Continued

495

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

To turn on or off the text message
notice

1. Select .
2. Select Messages.
3. Select Settings.
4. Select Notifications.
5. Select ON or OFF.

■

To Set Up Text Message Options

1

To Set Up Text Message Options

To use the text message function, it may be necessary
to set up on your phone.

1

To turn on or off the text message notice

ON: A pop-up notification comes on every time you
receive a new message.
OFF: The message you receive is stored in the system
without notification.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

496

Features

HFL can display newly received text messages as well as the last 20 messages
received on a linked cell phone. Each received message can be read aloud and
replied to using a fixed common phrase.

1. A pop-up appears and notifies you of a new

text message.

2. Select Open to display the message.

u

The text message is displayed.

3. Select Play to listen to the message. To

discontinue the message read-out, select
Stop.

■

Receiving a Text Message

1

Receiving a Text Message

The system does not display any received messages
while you are driving. You can only hear them read
aloud.

The system can only receive messages that are sent a
text (SMS) messages. The message sent using the
data services will not be displayed in the list.

With some phones, you may be able to display up to
20 of the last text messages received.

State or local laws may limit your use of the HFL text
message feature. Only use the text message feature
when conditions allow you to do so safely.

Continued

497

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

You can select one from the Bluetooth® device list to be active and receive
notifications.

1. Select .
2. Select Messages.
3. Select Settings.
4. Select Change Connected Phone.
5. Change a desired phone.

2 To change the currently paired phone

P. 486

■

Selecting a Phone

1

Selecting a Phone

You can only receive notifications from one phone at
a time.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

498

Features

1. Select .
2. Select Messages.

u

Select a phone if necessary.

3. Select a message.

u

The text message is displayed.

■

Displaying Messages

1

Displaying Messages

The

 (blue) icon appears next to an unread

message.

If you delete a message on the phone, the message
will also be deleted from the system. If you send a
message from the system, the message goes to your
phone’s outbox.

To see the previous or next message, select

 Prev

or Next

 on the message screen.

Message List

Text Message

Continued

499

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

Read or Stop reading a message

1. Go to the text message screen.
2. Select Play.

u

The system starts reading the message
aloud.

3. Select Pause to stop reading.

Select Play again to start reading the
message.

■

Reply to a message

1. Go to the text message screen.
2. Select Reply.
3. Select the reply message.

u

The pop-up menu appears on the screen.

4. Select Send to send the message.

u

Message sent appears on the screen
when the reply message was successfully
sent.

1

Reply to a message

The available fixed reply messages are as follows:

•

Talk to you later, I’m driving.

•

I’m on my way.

•

I’m running late.

•

OK

•

Yes

•

No

You can add a reply message by selecting + Create
New Message.

2 To edit a reply message P. 500

Only certain phones receive and send messages when
paired and connected. For a list of compatible
phones:

•

U.S.: Visit automobiles.honda.com/handsfreelink/,
or call 1-888-528-7876.

•

Canada: Visit www.handsfreelink.ca, or call 1-888-
528-7876.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

500

Features

■

To edit a reply message

1. Select .
2. Select Messages.
3. Select Settings.
4. Select Edit System Replies.
5. Select the reply message you want to edit

or + Create New Message.

u

The on-screen keyboard screen is
displayed.

6. Enter a reply message, and then select

Save.

■

To delete a reply message

1. Select .
2. Select Messages.
3. Select Settings.
4. Select Delete System Replies.
5. Select

 on the reply message you want to

delete.

u

The pop-up menu appears on the screen.

6. Select Delete.

1

To edit a reply message

You can change the order of reply messages by
selecting Reorder.

501

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

■

Making a call to a sender

1. Go to the text message screen.
2. Select Call.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

502

Features

■

Automatic collision notification

If your vehicle’s airbags deploy or if the unit
detects that the vehicle is severely impacted,
your vehicle automatically will attempt to
connect to the HondaLink® operator. If
connected, information about your vehicle, its
location, and its condition can be sent to the
operator

*1

; you also can speak to the operator

when connected.

