Honda HR-V (2019 year). Instruction - part 2

Quick

Referenc

e Guide

Power Door Mirrors

(P186)
● With the ignition switch in ON

(

, move

the selector switch to L or R.

● Push the appropriate edge of the

adjustment switch to adjust the mirror.

*1 : Models with the smart entry system have an

ENGINE START/STOP button instead of an ignition
switch.

Selector Switch

Adjustment Switch

Power Windows

(P160)

● With the ignition switch in ON

(

, open

and close the power windows.

● If the power window lock button is in the

off position, each passenger’s window
can be opened and closed with its own
switch.

● If the power window lock button is in the

on position (indicator on), each
passenger’s window switch is disabled.

Power Window Lock Button

Window Switch

Indicator

Quick

Referenc

e Guide

Heating and Cooling System

(P209)

● Rotate the fan control dial to adjust the fan speed.

● Rotate the mode control dial (

) to select the vents air flows from.

● Rotate the temperature control dial to adjust the temperature.

● Rotate the fan control dial to OFF to turn the system off.

● Rotate the mode control dial to

to defrost the windshield.

Fan Control Dial

A/C (Air Conditioning) Button

Air flows from
windshield
defroster
vents.

Air flows
from floor
vents.

Air flows from
floor and
dashboard
vents.

Air flows
from
dashboard
vents.

Temperature Control Dial

Air flows from
floor and
windshield
defroster vents.

Mode Control Dial

(Recirculation) Button

* Not available on all models

Quick

Referenc

e Guide

Climate Control System

(P213)

● Select the AUTO icon to activate the climate control system.

● Select the

icon to turn the system on or off.

● Select the icon to defrost the windshield.

Models without SYNC icon

AUTO Icon

A/C (Air Conditioning) Icon

Air flows from
floor and
windshield
defroster vents.

Air flows from
floor vents.

Air flows from
floor and
dashboard vents.

Air flows from
dashboard
vents.

Temperature Control Icons

Fan Control Icons

(Recirculation) Icon

(On/Off) Icon

(Fresh Air) Icon

Mode Control Icon

(Windshield Defroster) Icon

Quick

Referenc

e Guide

Models with SYNC icon

AUTO Icon

SYNC (Synchronization) Icon

Air flows from
floor and
windshield
defroster vents.

Air flows from
floor vents.

Air flows from
floor and
dashboard vents.

Air flows from
dashboard
vents.

Driver Side Temperature
Control Icons

Passenger Side
Temperature Control
Icons

(Recirculation) Icon

(On/Off) Icon

Mode Control Icon

(Windshield Defroster) Icon

A/C (Air Conditioning) Icon

Fan Control Icons

* Not available on all models

Quick

Referenc

e Guide

Features

(P223)

Audio Remote Controls

(P227)

●

(

Button

Press to adjust the volume up/down.

● SOURCE Button

Press to change the audio mode: FM/AM/
CD/USB/iPod/Bluetooth® Audio.

Press to change the audio mode: FM/AM/
SiriusXM®

/USB/iPod/Bluetooth® Audio/

Pandora®

/Apps/Apple CarPlay

/Android

Auto

(

+ /

(

- /

Buttons

SOURCE Button

Models with color audio system

Models with display audio system

●

Button

Radio:Press to change the preset station.

Press and hold to select the next or
previous strong station.

/USB device:

Press to skip to the beginning of
the next song or return to the
beginning of the current song.
Press and hold to change a folder.

Quick

Referenc

e Guide

Audio System

(P224)

For navigation system operation

() See the Navigation System Manual

(P230)

Models with color audio system

MENU/CLOCK Button

LIST/SELECT Knob

(Day/Night)

Button

(Back) Button

(Sound) Button

VOL /

(Volume/Power)
Knob

CD Slot

(CD Eject) Button

Preset Buttons (1-6)

(Phone) Button

RADIO Button

(Skip/Seek) Buttons

MEDIA Button

Audio/Information Screen

* Not available on all models

Quick

Referenc

e Guide

(P251)

Models with display audio system

(Day/Night) Button

Audio/Information Screen

VOL /

(Volume/Power) Knob

(Back) Icon

(Menu) Icon

(Home) Icon

Quick

Referenc

e Guide

Driving

(P417)

Depress the brake pedal and press
the release button to move out of

(

Continuously Variable Transmission

(P434, 436)
● Shift to

(

P and depress the brake pedal when starting the engine.

