Honda Civic Hybrid (2015 year). Instruction - part 12

uu

Audio System Basic Operation

u

Playing a USB Flash Drive

176

Features

1. Select MENU and select Music Search.

2. Select a folder.

3. Select a track.

■

How to Select a File from the Music Search List

1

Playing a USB Flash Drive

Use the recommended USB flash drives.

2 General Information on the Audio System

P. 188

Files in WMA format protected by digital rights
management (DRM) cannot be played.
The audio system displays Unplayable File, and then
skips to the next file.

If there is a problem, you may see an error message
on the audio/information screen.

2 iPod/USB Flash Drive P. 185

Folder Selection

Track Selection

177

uu

Audio System Basic Operation

u

Playing a USB Flash Drive

Features

You can select scan, repeat, and random modes when playing a file.

1. Select MENU.
2. Select Scan or Random/Repeat.
3. Select a mode.

■

To turn off a play mode

1. Select MENU.
2. Select the mode you want to turn off.

■

How to Select a Play Mode

1

How to Select a Play Mode

Play Mode Menu Items
Scan
Scan Folders: Provides 10-second sampling of the
first file in each of the main folders.
Scan Tracks: Provides 10-second sampling of all files
in the current folder.

Random/Repeat
Repeat Folder: Repeats all files in the current folder.
Repeat Track: Repeats the current file.
Random in Folder: Plays all files in the current folder
in random order.
Random All Tracks: Plays all files in random order.

Random/Repeat is selected.

178

uu

Audio System Basic Operation

u

Playing Bluetooth® Audio

Features

Playing Bluetooth® Audio

Your audio system allows you to listen to music from your Bluetooth-compatible
phone.
This function is available when the phone is paired and connected to the vehicle’s
Bluetooth® HandsFreeLink® (HFL) system.

2 Phone Setup P. 211

1

Playing Bluetooth® Audio

Not all Bluetooth-enabled phones with streaming
audio capabilities are compatible with the system.
For a list of compatible phones:

•

U.S.: Visit www.handsfreelink.honda.com, or call
1-888-528-7876.

•

Canada: Visit www.handsfreelink.ca, or call 1-888-
528-7876.

In some states, it may be illegal to perform some data
device functions while driving.

Only one phone can be used with HFL at a time.
When there are more than two paired phones in the
vehicle, the first paired phone the system finds is
automatically linked.

If more than one phone is paired to the HFL system,
there may be a delay before the system begins to
play.

In some cases, the name of the artist, album, or track
may not appear correctly.

A NO CONNECT message may be displayed if:

•

The phone is not linked to HFL.

•

The phone is not turned on.

•

The phone is not in the vehicle.

•

An incompatible phone is connected.

The following functions may not be available on
some devices:

•

Pause function

•

Group selection

*1: Depending on the Bluetooth® device you
connect, some or all of the lists may not be displayed.

ᵟᶐᶒᶇᶑᶒᴾᵟᵟᵟ

ᵟᶊᶀᶓᶋᴾᵟᵟᵟ

ᵎᵏᴾᵤᶇᶊᶃᴾᵟᵟᵟ

ᵮᶆᶍᶌᶃᴾᵟᵟᵟ

▲

▲

002300

75°

F

miles

123456

Genre AAA

File AAA

Artist AAA

Track Icons
Select

 or

 to change tracks.

Bluetooth Indicator
Appears when your
phone is connected
to HFL.

 (Power) Button

Press to turn the
audio system on
and off.

Audio/Information
Screen

Play Icon

Pause Icon

BACK
Select to go back to the
previous display.

MENU
Select to display the menu items.

Group Icons
Select

 or

 to change group.

VOL (Volume)
Select to adjust the volume.

Open/Close Icon

*1

Displays/hides the
detailed
information.

179

uu

Audio System Basic Operation

u

Playing Bluetooth® Audio

Features

1. Make sure that your phone is paired and

connected to the system.

2. Select the Bluetooth® Audio mode.

If the phone is not recognized, another HFL-
compatible phone, which is not compatible
for Bluetooth® Audio, may already be
connected.

