uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

240

Co
ntrols

To open the sunglasses holder, push and
release the indent. To close, push it again until
it latches.

You can store eyeglasses and other small
items in this holder.

■

Conversation mirror

The sunglasses holder comes with a mirror.
Open the sunglasses holder fully, then push it
back to the first detent. You can use the
mirror to view the rear seats.

■

Sunglasses Holder

1

Sunglasses Holder

Keep the holder closed while driving except when
accessing stored items.

Push

Continued

241

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

The power mode must be in ON to use the
heated steering wheel.

Press the button on the right side of the
steering wheel.

When a comfortable temperature is reached,
press the button again to turn it off.

The heated steering wheel is turned off every
time you start the engine, even if you turned it
on the last time you drove the vehicle.

■

Heated Steering Wheel

*

1

Heated Steering Wheel

*

Do not use the heated steering wheel continuously
when the engine is off. Under such conditions, the
battery may be weakened, making the engine
difficult to start.

* Not available on all models

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

242

Co
ntrols

The power mode must be in ON to use the
seat heaters.

Press the seat heater button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)
When the power mode is turned on after it is
turned off, the previously selected setting of
seat heaters is maintained.

■

Front Seat Heaters

*

1

Front Seat Heaters

*

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

After a certain period of time, the strength setting for
the seat heaters will automatically be reduced by one
level at a time until the seat heater shuts off. The
elapsed time varies according to the interior
environment.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

Continued

243

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

The power mode must be in ON to use the
seat heaters and ventilation.

Press the seat heater or the seat ventilation
button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)
When the power mode is turned on after it is
turned off, the previously selected setting of
seat heaters and ventilations is maintained.

■

Front Seat Heaters and Seat Ventilation

*

1

Front Seat Heaters and Seat Ventilation

*

Do not use the seat heaters and the seat ventilation
even in LO when the engine is OFF. Under such
conditions, the battery may be weakened, making
the engine difficult to start.

After a certain period of time, the strength setting for
the seat heaters will automatically be reduced by one
level at a time until the seat heater shuts off. The
elapsed time varies according to the interior
environment.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

244

Co
ntrols

■

Second row sunshades

Pull the tab and roll up the sunshade all the
way. Use the hooks to hang it.

■

Third row sunshades

Pull the tab and roll up the sunshade all the
way. Attach the tab to the anchor.

■

Integrated Sunshades

*

1

Integrated Sunshades

*

Use the sunshades only when the windows are fully
closed. If a window is open while a shade is being
used, the shade can blow off and unhook, hitting
and hurting anyone sitting near the window.

Second row

Hooks

Tab

Third row

Anchor

Tab

* Not available on all models

Continued

245

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

An in-car vacuum system used for cleaning the inside of your vehicle. The vacuum
can be operated with the engine running or for up to eight minutes without the
engine running.

■

HondaVAC

TM

*

1

HondaVAC

TM

*

NOTICE

The vacuum is intended for dry use only.
Water and other liquids can damage the vacuum.

3

WARNING

• Engine exhaust contains toxic carbon

monoxide that builds up rapidly in
enclosed areas.
Breathing it can cause unconsciousness
and even kill you.
If running the engine to power the
vacuum, park the vehicle outdoors and
lower all windows to ensure adequate
ventilation.

• Do not vacuum flammable liquids or in an

area with flammable vapors.
A fire or explosion could result, causing
death or serious injury.

Open the
upper lid and
pull out the
hose.

Install a desired attachment.

 (Power)

Button
PWR SAVE
Indicator

* Not available on all models

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

246

Co
ntrols

■

To operate:

1. Set the parking brake.

2. Set the power mode to ACCESSORY.

2. Start the engine.
3. Press the   button to turn on the system.

1

To operate:

The vacuum automatically shuts off and the PWR
SAVE indicator comes on if the system detects that
running the vacuum is over discharging the battery.

After seven minutes of operation:
The beeper sounds intermittently.
When eight minutes elapse:
The beeper sounds once and the PWR SAVE
indicator comes on. The vacuum automatically shuts
off.

To continue vacuuming, start the engine.

Operate the engine only when there is sufficient
ventilation.

Without engine running

With engine running

Without engine running

With engine running

247

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

■

To empty the canister or change the debris bag

1. Remove the lower vacuum lid.
2. Push the lever in.
3. Pull the canister down, then slide out from the track.

4. Push the three lid tabs outward and remove

the canister lid.

u

The debris bag and canister can be
accessed.

To reinstall the empty canister:
After sliding the canister into the track, push the lever in to lift the canister up.
Release the lever to lock the canister in position.

u

The orange unlocked decal should not be visible.

