64

uu

Child Safety

u

Safety of Larger Children

Safe Driving

Safety of Larger Children

The following pages give instructions on how to check proper seat belt fit, what kind
of booster seat to use if one is needed, and important precautions for a child who
must sit in front.

When a child is too big for a child seat, secure the child in a rear seat using the lap/
shoulder seat belt. Have the child sit upright and all the way back, then answer the
following questions.

■

Checklist

• Do the child’s knees bend comfortably over

the edge of the seat?

• Does the shoulder belt cross between the

child’s neck and arm?

• Is the lap part of the seat belt as low as

possible, touching the child’s thighs?

• Will the child be able to stay seated like this

for the whole trip?

If you answer yes to all these questions, the child is ready to wear the lap/shoulder
seat belt correctly. If you answer no to any question, the child needs to ride on a
booster seat until the seat belt fits properly without a booster seat.

■

Protecting Larger Children

■

Checking Seat Belt Fit

1

Safety of Larger Children

3

WARNING

Allowing a child age 12 or under to sit in
front can result in injury or death if the
passenger’s front airbag inflates.

If a larger child must ride in front, move the
vehicle seat as far to the rear as possible,
have the child sit up properly and wear the
seat belt properly, using a booster seat if
needed.

65

uu

Child Safety

u

Safety of Larger Children

Safe Driving

If a lap/shoulder seat belt cannot be used
properly, position the child in a booster seat in
a rear seating position. For the child’s safety,
check that the child meets the booster seat
manufacturer’s recommendations.

Your vehicle has a rear seat where children can be properly restrained. If you ever
have to carry a group of children, and a child must ride in front:
• Make sure you read and fully understand the instructions and safety information

in this manual.

• Move the front passenger seat as far back as possible.
• Have the child sit upright and well back in the seat.
• Check that the seat belt is properly positioned so that the child is secure in the

seat.

■

Monitoring child passengers

We strongly recommend that you keep an eye on child passengers. Even older, more
mature children sometimes need to be reminded to fasten their seat belts and sit up
properly.

■

Booster Seats

1

Booster Seats

When installing a booster seat, make sure to read the
instructions that came with it, and install the seat
accordingly.
There are high- and low-type booster seats. Choose a
booster seat that allows the child to wear the seat
belt correctly.

Some U.S. states and Canadian provinces and
territories require children to use a booster seat until
they reach a given age or weight (e.g. 6 years or 60
lbs). Be sure to check current laws in the state or
province, or territory where you intend to drive.

■

Protecting Larger Children-Final Checks

66

Safe Driving

Exhaust Gas Hazard

Carbon Monoxide Gas

The engine exhaust from this vehicle contains carbon monoxide, a colorless,
odorless, and highly toxic gas. As long as you properly maintain your vehicle, carbon
monoxide gas will not get into the interior.

■

Have the exhaust system inspected for leaks whenever

• The exhaust system is making an unusual noise.
• The exhaust system may have been damaged.
• The vehicle is raised for an oil change.

When you operate a vehicle with the tailgate open, airflow can pull exhaust gas into
the interior and create a hazardous condition. If you must drive with the tailgate
open, open all the windows and set the heating and cooling system

*

/climate control

system

*

 as shown below.

1. Select the fresh air mode.

2. Select the

 mode.

3. Set the fan speed to high.
4. Set the temperature control to a comfortable setting.

Adjust the heating and cooling system

*

/climate control system

*

 in the same manner

if you sit in your parked vehicle with the engine running.

1

Carbon Monoxide Gas

An enclosed area such as a garage can quickly fill up
with carbon monoxide gas.
Do not run the engine with the garage door closed.
Even when the garage door is open, drive out of the
garage immediately after starting the engine.

3

WARNING

Carbon monoxide gas is toxic.
Breathing it can cause unconsciousness and
even kill you.

Avoid any enclosed areas or activities that
expose you to carbon monoxide.

* Not available on all models

67

Safe Driving

Safety Labels

Label Locations

These labels are in the locations shown. They warn you of potential hazards that can cause serious injury or death. Read these labels
carefully.

