384

uu

Customized Features

u

Features

Show with turn signal

Show Reference Line

Fixed Guideline

Dynamic Guideline

Cross Traffic

Monitor

*

Display Time after Turn Signal Off

Camera

Rear Camera

LaneWatch

*

* Not available on all models

385

uu

Customized Features

u

Continued

Features

■

List of customizable options

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

System

Day & Time

Set Date
& time

Automatic
Date &
Time

Selects ON to have the GPS automatically adjust
the clock. Select OFF to cancel this function.

ON

*1

/OFF

Set Date

Adjusts date.

2 Adjusting the Clock P. 164

—

Set Time

Adjusts clock.

2 Adjusting the Clock P. 164

—

Time
Zone

Automatic
Time
Zone

*

Sets the navigation system to automatically
adjust the clock when driving through different
time zones.

ON

*1

/OFF

(Select time
zone)

Changes the time zone manually.

—

Auto Daylight Saving
Time

Select ON to have the GPS automatically adjust
the clock to daylight savings time. Select OFF to
cancel this function.

ON

*1

/OFF

Date Format

Sets the date format.

MM/DD/YYYY

*1

/

DD/MM/YYYY/
YYYY/MM/DD

Time Format

Selects the digital clock display from 12H to 24H.

12H

*1

/24H

* Not available on all models

386

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

System

Language

Changes the display language.

English (United
States)

*1

/Español/

Français/

Touch Panel
Sensitivity

Sets the sensitivity of the touch panel screen.

High/Normal

*1

System
Volumes

System Volumes

Changes the system sounds volume.

—

Reading/
Warning

Verbal
Reminder

Turns the verbal reminders on and off.

ON

*1

/OFF

Config. of
Instrument
Panel

Select Configuration

Select which apps display on the driver
information interface.

Config.1

*1

/Config.2/

Config.3

Security

Password

Set the value of password display.

ON

*1

/OFF

Unknown sources

—

ON/OFF

*1

387

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

System

Accessibility

Caption

Caption

Turns the subtitles on and off.

ON/OFF

*1

Language

Change the subtitle language.

Default

*1

/English

(United States)/
Español/Français

Text Size

Change the subtitle Text Size.

Very small/Small/
Normal

*1

/Large

Caption
style

Change the subtitle Caption style.

Use app defaults

*1

/

White on black/
Black on white/
Yellow on black/
Yellow on blue/
Custom

Text-to-
speech
output

Current
TTS engine
TtsService

TtsService

—

—

Refuel
recommend

*

Turns the refuel recommend function on and off.

2 Refuel Recommend P. 449

ON

*1

/OFF

About

Status

Displays the Android setting items.

—

Legal Information

* Not available on all models

388

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

System

Factory Data
Reset

Resets all the settings to their factory default.

2 Defaulting All the Settings P. 396

Continue/Cancel

Detail
Information

App Manager

Displays the Android system memory and apps
information.

—

Recent Location
Requests Apps

Displays the recent location requests from apps.

—

Connec-
tions

Wi-Fi

Change Mode

Changes the Wi-Fi mode.

Network

*1

/Hotspot/

OFF

(Available Networks/
Connected Devices)

Displays the available network(s) or current
connected device(s).

—

Bluetooth

+ Connect New Device

Pairs a new phone to HFL.

2 Phone Setup P. 429

—

(Saved Devices)

Connects, disconnects, or deletes a paired
phone.

2 Phone Setup P. 429

—

Smartphone
Connection

Apple CarPlay

Sets up the Apple CarPlay connection.

—

Android Auto

Sets up the Android Auto connection.

—

NFC

*

Turns the NFC function on and off.

ON

*1

/OFF

Android Beam

*

Turns the NFC connection on and off.

ON

*1

/OFF

* Not available on all models

389

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Display

Day Mode

Adjusts the settings of the audio/information
screen.