1

To empty the canister or change the debris bag

Both the debris bag and the filter are replaceable.
Contact a dealer for component replacement
information.

The vacuum can be used with or without the bag.

If you find the vacuum performance poor or there is
no suction:

•

Check if the canister is locked in position.

•

Check if the hose is attached to the vacuum.

•

Empty the canister or change the bag.

•

Clean or replace the filter.

•

Check the hose for clogs or damage.

Lower Vacuum Lid

Lever

Canister

Canister Lid

Three Lid Tabs

248

Co
ntrols

Climate Control System

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air that raises or lowers
the interior temperature to your preference as quickly as possible.

Use the system when the engine is running.
1. Press the AUTO button.
2. Adjust the interior temperature using the temperature control switch.
3. Press the

 button to cancel.

■

Switching between the recirculation and fresh air modes

Press the

 button and switch the mode depending on environmental

conditions.
Recirculation Mode (indicator on): Recirculates air from the vehicle’s interior through
the system.
Fresh Air Mode (indicator off): Maintains outside ventilation. Keep the system in
fresh air mode in normal situations.

Dual-zone climate control system

1

Using Automatic Climate Control

If any buttons are pressed while using the climate
control system in auto, the function of the button
that was pressed will take priority.
The AUTO indicator will go off, but functions
unrelated to the button that was pressed will be
controlled automatically.

To prevent cold air from blowing in from outside, the
fan may not start immediately when the AUTO
button is pressed.

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows,
turning the system on auto, and setting the
temperature to low. Change the fresh air mode to
recirculation mode until the temperature cools down.

When you set the temperature to the lower or upper
limit, Lo or Hi is displayed.

Pressing the

 button switches the climate

control system between on and off. When turned on,
the system returns to your last selection.

While ECON mode is active, the climate control
system may have reduced cooling performance.

Dashboard
vents

Dashboard
and floor
vents

Floor vents

Floor and
defroster
vents

AUTO Button

Temperature
Control Switch

A/C (Air Conditioning) Button

Fan Control Switch



(Recirculation)
Button

 (On/Off)

Button

SYNC
(Synchronized)
Button

 (Windshield

Defroster) Button

MODE Button

Continued

249

uu

Climate Control System

u

Using Automatic Climate Control

Co
ntrols

Pressing the

 button turns the air

conditioner system on and automatically
switches the system to fresh air mode.

■

To rapidly defrost the windows

1. Press the

 button.

2. Press the

 button.

■

Defrosting the Windshield and Windows

1

Defrosting the Windshield and Windows

For your safety, make sure you have a clear view
through all the windows before driving.

Do not set the temperature near the upper or lower
limit.
When cold air hits the windshield, the outside of the
windshield may fog up.

If the side windows fog up, adjust the vents so that
the air hits the side windows.

1

To rapidly defrost the windows

After defrosting the windows, switch over to fresh air
mode.
If you keep the system in recirculation mode, the
windows may fog up from humidity. This impedes
visibility.

uu

Climate Control System

u

Using Automatic Climate Control

250

Co
ntrols

You can set the temperature synchronously for the front compartment and the rear
passenger compartment in synchronization mode.
1. Press the SYNC button.

u

The system switches to synchronization mode.

2. Adjust the temperature using the temperature control switch.

Press the SYNC button to return to dual mode.

■

Synchronization Mode

1

Synchronization Mode

When the system is not in synchronization mode, the
temperature for the front compartment and rear
passenger compartment can be set separately.

251

uu

Climate Control System

u

Rear Climate Control System

Co
ntrols

Rear Climate Control System

Use the system when the engine is running.
1. Press the REAR

button.

2. Press the REAR SETTINGS button.

u

The system switches to the rear control mode for 10 seconds. The REAR
indicator appears on the display.

3. Press the AUTO button.

u

The rear system changes to AUTO mode.

u

The system automatically adjusts the fan speed and airflow levels to maintain
the set rear temperature. Change the temperature if necessary.

u

To turn off the rear climate control system, press the REAR

button.

■

Using the Rear Climate Control System

REAR SETTINGS
Button

REAR

(On/Off)

Button

252

Co
ntrols

Climate Control System

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air that raises or lowers
the interior temperature to your preference as quickly as possible.

Use the system when the engine is running.
1. Press the AUTO button.
2. Adjust the interior temperature using the driver’s side or passenger’s side control

switch.

3. Press the

 button to cancel.

Tri-zone climate control system

1

Using Automatic Climate Control

Press the FRONT CLIMATE button to display A/C,
MODE, fan control information on the audio/
information screen for several seconds. Select icon to
turn on or off A/C, change the vent mode, or change
the fan speed.

