Audio System Basic Operation

u

Playing Pandora®

*

288

Features

You can operate some of the Pandora® menu items from your vehicle’s audio
system. The available items are:
• Bookmark
• Station List
• New Station
• Sound
• Setting

■

Operating a menu item

1. Select MENU.
2. Select an item.

■

Pandora® Menu

1

Pandora® Menu

Available operating functions vary on software
versions. Some functions may not be available on the
vehicle’s audio system.

If there is a problem, you may see an error message
on the audio/information screen.

2 Pandora®

*

 P. 310

Pandora® may limit the total number of skips allowed
on the service. If you dislike a track after the skip limit
has been reached, your feedback will be saved but
the current track will continue to play.

To change stations, activate the Pandora® menu,
select Station List, and then select a new station. It
also changes stations on the main Pandora® screen.

* Not available on all models

289

uu

Audio System Basic Operation

u

Playing a USB Flash Drive

Continued

Features

Playing a USB Flash Drive

Your audio system reads and plays sound files on a USB flash drive in either MP3,
WMA, or AAC

*1

 format.

Connect your USB flash drive to the USB port, then select the USB mode.

2 USB Port(s) P. 215

*1:Only AAC format files recorded with iTunes are playable on this unit.
*2:Some or all of the lists may not be displayed.

Track Icons
Select

or

to

change

files.

Select and hold to move rapidly within
a track.

Open/Close Icon

*2

Displays/hides the detailed
information.

Folder Icons
Select

 to skip to the next folder, and

 to skip to the beginning of the previous folder.

Audio/Information Screen

Driver Information Interface

 Button

Press to go back to the previous display.

VOL/

 AUDIO Knob

Press to turn the audio system on and off.
Turn to adjust the volume.

 Button

Press to display the audio screen.

uu

Audio System Basic Operation

u

Playing a USB Flash Drive

290

Features

1. Select MENU and select Music Search.
2. Select Music.

3. Select a folder.

4. Select a track.

■

How to Select a File from the Music Search List

1

Playing a USB Flash Drive

Use the recommended USB flash drives.

2 General Information on the Audio System

P. 312

WMA files protected by digital rights management
(DRM) cannot be played.
The audio system displays Unplayable File, then
skips to the next file.

If there is a problem, you may see an error message
on the audio/information screen.

2 iPod/USB Flash Drive P. 309

Folder Selection

Track Selection

291

uu

Audio System Basic Operation

u

Playing a USB Flash Drive

Features

You can select scan, repeat, and random modes when playing a file.

■

Scan

1. Select MENU.
2. Select Scan.
3. Select a play mode.

■

Random/Repeat

Select a play mode.

■

To turn off a play mode

To turn off Scan, press the

 button or Cancel.

To turn off Random/Repeat, select the mode again.

■

How to Select a Play Mode

1

How to Select a Play Mode

Play Mode Menu Items
Scan
Scan Folders: Provides 10-second sampling of the
first file in each of the main folders.
Scan Tracks: Provides 10-second sampling of all files
in the current folder.

Random/Repeat
Random in Folder: Plays all files in the current
folder in random order.
Random All Tracks: Plays all files in random order.
Repeat Folder: Repeats all files in the current folder.
Repeat Track: Repeats the current file.

292

uu

Audio System Basic Operation

u

Playing Bluetooth® Audio

Features

Playing Bluetooth® Audio

Your audio system allows you to listen to music from your Bluetooth-compatible
phone.
This function is available when the phone is paired and connected to the vehicle’s
Bluetooth® HandsFreeLink® (HFL) system.

2 Phone Setup P. 402

*1:Depending on the Bluetooth® device you connect, some or all of the lists may not

be displayed.

1

Playing Bluetooth® Audio

Not all Bluetooth-enabled phones with streaming
audio capabilities are compatible.
To check if your phone is compatible, visit
automobiles.honda.com/handsfreelink/.

It may be illegal to perform some data device
functions while driving.

Only one phone can be used with HFL at a time.
When there are more than two paired phones in the
vehicle, the system automatically connects to the
prioritized phone. You can assign priority to a phone
in the Priority Device Settings.

2 Customized Features P. 337

The connected phone for Bluetooth® Audio can be
different.

If more than one phone is paired to the HFL system,
there may be a delay before the system begins to play.

In some cases, the name of the artist, album, or track
may not appear correctly.

Some functions may not be available on some devices.

If a phone is currently connected via Apple CarPlay or
Android Auto, Bluetooth® Audio from that phone is
unavailable. However, a second previously paired
phone can stream Bluetooth® Audio by selecting
Connect

from

the

Bluetooth Device List.

2 Phone Setup P. 402

Audio/Information
Screen

Group Icons
Select

 or

 to change group.

Pause Icon

Play Icon

Bluetooth
Indicator
Appears when
your phone is
connected to
HFL.

Track Icons
Select

 or

 to change tracks.

Open/Close
Icon

*1

Displays/hides
the detailed
information.

Driver Information
Interface

 Button

Press to go back
to the previous
display.

VOL/

 AUDIO Knob

Press to turn the audio
system on and off. Turn to
adjust the volume.

