When Driving

u

Shifting

Driving

Use the paddle shifters to change between 1st and 10th gears without removing
your hands from the steering wheel. The transmission will switch to the sequential
mode.

■

When the transmission is in

(

D:

The vehicle will go into the sequential mode momentarily, and the gear selection
indicator will come on.
When the vehicle goes into the sequential mode by

(

- paddle shifter and the lower

gear is available, the transmission properly selects single or double gear change.

Once you start traveling at a constant speed, the sequential mode will automatically
switch off, and the gear selection indicator will go off.

Hold the

(

+ paddle shifter for two seconds to return to normal drive.

■

When the transmission is in

(

D with SPORT mode:

The vehicle will go into the sequential mode, and the M (sequential mode) indicator
and gear selection indicator will come on.
If the vehicle speed increases and the engine speed reaches near the tachometer’s
red zone, the transmission automatically shifts up to the next gear.
You can cancel this mode by holding the

(

+ paddle shifter for two seconds. When

the sequential mode is canceled, the sequential mode indicator and gear selection
indicator go off.

■

Sequential Mode

481

uu

When Driving

u

Shifting

Driving

■

Sequential Mode Operation

1

Sequential Mode Operation

Each paddle shift operation makes a single gear
change.
To change gears continuously, release the paddle
shifter before pulling it again for the next gear.

If the gear selection indicator blinks when you try to
shift up or down, this means your vehicle speed is not
in its allowable gear range or the protection of
transmission system is necessary.
Slightly accelerate to shift up and decelerate to shift
down while the indicator is blinking.

Gear Selection
Indicator

(

- Paddle Shifter

(Shift down)

(

+ Paddle Shifter

(Shift up)

Downshifting when pulling
the

(

- paddle shifter.

(Changes to a lower gear)

Upshifting when pulling
the

(

+ paddle shifter.

(Changes to a higher gear)

482

uu

When Driving

u

Shifting

Driving

Shifting

Change the shift position in accordance with your driving needs.

■

Shift lever positions

Continuously variable transmission models without paddle shifters

1

Shifting

You cannot change the power mode from ON to
VEHICLE OFF unless the shift lever is in

(

P.

The vehicle may move very slightly even in

(

N while

the engine is cold.
Depress the brake pedal firmly and, when necessary,
apply the parking brake.

Reverse
Used when reversing

Drive
Used for normal driving

Park
Used when parking or starting the engine

Neutral
Transmission is not locked.

Release Button

Drive (S)
Used:

●

For better acceleration

●

To increase engine braking

●

When going up or down hills

Low
Used:

●

To further increase engine braking

●

When going up or down hills

483

uu

When Driving

u

Shifting

Driving

■

Shift Lever Operation

1

Shift Lever Operation

NOTICE

When you change the shift lever from

(

D to

(

R and

vice versa, come to a complete stop and keep the
brake pedal depressed.
Operating the shift lever before the vehicle has come
to a complete standstill can damage the transmission.

Use the gear position indicator to check the lever
position before pulling away.

If the transmission system indicator blinks when
driving, in any shift position, there is a problem with
the transmission.
Avoid sudden acceleration and have the transmission
checked by a dealer as soon as possible.

The fuel supply may be cut off if you drive at engine
speeds in or over the tachometer’s red zone (engine
speed limit). If this happens, you may experience a
slight jolt.

It may not be possible to operate the shift lever if the
brake pedal is applied while the shift lever release
button is held down.
Depress the brake pedal first.

When shifting positions in extremely low
temperatures (-22°F/-30°C), there may be a short
delay before the shift position is displayed. Always
confirm you are in the correct shift position before
driving.

Depress the brake pedal and press the shift lever release
button to shift.

Shift without pressing the shift lever release button.

Press the shift lever release button and shift.

Gear Position Indicator
(Transmission System Indicator)

Tachometer’s red zone

484

uu

When Driving

u

Shifting

Driving

Shifting

Change the shift position in accordance with your driving needs.

