Interior Lights/Interior Convenience Items

Interior Convenience Items

224

Co
ntrols

To use the wireless charger, the power mode must be in ACCESSORY or ON.
Charge a compatible device on the area indicated by the

mark as follows:

1. To turn the system on and off, press and

hold the

(power) button.

When the system is activated, the green
indicator light comes on.

2. Place the device you want to charge on the

charging area.

The system will automatically start
charging the device, and the amber
indicator light will come on.

Make sure that the device is compatible
with the system, and placed with the
chargeable side in the center of the
charging area.

3. When charging is completed, the green

indicator light will come on.

Depending on the device, the amber
indicator light will stay on.

■

Wireless Charger

Wireless Charger

FCC statement
This product complies with the appropriate
requirements or the required standards of FCC
(Federal Communication Commission), described
below:
This device complies with Part 18 of the FCC rules.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used
per the instructions, may cause harmful interference
to radio communications.
In order to use safely:

•

Remove any metal objects from the charge pad
before charging a device.

•

Do not open the charger case.

•

Do not use the charger if it malfunctions. Contact
your dealer.

If the charger interferes with radio communications,
attempt to correct the interference:

•

Press and hold the switch on the charger for a few
seconds to turn off the charger.

appears on the audio/information screen when

the device is being charged by the wireless charger.

Green Indicator
Amber Indicator

Charging Area

(Power)

Button

* Not available on all models

Continued

225

Interior Lights/Interior Convenience Items

Interior Convenience Items

Co
ntrols

■

When charging does not start

Perform one of the solutions in the following table.

Indicator

Cause

Solution

Green

Amber

Blinking
simulta-

neously

There is an obstacle(s) between
the charging area and the
device.

Remove the
obstacle(s).

The device is not within the
charging area.

Move the device to the
center of the charging
area where

located.

Amber

Blinking

The wireless charger is faulty.

Contact a dealer for
repairs.

Wireless Charger

This system consumes a lot of power. Do not use the
system for a long time when the power system is off.
This may weaken the 12-volt battery, making it
difficult to turn the power system on.

When using the wireless charger, check the user’s manual that
came with the compatible device you want to charge.

CAUTION

Metal objects between the charge pad
and the device to be charged will get
hot and can burn you.
• Always remove foreign objects from

the charge pad before charging the
device.

• Be sure the surface is clear of dust and

other debris before charging.

• Do not spill liquids (i. e. water, drinks,

etc.) on the charger and the device.

• Do not use oil, grease, alcohol,

benzine or thinner for cleaning the
charge pad.

• Do not cover the system with towels,

clothing, or other objects while
charging etc.

• Avoid spraying aerosols which may

come in contact with the change pad
surface.

* Not available on all models

Interior Lights/Interior Convenience Items

Interior Convenience Items

226

Co
ntrols

Wireless Charger

NOTICE

Do not place any magnetic recording media or
precision machines within the charging area while
charging.
The data on your cards such as credit cards can be
lost because of the magnetic effect. Also precision
machines such as watches can go wrong.

“Qi” and

marks are the registered trademarks

owned by Wireless Power Consortium (WPC).

In the following cases, charging may stop or not start:

•

The device is already fully charged.

•

The temperature of the device is extremely high
while charging.

•

You are at a place that emits strong
electromagnetic waves or noises such as TV station,
electric power plant, or gas station.

A device may not charge if the size or shape of its
chargeable side is not appropriate for use with the
charging area.

Not all devices are compatible with the system.

During the charging phase, it is normal for the
charging area and device to heat up.

Charging may be briefly interrupted when:

•

All the doors or the trunk are closed

- to avoid interference with the proper functioning
of the smart entry system.

•

The position of the device is altered.

Do not charge more than one device at a time on a
charging area.

* Not available on all models

Continued

227

Interior Lights/Interior Convenience Items

Interior Convenience Items

Co
ntrols

There is a coat hook on the rear left grab
handle. Pull it down to use it.

The cargo hook in the trunk can be used to
install a net for securing items.

■

Coat Hook

Coat Hook

The coat hook is not designed for large or heavy
items.

■

Cargo Hook

Cargo Hook

Heavy objects may damage the hook.
Make sure any items put on this hook weigh less than
6.6 lbs (3 kg).

Distribute cargo evenly on the floor of the trunk,
placing the heaviest items on the bottom and as far
forward as possible.

2 Maximum Load Limit P. 455

Interior Lights/Interior Convenience Items

Interior Convenience Items

228

Co
ntrols

To open the sunglasses holder, push and
release the indent. To close, push it again until
it latches.

You can store eyeglasses and other small
items in this holder.

The power mode must be in ON to use the
heated steering wheel.

Press the button on the lower side of the
steering wheel.

When a comfortable temperature is reached,
press the button again to turn it off.

The heated steering wheel is turned off every
time you start the power system, even if you
turned it on the last time you drove the
vehicle.