 Button

Press to display
the audio screen.

293

uu

Audio System Basic Operation

u

Playing Bluetooth® Audio

Features

1. Make sure that your phone is paired and

connected to the system.

2 Phone Setup P. 402

2. Select the Bluetooth® Audio mode.

If the phone is not recognized, another HFL-
compatible phone, which is not compatible
for Bluetooth® Audio, may already be
connected.

■

To pause or resume a file

Select the play icon or pause icon.

1. Select MENU.
2. Select Music Search.
3. Select a search category (e.g., Albums).
4. Select an item.

u

The selection begins playing.

■

To Play Bluetooth® Audio Files

1

To Play Bluetooth® Audio Files

To play the audio files, you may need to operate your
phone. If so, follow the phone maker’s operating
instructions.

Switching to another mode pauses the music playing
from your phone.

You can change the connected phone in the
Bluetooth® settings on the Audio menu screen by
the following procedure.
1. Select MENU.
2. Select Setting.

■

Searching for Music

1

Searching for Music

Depending on the Bluetooth® device you connect,
some or all of the lists may not be displayed.

294

uu

Audio System Basic Operation

u

HondaLink®

Features

HondaLink®

HondaLink® connects you to the latest information from Honda. You can connect
your phone wirelessly through Wi-Fi or Bluetooth®.

2 Wi-Fi Connection P. 299
2 Phone Setup P. 402

■

Places

*

Displays restaurants, gas stations, Honda dealer, and so on. You can also navigate to
the found locations via the navigation.

■

Vehicle

Displays instruction messages when the vehicle needs service.

■

Help & Support

Displays tips for vehicle usage, and get support via road side or customer service
center.

■

HondaLink® Menu

1

HondaLink®

The HondaLink® connect app is compatible with most
iPhone and Android phones.

Some cell phone carriers charge for tethering and
smartphone data use. Check your phone’s data
subscription package.

When Apple CarPlay or Android Auto is connected to
the audio system, HondaLink® can be accessed even
without a Wi-Fi connection.

* Not available on all models

295

uu

Audio System Basic Operation

u

HondaLink®

Continued

Features

■

Messages from Honda

Displays helpful and important information from Honda.

■

Weather

*

Displays a weekly five-day weather forecast for any location you want. You can
change the ZIP Code at any time.

Use the following procedure to connect to HondaLink® service.

■

To enable the HondaLink® service

1. Press the

 button.

2. Select Settings.
3. Select Info.
4. Select the HondaLink tab.
5. Select Diagnostics & Location Data.
6. Select On.

You need to allow the consent of the location
service to enable the HondaLink® service.

Enable once: Allows only one time. (Prompt
shows again next time.)
Always Enable: Allows anytime. (Prompt
does not show again.)
Cancel: Does not allow this consent.

■

To Set Up to Connect HondaLink® Service

* Not available on all models

296

uu

Audio System Basic Operation

u

HondaLink®

Features

■

To link with HondaLink®

You can see the Connection Guide screen
after launching HondaLink®. If you do not
need this guide, select check-box and select
OK.

297

uu

Audio System Basic Operation

u

HondaLink®

Continued

Features

You can check the messages that are received quickly in the shortcut operation.

1. A message appears and notifies you of a

new message on the header area.

u

When the message is received, a
notification ring can be heard.

2. A message icon is continuously displayed in

the header area until the new message is
read.

■

Vehicle Information and Message from Honda Tips

Message
Icon

298

uu

Audio System Basic Operation

u

HondaLink®

Features

3. From the top of the screen, swipe down to

see the messages.

4. Select a new message to open.

299

uu

Audio System Basic Operation

u

Wi-Fi Connection

Continued

Features

Wi-Fi Connection

You can connect the audio system to the Internet using Wi-Fi and browse websites
or use online services on the audio/information screen. If your phone has wireless
hotspot capabilities, the system can be tethered to the phone. Use the following
steps to setup.

1. Press the

 button.

2. Select Settings.
3. Select Bluetooth/Wi-Fi.
4. Select the Wi-Fi tab.
5. Select Wi-Fi On/Off Status, then On.
6. Select Wi-Fi Device List.

u

Make sure your phone’s Wi-Fi setting is
in access point (tethering) mode.

u

Select the phone you want to connect to
the system.

u

If you do not find the phone you want to
connect in the list, select Scan.

7. Select Connect.

u

If needed, enter a password for your
phone and select OK.

u

When the connection is successful, the

 icon is displayed on the top of the

screen.

8. Press the

 button to go back to the home

screen.

■

Wi-Fi mode (setting for the first time)

1

Wi-Fi mode (setting for the first time)

You cannot go through the setting procedure while a
vehicle is moving. Park in a safe place to setup the
Wi-Fi connection.

Some cell phone carriers charge for tethering and
smartphone data use. Check your phone’s data
subscription package.

Check your phone manual to find out if the phone
has Wi-Fi connectivity.

You can confirm whether Wi-Fi connection is on or
off with the

 icon on Wi-Fi Device List. Network

speed will not be displayed on this screen.

