Honda Odyssey (2019 year). Instruction

432

Blu-ray/DVD Rear Entertainment System

Playable Discs

Features

FreeType

Legal Terms

0. Definitions

Throughout this license, the terms 'package', 'FreeType Project', and 'FreeType archive' refer to the set of files originally distributed by the
authors (David Turner, Robert Wilhelm, and Werner Lemberg) as the 'FreeType Project', be they named as alpha, beta or final release.

'You' refers to the licensee, or person using the project, where 'using' is a generic term including compiling the project's source code as
well as linking it to form a 'program' or 'executable'. This program is referred to as 'a program using the FreeType engine'.

This license applies to all files distributed in the original FreeType Project, including all source code, binaries and documentation, unless
otherwise stated in the file in its original, unmodified form as distributedin the original archive. If you are unsure whether or not a particular
file is covered by this license, you must contact us to verify this.

The FreeType Project is copyright (C) 1996-2000 by David Turner, Robert Wilhelm, and Werner Lemberg. All rights reserved except as
specified below.

1. No Warranty

THE FREETYPE PROJECT IS PROVIDED 'AS IS' WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT
LIMITED TO, WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT WILL ANY OF THE AUTHORS
OR COPYRIGHT HOLDERS BE LIABLE FOR ANY DAMAGES CAUSED BY THE USE OR THE INABILITY TO USE, OF THE FREETYPE PROJECT.

433

Blu-ray/DVD Rear Entertainment System

Playable Discs

Continued

Features

2. Redistribution

This license grants a worldwide, royalty-free, perpetual and irrevocable right and license to use, execute, perform, compile, display, copy,
create derivative works of, distribute and sublicense the FreeType Project (in both source and object code forms) and derivative works
thereof for any purpose; and to authorize others to exercise some or all of the rights granted herein, subject to the following conditions:

• Redistribution of source code must retain this license file ('FTL.TXT') unaltered; any additions, deletions or changes to the original files

must be clearly indicated in accompanying documentation. The copyright notices of the unaltered, original files must be preserved in all
copies of source files.

• Redistribution in binary form must provide a disclaimer that states that the software is based in part of the work of the FreeType Team,

in the distribution documentation. We also encourage you to put an URL to the FreeType web page in your documentation, though this
isn't mandatory.

These conditions apply to any software derived from or based on the FreeType Project, not just the unmodified files. If you use our work,
you must acknowledge us. However, no fee need be paid to us.

3. Advertising

Neither the FreeType authors and contributors nor you shall use the name of the other for commercial, advertising, or promotional
purposes without specific prior written permission.

We suggest, but do not require, that you use one or more of the following phrases to refer to this software in your documentation or
advertising materials: 'FreeType Project', 'FreeType Engine', 'FreeType library', or 'FreeType Distribution'.

As you have not signed this license, you are not required to accept it. However, as the FreeType Project is copyrighted material, only this
license, or another one contracted with the authors, grants you the right to use, distribute, and modify it. Therefore, by using, distributing,
ormodifying the FreeType Project, you indicate that you understand and accept all the terms of this license.

434

Blu-ray/DVD Rear Entertainment System

Playable Discs

Features

4. Contacts

There are two mailing lists related to FreeType:

• freetype@nongnu.org Discusses general use and applications of FreeType, as well as future and wanted dditions to the library and

distribution. If you are looking for support, start in this list if you haven't found anything to help you in the documentation.

• freetype-devel@nongnu.org Discusses bugs, as well as engine internals, design issues, specific licenses, porting, etc.

Our home page can be found at

http://www.freetype.org

libjpeg

this software is based in part on the work of the Independent JPEG Group

Vera.ttf

Permission is hereby granted, free of charge, to any person obtaining a copy of the fonts accompanying this license ("Fonts") and
associated documentation files (the "Font Software"), to reproduce and distribute the Font Software, including without limitation the
rights to use, copy, merge, publish, distribute, and/or sell copies of the Font Software, and to permit persons to whom the Font Software
is furnished to do so, subject to the following conditions:

The above copyright and trademark notices and this permission notice shall be included in all copies of one or more of the Font Software
typefaces.

The Font Software may be modified, altered, or added to, and in particular the designs of glyphs or characters in the Fonts may be modified
and additional glyphs or characters may be added to the Fonts, only if the fonts are renamed to names not containing either the words
"Bitstream" or the word "Vera".