■

Sunglasses Holder

Sunglasses Holder

Keep the holder closed while driving except when
accessing stored items.

Push

■

Heated Steering Wheel

Canadian models

Heated Steering Wheel

Do not use the heated steering wheel continuously
when the power system is off. Under such conditions,
the 12-volt battery may be weakened, making the
power system difficult to start.

* Not available on all models

Continued

229

Interior Lights/Interior Convenience Items

Interior Convenience Items

Co
ntrols

The power mode must be in ON to use the
seat heaters.

Press the seat heater button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)

When the power mode is turned on after it is
turned off, the previous setting of front seat
heaters is maintained.

■

Front Seat Heaters

Front Seat Heaters

Do not use the seat heaters even in LO when the
power system is off. Under such conditions, the 12-
volt battery may be weakened, making the power
system difficult to start.

After a certain period of time, the strength setting for
the front seat heaters will automatically be reduced
by one level at a time until the front seat heaters
shuts off. The elapsed time varies according to the
interior environment.

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

Interior Lights/Interior Convenience Items

Interior Convenience Items

230

Co
ntrols

The power mode must be in ON to use the
seat heaters or ventilation.

Press the seat heater or the seat ventilation
button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)

When the power mode is turned on after it is
turned off, the previous setting of front seat
heaters is maintained.

■

Front Seat Heaters and Seat Ventilation

Front Seat Heaters and Seat Ventilation

Do not use the seat heaters and the seat ventilation
even in LO when the power system is off. Under such
conditions, the 12-volt battery may be weakened,
making the power system difficult to start.

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

231

Interior Lights/Interior Convenience Items

Interior Convenience Items

Co
ntrols

The power mode must be in ON to use the
seat heaters.

There is no heater in the rear center seating
position.

■

Rear Seat Heaters

Rear Seat Heaters

Do not use the seat heaters even in LO when the
power system is off. Under such conditions, the 12-
volt battery may be weakened, making the power
system difficult to start.

After a certain period of time, the strength setting for
the rear seat heaters will automatically be reduced by
one level at a time until the rear seat heaters shuts
off. The elapsed time varies according to the interior
environment.

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

232

Co
ntrols

Climate Control System

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air that raises or lowers
the interior temperature to your preference as quickly as possible.

Use the system when the power system is on.
1. Press the AUTO button.
2. Adjust the interior temperature using the driver’s side or passenger’s side control

dial.

3. Press the

(on/off) button to cancel.

■

Switching between the recirculation and fresh air modes

Press the

(recirculation) button and switch the mode depending on

environmental conditions.
Recirculation mode (indicator on): Recirculates air from the vehicle’s interior through
the system.
Fresh air mode (indicator off): Maintains outside ventilation. Keep the system in
fresh air mode in normal situations.

Using Automatic Climate Control

If any buttons are pressed while using the climate
control system in auto, the function of the button
that was pressed will take priority.
The AUTO indicator will go off, but functions
unrelated to the button that was pressed will be
controlled automatically.

To prevent cold air from blowing in from outside, the
fan may not start immediately when the AUTO
button is pressed.

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows,
turning the system on auto, and setting the
temperature to low. Change the fresh mode to
recirculation mode until the temperature cools down.

When you set the temperature to the lower or upper
limit, Lo or Hi is displayed.

Pressing the

button switches the climate control

system between on and off. When turned on, the
system returns to your last selection.

While ECON mode is active, the climate control
system may have reduced cooling performance.

Floor and
defroster
vents

Floor vents

Dashboard and floor
vents, and back of
the center console

Dashboard vents
and back of the
center console

AUTO Button

Driver’s Side
Temperature
Control Dial

(Recirculation)

Button

Fan Control Dial

A/C (Air Conditioning)
Button

Passenger’s
Side
Temperature
Control Dial

(on/off) Button

* Not available on all models

Continued

233

Climate Control System

Using Automatic Climate Control

Co
ntrols

Pressing the

button turns the air

conditioning system on and automatically
switches the system to fresh air mode.

Press the

button again to turn off, the

system returns to the previous settings.

■

To rapidly defrost the windows

1. Press the

button.

2. Press the

button.

■

Defrosting the Windshield and Windows

Defrosting the Windshield and Windows

For your safety, make sure you have a clear view
through all the windows before driving.

Do not set the temperature near the upper or lower
limit.
When cold air hits the windshield, the outside of the
windshield may fog up.

If the side windows fog up, adjust the vents so that
the air hits the side windows.

To rapidly defrost the windows

After defrosting the windows, switch over to fresh air
mode. If you keep the system in recirculation mode,
the windows may fog up from humidity. This
impedes visibility.

Climate Control System

Using Automatic Climate Control

234

Co
ntrols

You can set the temperature synchronously for the driver side and the passenger
side in synchronization mode.

1. Press the SYNC button.

The system will switch to the synchronization mode.

2. Adjust the temperature using driver’s side temperature control dial.

Press the SYNC button or adjust the interior temperature using the passenger’s side
temperature control dial to return to dual mode.