If a label comes off or becomes hard to read (except for the U.S. dashboard label which may be removed by the owner), contact a dealer
for a replacement.

Sun Visor
U.S. models

Canadian models

Radiator Cap

U.S. models

U.S. models only

Dashboard

Canadian models

Doorjambs

68

69

Instrument Panel

This chapter describes the buttons, indicators, and gauges that are used while driving.

Indicators ............................................ 70

Information Display Warning and

Information Messages...................... 82

Gauges and Displays

Gauges.............................................. 83
Information Display............................ 84

70

In

strum

e

nt Pa

nel

Indicators

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Parking Brake
and Brake
System Indicator
(Red)

●

Comes on for a few seconds when you
turn the ignition switch to ON

(

w

*1

, then

goes off if the parking brake has been
released.

●

Comes on when the parking brake is
applied, and goes off when it is released.

●

Comes on when the brake fluid level is
low.

●

Comes on if there is a problem with the
brake system.

●

The beeper sounds and the indicator
comes on if you drive with the parking
brake not fully released.

●

Comes on while driving - Make sure the parking
brake is released. Check the brake fluid level.

2 What to do when the indicator comes on while

driving P. 536

●

Comes on along with the ABS indicator - Have
the vehicle checked by a dealer.

2 If the Brake System Indicator (Red) Comes On

P. 536

Low Oil Pressure
Indicator

●

Comes on when you turn the ignition
switch to ON

(

w

*1

, and goes off when the

engine starts.

●

Comes on when the engine oil pressure is
low.

●

Comes on while driving - Immediately stop in a safe
place.

2 If the Low Oil Pressure Indicator Comes On P. 534

U.S.

Canada

71

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Malfunction
Indicator Lamp

●

Comes on when you turn the ignition switch
to ON

(

w

*1

, and goes off when the engine

starts, or after several seconds if the engine
did not start. If “readiness codes” have not
been set, it blinks five times before it goes off.

●

Comes on if there is a problem with the
emissions control system.

●

Blinks when a misfire in the engine’s cylinders
is detected.

●

Readiness codes are part of the on board diagnostics
for the emissions control systems.

2 Testing of Readiness Codes P. 553

●

Comes on while driving - Have the vehicle checked
by a dealer.

●

Blinks while driving - Stop in a safe place where
there are no flammable objects. Stop the engine for
10 minutes or more, and wait for it to cool down.
Then, take the vehicle to a dealer.

2 If the Malfunction Indicator Lamp Comes On or

Blinks P. 535

Charging System
Indicator

●

Comes on when you turn the ignition switch
to ON

(

w

*1

, and goes off when the engine

starts.

●

Comes on when the battery is not charging.

●

Comes on while driving - Turn off the heating and
cooling system

*

/climate control system

*

 and rear

defogger in order to reduce electricity consumption.

2 If the Charging System Indicator Comes On

P. 534

Seat Belt
Reminder
Indicator

●

Comes on and the beeper sounds if you are
not wearing a seat belt when you turn the
ignition switch to ON

(

w

*1

.

●

If the front passenger is not wearing a seat belt,
the indicator comes on a few seconds later.

●

Blinks while driving if either you or the front
passenger has not fastened a seat belt. The
beeper sounds and the indicator blinks at
regular intervals.

●

The beeper stops and the indicator goes off when you
and the front passenger fasten their seat belts.

●

Stays on after you or the front passenger has
fastened the seat belt - A detection error may have
occurred in the sensor. Have the vehicle checked by a
dealer.

2 Seat Belt Reminder P. 33

* Not available on all models

72

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Shift Lever
Position
Indicator

●

Indicates the current shift lever position.

2 Shifting P. 426, 428

M (sequential
shift mode)
Indicator/Gear
Position
Indicator

*

●

Comes on when the sequential shift mode is
applied.

2 Sequential Shift Mode P. 430

Transmission
Indicator

●

Comes on for a few seconds when you turn
the ignition switch to ON

(

w

*1

, then goes

off.

