Honda Accord Hybrid (2019 year). Instruction - part 29

uu

Bluetooth® HandsFreeLink®

u

HondaLink® Assist

*

448

Features

■

To enable notification

1. Go to the phone settings screen.

2 Phone settings screen P. 427

2. Select HondaLink Assist.
3. Select YES or NO.

1

To enable notification

Setting options:

•

YES: Notification is available.

•

NO: Disable the feature.

449

Features

Refuel Recommend

Your vehicle is equipped with a feature that recommends refueling at a timing of
your preference. Once the system is programmed, this feature will notify you when
refueling is recommended as well as enable you to search for gas stations that are
located in the vicinity of your vehicle.

1. When it is time to refuel the vehicle, a

notification is displayed and a notification
icon is displayed in the header.

2. Touch the box that contains the icon.

3. Select Find Gas Station Now.

4. Choose a gas station from the search

screen of the navigation system.

u

For instructions on how to use the
navigation system, refer to the
navigation system manual.

1

Refuel Recommend

You can change the setting for Refuel Recommend
by selecting: SettingsSystemRefuel
recommend

When you turn off this feature, the timing that you
programmed for refueling will be deleted.

This feature can only be used when the fuel level in
the tank is below 30 percent.

If you select Find Gas Station Now or put more
than 5 liters of gasoline into the fuel tank, the
notification for refueling will disappear. If you prefer
not to be notified, select OFF in the settings for
Refuel Recommend.

When you drive on a rough road or ascend or
descend a hill for an extended period of time, the
notification may disappear or may not be displayed at
all.

Models with navigation system

Notification
Icon

450

451

Driving

This chapter discusses driving and refueling.

Before Driving................................... 452
Towing a Trailer................................ 457
When Driving

Turning on the Power ...................... 458
Precautions While Driving................. 464
Transmission .................................... 464
Shifting ............................................ 465
SPORT Mode.................................... 471
Deceleration Paddle Selector ............ 472
ECON Button ................................... 475
Acoustic Vehicle Alerting System...... 476
Adaptive Damper System

*

............... 476

Vehicle Stability Assist® (VSA®), aka Electronic

Stability Control (ESC), System .............. 477

Agile Handling Assist ....................... 479
Tire Pressure Monitoring System (TPMS) .. 480
Tire Pressure Monitoring System (TPMS) -

Required Federal Explanation ......... 483

Blind spot information System

*

........... 485

High Voltage Battery........................ 488
LaneWatch

TM

*

.................................. 489

Honda Sensing®

Collision Mitigation Braking System

TM



(CMBS

TM

) ....................................... 494

Adaptive Cruise Control (ACC) with Low

Speed Follow (LSF) ......................... 503

Lane Keeping Assist System (LKAS) .. 519

Road Departure Mitigation (RDM) System....527
Traffic Sign Recognition System ....... 531
Front Sensor Camera ....................... 537
Radar Sensor ................................... 539

Braking

Brake System ................................... 540
Anti-lock Brake System (ABS) ........... 547
Brake Assist System ......................... 548

Parking Your Vehicle........................ 549
Multi-View Rear Camera.................. 560
Refueling........................................... 563
Fuel Economy and CO

2

 Emissions.... 566

* Not available on all models

452

Driving

Before Driving

Driving Preparation

Check the following items before you start driving.

• Make sure there are no obstructions on the windows, door mirrors, exterior

lights, or other parts of the vehicle.

u

Remove any frost, snow, or ice.

u

Remove any snow on the roof, as this can slip down and obstruct your field of
vision while driving. If frozen solid, remove ice once it has softened.

u

When removing ice from around the wheels, be sure not to damage the wheel
or wheel components.

• Make sure the hood is securely closed.

u

If the hood opens while driving, your front view will be blocked.

• Make sure the tires are in good condition.

u

Check air pressures, and check for damage and excessive wear.

2 Checking and Maintaining Tires P. 602

• Make sure there are no people or objects behind or around the vehicle.

u

There are blind spots from the inside.

■

Exterior Checks

1

Exterior Checks

NOTICE

When doors are frozen shut, use warm water around
the door edges to melt any ice. Do not try to force
them open, as this can damage the rubber trim
around the doors. When done, wipe dry to avoid
further freezing.

Do not pour warm water into the key cylinder.
You will be unable to insert the key if the water
freezes in the hole.