435

Blu-ray/DVD Rear Entertainment System

Playable Discs

Continued

Features

This License becomes null and void to the extent applicable to Fonts or Font Software that has been modified and is distributed under the
"Bitstream Vera" names.

The Font Software may be sold as part of a larger software package but no copy of one or more of the Font Software typefaces may be
sold by itself.

THE FONT SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED
TO ANY WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OF COPYRIGHT, PATENT,
TRADEMARK, OR OTHER RIGHT. IN NO EVENT SHALL BITSTREAM OR THE GNOME FOUNDATION BE LIABLE FOR ANY CLAIM, DAMAGES
OR OTHER LIABILITY, INCLUDING ANY GENERAL, SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, WHETHER IN AN
ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF THE USE OR INABILITY TO USE THE FONT SOFTWARE OR FROM
OTHER DEALINGS IN THE FONT SOFTWARE.

Except as contained in this notice, the names of Gnome, the Gnome Foundation, and Bitstream Inc., shall not be used in advertising or
otherwise to promote the sale, use or other dealings in this Font Software without prior written authorization from the Gnome Foundation
or Bitstream Inc., respectively. For further information, contact: fonts at gnome dot org.

libtiff

Permission to use, copy, modify, distribute, and sell this software and its documentation for any purpose is hereby granted without fee,
providedbthat (i) the above copyright notices and this permission notice appear in all copies of the software and related documentation,
and (ii) the names of Sam Leffler and Silicon Graphics may not be used in any advertising or publicity relating to the software without the
specific, prior written permission of Sam Leffler and Silicon Graphics.

436

Blu-ray/DVD Rear Entertainment System

Playable Discs

Features

THE SOFTWARE IS PROVIDED "AS-IS" AND WITHOUT WARRANTY OF ANY KIND, EXPRESS, IMPLIED OR OTHERWISE, INCLUDING
WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL SAM
LEFFLER OR SILICON GRAPHICS BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR
ANY DAMAGES WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER OR NOT ADVISED OF THE POSSIBILITY OF
DAMAGE, AND ON ANY THEORY OF LIABILITY, ARISING OUT OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THIS
SOFTWARE.

giflib

Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the
"Software"), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish,
distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the
following conditions:

The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software.

THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE
WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF
CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS
IN THE SOFTWARE.

437

Blu-ray/DVD Rear Entertainment System

Playable Discs

Continued

Features

zlib

zlib License
This software is provided 'as-is', without any express or implied warranty. In no event will the authors be held liable for any damages arising
from the use of this software.

Permission is granted to anyone to use this software for any purpose, including commercial applications, and to alter it and redistribute it
freely, subject to the following restrictions:

1. The origin of this software must not be misrepresented; you must not claim that you wrote the original software. If you use this software
in a product, an acknowledgment in the product documentation would beappreciated but is not required.

2. Altered source versions must be plainly marked as such, and must not be misrepresented as being the original software.

3. This notice may not be removed or altered from any source distribution.

■

FDA

-Caution-
Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

Blu-ray/DVD Rear Entertainment System

Playable Discs

438

Features

This unit is compatible with NTSC and PAL color TV systems. Use discs that are
labeled as NTSC or PAL. Capability of this unit to play discs other than NTSC or PAL
TV system (SECAM) is not guaranteed.

Some DVD/Blu-ray

discs have a region code such as

, ,

and this number

shows the region the disc can be played in. Playable disc regions are restricted
depending on the map coverage areas. If you play other discs, Check Disc message
is displayed. In addition, some discs that do not have a region code number may still
have a region restriction and may not be played on this unit.

■

Playable Disc Types

Type and symbol

of playable disc

Size/Playable Side

Max. play time

12 cm/single-sided

Single layer
Dual layer

133 min.
242 min.
266 min.
484 min.

12 cm/Double-sided Single layer

Dual layer

12 cm/signal-side

Single layer
Dual layer

at 27 Mbps 123 min.
246 min.

■

Playable Disc Region Codes

Playable Disc Types

Some discs may not function as expected. Also read
the instruction book which comes with the disc.
Disc Symbols
The following symbols appear on DVD/Blu-ray

discs

or packing.