2 Display Setup P. 290

—

Night Mode

Sound

Bass/Treble

Treble

Adjusts the settings of the audio speakers’
sound.

2 Adjusting the Sound P. 289

—

Midrange

Bass

Subwoofer

*

Balance/Fader

DTS Neural Surround

*

Speed Volume Compensation

Vehicle

TPMS Calibration

Cancels/Calibrates the tire pressure monitoring
system (TPMS).

Calibrate/Cancel

Driver Assist
System Setup

Blind Spot Info

*

Changes the setting for the blind spot
information.

Audible And Visual
Alert

*1

/Visual Alert

Head-up Warning

*

Turns the head-up warning on and off.

ON

*1

/OFF

Traffic Sign
Recognition System

Select On/Off to indicate small displaying traffic
sign icon on the driver information interface and
the head-up display

*

.

Small Icons ON

*1

/

Small Icons OFF

* Not available on all models

390

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle

Driver Assist
System Setup

Forward Collision
Warning Distance

Changes Collision Mitigation Braking System
(CMBS) alert distance.

Normal

*1

/Short/

Long

ACC Forward Vehicle
Detect Beep

Causes the system to beep when the system
detects a vehicle, or when the vehicle goes out of
the ACC with LSF range.

ON/OFF

*1

Lane Keeping Assist
Suspend Beep

Causes the system to beep when Lane Keeping
Assist System (LKAS) is suspended.

ON/OFF

*1

Road Departure
Mitigation Setting

Changes the setting for the road departure
mitigation system.

Normal

*1

/Wide/

Warning Only/
Narrow

Driver Attention
Monitor

Changes the setting for the driver attention
monitor.

OFF/Tactile Alert/
Tactile And Audible
Alert

*1

Meter Setup

Language Selection

Changes the display language.

English

*1

/Français/

Español

Adjust Outside Temp.
Display

Adjusts the temperature reading by a few
degrees.

-5°F ~ ±0°F

*1

 ~ +5°F

(U.S.)
-3°C ~ ±0°C

*1

 ~ +3°C

(Canada)

Adjust Alarm Volume

Changes the alarm volume, such as the buzzers,
warnings, turn signal sound, and so on.

High/Mid

*1

/Low

391

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle

Meter Setup

Reverse Alert Tone

Turns the reverse alert tone on and off.

ON

*1

/OFF

Config. of Instrument
Panel

Select which apps display on the driver
information interface.

Config.1

*1

/Config.2/

Config.3

Fuel Efficiency
Backlight

Turns the ambient meter feature on and off.

ON

*1

/OFF

“Trip A” Reset Timing

Changes the setting of how to reset trip meter A
and average fuel economy A.

When Fully
Refueled/Manually
Reset

*1

/IGN OFF

“Trip B” Reset Timing

Changes the setting of how to reset trip meter B
and average fuel economy B.

When Fully
Refueled/Manually
Reset

*1

/IGN OFF

Speed/Distance Units

Selects the trip computer units.

km/h · km/mph ·
miles

*1

 (U.S.)

km/h · km

*1

/mph ·

miles (Canada)

Turn By Turn Auto
Display

Selects whether the turn-by-turn display comes
on during the route guidance.

ON

*1

/OFF

392

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle

Driving
Position
Setup

*

Memory Position Link

Turns the driving position memory system on and
off.

ON

*1

/OFF

Seat Position
Movement at Entry/
Exit

Moves the seat rearward when you get in/get out
of the vehicle. Changes the setting for this
feature.

ON

*1

/OFF

Keyless Access
Setup

Door Unlock Mode

Changes which doors to unlock when you grab
the driver’s door handle.

Driver Door Only

*1

/All

Doors

Smart Entry Light Flash

Causes some exterior lights to flash when you
unlock/lock the doors.

ON

*1

/OFF

Smart Entry Beep

Causes the beeper to sound when you unlock/
lock the doors.