■

To pause or resume a file

Select the play icon or pause icon.

1. Select MENU.
2. Select Music Search.
3. Select a search category (e.g., Albums).
4. Select an item.

u

The selection begins playing.

■

To Play Bluetooth® Audio Files

1

To Play Bluetooth® Audio Files

To play the audio files, you may need to operate your
phone. If so, follow the phone maker’s operating
instructions.

Switching to another mode pauses the music playing
from your phone.

▲

▲

■

Searching for Music

1

Searching for Music

Depending on the Bluetooth device you connect,
some or all of the lists may not be displayed.

180

uu

Audio System Basic Operation

u

Playing a Video Using the HDMI®

Features

Playing a Video Using the HDMI®

Your audio system allows you to play videos from an HDMI®-compatible device.
Connect the device, using an HDMI® cable, then select the HDMI® mode.

2 USB/HDMI® Port P. 149

Audio/Information Screen

BACK
Select to go back to the previous display.

VOL (Volume)
Select to adjust the volume.

MENU
Select to display the menu
items.

 (Power) Button

Press to turn the audio
system on and off.

181

uu

Audio System Basic Operation

u

Playing a Video Using the HDMI®

Features

1. Select Settings to go to the Settings

screen.

2. Select Audio.
3. Select Aspect Ratio Adjustment.
4. Select the setting you want.
5. Select OK.

■

Changing the Screen Aspect

1

Playing a Video Using the HDMI®

This feature is limited while driving. To play videos,
stop your vehicle and apply the parking brake.

182

uu

Audio System Basic Operation

u

Smartphone Apps

Features

Smartphone Apps

You can connect a compatible smartphone to the system to enable integration
between the smartphone's approved apps and the vehicle. This allows you to
control the phone through the vehicle display. To check smart phone compatibility,
download the HondaLink app, and view connection instructions, visit
handsfreelink.honda.com. For the latest apps and feature details, check
hondalink.com.

1

Smartphone Apps

Park in a safe place before connecting your phone
and while operating the displayed apps.

Not all phones and apps are compatible with the
system. The system does not display all the available
apps on smartphone, and some apps need to be
preinstalled. Ask a dealer for details.

You need to switch the Bluetooth connection to your
smartphone if another electronic device is connected.

2 Changing the currently paired phone

P. 212

The following may vary by phone type:

•

How to connect a smartphone to the system.

•

Apps that can be operated on the screen.

•

Display response time/update time.

We do not support every app operation on the
display audio.
Ask the app provider for any questions on the app’s
features.

MENU
Select to display the
menu on the app you
selected. (Not
available on all apps.)

BACK
Select to go back to the previous display.
(Not available on all phones.)

HOME
Select to go back to
HOME or to a previous
display.

Microphones

183

uu

Audio System Basic Operation

u

Siri Eyes Free

Features

Siri Eyes Free

You can talk to Siri using the Talk button on the steering wheel when your iPhone is
paired to Bluetooth® HandsFreeLink.

2 Phone Setup P. 211

■

Using Eyes Free

1

Siri Eyes Free

Siri is a trademark of Apple Inc.

Check Apple Inc. website for features available for
Siri.

When operating the vehicle, only use Siri through the
Talk button.

1

Using Eyes Free

Some commands work only on specific phone
features or apps.

 (Talk) button:

Press and hold until the display
changes as shown.

 (Hang-up/back) button:

Press to deactivate Siri.

While in Eyes Free:
The display remains the same.
No feedback or commands
appear.

Appears
when Siri is
activated in
Eyes Free

184

Features

Audio Error Messages

CD Player

If a disc error occurs, you may see the following error messages.

Error Message

Cause

Solution

Heat Error

High temperature

●

Turn the audio system off and allow the player to cool down until
the error message is cleared.

Unplayable File

Track/file format not
supported

●

Current track/file will be skipped. The next supported track/file
plays automatically.

Bad Disc
Please Check Owners Manual
Push Eject

Mechanical error

●

Press the

 (eject) button and remove the disc, and check that the

error message is cleared.

●

Check that the disc is not damaged or deformed, and insert the
disc again.