Heat from the engine and exhaust can ignite
flammable materials left under the hood, causing a
fire. If you’ve parked your vehicle for an extended
period, inspect and remove any debris that may have
collected, such as dried grass and leaves that have
fallen or have been carried in for use as a nest by a
small animal. Also check under the hood for leftover
flammable materials after you or someone else has
performed maintenance on your vehicle.

Continued

453

uu

Before Driving

u

Driving Preparation

Driving

• Store or secure all items on board properly.

u

Carrying too much cargo, or improperly storing it, can affect your vehicle's
handling, stability, stopping distance, and tires, and make it unsafe.

2 Maximum Load Limit P. 455

• Do not pile items higher than the seat height.

u

They can block your view and may be thrown forward in the event of sudden
braking.

• Do not place anything in the front seat footwells. Make sure to secure the floor

mat.

u

An object or unsecured floor mat can interfere with your brake and accelerator
pedal operation while driving.

• If you have any animals on board, do not let them move around in the vehicle.

u

They may interfere with driving and a crash could occur.

• Securely close and lock all doors and the trunk.

2 Locking/Unlocking the Doors from the Inside P. 174

• Adjust your seating position properly.

u

Adjust the head restraint, too.

2 Adjusting the Seats P. 208
2 Adjusting the Front and Rear Outer Head Restraint Positions P. 214

• Adjust the mirrors and steering wheel properly for your driving.

u

Adjust them while sitting in the proper driving position.

2 Adjusting the Mirrors P. 206
2 Adjusting the Steering Wheel P. 205

■

Interior Checks

1

Interior Checks

The headlight aim is set by the factory, and does not
need to be adjusted. However, if you regularly carry
heavy items in the trunk, have the aiming readjusted
at a dealer or by a qualified technician.

454

uu

Before Driving

u

Driving Preparation

Driving

• Be sure items placed on the floor behind the front seats cannot roll under the

seats.

u

They can interfere with the driver’s ability to operate the pedals, the operation
of the seats, or the operation of the sensors under the seats.

• Everyone in the vehicle must fasten their seat belt.

2 Fastening a Seat Belt P. 45

• Make sure that the indicators in the instrument panel come on when you start the

vehicle, and go off soon after.

u

Always have a dealer check the vehicle if a problem is indicated.

2 Indicators P. 82

455

uu

Before Driving

u

Maximum Load Limit

Continued

Driving

Maximum Load Limit

The maximum load for your vehicle is 850 lbs (385 kg). See the
Tire and Loading Information label attached to the driver’s
doorjamb.

This figure includes the total weight of all occupants, cargo, and
accessories, and the tongue load if you are towing a trailer.

Steps for Determining Correct Load Limit -
(1) Locate the statement “The combined weight of occupants and

cargo should never exceed XXX kg or XXX lbs.” on your
vehicle’s placard.

(2) Determine the combined weight of the driver and passengers

that will be riding in your vehicle.

(3) Subtract the combined weight of the driver and passengers

from XXX kg or XXX lbs.

(4) The resulting figure equals the available amount of cargo and

luggage load capacity. For example, if the “XXX” amount
equals 1,400 lbs. and there will be five 150 lb. passengers in
your vehicle, the amount of available cargo and luggage load
capacity is 650 lbs. (1,400 - 750 (5 x 150) = 650 lbs.)

1

Maximum Load Limit

Gross Vehicle Weight Rating (GVWR):
The maximum allowable weight of the vehicle, all
occupants, all accessories and all cargo.

2 Specifications P. 662

Gross Axle Weight Rating (GAWR):
The maximum allowable weight of the vehicle axle.

2 Specifications P. 662

3

WARNING

Overloading or improper loading
can affect handling and stability
and cause a crash in which you
can be hurt or killed.

Follow all load limits and other
loading guidelines in this manual.

Label Example

uu

Before Driving

u

Maximum Load Limit

456

Driving

(5) Determine the combined weight of luggage and cargo being

loaded on the vehicle. That weight may not safely exceed the
available cargo and luggage load capacity calculated in step 4.

(6) If your vehicle will be towing a trailer, load from your trailer will

be transferred to your vehicle. Consult this manual to
determine how this reduces the available cargo and luggage
load capacity of your vehicle.