During idle-stops, air-conditioning is suspended, and
only the blower remains active. If you do not want
air-conditioning suspended, press

 to cancel idle-

stop.

If any buttons are pressed while using the climate
control system in auto, the function of the button
that was pressed will take priority.
The AUTO indicator will go off, but functions
unrelated to the button that were pressed will be
controlled automatically.

To prevent cold air from blowing in from outside, the
fan may not start immediately when the AUTO
button is pressed.

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows,
turning the system on AUTO, and setting the
temperature to low. Change the fresh mode to
recirculation mode until the temperature cools down.

When you set the temperature to the lower or upper
limit, Lo or Hi is displayed.

Models with Auto Idle Stop

Mode Control Icon
(Air flows from
dashboard vents)

Mode Control Icon
(Air flows from
floor vents)

Mode Control Icon
(Air flows from
floor and
windshield
defroster vents)

Fan Control Icon

Mode Control Icon (Air flows from
floor and dashboard vents)

A/C (Air Conditioning)
Icon

 (On/Off) Button

 (Recirculation) Button

SYNC (Synchronized) Button

FRONT
CLIMATE
Button

Driver’s Side
Temperature
Control switch

Fan Control Button

Passenger’s
Side
Temperature
Control switch

AUTO Button

Continued

253

uu

Climate Control System

u

Using Automatic Climate Control

Co
ntrols

■

Switching between the recirculation and fresh air modes

Press the

 button and switch the mode depending on environmental

conditions.
Recirculation Mode (indicator on): Recirculates air from the vehicle’s interior through
the system.
Fresh Air Mode (indicator off): Maintains outside ventilation. Keep the system in
fresh air mode in normal situations.

Pressing the

 button turns the air

conditioner system on and automatically
switches the system to fresh air mode.

■

To rapidly defrost the windows

1. Press the

 button.

2. Press the

 button.

■

Defrosting the Windshield and Windows

1

Using Automatic Climate Control

Pressing the

 button switches the climate control

system between on and off. When turned on, the
system returns to your last selection.

While ECON mode is active, the climate control
system may have reduced cooling performance.

1

Defrosting the Windshield and Windows

For your safety, make sure you have a clear view
through all the windows before driving.

Do not set the temperature near the upper or lower
limit.
When cold air hits the windshield, the outside of the
windshield may fog up.

If the side windows fog up, adjust the vents so that
the air hits the side windows.

If you press the

 button during Auto Idle Stop, the

engine restarts automatically.

Models with Auto Idle Stop

1

To rapidly defrost the windows

After defrosting the windows, switch over to fresh air
mode.
If you keep the system in recirculation mode, the
windows may fog up from humidity. This impedes
visibility.

uu

Climate Control System

u

Using Automatic Climate Control

254

Co
ntrols

You can set the temperature synchronously for the driver side, the passenger side
and the rear passenger compartment in synchronization mode.
1. Press the SYNC button.

u

The system switches to synchronization mode.

2. Adjust the temperature using the driver’s side temperature control switch.

Press the SYNC button to return to tri-zone mode.

■

Synchronization Mode

1

Synchronization Mode

When the system is not in synchronization mode, the
temperature for the driver side, passenger side, and
rear passenger compartment can be set separately.

255

uu

Climate Control System

u

Rear Climate Control System

Continued

Co
ntrols

Rear Climate Control System

Use the system when the engine is running.
1. Press the REAR CLIMATE button.
2. Press the REAR CLIMATE button to display AUTO, MODE, temperature control,

and fan control information on the audio/information screen for several seconds.

3. Select the AUTO icon.

u

The rear system changes to AUTO mode.

u

The system automatically adjusts the fan speed and airflow levels to maintain
the set rear temperature. Change the temperature if necessary.

u

To turn off the rear climate control system, select the ON/OFF icon.

■

Using the Rear Climate Control System From the Front Panel

1

Rear Climate Control System

LOCK appears on the rear control panel while the
rear lock is on.

If the rear lock is on while in SYNC mode, the rear
control panel is disabled. LOCK SYNC appears on the
rear control panel.

1

Using the Rear Climate Control System From the Front Panel

Select the LOCK icon to turn the rear lock mode on
and off.

While the rear lock mode is on, the rear control panel
is disabled.

u

The color of LOCK icon on the audio/information

screen changes from grey to blue.

LOCK Icon

REAR CLIMATE
Button

Rear AUTO Icon

Rear Fan Control
Icon

Mode Control Icon
(Rear floor vents)

Mode Control Icon
(Rear ceiling vents and
floor vents)

Mode Control Icon
(Rear ceiling vents)

ON/OFF Icon

Rear
Temperature
Control Icon
