Honda Civic Hatchback (2018 year). Instruction - part 30

When Driving

Shifting

464

Driving

■

7-Speed Manual Shift Mode Operation

7-Speed Manual Shift Mode Operation

Each paddle shift operation makes a single speed
change.
To change continuously, release the paddle shifter
before pulling it again for the next speed.

The shift indicator blinks when you cannot shift up or
down. It indicates that your vehicle speed is not in its
allowable shifting range.
Slightly accelerate to shift up and decelerate to shift
down while the indicator is blinking.

The shift indicator may also blink when you cannot
shift down while driving in low speed. This prevents
the transmission from being damaged.

(

- Paddle Shifter

(Shift down)

(

+ Paddle Shifter

(Shift up)

Downshifting when pulling
the

(

- paddle shifter

(Changes to lower speed
number)

Upshifting when pulling
the

(

+ paddle shifter

(Changes to higher speed
number)

465

When Driving

Shifting

Driving

Come on while the vehicle is in the 7-speed
manual shift mode to indicate when a speed
position change is appropriate to maintain the
most fuel efficient driving style.

The shift up indicator: Comes on when
shifting up is recommended.
The shift down indicator: Comes on when
shifting down is recommended.

■

Shift Up/Down Indicators

Shift Up/Down Indicators

This indicator will not prompt you to downshift to
increase engine braking. It is up to you to downshift
to increase engine braking when driving downhill.

Always shift down at the appropriate vehicle speed.

When the ECON mode is on, ambient meter color
may change if you do not change gears when a shift
indicator illuminates. This can result in a change in
fuel economy.

Road and traffic conditions may require you to shift
at times other than those indicated.

WARNING

The shift indicator is only a guide to help
you achieve better fuel economy.
Never refer to the Shift Indicators when
road and traffic conditions are unsuitable
or when it may distract you.

* Not available on all models

466

When Driving

Shifting

Driving

Shifting

Fully depress the clutch pedal to operate the shift lever and change gears, then
slowly release the pedal.

Depress the clutch pedal, and pause for a few seconds before shifting into

(

R, or

shift into one of the forward gears for a moment. This stops the gears so they do not
“grind.”

When you are not shifting, do not rest your
foot on the clutch pedal. This can cause your
clutch to wear out faster.

■

Shift Lever Operation

Manual transmission models

Shift Lever Operation

NOTICE

Do not shift to

(

R before the vehicle comes to a

complete stop.
Shifting to

(

R before stopping can damage the

transmission.

NOTICE

Before downshifting, make sure the engine will not
go into the tachometer's red zone. Should this occur,
it can severely damage your engine.

There is a metallic part on the shift lever. If you leave
the vehicle parked outside for a long time on a hot
day, be careful before moving the shift lever. Because
of heat, the shift lever may be extremely hot. If the
outside temperature is low, the shift lever may feel
cold.

If you exceed the maximum speed for the gear you
are in, the engine speed will enter into the
tachometer’s red zone. When this happens, you may
experience a slight jolt.

2.0 L engine models

Continued

467

When Driving

Shifting

Driving

Adjusts the engine’s RPM to match the optimal speed of the gear that is about to be
engaged.

2 Drive Mode Switch P. 471

■

Limitations

The rev match system will not activate under the following conditions:
• You are shifting into a lower gear, but the system has determined that the engine

will over rev.

• You are shifting into 1st gear from a higher gear.
• Engine RPM is low and you are shifting into a lower gear in sequential order.
• The system has determined that the engine will be at idling speed after you have

shifted into a higher gear.

• The clutch pedal is not fully depressed.
The rev match system may deactivate if the clutch is kept engaged for a extended
period of time.

■

Rev Match System

2.0 L engine models

Rev Match System

You can turn off the rev match system using the
driver information interface

or the audio/

information screen

2 Customized Features P. 133, 348

If you depress the accelerator pedal while changing
gears, the system will give priority to inputs from the
accelerator pedal.

If the message below appears, there may be a
problem with the system. The rev match system may
not operate, but you can perform regular gear
shifting. Have the system checked by a dealer.

* Not available on all models

When Driving

Shifting

468

Driving

Come on to indicate when a gear change is
appropriate to maintain the most fuel efficient
driving style.

The shift up indicator: Comes on when
shifting up is recommended.

The shift down indicator: Comes on when
shifting down is recommended.

■

Shift Up/Down Indicators

Shift Up/Down Indicators

This indicator will not prompt you to downshift to
increase engine braking. It is up to you to downshift
to increase engine braking when driving downhill.

Always shift down at the appropriate vehicle speed.

The shift down indicator does not come on when
downshifting from

(

2 to

(

When the ECON mode is on, ambient meter color
may change if you do not change gears when a shift
indicator illuminates. This can result in a change in
fuel economy.

Road and traffic conditions may require you to shift
at times other than those indicated.

WARNING

The shift indicator is only a guide to help
you achieve better fuel economy.
Never refer to the Shift Indicators when
road and traffic conditions are unsuitable
or when it may distract you.