12

ᾉ34

AAAAA

BBBBB

CCCCC

DDDDD

EEEEE

uu

Audio System Basic Operation

u

Wi-Fi Connection

300

Features

Make sure your phone's Wi-Fi setting is in access point (tethering) mode.

■

Wi-Fi mode (after the initial setting has been made)

1

Wi-Fi mode (after the initial setting has been made)

You may need to go through an initial setup for Wi-
Fi connection again after you boot your phone.

iPhone users

301

uu

Audio System Basic Operation

u

Siri Eyes Free

Features

Siri Eyes Free

You can talk to Siri using the

 (Talk) button on the steering wheel when your

iPhone is paired to the Bluetooth® HandsFreeLink® (HFL) system.

2 Phone Setup P. 402

■

Using Siri Eyes Free

1

Siri Eyes Free

Siri is a trademark of Apple Inc.

Check Apple Inc. website for features available for
Siri.

We recommend against using Siri other than in Siri
Eyes Free mode while operating a vehicle.

1

Using Siri Eyes Free

Some commands work only on specific phone
features or apps.

Voice Recognition

XXXXXX

 (Talk) Button

Press and hold until the display
changes as shown.

 (Hang-up/back) Button

Press to deactivate Siri Eyes Free.

While in Siri Eyes Free:
The display remains the same.
No feedback or commands
appear.

Appears
when Siri is
activated in
Siri Eyes Free

302

uu

Audio System Basic Operation

u

Apple CarPlay

Features

Apple CarPlay

If you connect an Apple CarPlay-compatible iPhone to the system via the front USB,
you can use the audio/information screen, instead of the iPhone display, to make a
phone call, listen to music, view maps (navigation), and access messages.

2 USB Port(s) P. 215

■

Phone

Access the contact list, make phone calls, or listen to voice mail.

■

Messages

Check and reply to text messages, or have messages read to you.

■

Music

Play music stored on your iPhone.

■

Apple CarPlay Menu

1

Apple CarPlay

Only iPhone 5 or newer versions with iOS 8.4 or later
are compatible with Apple CarPlay.

Park in a safe place before connecting your iPhone to
Apple CarPlay and when launching any compatible
apps.

To use Apple CarPlay, connect the USB cable to the
front USB port. The USB port located in the center
console storage will not enable Apple CarPlay
operation.

2 USB Port(s) P. 215

To directly access the Apple CarPlay phone function,
select Phone on the home screen. While connected
to Apple CarPlay, calls are only made through Apple
CarPlay. If you want to make a call with
HandsFreeLink, turn Apple CarPlay OFF or detach the
USB cable from your iPhone.

2 Setting Up Apple CarPlay P. 303

When your iPhone is connected to Apple CarPlay, it is
not possible to use the Bluetooth® Audio or
Bluetooth® HandsFreeLink®. However, other
previously paired phones can stream audio via
Bluetooth® while Apple CarPlay is connected.

2 Phone Setup P. 402

For details on countries and regions where Apple
CarPlay is available, as well as information pertaining
to function, refer to the Apple homepage.

Go back to the
home screen

Home screen

Apple CarPlay icon

Apple CarPlay menu screen

Go back to the Apple
CarPlay menu screen

Continued

303

uu

Audio System Basic Operation

u

Apple CarPlay

Features

■

Maps

Display Apple Maps and use the navigation function just as you would on your
iPhone.

Only one navigation system (pre-installed navigation or Apple CarPlay) can give
directions at a time. When you are using one system, directions to any prior
destination set on the other system will be canceled, and the system you are
currently using will direct you to your destination.

After you have connected your iPhone to the system via the front USB, use the
following procedure to set up Apple CarPlay. Use of Apple CarPlay will result in the
transmission of certain user and vehicle information (such as vehicle location, speed,
and status) to your iPhone to enhance the Apple CarPlay experience. You will need
to consent to the sharing of this information on the audio/information screen.

■

Enabling Apple CarPlay

Enable Once: Allows only once. (Prompt
shows again next time.)
Always Enable: Allows anytime. (Prompt
does not show again.)
Cancel: Does not allow this consent.

You may change the consent settings under
the Smartphone settings menu.

■

Setting Up Apple CarPlay

1

Apple CarPlay

Apple CarPlay Operating Requirements &
Limitations
Apple CarPlay requires a compatible iPhone with an
active cellular connection and data plan. Your
carrier’s rate plans will apply.

Changes in operating systems, hardware, software,
and other technology integral to providing Apple
CarPlay functionality, as well as new or revised
governmental regulations, may result in a decrease or
cessation of Apple CarPlay functionality and services.
Honda cannot and does not provide any warranty or
guarantee of future Apple CarPlay performance or
functionality.

It is possible to use 3rd party apps if they are
compatible with Apple CarPlay. Refer to the Apple
homepage for information on compatible apps.

Models with navigation system

1

Setting Up Apple CarPlay

You can also use the method below to set up Apple
CarPlay:
Press the

 button

Select Settings

Smartphone

Apple CarPlay

Use of user and vehicle information
The use and handling of user and vehicle information
transmitted to/from your iPhone by Apple CarPlay is
governed by the Apple iOS terms and conditions and
Apple’s Privacy Policy.