For Dual Disc (double sided disc with
both a DVD layer and a non-DVD
layer), the DVD layer can be played as a
Video DVD if the disc has the mark
displayed on the right. Discs without the mark and
the non-DVD layer are not supported, and operation
cannot be guaranteed. In addition, the discs may be
scratched when they are inserted or ejected.

Symbol

Description

Number of available soundtracks

Number of available subtitles

Number of angles

Selectable screen aspect ratios
(TV screen’s horizontal to vertical ratio)
16:9: Widescreen
4:3: Normal screen
Selectable region codes
ALL: Region free
A number (ex. 1): Particular region code

Selectable region codes
ABC: Region free
An alphabet (ex. A): Particular region code

439

Blu-ray/DVD Rear Entertainment System

Playable Discs

Features

Compression video not supported, Compression audio specification are following.

■

Recommended Discs

Media

CD-R/CD-RW

DVD-R/DVD-RW

DVD+R/DVD+RW

Disc format

CD-ROM Mode1

CD-ROM Mode2 Form1

DVD-ROM

File format

ISO9660 Level 1 & 2

Romeo, Joliet

Audio format

MP3

WMA

AAC

Audio format

specification

MPEG-1 AUDIO LAYER3
MPEG-2 AUDIO LAYER3

MPEG-2.5 AUDIO LAYER3

Microsoft Windows Media

Audio Ver7,8,9

MPEG4-AAC

m4a files created by iTunes

(Apple)

Sampling

frequency

[kHz]

MPEG-1: 32/44.1/48

MPEG-2: 16/22.05/24

MPEG-2.5: 8/11.025/12

8/11.025/12/16/22.05/24/

32/44.1/48

Exceptions not supported by

DVD Player:12/24

8/11.025/12/16/22.05/24/

32/44.1/48

Bit rate [kbps]

MPEG1: 32/40/48/56/64/

80/96/112/128/160/192/

224/256/320

MPEG2: 8/16/24/32/40/48/

56/64/80/96/112/128/144/

160

MPEG2.5: 8/16/24/32/40/

48/56/64/80/96/112/128/

144/160

5/8/16/24/32/40/48/64/80/

96/128/160/192/224/256/

320/384

Exceptions not supported by

DVD Player: 24/224/384

8/16/20/24/28/32/40/48/56/
64/80/96/112/128/160/192/

224/256/320/384/448/512/

576

Exceptions not supported by

DVD Player: 384/448/512/

576

File extension

.mp3/.MP3

.wma/.WMA

.m4a/.M4A

Recommended Discs

Large files may take longer to change audio or fast-
forward/fast-rewind.

Some CD-R/CD-RW/DVD-R/DVD-RW may not be read
due to the discs’ encoding properties. Use discs
recorded with disc-at-once or track-at-once for this
unit.

“AVCHD Progressive” and the “AVCHD Progressive”
logo are trademarks of Panasonic Corporation and
Sony Corporation.

440

Blu-ray/DVD Rear Entertainment System

DVD or Blu-ray

Player Error Messages

Features

DVD or Blu-ray

Player Error Messages

If a disc error occurs, you may see the following error messages.

Error Message in Audio/

Information Screen

Error Message in Overhead

Screen

Cause

Solution

Problem ejecting disc from the
player. Contact Honda dealer to
fix this problem.

Problem ejecting disc from the
player.
Contact Honda dealer to fix this
problem.

Disc stuck in player

• Contact a dealer and the

player needs to be replaced.

There is a problem with the
player. Eject and re-insert the
disc. If this does not work, try
another disc. If the error
continues, contact Honda
dealer.

There seems to be a problems
playing this disc. Try inserting
the disc into the Blu-ray player
again.

Focus error
Unsupported disc error
Mechanical error
Servo error
DRM file access
Error file access
Device error

• Press the

button and

remove the disc, and check
that the error message is
cleared.

• Check that the disc is not

damaged or deformed, and
insert the disc again.

2 Protecting CDs P. 374

The system has overheated. Try
to reduce the temperature by
tuning the audio system off
and allowing the player to cool
down.

The Blu-ray player is too hot
right now.
Give it some time to cool off
and try again later.

High temperature

• Turn the audio system off and

allow the player to cool down
until the error message is
cleared.

441

Blu-ray/DVD Rear Entertainment System

DVD or Blu-ray

Player Error Messages

Continued

Features

Playback stopped. The content
being played is protected by
Cinavia and is not authorized
for playback on this device.