ON

*1

/OFF

Remote Start System
ON/OFF

Turns the remote engine start feature on and off.

ON

*1

/OFF

* Not available on all models

393

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle

Lighting
Setup

Headlight Auto OFF
Timer

Changes the length of time the exterior lights
stay on after you close the driver’s door.

0 sec/15 sec

*1

/30 sec/

60 sec

Interior Light Dimming
Time

Changes the length of time the interior lights stay
on after you close the doors.

15 sec/30 sec

*1

/60

sec

Auto Light Sensitivity

Changes the timing for the headlights to come
on.

Min/Low/Mid

*1

/

High/Max

Auto Interior
Illumination Sensitivity

Changes the sensitivity of the brightness of the
instrument panel when the headlight switch is in
AUTO.

Min/Low/Mid

*1

/

High/Max

Auto Headlight On
with Wiper On

Used to automatically come on the headlights
when the wipers are used several times within a
certain number of intervals with the headlight
switch is in AUTO.

ON

*1

/OFF

394

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle

Door/Window
Setup

Auto Door Lock

Changes the setting for the automatic locking
feature.

OFF/With Vehicle
Speed

*1

/Shift From P

Key and Remote
Unlock Mode

Sets up either the driver’s door or all doors to
unlock on the first push of the remote or built-in
key.

Driver Door Only

*1

/

All Doors

Keyless Lock Answer
Back

LOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds.

ON

*1

/OFF

Security Relock Timer

Changes the time it takes for the doors to relock
and the security system to set after you unlock
the vehicle without opening any door.

30 sec

*1

/60 sec/90

sec

Auto Door Unlock

Changes the setting for when the doors unlock
automatically.

OFF/All Doors When
Driver’s Door
Opens

*1

/All Doors

When Shifted to
Park/All Doors with
IGN OFF

Walk Away Auto Lock

Changes the settings for the auto lock function
when you walk away from the vehicle.

ON/OFF

*1

Maintenance
Info.

Select Reset Items

Resets the engine oil life display when you have
performed the maintenance service.

—

395

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Camera

Rear Camera

Fixed Guideline

Selects whether the guidelines come on the rear
camera monitor.

2 Multi-View Rear Camera P. 560

ON

*1

/OFF

Dynamic Guideline

Selects whether the guidelines come on the rear
camera monitor.

2 Multi-View Rear Camera P. 560

ON

*1

/OFF

Cross Traffic Monitor

*

Turns the cross traffic monitor on and off.

ON

*1

/OFF

LaneWatch

*

Show with turn signal

Selects whether the LaneWatch display comes on
when you move the turn signal lever to indicate a
right turn.

ON

*1

/OFF

Display Time after Turn
Signal off

Changes the length of time the LaneWatch
display stays on after the turn signal lever returns
to the center.

0 seconds

*1

/2

seconds

Show Reference Line

Selects whether the reference lines come on the
LaneWatch monitor.

ON

*1

/OFF

* Not available on all models

396

uu

Customized Features

u

Defaulting All the Settings

Features

Defaulting All the Settings

Reset all the menu and customized settings as the factory defaults.

1. Press the

 button.

2. Select Settings.
3. Select System.
4. Select Factory Data Reset.

u

A confirmation message appears on the
screen.

5. Select Continue to reset the settings.
6. Select Continue again to reset the settings.

u

The system will reboot.

1. Press the

 button.

2. Select Settings.
3. Select Vehicle.
4. Select Default.
5. Select Yes.

■

Defaulting System Settings

1

Defaulting All the Settings

When you transfer the vehicle to a third party, reset
all settings to default and delete all personal data.

If you perform Factory Data Reset, it will reset the
preinstalled apps to their factory default.

If you perform Factory Data Reset, you cannot use
the HondaLink® because it becomes off line.