Shifting

Park
Turn off or start the engine.
Transmission is locked.

Reverse
Used when reversing.

Neutral
Transmission is not locked.

Drive
Normal driving.
On models with paddle shifters,
7-speed mode can be used
temporarily.

Drive (S)

●

Better acceleration

●

Used to increase engine braking

●

Used when going up or down hills

Models without paddle shifters

Low

●

Used to further increase engine braking

●

Used when going up or down hills

Models without paddle shifters

Drive (S)
7-speed manual shift mode can
be used.

Models with paddle shifters

Move the shift lever without
pressing the release button.

Press the release button to move
the shift lever.

7-Speed Manual Shift Mode

(P438)

● Allows you to manually shift the transmission up or

down without removing your hands from the steering
wheel.

When the shift lever is in

(

● Pulling a paddle shifter changes the mode from

continuously variable transmission to 7-speed manual
shift mode.

● The M indicator and the selected speed number are

displayed in the shift indicator.

When the shift lever is in

(

● Pulling a paddle shifter temporarily changes the mode

from continuously variable transmission to 7-speed
manual shift mode. The selected speed number is
displayed in the shift indicator.

Shift Down

(

Paddle Shifter

Shift Up

(

Paddle Shifter

M Indicator

Models with
paddle shifters

Models without
paddle shifters

Shift Lever

Release
Button

Shift Indicator

* Not available on all models

Quick

Referenc

e Guide

VSA® On and Off

(P445)

● The Vehicle Stability Assist® (VSA®) system

helps stabilize the vehicle during
cornering, and helps maintain traction
while accelerating on loose or slippery
road surfaces.

● VSA® comes on automatically every time

you start the engine.

● To partially disable or fully restore VSA®

function, press and hold the button until
you hear a beep.

Cruise Control

(P441)

● Cruise control allows you to maintain a

set speed without keeping your foot on
the accelerator pedal.

● To use cruise control, press the CRUISE

button, then press the -/SET button once
you have achieved the desired speed
(above 25 mph or 40 km/h).

Tire Pressure Monitoring
System (TPMS)

(P449)

● Detects a change in tire conditions and

overall dimensions due to decrease in tire
pressures.

● TPMS is turned on automatically every

time you start the engine.

● A calibration procedure must be

performed when certain conditions arise.

U.S. models only

CMBS

On and Off

(P460)
● When a possible collision is likely

unavoidable, the CMBS

can help you to

reduce the vehicle speed and the severity
of the collision.

● The CMBS

is turned on every time you

start the engine.

● To turn the CMBS

on or off, press and

hold the button until you hear a beep.

Quick

Referenc

e Guide

Refueling

(P507)

Fuel recommendation: Unleaded gasoline, pump octane number 87 or higher

Fuel tank capacity: 13.2 US gal (50 L)

Pull the fuel fill door
release handle.

Turn the fuel fill cap
slowly to remove the
cap.

Place the cap in the
holder on the fuel fill
door.

After refueling, screw
the cap back on until it
clicks at least once.

* Not available on all models

Quick

Referenc

e Guide

Honda Sensing®

(P 454)

Honda Sensing® is a driver support system
which employs the use of two distinctly
different kinds of sensors, a radar sensor
located in the front grille and a front sensor
camera mounted to the interior side of the
windshield, behind the rearview mirror.

Front Sensor
Camera

The camera is located
behind the rearview
mirror.

Radar Sensor

The radar sensor is in
the front grille.

Collision Mitigation
Braking System

(CMBS

)

(P 457)

Can assist you when there is a possibility of
your vehicle colliding with a vehicle or a
pedestrian detected in front of yours. The
CMBS

is designed to alert you when a

potential collision is determined, as well as
to reduce your vehicle speed to help
minimize collision severity when a collision is
deemed unavoidable.

Adaptive Cruise Control
(ACC)

(P 467)

Helps maintain a constant vehicle speed and
a set following interval behind a vehicle
detected ahead of yours, without you
having to keep your foot on the brake or
the accelerator.

Lane Keeping Assist
System (LKAS)

(P 480)

Provides steering input to help keep the
vehicle in the middle of a detected lane and
provides tactile and visual alerts if the
vehicle is detected drifting out of its lane.