■

Shift lever positions

Continuously variable transmission models with paddle shifters

1

Shifting

You cannot change the power mode from ON to
VEHICLE OFF unless the shift lever is in

(

P.

The vehicle may move very slightly even in

(

N while

the engine is cold.
Depress the brake pedal firmly and, when necessary,
apply the parking brake.

Reverse
Used when reversing

Drive
Used:

●

For normal driving

●

When temporarily driving in the 7-speed
manual shift mode

●

When driving in the 7-speed manual
shift mode (when driving in SPORT
mode)

Neutral
Transmission is not locked.

Release Button

Park
Used when parking or starting the engine

Continued

485

uu

When Driving

u

Shifting

Driving

■

Shift Lever Operation

1

Shift Lever Operation

NOTICE

When you change the shift lever from

(

D to

(

R and

vice versa, come to a complete stop and keep the
brake pedal depressed.
Operating the shift lever before the vehicle has come
to a complete standstill can damage the transmission.

Use the gear position indicator to check the lever
position before pulling away.

If the transmission system indicator blinks when
driving, in any shift position, there is a problem with
the transmission.
Avoid sudden acceleration and have the transmission
checked by a dealer as soon as possible.

The fuel supply may be cut off if you drive at engine
speeds in or over the tachometer’s red zone (engine
speed limit). If this happens, you may experience a
slight jolt.

It may not be possible to operate the shift lever if the
brake pedal is applied while the shift lever release
button is held down.
Depress the brake pedal first.

When shifting positions in extremely low
temperatures (-22°F/-30°C), there may be a short
delay before the shift position is displayed. Always
confirm you are in the correct shift position before
driving.

Depress the brake pedal and press the shift lever release
button to shift.

Shift without pressing the shift lever release button.

Press the shift lever release button and shift.

Gear Position Indicator
(Transmission System Indicator)

Tachometer’s red zone

M (7-Speed Manual Shift Mode)
Indicator

Gear Selection Indicator

uu

When Driving

u

Shifting

486

Driving

Use the paddle shifters to change between 1st and 7th speeds without releasing
your hands from the steering wheel. The transmission switches to the 7-speed
manual shift mode when you pull a paddle shifter while driving. This mode is useful
when engine braking is needed.

■

When the shift lever is in

(

D:

The shift mode goes into the 7-speed manual shift mode temporarily, and the
number is displayed in the gear selection indicator.
The 7-speed manual shift mode is canceled automatically if you drive at constant
speed or accelerate, and the number in the gear selection indicator goes off.
You can cancel this mode by pulling the

(

+ paddle shifter for a few seconds.

The 7-speed manual shift mode is especially useful when reducing the vehicle speed
temporarily before making a turn.

■

When the shift lever is in

(

D with SPORT mode:

The shift mode goes into the 7-speed manual shift mode. The M indicator and the
speed number are displayed in the gear selection indicator. As the vehicle speed
slows down, the transmission automatically shifts down accordingly. When the
vehicle comes to a stop, it automatically shifts down into 1st.

If the vehicle speed increases and the engine speed reaches near the tachometer’s
red zone, the transmission automatically shifts up.

You can only pull away in 1st speed.

When canceling the 7-speed manual shift mode, pressing the SPORT button. When
the 7-speed manual shift mode is canceled, the M indicator and gear selection
indicator go off.

■

7-Speed Manual Shift Mode

1

7-Speed Manual Shift Mode

In the 7-speed manual shift mode, the transmission
shifts up or down by operating either paddle shifter
under the following conditions:
Shift Up: The engine speed reaches the lowest
threshold of the higher speed position.
Shift Down: The engine speed reaches the highest
threshold of the lower speed position.

When the engine speed reaches near the
tachometer’s red zone, the transmission shifts up
automatically.
When the engine speed reaches the lowest threshold
of the selected speed position, the transmission shifts
down automatically.

Operating the paddle shifters on slippery surfaces
may cause the tires to lock up. In this case, the 7-
speed manual shift mode is canceled and goes back
to the normal D driving mode.