* Not available on all models

469

When Driving

Shifting

Driving

The manual transmission has a lockout mechanism that stops you from accidentally
shifting into

(

R from a forward gear while the vehicle is moving above a certain

speed.

If you cannot shift to

(

R when the vehicle is stopped, do the following:

1. Depress the clutch pedal, move the shift

lever all the way to the left, and shift to

(

2. If you still cannot shift into

(

R, apply the

parking brake, and turn the ignition switch
to ACCESSORY

(

q or LOCK

(

3. Depress the clutch pedal and shift into

(

4. Keep depressing the clutch pedal and start

the engine.

Have the vehicle checked by a dealer if you
have to go through this procedure repeatedly.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Reverse Lockout

470

When Driving

ECON Button

Driving

ECON Button

The ECON button turns the ECON mode on and off.
The ECON mode helps you improve your fuel economy by adjusting the
performance of the engine, transmission, climate control system, and cruise
control

ECON Button

While in the ECON mode, the climate control system
has greater temperature fluctuations.

Models with information display

Models with driver information interface

* Not available on all models

471

When Driving

Drive Mode Switch

Continued

Driving

Drive Mode Switch

Constantly controls your vehicle’s engine, transmission, EPS, dampers, brakes and
VSA® according to the mode you select.
You can choose between three modes, +R mode, SPORT mode and COMFORT
mode by moving the drive mode switch forward or back.
The current mode is displayed on the driver information interface, and each mode
will appear differently.

2.0 L engine models

Drive Mode Switch

SPORT mode is selected every time you set the
power mode to ON.

The mode may not be able to be changed under
some driving conditions. If mode change is necessary,
reduce speed or cornering speed.
This message will also appear if you try to change
modes when there is a vehicle system failure.

Drive Mode Switch

+R Mode

SPORT
Mode

COMFORT
Mode

472

When Driving

Drive Mode Switch

Driving

2 Vehicle Stability Assist (VSA®), aka Electronic Stability Control (ESC), System P. 520
2 Rev Match System P. 467

Category

COMFORT

SPORT

Chassis
Control

Steering

Light feedback for easy
driving.

Increased feedback for sport
driving.

Increased feedback for high
performance driving.

Suspension
Damping

Minimized to provide a
soft ride.

Increased to provide improved
handling for sport driving.

Maximized to provide responsive
handling for high performance
driving.

VSA® and TCS

Balanced calibration for VSA® and Traction control in all
environments.

Track oriented control allowing
increased freedom for the driver.

Powertrain
Control

Acceleration
Feeling

Relaxed

Aggressive

Rev Match
System

Seamless

Responsive

473

When Driving

Cruise Control

Continued

Driving

Cruise Control

Maintains a constant vehicle speed without having to keep your foot on the
accelerator. Use cruise control on freeways or open roads where you can travel at a
constant speed with little acceleration or deceleration.

Cruise Control

It may not be possible to maintain a constant speed
when driving uphill or downhill.

When not using cruise control:
Turn off cruise control by pressing the CRUISE
button.

While in ECON mode

, it may take relatively more

time to accelerate to maintain the set speed.

When the engine speed slows down, try to
downshift.
You can maintain the set speed if you change gear
within five seconds.

WARNING

Improper use of the cruise control can lead
to a crash.

Use the cruise control only when traveling
on open highways in good weather.

Manual transmission models

Models with information display

When to use

■

Shift positions for cruise control:
In

(

D or

(

Always keep sufficient distance
between you and the vehicle in
front of you.

Continuously variable transmission models

■

Vehicle speed for cruise control:
Desired speed in a range above
roughly 25 mph (40 km/h) ~

How to use

CRUISE MAIN is on in the
instrument panel.
Cruise control is ready to use.

■

Press the CRUISE button on the
steering wheel.

* Not available on all models

474

When Driving

Cruise Control

Driving

Models with driver information interface

When to use

■

Shift positions for cruise control:
In

(

D or

(

Always keep sufficient distance
between you and the vehicle in
front of you.

Continuously variable transmission models

■

Vehicle speed for cruise control:
Desired speed in a range above
roughly 25 mph (40 km/h) ~

How to use

CRUISE MAIN is on in the
instrument panel.
Cruise control is ready to use.

■

Press the CRUISE button on the
steering wheel.

475

When Driving

Cruise Control

Continued

Driving

Take your foot off the pedal and press the –/SET button when you reach the desired speed.

The moment you release the –/SET button, the set speed is fixed, and cruise control begins. The CRUISE CONTROL indicator comes on.

When you use cruise control, Straight Driving Assist (a feature of the Electric Power Steering system) is activated.
By enabling the steering system to automatically compensate for natural steering pull, Straight Driving Assist makes it easier for you to keep
your vehicle in a straight line.