Road Departure
Mitigation (RDM) System

(P 489)

Alerts and helps to assist you when the
system detects a possibility of your vehicle
unintentionally crossing over detected lane
markings and/or leaving the roadway
altogether.

Quick

Referenc

e Guide

Maintenance

(P511)

Under the Hood

(P523)

● Check engine oil, engine coolant, and window washer fluid.

Add when necessary.

● Check brake fluid.

● Check the battery condition monthly.

Pull the hood release handle under the corner of the
dashboard.

Locate the hood latch lever, push it to the side, and then
raise the hood. Once you have raised the hood slightly,
you can release the lever.

When finished, close the hood and make sure it is firmly
locked in place.

Lights

(P535)

● Inspect all lights regularly.

Wiper Blades

(P545)

● Replace blades if they leave streaks

across the windshield.

Tires

(P549)

● Inspect tires and wheels regularly.

● Check tire pressures regularly.

● Install snow tires for winter driving.

* Not available on all models

Quick

Referenc

e Guide

Handling the Unexpected

(P573)

Flat Tire

(P576)

● Park in a safe location and replace the

flat tire with the compact spare tire in the
cargo area.

Indicators Come On

(P593)
● Identify the indicator and consult the

owner’s manual.

Engine Won’t Start

(P585)

● If the battery is dead, jump start using a

booster battery.

Blown Fuse

(P598)

● Check for a blown fuse if an electrical

device does not operate.

Overheating

(P591)

● Park in a safe location. If you do not see

steam under the hood, open the hood,
and let the engine cool down.

Emergency Towing

(P603)

● Call a professional towing service if you

need to tow your vehicle.

Quick

Referenc

e Guide

What to Do If

*1 : Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

The ignition switch does
not turn from

(

Why?

●

The steering wheel may be locked.

●

Try to turn the steering wheel left and
right while turning the ignition key.

●

Move the steering wheel left and right
after pressing the ENGINE START/STOP button.

The ignition switch does
not turn from

(

and

I cannot remove the key.
Why?

The power mode does not
change from ACCESSORY
to VEHICLE OFF (LOCK).
Why?

The shift lever should be moved to

(

Why does the brake pedal
pulsate slightly when
applying the brakes?

This can occur when the ABS activates and does not indicate a
problem. Apply firm, steady pressure on the brake pedal. Never
pump the brake pedal.

2 Anti-lock Brake System (ABS) (P502)

U.S. models without smart entry system
Canadian models

Models without smart entry system

Models with smart entry system

Models without smart entry system

Models with smart entry system

Quick

Referenc

e Guide

The rear door cannot be
opened from inside the
vehicle. Why?

Check if the childproof lock is in the
lock position. If so, open the rear door
with the outside door handle.
To cancel this function, push the lever
to the unlock position.

Why do the doors lock
after I unlocked the doors?

If you do not open the doors within 30 seconds, the doors are
relocked automatically for security.

Why does the beeper
sound when I open the
driver’s door?

The beeper sounds when:

●

The exterior lights are left on.

●

The key is left in the ignition switch.

●

The power mode is in ACCESSORY.

Why does a beeper sound
when I walk away from the
vehicle after I close the
door?

The beeper sounds if you move outside the walk away auto lock
operating range before the door completely closes.

2 Locking the doors and tailgate (Walk away auto lock®) (P140)

Models without smart entry system

Models with smart entry system

Quick

Referenc

e Guide

Why does the beeper
sound when I start driving?

The beeper sounds when the driver and/or front passenger are
not wearing their seat belts.

Why do I hear a screeching
sound when I apply the
brake pedal?

The brake pads may need to be replaced. Have your vehicle
inspected by a dealer.

Pressing the electric
parking brake switch does
not release the parking
brake. Why?

Press the electric parking brake switch with the brake pedal
depressed.

Depressing the accelerator
pedal does not release the
parking brake
automatically. Why?

●

Fasten the driver’s seat belt.

●

Check if the transmission is in

(

. If so, select any other

position.

I’m seeing an amber
indicator of a tire with an
exclamation point. What is
that?

The Tire Pressure Monitoring System (TPMS) needs attention. If
you recently inflated or changed a tire, you have to recalibrate
the system.

2 Tire Pressure Monitoring System (TPMS) (P449)

U.S. models only

Content .. 1 2 3 ..
