Honda Insight (2019 year). Instruction - part 25

383

Customized Features

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle

Door/Window
Setup

Auto Door Lock

Changes the setting for the automatic locking
feature.

OFF/With Vehicle
Speed

/Shift From P

Key and Remote
Unlock Mode

Sets up either the driver’s door or all doors to
unlock on the first push of the remote or built-in
key.

Driver Door Only

All Doors

Keyless Lock Answer
Back

LOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds.

/OFF

Security Relock Timer

Changes the time it takes for the doors to relock
and the security system to set after you unlock the
vehicle without opening any door.

30sec

/60sec/90sec

Auto Door Unlock

Changes the setting for when the doors unlock
automatically.

OFF/All Doors When
Driver’s Door
Opens

/All Doors

When Shifted to
Park/All Doors With
IGN OFF

Walk Away Auto
Lock

Changes the settings for the auto lock function
when you walk away from the vehicle.

ON/OFF

Maintenance
Info.

Select Reset Items

Resets the Maintenance Minder

display when you

have performed the maintenance service.

—

384

Customized Features

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Camera

Rear Camera

Fixed Guideline

Selects whether the guidelines come on the rear
camera monitor.

2 Multi-View Rear Camera P. 543

/OFF

Dynamic Guideline

Selects whether the guidelines come on the rear
camera monitor.

2 Multi-View Rear Camera P. 543

/OFF

LaneWatch

Show with turn
signal

Selects whether the LaneWatch display comes on
when you move the turn signal lever to indicate a
right turn.

/OFF

Display Time after
Turn Signal Off

Changes the length of time the LaneWatch display
stays on after the turn signal lever returns to the
center.

0 seconds

seconds

Show Reference Line

Selects whether the reference lines come on the
LaneWatch monitor.

/OFF

* Not available on all models

385

Customized Features

Defaulting All the Settings

Features

Defaulting All the Settings

Reset all the menu and customized settings as the factory defaults.

1. Press the

button.

2. Select Settings.
3. Select System.
4. Select Factory Data Reset.

A confirmation message appears on the
screen.

5. Select Continue to reset the settings.
6. Select Continue again to reset the settings.

The system will reboot.

1. Press the

button.

2. Select Settings.
3. Select Vehicle.
4. Select Default.
5. Select Yes.

■

Defaulting System Settings

Models with Display Audio

Defaulting All the Settings

When you transfer the vehicle to a third party, reset
all settings to default and delete all personal data.

If you perform Factory Data Reset, it will reset the
preinstalled apps to their factory default.

If you perform Factory Data Reset, you cannot use
the HondaLink® because it becomes off line.

2 HondaLink® P. 313

■

Defaulting Vehicle Settings

386

Features

HomeLink® Universal Transceiver

The HomeLink® Universal Transceiver can be programmed to operate up to three
remote controlled devices around your home, such as garage doors, lighting, or
home security systems.

Refer to the safety information that came with your garage door opener to test that
the safety features are functioning properly. If you do not have the safety
information, contact the manufacturer.

Before programming HomeLink, make sure that people and objects are out of the
way of the garage or gate to prevent potential injury or damage.

When programming a garage door opener, park just outside the garage door’s path.

■

Important Safety Precautions

HomeLink® Universal Transceiver

Before programming HomeLink to operate a garage
door opener, confirm that the opener has an external
entrapment protection system, such as an “electronic
eye,” or other safety and reverse stop features. If it
does not, HomeLink may not be able to operate it.

* Not available on all models

387

HomeLink® Universal Transceiver

Training HomeLink

Continued

Features

Training HomeLink

If it is necessary to erase a previously entered
learned code:
• Press and hold the I and III HomeLink

buttons for about 10 seconds, until the
green indicator blinks. Release the buttons,
and proceed to step 1.

• If you are training the second or third

button, go directly to step 1.

The instructions on the next page should work for most gate or garage openers, but
may not work for all. For detailed instructions about your specific remote opener,
visit http://www.homelink.com or call (800) 355-3515.

Indicator

I HomeLink Button

III HomeLink Button

HomeLink® Universal Transceiver

Training HomeLink

388

Features

■

Programming a Button

Training HomeLink

Reprogramming a Button
If you want to retrain a programmed button for a
new device, you do not have to erase all button
memory. You can replace the existing memory code
using this procedure:

Erasing Button Memory
To erase programming from the buttons, press and hold
the two outside HomeLink buttons until the HomeLink
indicator changes from orange to rapidly flashing green.
This should take about 10 seconds. You should erase all
programming before selling the vehicle.

Operating
To operate, simple press and release the
programmed HomeLink button. Activation will now
occur for the trained device.

Questions
For questions or comments, visit
www.HomeLink.com, www.youtube.com/
HomeLinkGentex, or by calling the HomeLink Hotline
(North America only) at (800) 355-3515.

HomeLink® is a registered trademark of Gentex
Corporation.

1. Press and hold the desired HomeLink button until

the HomeLink indicator begins to slowly flash
orange. This should take about 20 seconds.