IMPORTANT: For vehicles equipped with HondaLink® Assist, owner activation
constitutes authorization for Honda to collect information from your vehicle needed
to provide the service, and agreement to the Terms of Use at
www.hondalink.com/TermsAndConditions. In a crash, HondaLink® Assist will
attempt to notify emergency services but NEITHER HONDA NOR ITS SERVICE
PROVIDERS GUARANTEE THAT SUCH NOTIFICATION WILL OCCUR.

Honda reserves the right to terminate HondaLink® Assist services at any time or for
any reason, and in the future may not be able to provide services due to changes in,
or obsolescence of, technology integral to the service or changes in governmental
regulation.

*1: Depending on your phone and adequate cellular coverage, your vehicle’s location may not
be sent to the operator.

■

In Case of Emergency

1

In Case of Emergency

Your vehicle may not be able to connect to the
operator if the battery level is low, the line is
disconnected, or you do not have adequate cellular
coverage.

You cannot use this emergency service when:

•

You travel outside the HondaLink® service coverage
areas.

•

There is a problem with the connecting devices,
such as the microphones, speakers, or the unit
itself.

You cannot operate other phone-related functions
using the screen while talking to the operator.
Select Hang Up to terminate the connection to your
vehicle.

1

Automatic collision notification

If the unit fails to connect to the operator, it
repeatedly tries until it succeeds.

Continued

503

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

To enable notification

1. Go to the phone settings screen.

2 Phone settings screen P. 482

2. Select HondaLink Assist.
3. Select ON or OFF.

1

To enable notification

Setting options:

•

ON: Notification is available.

•

OFF: Disable the feature.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

504

Features

■

Manual operator connection

*

If you need to talk to the HondaLink® operator
in a situation where no airbag has deployed,
you can manually connect to them by pressing
the ASSIST button with the power mode in
ACCESSORY or ON.
1. Open the cover attached to the ceiling

console.

2. Press the ASSIST button.

u

You are connected to the HondaLink®
operator.

1

Manual operator connection

*

Do not press the button while driving. When you
need to contact the operator, park the vehicle in a
safe place.

If the unit fails to connect to the operator, it
automatically cancels the action after three minutes.

If necessary, the cover can be broken to access the
ASSIST button.

ASSIST Button

* Not available on all models

505

Features

CabinTalk

TM*

Your audio system allows you or the front passenger voices to be broadcast to the
second and third row seat’s passengers using the rear speakers and/or headphones.

1. Select .
2. Select CabinTalk.

u

Select Speakers to broadcast to the rear
speakers.

u

Select Headphones to broadcast to
headphones.

u

Select Mic is On to mute your voice.

■

How to use

1

CabinTalk

TM*

You can also switch to the CabinTalk screen by
selecting CabinTalk on the front control panel for
the Blu-ray/DVD rear entertainment system.

2 Front Control Panel Operation P. 390

When Speakers is selected, you can adjust the
speaker volume by turning the volume knob.

Models with center speaker

Models with center speaker

Models without center speaker

Models with center speaker

* Not available on all models

506

507

Driving

This chapter discusses driving and refueling.

Before Driving................................... 508
Towing a Trailer................................ 514
Off-Highway Driving Guidelines ..... 525
When Driving

Starting the Engine .......................... 527
Automatic Transmission ................... 534
Shifting .................................... 535, 537
Auto Idle Stop

*

................................ 545

ECON Mode .................................... 550
Intelligent Traction Management

*

.... 551

Vehicle Stability Assist® (VSA®), aka Electronic

Stability Control (ESC), System............ 553

Agile Handling Assist ....................... 555
Blind spot information System

*

........ 556

LaneWatch

TM

*

.................................. 559

Intelligent Variable Torque Management (i-

VTM4

TM

) AWD System

*

.................. 561

Tire Pressure Monitoring System (TPMS)

with Tire Fill Assist.......................... 562

Tire Pressure Monitoring System (TPMS) -

Required Federal Explanation ......... 564

Honda Sensing® ................................ 566

Collision Mitigation Braking System

TM



(CMBS

TM

) ....................................... 569

Adaptive Cruise Control (ACC)......... 581
Lane Keeping Assist System (LKAS) .. 594