■

To Set the Vehicle Speed

–/SET Button

On when cruise control begins

Press and release

Models with information display

Models with driver information interface

On when cruise control begins

Press and release

–/SET Button

When Driving

Cruise Control

476

Driving

Increase or decrease the vehicle speed using the RES/+ or –/SET buttons on the
steering wheel.

• Each time you press the button, the vehicle speed is increased or decreased by

about 1 mph (1.6 km/h).

• If you keep the button pressed, the vehicle speed increases or decreases until you

release it. This speed is then set.

To cancel cruise control, do any of the
following:
• Press the CANCEL button.
• Press the CRUISE button.
• Depress the brake pedal.
• Depress the clutch pedal

for five seconds

or more.

The CRUISE CONTROL indicator goes off.

■

To Adjust the Vehicle Speed

To Adjust the Vehicle Speed

You can set the vehicle speed using the –/SET button
on the steering wheel when adjusting the speed with
the accelerator and brake pedals.

■

To Cancel

To decrease speed

To increase speed

To Cancel

Resuming the prior set speed:
After cruise control has been canceled, you can still
resume the prior set speed by pressing the RES/+
button while driving at a speed of at least 25 mph (40
km/h) or more.

You cannot set or resume in the following situations:

•

When vehicle speed is less than 25 mph (40 km/h)

•

When the CRUISE button is turned off.

At vehicle speeds of 22 mph (35 km/h) or less, cruise
control is canceled automatically.

CRUISE
Button

CANCEL
Button

* Not available on all models

477

When Driving

Front Sensor Camera

Continued

Driving

Front Sensor Camera

The camera, used in systems such as LKAS, RDM, ACC

, ACC with LSF

, CMBS

and auto high-beam, is designed to detect an object that triggers any of the systems
to operate its functions.

This camera is located behind the rearview
mirror.

To help reduce the likelihood that high interior
temperatures will cause the camera’s sensing
system to shut off, when parking, find a shady
area or face the front of the vehicle away from
the sun. If you use a reflective sun shade, do
not allow it to cover the camera housing.
Covering the camera can concentrate heat on
it.

■

Camera Location and Handling Tips

Front Sensor Camera

Never apply a film or attach any objects to the
windshield, hood, or front grill that could obstruct
the camera’s field of vision and cause the system to
operate abnormally.
Scratches, nicks, and other damage to the windshield
within the camera’s field of vision can cause the
system to operate abnormally. If this occurs, we
recommend that you replace the windshield with a
genuine Honda replacement windshield. Making
even minor repairs within the camera’s field of vision
or installing an aftermarket replacement windshield
may also cause the system to operate abnormally.
After replacing the windshield, have a dealer
recalibrate the camera. Proper calibration of the
camera is necessary for the system to operate
properly.

Do not place an object on the top of the instrument
panel. It may reflect onto the windshield and prevent
the system from detecting lane lines properly.

Front Sensor
Camera

* Not available on all models

When Driving

Front Sensor Camera

478

Driving

Front Sensor Camera

If the Some Driver Assist Systems Cannot
Operate: Camera Temperature Too High message
appears:

•

Use the climate control system to cool down the
interior and, if necessary, also use defroster mode
with the airflow directed towards the camera.

•

Start driving the vehicle to lower the windshield
temperature, which cools down the area around
the camera.

If the Some Driver Assist Systems Cannot
Operate: Clean Front Windshield message
appears:

•

Park your vehicle in a safe place, and clean the
windshield. If the message does not disappear after
you have cleaned the windshield and driven for a
while, have your vehicle checked by a dealer.

* Not available on all models

479

When Driving

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

Continued

Driving

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

Helps maintain a constant vehicle speed and a set following-interval behind a vehicle
detected ahead of yours and, if the detected vehicle comes to a stop, can decelerate
and stop your vehicle, without you having to keep your foot on the brake or the
accelerator.
When ACC with LSF slows your vehicle by applying the brakes, your vehicle’s brake
lights will illuminate.

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

Important Reminder
As with any system, there are limits to ACC with LSF.
Use the brake pedal whenever necessary, and always
keep a safe interval between your vehicle and other
vehicles.

WARNING

Improper use of ACC with LSF can lead to a
crash.

Use ACC with LSF only when driving on
expressways or freeways and in good
weather conditions.

WARNING

ACC with LSF has limited braking capability
and may not stop your vehicle in time to
avoid a collision with a vehicle that quickly
stops in front of you.

Always be prepared to apply the brake
pedal if the conditions require.

When to use

■

Vehicle speed for ACC with LSF: A vehicle is detected ahead within ACC with
LSF range – ACC with LSF operates at speeds up to 90 mph (145 km/h).
No vehicle is detected within ACC with LSF range – ACC with LSF operates at
the speed of 25 mph (40km/h) or above.

■

Shift position for ACC with LSF: In

(

D or

(

The radar sensor is in
the lower bumper
next to the fog light

Be careful not to have
the radar sensor cover
strongly impacted.

The camera is
located behind
the rearview
mirror.

* Not available on all models

Content .. 28 29 30 31 ..
