you want to program.

Press and release the desired HomeLink button. Hold the button on the remote
transmitter. Does the HomeLink indicator (LED) change from slowly blinking to
constantly on or rapidly blinking? The process should take less than 60 seconds.

Press and hold the
programmed HomeLink
button for about a sec.
Does the device (garage
door opener) work?

Press and release the HomeLink button. Press
and release the button on the remote every 2
secs.
Does the HomeLink indicator (LED) change from
slowly blinking to constantly on or rapidly
blinking
? The process should take less than 60
seconds.

Training
Complete

Press and hold the HomeLink button again.

Press and hold the HomeLink
button again.
The remote-controlled device
should operate.

Training Complete

The remote has a rolling code. Press the
“learn” button on the remote-controlled
device (e.g. garage door opener).

Within 30 secs, press and hold the
programmed HomeLink button for 2 secs.

HomeLink indicator rapidly blinks.

HomeLink LED is

constantly on.

YES

NO

YES

YES

NO

NO















Content   ..  20  21  22  23   ..