2 Protecting CDs P. 190

●

If the error message reappears, press the

 button, and pull out

the disc.

●

Insert a different disc.
If the new disc plays, there is a problem with the first disc.

●

If the error message repeats, or the disc cannot be removed,
contact a dealer.
Do not try to force the disc out of the player.

Mecha Error

Bad Disc
Please Check Owners Manual

Servo error

Check Disc

Disc error

●

Check that the disc is not damaged or deformed.

2 Protecting CDs P. 190

185

uu

Audio Error Messages

u

iPod/USB Flash Drive

Continued

Features

iPod/USB Flash Drive

If an error occurs while playing an iPod or USB flash drive, you may see the following
error messages. If you cannot clear the error message, contact a dealer.

Error Message

Solution

USB Error

Appears when there is a problem with the USB adapter unit. Check if the device is compatible with the
USB adapter unit.

The connected USB device
has a problem.
See Owner’s Manual

Appears when an incompatible device is connected. Disconnect the device. Then turn the audio system
off, and turn it on again. Do not reconnect the device that caused the error.

Unsupported Version

Appears when an unsupported iPod is connected. If it appears when a supported iPod is connected,
update the iPod software to the newer version.

Connect Retry

Appears when the system does not acknowledge the iPod. Reconnect the iPod.

Unplayable File

Appears when the files in the USB flash drive are DRM or an unsupported format. This error message
appears for about 3 seconds, then plays the next song.

No Data

Appears when the iPod is empty.

Appears when the USB flash drive is empty or there are no MP3, WMA, or AAC files in the USB flash
drive.

Check that compatible files are stored on the device.

Unsupported

Appears when an unsupported device is connected. If it appears when a supported device is
connected, reconnect the device.

iPod

USB flash drive

iPod and USB flash drive

186

uu

Audio Error Messages

u

Pandora®

Features

Pandora®

If an error occurs while playing Pandora®, you may see the following error messages.
If you cannot clear the error message, contact a dealer.

Error Message

Solution

The maximum number of stations that can be created is
100.
To create more, please delete one or more previously
created stations.

●

Appears when the number of stations that can be created is
exceeded. Follow the message.

Unable to create new station. Please try again.

●

Appears when the commanded operation is failed. Try again later.

Unable to play Pandora. Please try again later.

Unable to save bookmark.

This Pandora station is currently not available. Please select
another station.

●

Appears when the station you selected is not available. Change a
station, or try again later.

Unable to play Pandora. When stopped, log-in to Pandora.

●

Appears when you have not logged into Pandora®. Follow the
message.

Unable to connect to Pandora. When stopped, check your
mobile phone.

●

Appears when failed to connect. Check your device and try again.

Unable to play Pandora. Please try again later.

Connect Retry

U.S. models

187

uu

Audio Error Messages

u

Pandora®

Features

Error Message

Solution

Unsupported

●

Appears when the device is not supported. Use another device.

Unsupported Version

●

Appears when Pandora® version is not supported. Update
Pandora® to the latest version.

Pandora App version is not supported

Unable to connect to the phone.
Please make sure the phone’s Bluetooth setting is ON and
try again.

●

Appears when Pandora® is unable to play music. Check the
Bluetooth status on your device.

No Data

●

Appears when no data is available with Pandora® activated.
Reboot the app and reconnect the device.

The connected USB device has a problem.
See Owner’s Manual

●

Appears when an incompatible device is connected. Disconnect
the device. Then turn the audio system off, and turn it again. Do
not reconnect the device that caused the error.

No station list on device.
Use device to create station.

●

Appears when there is no station list on the device. Create one on
your device.

No Stations stored in Pandora App

●

Appears when there is no station on app. Store some.

The maximum number of tracks that can be skipped per
hour has been reached.

●

Appears when you try to skip a song or select Dislike over the
predetermined number of times in an hour.

188

Features

General Information on the Audio System

SiriusXM® Radio Service

*

1. You need your radio ID ready before registering for subscription. To see the ID in

the display: Select Channel List.

2. Have your radio ID and credit card number ready, and either call or visit the

SiriusXM® website to subscribe.