■

Synchronization Mode

Synchronization Mode

When you press the

button, the system changes

to synchronization mode.

When the system is in dual mode, the driver side
temperature and the passenger side temperature can
be set separately.

Driver’s Side
Temperature Control
Dial

Passenger’s Side
Temperature Control
Dial

SYNC Button

235

Climate Control System

Automatic Climate Control Sensors

Co
ntrols

Automatic Climate Control Sensors

The automatic climate control system is
equipped with sensors. Do not cover or spill
any liquid on them.

Sensor

236

237

Features

This chapter describes how to operate technology features.

Audio System .................................... 238

About Your Audio System................ 238
USB Port(s) ....................................... 239
Audio System Theft Protection ......... 241
Audio Remote Controls.................... 242

Audio System Basic Operation ........ 246

Audio/Information Screen ................ 247
Adjusting the Sound ........................ 251
Display Setup ................................... 252
Playing AM/FM Radio ....................... 253
Playing an iPod ................................ 255
Playing Pandora®.............................. 258
Playing a USB Flash Drive ................. 260

Models with color audio system

Playing Bluetooth® Audio................. 263
Siri® Eyes Free .................................. 266

Audio System Basic Operation ........ 267

Audio/Information Screen ................ 268
System Updates ............................... 283
Adjusting the Sound ........................ 289
Display Setup ................................... 290
Voice Control Operation .................. 292
Playing AM/FM Radio....................... 295
Playing SiriusXM® Radio

................. 299

Playing an iPod ................................ 310
Playing a USB Flash Drive ................. 313
Playing Bluetooth® Audio................. 316

Models with Display Audio

HondaLink® ..................................... 318
HondaLink® Service

........................ 322

Wi-Fi Connection............................. 327
Near Field Communication (NFC)

... 329

Siri® Eyes Free .................................. 332
Apple CarPlay

............................... 333

Android Auto

............................... 336

Audio Error Messages ...................... 340
General Information on the Audio

System ............................................. 345

Customized Features................ 367, 378
HomeLink® Universal Transceiver

.. 397

Bluetooth® HandsFreeLink®..... 400, 424
Refuel Recommend .......................... 449

* Not available on all models

238

Features

Audio System

About Your Audio System

The audio system features AM/FM radio and SiriusXM® Radio

service. It can also

play USB flash drives, and iPod, iPhone and Bluetooth® devices.

You can operate the audio system from the buttons and knobs on the panel, the
remote controls on the steering wheel, or the icons on the touchscreen interface

About Your Audio System

iPod, iPhone and iTunes are trademarks of Apple Inc.

State or local laws may prohibit the operation of
handheld electronic devices while operating a
vehicle.

SiriusXM® Radio

is available on a subscription basis

only. For more information on SiriusXM® Radio

contact a dealer.

2 General Information on the Audio System

P. 345

SiriusXM® Radio

is available in the United States and

Canada, except Hawaii, Alaska, and Puerto Rico.

SiriusXM®

is a registered trademark of SiriusXM

Radio

, Inc.

Remote Controls

iPod

USB Flash Drive

*1 : Models with color audio
*2 : Models with Display Audio

* Not available on all models

239

Audio System

USB Port(s)

Continued

Features

USB Port(s)

Install the iPod USB connector or the USB flash drive to the USB port.

■

In the Center Pocket

The USB port (1.0A) is for playing audio files
on a USB flash drive, connecting a cellular
phone and charging devices.

The USB port (2.5A) is for charging devices,
playing audio files and connecting compatible
phones with Apple CarPlay or Android Auto.

To prevent any potential issues, be sure
to use an Apple MFi Certified Lightning
Connector for Apple CarPlay, and for
Android Auto, the USB cables should be
certified by USB-IF to be compliant with
USB 2.0 Standard.

USB Port(s)

•

Do not leave the iPod or USB flash drive in the
vehicle. Direct sunlight and high temperatures may
damage it.

•

We recommend using an extension cable with the
USB port.

•

Do not connect the iPod or USB flash drive using a
hub.

•

Do not use a device such as a card reader or hard
disk drive, as the device or your files may be
damaged.

•

We recommend backing up your data before using
the device in your vehicle.

•

Displayed messages may vary depending on the
device model and software version.

If the audio system does not recognize the iPod, try
reconnecting it a few times or reboot the device. To
reboot, follow the manufacturer’s instructions
provided with the iPod or visit www.apple.com/ipod.

The USB port can supply up to 1.0A/2.5A of power. It
does not output 1.0A/2.5A unless the device
requests.
For amperage details, read the operating manual of
the device that needs to be charged.
Set the power mode to ACCESSORY or ON first.

Under certain conditions, a device connected to the
port may generate noise in the radio you are listening
to.

USB charge

Models
with
color
audio

Models
with
Display
Audio

In the Center Pocket

Models with color audio

Models with Display Audio

Content .. 13 14 15 16 ..