487

uu

When Driving

u

Shifting

Driving

■

7-Speed Manual Shift Mode Operation

1

7-Speed Manual Shift Mode Operation

Each paddle shift operation makes a single speed
change.
To change continuously, release the paddle shifter
before pulling it again for the next speed.

The gear selection indicator blinks when you cannot
shift up or down. It indicates that your vehicle speed
is not in its allowable shifting range.
Slightly accelerate to shift up and decelerate to shift
down while the indicator is blinking.

(

- Paddle Shifter

(Shift down)

(

+ Paddle Shifter

(Shift up)

Downshifting when pulling
the

(

- paddle shifter.

(Changes to lower speed
number)

Upshifting when pulling
the

(

+ paddle shifter.

(Changes to higher speed
number)

488

uu

When Driving

u

Shifting

Driving

Shifting

Fully depress the clutch pedal to operate the shift lever and change gears, then
slowly release the pedal.

Depress the clutch pedal, and pause for a few seconds before shifting into

(

R, or

shift into one of the forward gears for a moment. This stops the gears so they do not
“grind.”

When you are not shifting, do not rest your
foot on the clutch pedal. This can cause your
clutch to wear out faster.

■

Shift Lever Operation

Manual transmission models

1

Shifting

NOTICE

Do not shift to

(

R before the vehicle comes to a

complete stop.
Shifting to

(

R before stopping can damage the

transmission.

NOTICE

Before downshifting, make sure the engine will not
go into the tachometer’s red zone. Should this occur,
it can severely damage your engine.

There is a metallic part on the shift lever. If you leave
the vehicle parked outside for a long time on a hot
day, be careful before moving the shift lever. Because
of heat, the shift lever may be extremely hot. If the
outside temperature is low, the shift lever may feel
cold.

If you exceed the maximum speed for the gear you
are in, the engine speed will enter into the
tachometer’s red zone. When this happens, you may
experience a slight jolt.

Continued

489

uu

When Driving

u

Shifting

Driving

Come on to inform you that upshifting or
downshifting is necessary to prevent the
engine from over revving or stalling.

The shift up indicator:
Comes on when upshifting is recommended.

The shift down indicator:
Comes on when downshifting is
recommended.

■

Shift Up/Down Indicators

1

Shift Up/Down Indicators

This indicator will not prompt you to downshift to
increase engine braking. It is up to you to downshift
to increase engine braking when driving downhill.

Always shift down at the appropriate vehicle speed.

The shift down indicator does not come on when
downshifting from

(

2 to

(

1.

Road and traffic conditions may require you to shift
at times other than those indicated.

490

uu

When Driving

u

Shifting

Driving

The manual transmission has a lockout mechanism that stops you from accidentally
shifting into

(

R from a forward gear while the vehicle is moving above a certain

speed.

If you cannot shift to

(

R when the vehicle is stopped, do the following:

1. Depress the clutch pedal, move the shift

lever all the way to the left, and shift to

(

R.

2. If you still cannot shift into

(

R, apply the

parking brake, and set the power mode to
ACCESSORY or VEHICLE OFF.

3. Depress the clutch pedal and shift into

(

R.

4. Keep depressing the clutch pedal and start

the engine.

Have the vehicle checked by a dealer if you
have to go through this procedure repeatedly.

■

Reverse Lockout

491

uu

When Driving

u

SPORT Mode

*

Driving

SPORT Mode

*

To turn the SPORT mode on and off, press the SPORT button.

The SPORT mode increases engine performance, transmission and handling

*

.

This mode is suitable for driving on hills or through curves on mountain roads.

The SPORT mode is turned off every time you start the engine, even if you turned it
on the last time you drove the vehicle.

The ambient meter color changes to a constant red and the turbo meter appears on
the driver information interface.

SPORT Button

SPORT Mode Indicator

Models with adaptive
damper system

Models without adaptive
damper system

* Not available on all models

492

uu

When Driving

u

ECON Button

Driving

ECON Button

The ECON button turns the ECON mode on and off.
The ECON mode helps you improve your fuel economy by adjusting the
performance of the engine, transmission and climate control system.