Release the HomeLink button and position the
remote transmitter you wish to link 1 - 3 inches
(3 - 8 cm) from the HomeLink button you want to
program, then follow steps 3 - 6 under
“programming a button.”

Training
Complete

HomeLink LED is
continuously on green.

YES

1. Position the remote transmitter you wish to link 1 to 3 inches (3 - 8 cm) from the

HomeLink® button you want to program.

3b. Canadian Garage Door Opener

A. Press and release the HomeLink
button. Press, hold and release the
button on the remote every 2 secs.
Does the HomeLink indicator (LED)
change from slowly flashing orange to
rapidly flashing or continuously on
green? The process should take less
than 60 seconds.

2. Press and release the desired HomeLink button. Is the HomeLink indicator (LED) slowly

flashing orange?

3a. Hold the button on the remote

transmitter. Does HomeLink indicator
(LED) change from slowly flashing
orange to rapidly flashing green or
continuously on green? The process
should take less than 60 seconds.

5. Press and hold the HomeLink button again.

HomeLink indicator rapidly flashes
green.

5a. The remote has a rolling code. Press the

“learn” button on the remote-controlled
device (e.g. garage door opener).

6. Press and hold the HomeLink button

again.
The remote-controlled device should
operate.

Training Complete

5b. Within 30 secs, press and hold the

programmed HomeLink button for 2
secs.

4. Press and hold the programmed HomeLink

button for about a second. Does the device
(garage door opener) work?

389

Continued

Features

Bluetooth® HandsFreeLink®

Bluetooth® HandsFreeLink® (HFL) allows you to place and receive phone calls using
your vehicle's audio system, without handling your cell phone.

Using HFL

(Pick-up) button: Press to go directly to the phone screen or to answer an

incoming call.

(Hang-up/back) button: Press to end a call or to cancel a command.

(Talk) button: Press to call a number with a stored voice tag.

(Phone) button: Press to go directly to the phone screen.

Selector knob: Rotate

to select an item on the screen, then press

■

HFL Buttons

Bluetooth® HandsFreeLink®

Place your phone where you can get good reception.

To use HFL, you need a Bluetooth-compatible cell
phone. For a list of compatible phones, pairing
procedures, and special feature capabilities:

•

U.S.: Visit automobiles.honda.com/handsfreelink/,
or call 1-888-528 -7876.

•

Canada: For more information on smartphone
compatibility, call 1-888-528 -7876.

Voice control tips

•

Aim the vents away from the ceiling and close the
windows, as noise coming from them may interfere
with the microphone.

•

Press and release the

button when you want to

call a number using a stored voice tag. Speak
clearly and naturally after a beep.

•

If the microphone picks up voices other than yours,
the command may be misinterpreted.

•

To change the volume level, use the audio system’s
volume knob or the remote audio controls on the
steering wheel.

State or local laws may prohibit the operation of
handheld electronic devices while operating a vehicle.

If you receive a call while using the audio system, the
system resumes its operation after ending the call.

Up to 20 speed dial entries can be stored. If there is
no entry in the system, Speed Dial is disabled.

2 Speed Dial P. 405

Up to 20 call histories can be stored. If there is no call
history, Call History is disabled.

Models with color audio

(Talk) Button

Volume up

Microphone

(Hang-up/Back) Button

(Pick-up) Button

Volume down

Selector Knob

(Phone) Button

Bluetooth® HandsFreeLink®

Using HFL

390

Features

The audio/information screen notifies you
when there is an incoming call.

Certain manual functions are disabled or inoperable while the vehicle is in motion.
You cannot select a grayed-out option until the vehicle is stopped.

Only previously stored speed dial entries can be called using voice commands while
the vehicle is in motion.

2 Speed Dial P. 405

■

HFL Status Display

Bluetooth® HandsFreeLink®

Bluetooth® Wireless Technology
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc., and any
use of such marks by Honda Motor Co., Ltd., is under
license. Other trademarks and trade names are those
of their respective owners.

HFL Limitations
An incoming call on HFL will interrupt the audio
system when it is playing. It will resume when the call
is ended.

HFL Mode

Battery Level Status

Signal Strength

Bluetooth Indicator
Appears when your
phone is connected
to HFL.

Roam Status

Call Name

■

Limitations for Manual Operation

HFL Status Display

The information that appears on the audio/
information screen varies between phone models.

391

Bluetooth® HandsFreeLink®

HFL Menus

Continued

Features

HFL Menus

The power mode must be in ACCESSORY or ON to use HFL.

HFL Menus

To use HFL, you must first pair your Bluetooth-
compatible cell phone to the system while the vehicle
is parked.

Some functions are limited while driving. A message
appears on the screen when the vehicle is moving
and the operation is canceled.

Display the last 20 outgoing calls.

Display the last 20 incoming calls.

Display the last 20 missed calls.

*1 : Appears only when a phone is connected to HFL.

Speed Dial

Add New

Select a phone number from the call history to
store as a speed dial number.