2 HondaLink® P. 318

■

Defaulting Vehicle Settings

397

Features

HomeLink® Universal Transceiver

*

The HomeLink® Universal Transceiver can be programmed to operate up to three
remote controlled devices around your home, such as garage doors, lighting, or
home security systems.

Refer to the safety information that came with your garage door opener to test that
the safety features are functioning properly. If you do not have the safety
information, contact the manufacturer.

Before programming HomeLink, make sure that people and objects are out of the
way of the garage or gate to prevent potential injury or damage.

When programming a garage door opener, park just outside the garage door’s
path.

■

Important Safety Precautions

1

HomeLink® Universal Transceiver

*

Before programming HomeLink to operate a garage
door opener, confirm that the opener has an external
entrapment protection system, such as an “electronic
eye,” or other safety and reverse stop features. If it
does not, HomeLink may not be able to operate it.

* Not available on all models

398

uu

HomeLink® Universal Transceiver

*

u

Training HomeLink

Features

Training HomeLink

If it is necessary to erase a previously entered
learned code:
• Press and hold the I and III HomeLink

buttons for about 10 seconds, until the
green indicator blinks. Release the buttons,
and proceed to step 1.

• If you are training the second or third

button, go directly to step 1.

The instructions on the next page should work for most gate or garage openers, but
may not work for all. For detailed instructions about your specific remote opener,
visit http://www.homelink.com or call (800) 355-3515.

Indicator

I HomeLink
Button

III HomeLink Button

399

uu

HomeLink® Universal Transceiver

*

u

Training HomeLink

Features

■

Programming a Button

1

Training HomeLink

Reprogramming a Button
If you want to retrain a programmed button for a
new device, you do not have to erase all button
memory. You can replace the existing memory code
using this procedure:

2.

1. Press and hold the desired HomeLink button until

the HomeLink indicator begins to slowly flash
orange. This should take about 20 seconds.

Release the HomeLink button and position the
remote transmitter you wish to link 1 - 3 inches
(3 - 8 cm) from the HomeLink button you want to
program, then follow steps 3 - 6 under
“programming a button.”

Erasing Button Memory
To erase programming from the buttons, press and hold
the two outside HomeLink buttons until the HomeLink
indicator changes from orange to rapidly flashing green.
This should take about 10 seconds. You should erase all
programming before selling the vehicle.

Operating
To operate, simple press and release the
programmed HomeLink button. Activation will now
occur for the trained device.

Questions
For questions or comments, visit
www.HomeLink.com, www.youtube.com/
HomeLinkGentex, or by calling the HomeLink Hotline
(North America only) at (800) 355-3515.

HomeLink® is a registered trademark of Gentex
Corporation.

Training
Complete

HomeLink LED is
continuously on green.

YES

YES

1. Position the remote transmitter you wish to link 1 to 3 inches (3 - 8 cm) from the

HomeLink® button you want to program.

3b. Canadian Garage Door Opener

A. Press and release the HomeLink
button. Press, hold and release the
button on the remote every 2 secs.
Does the HomeLink indicator (LED)
change from slowly flashing orange to
rapidly flashing or continuously on
green? The process should take less
than 60 seconds.

NO

2. Press and hold the desired HomeLink button. Is the HomeLink indicator (LED) slowly

flashing orange?

NO

3a. Hold the button on the remote

transmitter. Does HomeLink indicator
(LED) change from slowly flashing
orange to rapidly flashing green or
continuously on green? The process
should take less than 60 seconds.

5. Press and hold the HomeLink button again.

HomeLink indicator rapidly flashes
green.

5a. The remote has a rolling code. Press the

“learn” button on the remote-controlled
device (e.g. garage door opener).

6. Press and hold the HomeLink button

again.
The remote-controlled device should
operate.

Training Complete

5b. Within 30 secs, press and hold the

programmed HomeLink button for 2
secs.

4. Press and hold the programmed HomeLink

button for about a second. Does the device
(garage door opener) work?