*1 : Models without the adaptive damper system
*2 : Models with the adaptive damper system
*3 : Continuously variable transmission models without SPORT mode
*4 : Manual transmission models
*5 : Automatic transmission/Continuously variable transmission models with SPORT mode

1

ECON Button

While in ECON mode, the climate control system has
greater temperature fluctuations.

*1

*2

*3

*4

*5

493

uu

When Driving

u

Adaptive Damper System

*

Driving

Adaptive Damper System

*

Constantly controls your vehicle’s front and rear dampers according to current road
conditions, vehicle speed and steering operation.

You can change handling response by turning the SPORT mode on.

2 SPORT Mode

*

 P. 491

* Not available on all models

494

uu

When Driving

u

Vehicle Stability Assist® (VSA®), aka Electronic Stability Control (ESC), System

Driving

Vehicle Stability Assist® (VSA®), aka Electronic
Stability Control (ESC), System

VSA® helps to stabilize the vehicle during cornering if the vehicle turns more or less
than what was intended. It also assists in maintaining traction on slippery surfaces.
It does so by regulating engine output and selectively applying the brakes.

When VSA® activates, you may notice that the
engine does not respond to the accelerator.
You may also notice some noise from the
hydraulic system. You will also see the
indicator blink.

■

VSA® Operation

1

Vehicle Stability Assist® (VSA®), aka Electronic Stability Control
(ESC), System

The VSA® may not function properly if tire type and
size are mixed. Make sure to use the same size and
type of tire, and the air pressures as specified.

When the VSA® system indicator comes on and stays
on while driving, there may be a problem with the
system. While this may not interfere with normal
driving, have your vehicle checked by a dealer
immediately.

VSA® cannot enhance stability in all driving situations
and does not control the entire braking system. You
still need to drive and corner at speeds appropriate
for the conditions and always leave a sufficient
margin of safety.

The main function of the VSA® system is generally
known as Electronic Stability Control (ESC). The
system also includes a traction control function.

The Vehicle Stability Assist® (VSA®) system, Vehicle
Stability Assist® (VSA®) OFF, adaptive cruise control
(ACC) with low speed follow (LSF)

*

, adaptive cruise

control (ACC)

*

, safety support and low tire pressure/

TPMS indicators may come on in amber along with a
message in the driver information interface when you
set the power mode to ON after re-connecting a
battery.
Drive a short distance at more than 12 mph (20 km/h).
Each indicator should go off. If any do not, have your
vehicle checked by a dealer.

VSA® System
Indicator

* Not available on all models

495

uu

When Driving

u

Vehicle Stability Assist® (VSA®), aka Electronic Stability Control (ESC), System

Driving

This button is on the driver side control panel.
To partially disable VSA® functionality/features,
press and hold it until you hear a beep.

Your vehicle will have normal braking and
cornering ability, but traction control function
will be less effective.

To restore VSA® functionality/features, press
the

(VSA® OFF) button until you hear a

beep.

VSA® is turned on every time you start the
engine, even if you turned it off the last time
you drove the vehicle.

■

VSA® On and Off

1

Vehicle Stability Assist® (VSA®), aka Electronic Stability Control
(ESC), System

In certain unusual conditions when your vehicle gets
stuck in shallow mud or fresh snow, it may be easier
to free it with the VSA® temporarily switched off.

When the

 button is pressed, the traction control

function becomes less effective. This allows for the
wheels to spin more freely at low speed. You should
only attempt to free your vehicle with the VSA® off if
you are not able to free it when the VSA® is on.

Immediately after freeing your vehicle, be sure to
switch VSA® on again. We do not recommend driving
your vehicle with the VSA® system switched off.

You may hear a motor sound coming from the
engine compartment while system checks are being
performed immediately after starting the engine or
while driving. This is normal.

VSA® OFF Indicator