In addition, the total weight of the vehicle, all occupants,
accessories, cargo, and trailer tongue load must not exceed the
Gross Vehicle Weight Rating (GVWR) or the Gross Axle Weight
Rating (GAWR). Both are on a label on the driver’s doorjamb.

1

Maximum Load Limit

Towing a Trailer:
See Towing a Trailer to determine whether your
vehicle is designed to tow a tailer.

2 Towing a Trailer P. 457

Load Limits Example

Example1

Max Load

850 lbs

(385 kg)

Passenger Weight

150 lbs x 2 = 300 lbs

(68 kg x 2 = 136 kg)

Cargo Weight

550 lbs

(249 kg)

Example2

Max Load

850 lbs

(385 kg)

Passenger Weight

150 lbs x 5 = 750 lbs

(68 kg x 5 = 340 kg)

Cargo Weight

100 lbs
(45 kg)

457

Driving

Towing a Trailer

Your vehicle is not designed to tow a trailer. Attempting to do so can void your
warranties.

Towing Your Vehicle

Your vehicle is not designed to be towed behind a motor home. If your vehicle needs
to be towed in an emergency, refer to the emergency towing information.

2 Emergency Towing P. 657

458

Driving

When Driving

Turning on the Power

1. Make sure the parking brake is applied.

u

The electric parking brake indicator
comes on for 30 seconds when you pull
up the electric parking brake switch.

2. Depress the brake pedal.

1

Turning on the Power

Keep your foot firmly on the brake pedal when
starting the power system.

The engine is harder to start in cold weather and in
thinner air found at altitudes above 8,000 feet (2,400
meters).

When turning on the power system in cold weather,
turn off all electrical accessories such as the lights,
climate control system, and rear defogger in order to
reduce the 12-volt battery drain.

If you live in a region where winter is extremely cold,
an engine block heater will improve starting and
warming of the engine. Consult a dealer for details.

If the exhaust system sounds abnormal or you can
smell exhaust gas inside the vehicle, have your vehicle
checked by a dealer. There may be a problem with
the engine or exhaust system.

Electric Parking Brake Switch

Brake Pedal

Continued

459

uu

When Driving

u

Turning on the Power

Driving

3. Press the POWER button without

depressing the accelerator pedal.

4. Check the READY indicator.

u

Keep depressing the brake pedal until
the READY indicator comes on.

u

The READY indicator comes on when
the power system is on and you can start
driving.

u

If the outside temperature is extremely
low, you cannot drive until conditions are
improved. In this case, the READY
indicator does not come on and a
warning message appears on the driver
information interface.

2 Driver Information Interface

Warning and Information Messages
P. 108

You can turn the power system off when the vehicle is completely stopped.

1. Put the transmission into

(

P.

2. Press the POWER button.

1

Turning on the Power

The immobilizer system protects your vehicle from
theft. If an improperly coded device is used, the
power system does not activate.

2 Immobilizer System P. 181

When you set the power mode to ON, you may feel
the brake pedal slightly sink down. This is normal.

Bring the smart entry remote close to the POWER
button if the battery in the smart entry remote is
weak.

2 If the Smart Entry Remote Battery is Weak

P. 639

The power system may not activate if the smart entry
remote is subjected to strong radio waves.

Do not hold the POWER button to start the power
system.
If the power system does not start, wait at least 30
seconds before trying again.

The engine may not run when the vehicle is ready for
driving.
You can start driving with the READY indicator on.
If you press the POWER button while depressing the
brake pedal with the READY indicator on, the power
mode is set to VEHICLE OFF and you cannot start
driving.

2 READY Indicator P. 87

■

Stopping the Power System

uu

When Driving

u

Turning on the Power

460

Driving

You can remotely turn the power system on using the

 button on the smart entry

remote.

■

To turn the power system on

The power system is on for up to 10 minutes without you starting the vehicle.
To extend the time for another 10 minutes during the first 10 minutes, press the

 button, then press and hold the

 button.

u

Some exterior lights flash six times if a 10-minute extension request was
transmitted successfully.

■

Remote Engine Start with Vehicle Feedback

1

Remote Engine Start with Vehicle Feedback

The remote engine start may violate local laws.
Before using the remote engine start, check your
local laws.

If there are buildings and obstacles between your
vehicle and the remote, the range will be reduced.
This distance may vary by external electrical
interference.
The power system may not be turned on by the
remote engine start if:

•

You have disabled a remote engine start setting
using the audio/information screen.