●

Blinks if the transmission system has a
problem.

●

Blinks while driving - Avoid sudden starts and
acceleration and have the vehicle checked by a dealer
immediately.

Low Fuel
Indicator

●

Comes on when the fuel reserve is running
low (approximately 2.5 U.S. gal./9.6 Liter
left on 2WD models, and 2.8 U.S. gal./10.5
Liter left on 4WD models).

●

Blinks if there is a problem with the fuel
gauge.

●

Comes on - Refuel your vehicle as soon as possible.

●

Blinks - Have the vehicle checked by a dealer.

* Not available on all models

73

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Anti-lock Brake
System (ABS)
Indicator

●

Comes on for a few seconds when you turn
the ignition switch to ON

(

w

*1

, then goes off.

●

If it comes on at any other time, there is a
problem with the ABS.

●

Stays on constantly - Have the vehicle checked by a
dealer. With this indicator on, your vehicle still has
normal braking ability but no anti-lock function.

2 Anti-lock Brake System (ABS) P. 451

Supplemental
Restraint System
Indicator

●

Comes on for a few seconds when you turn
the ignition switch to ON

(

w

*1

, then goes off.

●

Comes on if a problem with any of the
following is detected:
- Supplemental restraint system
- Side airbag system
- Side curtain airbag system
- Seat belt tensioner

●

Stays on constantly or does not come on at all -
Have the vehicle checked by a dealer.

Vehicle Stability
Assist (VSA®)
System Indicator

●

Comes on for a few seconds when you turn
the ignition switch to ON

(

w

*1

, then goes off.

●

Blinks when VSA® is active.

●

Comes on if there is a problem with the VSA®
system.

●

Stays on constantly - Have the vehicle checked by a
dealer.

2 Vehicle Stability Assist (VSA®), aka Electronic

Stability Control (ESC), System P. 442

VSA® OFF
Indicator

●

Comes on for a few seconds when you turn
the ignition switch to ON

(

w

*1

, then goes off.

●

Comes on when you deactivate VSA®.

2 VSA® On and Off P. 443

74

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Door and Tailgate
Open Indicator

●

Comes on for a few seconds if you turn the
ignition switch to ON

(

w

*1

, then goes off.

●

Comes on if any door or the tailgate is not
completely closed.

●

The beeper sounds and the indicator comes
on if any door or the tailgate is opened
while driving.

●

Goes off when all doors and the tailgate are closed.

Electric Power
Steering (EPS)
System Indicator

*

●

Comes on when you turn the ignition switch
to ON

(

w

*1

, and goes off when the engine

starts.

●

Comes on if there is a problem with the EPS
system.

●

Stays on constantly or does not come on at all -
Have the vehicle checked by a dealer.

2 If the Electric Power Steering (EPS) System

Indicator Comes On P. 536

* Not available on all models

75

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

TPMS Indicator

●

Comes on for a few seconds when you turn
the ignition switch to ON

(

w

*1

, then goes

off.

●

Comes on if there is a problem with the
TPMS, or when a compact spare tire is
temporarily installed.

●

Stays on constantly or does not come on at all -
Have the vehicle checked by a dealer. If the vehicle is
fitted with a compact spare, get your regular tire
repaired or replaced and put back on your vehicle as
soon as you can.

Low Tire Pressure
Indicator

●

Comes on for a few seconds when you turn
the ignition switch to ON

(

w

*1

, then goes

off.

●

Comes on if the tire pressure of any of the
tires becomes significantly low.

●

Comes on for a while and then goes off
when a compact spare tire is temporarily
installed.

●

Comes on while driving - Stop in a safe place,
check tire pressures, and inflate the tire(s) if
necessary.

Fuel Economy
Indicator

*

●

Comes on while the engine is operating in its
most economical range.

—

* Not available on all models

76

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Forward
Collision
Warning
(FCW)
Indicator

*

●

Comes on for a few seconds
when you turn the ignition
switch to ON

(

w

*1

, then goes

off.