Road Departure Mitigation (RDM)

System ....................................... 603

Front Sensor Camera ....................... 608
Radar Sensor.................................... 610

Braking

Brake System ................................... 611
Anti-lock Brake System (ABS) ........... 613
Brake Assist System ......................... 614

Parking Your Vehicle

When Stopped ................................ 615
Parking Sensor System

*

................... 617

Cross Traffic Monitor

*

..................... 622

Multi-View Rear Camera.................. 626
Refueling

Fuel Information .............................. 628
How to Refuel ................................. 629

Fuel Economy and CO

2

 Emissions

Improving Fuel Economy and Reducing

CO

2

 Emissions................................ 631

* Not available on all models

508

Driving

Before Driving

Driving Preparation

Check the following items before you start driving.

• Make sure there are no obstructions on the windows, door mirrors, exterior

lights, or other parts of the vehicle.

u

Remove any frost, snow, or ice.

u

Remove any snow on the roof, as this can slip down and obstruct your field of
vision while driving. If frozen solid, remove ice once it has softened.

u

When removing ice from around the wheels, be sure not to damage the wheel
or wheel components.

• Make sure the hood is securely closed.

u

If the hood opens while driving, your front view will be blocked.

• Make sure the tires are in good condition.

u

Check air pressures, and check for damage and excessive wear.

2 Checking and Maintaining Tires P. 663

• Make sure there are no people or objects behind or around the vehicle.

u

There are blind spots from the inside.

■

Exterior Checks

1

Exterior Checks

NOTICE

When doors are frozen shut, use warm water around
the door edges to melt any ice. Do not try to force
them open, as this can damage the rubber trim
around the doors. When done, wipe dry to avoid
further freezing.

Do not pour warm water into the key cylinder.
You will be unable to insert the key if the water
freezes in the hole.

Heat from the engine and exhaust can ignite
flammable materials left under the hood, causing a
fire. If you’ve parked your vehicle for an extended
period, inspect and remove any debris that may have
collected, such as dried grass and leaves that have
fallen or have been carried in for use as a nest by a
small animal.  Also check under the hood for leftover
flammable materials after you or someone else has
performed maintenance on your vehicle.

Continued

509

uu

Before Driving

u

Driving Preparation

Driving

• Store or secure all items on board properly.

u

Carrying too much cargo, or improperly storing it, can affect your vehicle’s
handling, stability, stopping distance, and tires, and make it unsafe.

2 Maximum Load Limit P. 511

• Do not pile items higher than the seat height.

u

They can block your view and may be thrown forward in the event of sudden
braking.

• Do not place anything in the front seat footwells. Make sure to secure the floor

mat.

u

An object or unsecured floor mat can interfere with your brake and accelerator
pedal operation while driving.

• If you have any animals on board, do not let them move around in the vehicle.

u

They may interfere with driving and a crash could occur.

• Securely close and lock all doors and the tailgate.

2 Locking/Unlocking the Doors from the Inside P. 149

• Adjust your seating position properly.

u

Adjust the head restraint, too.

2 Adjusting the Seats P. 194
2 Adjusting the Front and Second Row Outer Seat Head Restraint Positions

P. 200

• Adjust the mirrors and steering wheel properly.

u

Adjust them while sitting in the proper driving position.

2 Adjusting the Steering Wheel P. 191
2 Adjusting the Mirrors P. 192

■

Interior Checks

1

Interior Checks

The headlight aim is set by the factory, and does not
need to be adjusted. However, if you regularly carry
heavy items in the cargo area or tow a trailer, have
the aiming readjusted at a dealer or by a qualified
technician.

510

uu

Before Driving

u

Driving Preparation

Driving

• Be sure items placed on the floor behind the front seats cannot roll under the

seats.

u

They can interfere with the driver’s ability to operate the pedals, the operation
of the seats, or the operation of the sensors under the seats.

• Everyone in the vehicle must fasten their seat belt.

2 Fastening a Seat Belt P. 42

• Make sure that the indicators in the instrument panel come on when you start the

vehicle, and go off soon after.

u

Always have a dealer check the vehicle if a problem is indicated.

2 Indicators P. 80