Switch to the SiriusXM® mode by using the SOURCE button on the steering wheel,
or through the audio/information screen, and stay in this mode for about 30
minutes until the service is activated. Make sure your vehicle is in an open area with
good reception.

Loading:
SiriusXM® is loading the audio or program information.
Channel off air:
The channel is not currently broadcasting.
Channel unauthorized:
SiriusXM® radio is receiving information update from the network.
No Signal:
The signal is too weak in the current location.
Channel unavailable:
No such channel exists, the channel is not part of your subscription, or the artist or
title information is unavailable.
Check antenna:
There is a problem with the SiriusXM® antenna. Contact a dealer.

■

Subscribing to SiriusXM® Radio

■

Receiving SiriusXM® Radio

■

SiriusXM® Radio Display Messages

1

Subscribing to SiriusXM® Radio

Contact Information for SiriusXM® Radio, visit
www.siriusxm.com or 1-800-852-9696

U.S. models

1

Receiving SiriusXM® Radio

The SiriusXM® satellites are in orbit over the equator;
therefore, objects south of the vehicle may cause
satellite reception interruptions. Satellite signals are
more likely to be blocked by tall buildings and
mountains the farther north you travel from the
equator.

You may experience reception problems under the
following circumstances:

•

In a location with an obstruction to the south of
your vehicle.

•

In tunnels

•

On the lower level of a multi-tiered road

•

Large items carried on the roof rack

* Not available on all models

189

uu

General Information on the Audio System

u

Recommended CDs

Continued

Features

Recommended CDs

• Use only high-quality CD-R or CD-RW discs labeled for audio use.
• Use only CD-R or CD-RW discs on which the recordings are closed.
• Play only standard round-shaped CDs.

• Some software files may not allow for audio play or text data display.
• Some versions of MP3, WMA or AAC formats may be unsupported.

1

Recommended CDs

A Dual-disc cannot play on this audio unit. If recorded
under certain conditions, a CD-R or CD-RW may not
play either.

■

CDs with MP3, WMA or AAC files

The CD packages or jackets should have one of these marks.

uu

General Information on the Audio System

u

Recommended CDs

190

Features

■

Protecting CDs

Follow these precautions when handling or storing CDs:
• Store a CD in its case when it is not being played.
• When wiping a CD, use a soft clean cloth from the center to the outside edge.
• Handle a CD by its edge. Never touch either surface.
• Never insert foreign objects into the CD player.
• Keep CDs out of direct sunlight and extreme heat.
• Do not place stabilizer rings or labels on the CD.
• Avoid fingerprints, liquids, and felt-tip pens on the CD.

1

Protecting CDs

NOTICE

Do not insert a damaged CD. It may be stuck inside
and damage the audio unit.

Examples:

●

Damaged CDs

Bubbled/
Wrinkled

With Label/
Sticker

Using
Printer Label
Kit

Sealed

With Plastic Ring

●

Poor quality
CDs

Chipped/
Cracked

Warped

Burrs

●

Small CDs

3-inch
(8-cm)
CD

●

Bubbled, wrinkled, labeled, and
excessively thick CDs

191

uu

General Information on the Audio System

u

Compatible iPod and USB Flash Drives

Features

Compatible iPod and USB Flash Drives

• Use a recommended USB flash drive of 256 MB or higher.
• Some digital audio players may not be compatible.
• Some USB flash drives (e.g., a device with security lockout) may not work.
• Some software files may not allow for audio play or text data display.
• Some versions of MP3, WMA, or AAC formats may be unsupported.

■

iPod and iPhone Model Compatibility

Model

iPod (5th generation)

iPod classic 80GB/160GB (launch in 2007)

iPod classic 120GB (launch in 2008)
iPod classic 160GB (launch in 2009)

iPod nano

iPod touch

iPhone 3G/iPhone 3GS/iPhone 4/iPhone 4S/iPhone 5

■

USB Flash Drives

1

iPod and iPhone Model Compatibility

This system may not work with all software versions
of these devices.

1

USB Flash Drives

Files on the USB flash drive are played in their stored
order. This order may be different from the order
displayed on your PC or device.