●

Comes on when you have
customized FCW to turn off.

●

Comes on if there is a problem
with the FCW system.

●

Stays on constantly without FCW off - Have the vehicle
checked by a dealer.

●

Blinks when the system detects
a likely collision with a vehicle
in front of you. The beeper
sounds.

●

Blinks while driving - Take appropriate action to prevent
a collision (apply the brakes, change lanes, etc.).

—

●

Comes on when the FCW
system shuts itself off.

●

Stays on - The temperature inside the FCW system is too
high. The system activates when the temperature inside the
system cools down.

2 Automatic shutoff P. 437

●

Stays on - The radar sensor or the area around the camera
is blocked by dirt, mud, etc. Stop your vehicle in a safe
place, and wipe it off with a soft cloth.

●

Have your vehicle checked by a dealer if:
The indicator and message come back on after you cleaned
the area around the camera.

2 Automatic shutoff P. 437

2 Automatic shutoff P. 437

—

* Not available on all models

77

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Lane Departure
Warning (LDW)
Indicator

*

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

Comes on if there is a problem with
the LDW system.

●

Stays on constantly - Have the vehicle
checked by a dealer.

●

Blinks when your vehicle is too close
to the lane lines. The beeper sounds.

●

Blinks while driving - Take
appropriate action to keep your vehicle
within the lane lines.

—

●

Comes on when the LDW system
shuts itself off.

●

Stays on - The temperature inside the
LDW camera is too high.
The system activates when the
temperature inside the camera cools
down.

2 LDW Camera P. 440

●

Stays on - The area around the camera
is blocked by dirt, mud, etc. Stop your
vehicle in a safe place, and wipe it off
with a soft cloth.

●

Have your vehicle checked by a dealer if
the indicator and message come back
on after you cleaned the area around
the camera.

2 LDW Camera P. 440

* Not available on all models

78

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Smart Entry
System Indicator

*

●

Comes on for a few seconds when you
change the power mode to ON, then goes
off.

●

Comes on as soon as a problem is detected
in the smart entry system or push button
starting system.

●

Have your vehicle checked by a dealer.

Starter System
Indicator

*

●

Comes on for a few seconds when you set
the power mode to ON, then goes off.

●

Comes on if the starter system has a
problem.

●

As a temporary measure, press and hold the ENGINE
START/STOP button for 15 seconds while pressing
the brake pedal and manually start the engine. Have
the vehicle checked by a dealer.

Turn Signal and
Hazard Warning
Indicators

●

Blinks when you operate the turn signal
lever.

●

Blink if you press the hazard warning button.

●

Does not blink or blinks rapidly - A turn signal
light bulb has blown. Change the bulb immediately.

2 Replacing Light Bulbs P. 489, 490

U.S.

Canada

* Not available on all models

79

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

High Beam
Indicator

●

Comes on when the high beam headlights
are on.

—

Lights On
Indicator

●

Comes on whenever the light switch is on, or
in AUTO when the exterior lights are on.

●

If you remove the key from the ignition switch or set
the power mode to ACCESSORY or VEHICLE OFF
(LOCK) while the exterior lights are on, a chime
sounds when the driver’s door is opened.

Fog Light
Indicator

●

Comes on when the fog lights are on.

—

Daytime Running
Lights Indicator

●

Comes on for a few seconds when you turn
the ignition switch to ON

(

w

*1

, then goes

off.

●

Comes on if there is a problem with the DRL
system.

●

Have your vehicle checked by a dealer.

2 Daytime Running Lights P. 122

Side Airbag Off
Indicator

●

Comes on for a few seconds when you turn
the ignition switch to ON

(

w

*1

, then goes

off.

●

Comes on when the passenger side airbag
system is automatically shut off.

●

It does not mean there is a problem with your side
airbags.

●

Comes on when nobody is sitting in the
passenger seat - Have the vehicle checked by a
dealer.

●

Comes on when someone is sitting in the seat -
Have the passenger sit properly.

U.S.

Canada