Call History

Phonebook

Select a phone number from the phonebook to
store as a speed dial number.

Phone Number

Enter a phone number to store as a speed dial
number.

Dialed Calls

Received Calls

Missed Calls

Phonebook

Dial

Call History

Display the paired phones’s phonebook.

Enter a phone number to dial.

(Existing entry list)

392

Bluetooth® HandsFreeLink®

HFL Menus

Features

*1 : Appears only when a phone is connected to HFL.

Redial the last number dialed in the phone’s history.

Add New Device

Connect a Phone

Connect an Audio Device

Bluetooth Setup

Phone Setup

Redial

Pair a phone to the system.

Connect a phone to the system.

Create a code for a paired phone.

Disconnect All Devices

Delete Device

Pass-key

Disconnect a paired phone from the system.

Delete a previously paired phone.

Connect a Bluetooth® Audio device to the
system.

393

Bluetooth® HandsFreeLink®

HFL Menus

Continued

Features

*1 : Appears only when a phone is connected to HFL.

Call History

Phonebook

Phone Number

Speed Dial

Select a phone number from the phonebook
to store as a speed dial number.

Select a phone number from the call history
to store as a speed dial number.

Create a voice tag for a speed dial number.

Change Speed Dial

Delete Speed Dial

Store Voice Tag

Enter a phone number to store as a speed dial
number.

Delete a previously stored speed dial number.

Change Voice Tag

Delete Voice Tag

Change a previously stored speed dial
number.

Change a voice tag for a speed dial number.

Delete a voice tag for a speed dial number.

Add New

Existing entry list

394

Bluetooth® HandsFreeLink®

HFL Menus

Features

Fixed

Mobile Phone

System Clear

Ringtone

Select the ring tone stored in the connected
cell phone.

Name Priority

Number Priority

Caller ID Info

Prioritize the caller’s name as the caller ID.

Clear the system of all paired phones, phonebook entries,
and security codes.

Prioritize the caller’s phone number as the
caller ID.

Select the ring tone stored in HFL.

Auto Transfer

Set calls to automatically transfer from your phone to HFL
when you enter the vehicle.

Continued

395

Bluetooth® HandsFreeLink®

HFL Menus

Features

■

To pair a cell phone (No phone has
been paired to the system)

1. Press the

button or the

button.

2. Rotate

to select Yes, then press

3. Rotate

to select Add New Device,

then press

4. Press

to select OK.

5. Make sure your phone is in search or

discoverable mode.

HFL automatically searches for a
Bluetooth® device.

6. When your phone appears on the list, select

it by pressing

If your phone doesn’t appear, select
Phone Not Found? and search for
Bluetooth® devices using your phone.
From your phone, select
HandsFreeLink®.

7. The system gives you a pairing code on the

audio/information screen.

Confirm if the pairing code on the screen
and your phone match.
This may vary by phone.

8. A notification appears on the screen if

pairing is successful.

■

Phone Setup

Phone Setup

Your Bluetooth-compatible phone must be paired to
HFL before you can make and receive hands-free
calls.

Phone Pairing Tips:

•

You cannot pair your phone while the vehicle is
moving.

•

Up to six phones can be paired.

•

Your phone’s battery may drain faster when it is
paired to HFL.

•

If your phone is not ready for pairing or not found
by the system within 30 seconds, the system will
time out and return to idle.

Once you have paired a phone, you can see it
displayed on the screen with one or two icons on the
right side.
These icons indicate the following:

: The phone can be used with HFL.
: The phone is compatible with Bluetooth® Audio.

396

Bluetooth® HandsFreeLink®

HFL Menus

Features

■

To pair a cell phone (when a phone has already been paired to the system)

1. Press the

button or the

button.

If a prompt appears asking to connect to
a phone, select No and proceed with
step 2.

2. Rotate

select

Phone Setup, then

press .

3. Rotate

to select Bluetooth Setup, then

press .

4. Rotate

select

Add New Device,

then press

The screen changes to device list.

5. Make sure your phone is in search or

discoverable mode, then press

HFL automatically searches for a
Bluetooth® device.

397

Bluetooth® HandsFreeLink®

HFL Menus

Continued

Features

6. When your phone appears on the list, select

it by pressing

If your phone does not appear, select
Phone Not Found? and search for
Bluetooth® devices using your phone.
From your phone, select
HandsFreeLink®.

7. The system gives you a pairing code on the

audio/information screen.

Confirm if the pairing code on the screen
and your phone match.
This may vary by a phone.

398

Bluetooth® HandsFreeLink®

HFL Menus

Features

■

To change the currently paired phone

1. Press the

button or the

button.

2. Rotate

select

Phone Setup, then

press .

3. Rotate

to select Bluetooth Setup, then

press .

4. Rotate

select

Connect a Phone,

then press

The screen changes to a device list.

5. Rotate

to select a desired device name,

then press

HFL disconnects the connected phone
and starts searching for another paired
phone.

Content .. 23 24 25 26 ..