Playback stopped. The content

being played is protected by

Cinavia

and is not authorized

for playback on this device.
For more information, see
http://www.cinavia.com.
Message Code 1.

Cinavia 1 error

• Current track/file will be

skipped. The next supported
track/file plays automatically.

Error Message in Audio/

Information Screen

Error Message in Overhead

Screen

Cause

Solution

442

Blu-ray/DVD Rear Entertainment System

DVD or Blu-ray

Player Error Messages

Features

Error Message in Audio/

Information Screen

Error Message in Overhead

Screen

Cause

Solution

Audio outputs temporarily
muted. Do not adjust the
playback volume. The content
being played is protected by
Cinavia and is not authorized
for playback on this device. For
more information, see http://
www.cinavia.com. Message
Code 3.

Audio outputs temporarily
muted. Do not adjust the
playback volume. The content
being played is protected by
Cinavia

and is not authorized

for playback on this device. For
more information, see http://
www.cinavia.com. Message
Code 3.

Cinavia 3 error

• Current track/file will be

skipped. The next supported
track/file plays automatically.

This disc cannot be played.
Check that the disc is not
damaged or deformed. If the
disc is OK, see Owner’s Manual
for information on supported
disc types and files.

There seems to be a problem
with this disc.
Please check if it might be
damaged.

Region mismatch

• Press the

button and

remove the disc, and check
that the error message is
cleared.

• Check the disk if region code is

matched.

—

Cannot access Blu-ray Player.
Contact Honda dealer.

DTCP certificate error

• Contact a dealer and the

player needs to be replaced.

443

Continued

Features

Customized Features

Use the audio/information screen to customize certain features.

■

How to customize

While the vehicle is at a complete stop with the power mode in ON, press the
MENU/CLOCK button, then select Settings. To customize the phone settings,
press the

button, then select Phone Setup.

Customized Features

When you customize settings, make sure that the
vehicle is at a complete stop and shift to

(

How to customize

These indications are used to show how to operate
the selector knob.
Rotate

to select.

Press

to enter.

To customize other features, select Settings, rotate

, then press

2 List of customizable options P. 446

Models with color audio system

Audio/Information Screen

MENU/CLOCK Button

Selector Knob

(Phone) Button

444

Customized Features

Features

■

Customization Flow

Press the MENU/CLOCK button.

Adjust Clock

Bluetooth

Add New Device

Connect an Audio Device

Display Adjustment

Brightness

Contrast

Black Level

Rear Camera

Camera Guideline

RDS Settings

RDS Information

Radio Text

Display Change

Wallpaper

Select

Import

Delete

Color Theme

Language

Clock Format

*1 : FM mode

Settings

445

Customized Features

Continued

Features

Press the

button and rotate

select

Phone Setup, then press

Ringtone

Bluetooth Setup

Add New Device

Connect a Phone

Connect an Audio Device

Disconnect All Devices

Delete Device

Pass-Key

Speed Dial

Caller ID Info

System Clear

446

Customized Features

Features

■

List of customizable options

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Adjust Clock

Adjusts clock.

2 Clock P. 142

—

Settings

RDS
Settings

RDS Information

Selects whether the RDS information comes
on.

/Off

Radio Text

Displays the radio text information of the
selected RDS station.

—

Bluetooth

Add New Device

See

Bluetooth Setup

on P. 448

Connect an Audio
Device

Display
Adjustment

Brightness

Changes the brightness of the audio/
information screen.

—

Contrast

Changes the contrast of the audio/
information screen.

—

Black Level

Changes the black level of the audio/
information screen.

—

Rear
Camera

Camera Guideline

Selects whether the guidelines come on the
audio/information screen.

/Off

FM mode

447

Customized Features

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Settings

Display Change

Changes the display type.

Audio

/Wallpaper

Wallpaper

Select

Changes the wallpaper type.

Clock

/Image1/Image2/


Import

Imports an image file for a new wallpaper.

2 Wallpaper Setup P. 270

—

Delete

Deletes an image file for a wallpaper.


/Image2/Image3

Color Theme

Changes the background color of the audio/
information screen.

Blue

/Red/Amber/Gray

Language

Changes the display language.

English

/Français/Español

Clock Format

Selects the digital clock display from 12h to
24h.

12h

/24h

Honda Odyssey (2019 year). Instruction - part 28