•

The power mode is not in VEHICLE OFF.

•

The transmission is in a position other than

(

P.

•

The hood is open, or any door or the trunk is
unlocked.

3

WARNING

Carbon monoxide gas is toxic and can
rapidly accumulate in closed or even partly
enclosed areas.

Breathing it can cause unconsciousness and
even kill you.

Never use the remote engine starter with
the vehicle parked in a garage or other
areas with limited ventilation.

Press the

 button, then press and

hold the

 button.

Some exterior lights flash once.

Go within the range,
and try again.

LED: Blinks when any button is pressed.

Some exterior lights flash six
times if the power system
turns on successfully.

Some exterior lights will not
flash if the power system
turns on unsuccessfully.

Continued

461

uu

When Driving

u

Turning on the Power

Driving

■

To turn the power system off

1

Remote Engine Start with Vehicle Feedback

•

You have already used the remote twice to turn the
power system on.

•

Another registered smart entry remote is in the
vehicle.

•

There is an antenna failure.

•

The door is unlocked with the built-in key.

•

The engine oil pressure is low.

•

The engine coolant temperature is extremely high.

•

The security system alarm is not set.

The power system may be turned off while it is on if:

•

You do not start the vehicle within 10 minutes of
turning the power system on with the smart entry
remote.

•

The power system is turned off by using the smart
entry remote.

•

The security system alarm is activated.

•

The door is unlocked with the built-in key.

•

The hood is open.

•

The engine coolant temperature is extremely high.

•

The engine oil pressure is low.

•

The malfunction indicator lamp (MIL) comes on if
there is a problem with the emissions control
systems.

•

The transmission is in a position other than

(

P.

Press and hold
the

button

for one second.

Go within the range,
and try again.

The exterior lights flash once if the power system turns off
successfully.

The exterior lights will not flash when the remote is out of
the smart entry system range.
The power system will not be turned off.

uu

When Driving

u

Turning on the Power

462

Driving

1

Remote Engine Start with Vehicle Feedback

While the power system is on, the vehicle will
automatically precondition inside the vehicle.
When it is warm outside:

•

The climate control system is activated in auto
mode.

When it is cold outside:

•

The defroster is activated at a moderately warm
temperature.

•

The rear defogger and door mirror heaters are
activated.

•

The seat heaters

*

 and heated steering wheel

*

 are

activated.

2 Heated Steering Wheel

*

 P. 228

2 Front Seat Heaters

*

 P. 229

2 Front Seat Heaters and Seat Ventilation

*



P. 230

* Not available on all models

463

uu

When Driving

u

Turning on the Power

Driving

1. While depressing the brake pedal, press the POWER button.

2. Keeping your right foot on the brake pedal, check that the READY indicator is on,

then press the

(

D button. Select

(

R when reversing.

3. With the parking brake applied, release the brake pedal and gently depress the

accelerator pedal.

u

Make sure the electric parking brake indicator goes off.

2 Parking Brake P. 540
2 If the Transmission System Indicator Blinks along with the Warning

Message P. 652

■

Hill start assist system

Hill start assist keeps the brake engaged briefly to help prevent the vehicle from
rolling on inclines as you move your foot from the brake pedal to the accelerator.

Put the transmission into

(

D when facing uphill, or

(

R when facing downhill, then

release the brake pedal.

■

Starting to Drive

1

Starting to Drive

The power system is off when the shift position is
changed from

(

P before the POWER button is

pressed. Follow the step 1 when starting to drive.

You can also release the parking brake by pressing
the electric parking brake switch while depressing the
brake pedal.
When facing downhill, you can start your vehicle
more smoothly by manually releasing it with the
electric parking brake switch than by releasing it with
the accelerator pedal.

When the power system is turned on using the



button on the smart entry remote

When the power system is turned on using the

 button on the smart entry remote

When the power system is turned on in any case

1

Hill start assist system

Hill start assist may not prevent the vehicle from
rolling downhill on a very steep or slippery slope, and
does not operate on small inclines.

Hill start assist is not a replacement for the parking
brake.

As a hybrid vehicle, the sounds and vibrations from
the engine may be absent even though the vehicle is
ready for driving. It also makes you fail to recognize
that you can start.
Make sure to check if the READY indicator is on
before you start to drive.
